Summary of Contents for ARC Audio X2 650.1
-
Page 1: Table Of Contents
Remote Level Control Load Impedance Speaker Output Connections Power, Ground and Turn-On Connections Fuses Auto-Sense Turn-On Detection Accessing Controls and Mounting Provisions Installation Instructions Master/Slave Wiring Configuration Subwoofer Wiring Options Warranty X2 650.1 / X2 1100.1 / X2 2500.1 Specifications Rev 1.02... -
Page 2: Introduction
If the amp can’t get the power it needs form your alternator and battery, it will not be able to produce its full output. Your ARC Audio amplifier will produce full output for longer than other amps on the market today. If the Voltage or Current drops too low, even our amplifiers will drop below their rated output. -
Page 3: Class D Amplifier Recommendations
Speaker Level Input Pigtails All ARC Audio X2-Series amplifiers include a set of high-level speaker input RCA pigtails. These pigtails include a resistive voltage divider network to reduce the signal from a high-power source unit or factory amplifier so that it can be used with the differential Inputs on your X2-Series Amp. -
Page 4: Input Section
Gain / Sensitivity Controls Because of the wide range of head unit output configurations available, all ARC Audio amplifiers have an adjustable input sensitivity or “Gain” control. The gain is not a volume or a power limiting control like a throttle. It makes the amp more sensitive to input from the source. -
Page 5: Phase Control
SIGNAL DETECT DETECT CROSSOVER Phase Control FREQ Hz All three X2 Series Monoblock amplifiers include a PHASE SIGNAL switch that allows you to invert the polarity of the signal being DETECT DETECT CROSSOVER passed through the amplifier. Setting this switch to OUT has FREQ Hz the same effect as reversing the positive and negative speaker leads. -
Page 6: Load Impedance
HIGHPASS SELECT HP RANGE FREQ Hz Speaker Output Connections FULL HIGH The X2 650.1 and X2 1100.1 are equipped with set of removable plug-style terminals for speaker wire connections AUTO BANDPASS LP RANG SENSE DO NOT BRIDGE up to 12 AWG. -
Page 7: Fuses
Accessing Controls and Mounting Provisions All X2 Series Monoblock amplifiers feature a removable shroud that conceals the amplifier controls. The X2 650.1 features X2 Level 1 cosmetics with the X2 1100.1 and X2 2500.1 feature Level 2 X2 Series cosmetics. The Level 2 shroud features an elegant new silver brushed-aluminum extruded aluminum design. -
Page 8: Installation Instructions
In cases where multiple amplifiers share a common power wire, ensure each device has proper protection with a fuse. The fuses built-in to the ARC Audio X2-Series amplifiers satisfy this need. Processors, lighting, etc. will require dedicated fuses for safe operation. -
Page 9: Master/Slave Wiring Configuration
X2 MONOBLOCK MASTER / SLAVE WIRING SIGNAL DETECT DETECT CROSSOVER FREQ Hz All Controls and adjustments fully functional Master amp must be Set to NORMAL TURN ON FUSE 30 AMP X 3 INPUT SLAVE IN +12 V 1Ω MIN REMOTE LEVEL SLAVE OUT If desired, Remote Level... -
Page 10: Subwoofer Wiring Options
“Out of Warranty” repair cost. In no event will ARC AUDIO be liable for incidental, consequential, or other damages resulting from the use or miss-use of this product. This includes but is not limited to, damage of hearing, property or person, damage based upon inconvenience or in loss of use of the product, and to the extent permitted by law, damages for personal injury. -
Page 11: X2 650.1 / X2 1100.1 / X2 2500.1 Specifications
X2 650.1 Specifications Rated Continuous (RMS) Power into 4 Ohms at 14.4V 185 Watts x 1 Rated Continuous (RMS) Power into 2 Ohms at 14.4V 350 Watts x 2 Rated Continuous (RMS) Power into 4 Ohms at 14.4V 650 Watts x 1...
