HOBO® MX100 Temp Logger Manual
HOBO MX100
Temp Logger
Required Items:
HOBOmobile app
Device with iOS and
Bluetooth
Distributed By: MicroDAQ.com
20813-B
The HOBO MX100 Temp logger measures temperature in indoor environments. With an IP67
environmental rating, the logger can be deployed in indoor locations where moisture may
form. This Bluetooth® Low Energy-enabled logger is designed for wireless communication with
a mobile device. Using the HOBOmobile® app, you can easily configure the logger, read it out,
and view data on your phone or tablet, or automatically upload the data to HOBOlink® for
further analysis. The logger has a built-in alarm you can configure to trip at thresholds you
specify. Designed with a non-replaceable lithium battery, this logger also has a power-saving
mode that allows you to use the Bluetooth signal only when needed to maximize battery life.
Specifications
Temperature Sensor
Range
Accuracy
Resolution
Drift
Response Time
Logger
Logger Operating Range
Radio Power
Transmission Range
Wireless Data Standard
Logging Rate
Time Accuracy
Battery
Battery Life
Memory
Full Memory Download
Time
Dimensions
Weight
Environmental Rating
Passed RTCA DO160G, part 21H
www.MicroDAQ.com
-30° to 70°C (-22° to 158°F)
±1.0°C from -30° to -5°C (±1.8°F from -22° to 23°F)
±0.5°C from -5° to 50°C (±0.9°F from 23° to 122°F)
±1.0°C from 50° to 70°C (±1.8°F from 122° to 158°F)
0.04°C (0.072°F)
<0.01°C (0.018°F) per year
6 minutes typical to 90% in open air moving 1 m/s, unmounted
-30° to 70°C (-22° to 158°F)
1 mW (0 dBm)
Approximately 30.5 m (100 ft) line-of-sight
Bluetooth Low Energy (Bluetooth Smart)
1 second to 18 hours
±1 minute per month at 25°C (77°F)
CR2450 3V lithium, not replaceable
1 year, typical with logging interval of 1 minute and Power Saving Mode
disabled; 2 years, typical with logging interval of 1 minute and Power
Saving Mode enabled. Faster logging intervals, remaining connected with
the app, excessive downloads, and paging may impact battery life.
30,000 measurements
Approximately 30 seconds; may take longer the farther the device is
from the logger
6.9 x 4.5 x 1.1 cm (2.71 x 1.76 x 0.42 inches)
25.5 g (0.90 oz)
IP67
The CE Marking identifies this product as complying with all relevant
directives in the European Union (EU).
See last page
(603) 746-5524
