  • Page 1: Rf Signal Generator

    ® R&S SMA100B RF Signal Generator User Manual (;ÜVR2) 1178383402...
  • Page 2 ® This document describes the R&S SMA100B, stock no. 1419.8888.02 and its options: ● ® R&S SMAB-B1H ● ® R&S SMAB-B28 ● ® R&S SMAB-B29 ● ® R&S SMAB-B32/-B34 ● ® R&S SMAB-B80/-B85 ● ® R&S SMAB-B81 ● ® R&S SMAB-B86 ●...

  • Page 3: Safety Instructions

    Safety Instructions Instrucciones de seguridad Sicherheitshinweise Consignes de sécurité Risk of injury and instrument damage The instrument must be used in an appropriate manner to prevent electric shock, fire, personal injury or instrument damage. ● Do not open the instrument casing. ●...
  • Page 4 Gefahr von Verletzungen und Schäden am Gerät Betreiben Sie das Gerät immer ordnungsgemäß, um elektrischen Schlag, Brand, Verletzungen von Personen oder Geräteschäden zu verhindern. ● Öffnen Sie das Gerätegehäuse nicht. ● Lesen und beachten Sie die "Grundlegenden Sicherheitshinweise", die als gedruckte Broschüre dem Gerät beiliegen. ●...

  • Page 5: Table Of Contents

    ® Contents R&S SMA100B Contents 1 Preface....................17 Key Features........................17 For Your Safety......................17 About this Manual....................... 18 Documentation Overview................... 19 1.4.1 Getting Started Manual....................19 1.4.2 User Manuals and Help....................19 1.4.3 Service Manual......................19 1.4.4 Instrument Security Procedures..................20 1.4.5 Basic Safety Instructions....................20 1.4.6...
  • Page 6 ® Contents R&S SMA100B 2.2.1.1 Touchscreen........................33 2.2.1.2 Utility Keys........................34 2.2.1.3 On/Standby........................34 2.2.1.4 Function Keys....................... 34 2.2.1.5 Keypad.......................... 35 2.2.1.6 Navigation Controls.......................35 Rotary Knob........................35 Editing Keys........................35 Navigation Keys......................36 2.2.1.7 Display Keys......................... 36 2.2.1.8 USB Connector......................37 2.2.1.9...
  • Page 7 ® Contents R&S SMA100B 2.4.5.1 Entering Numeric Parameters..................57 2.4.5.2 Entering Alphanumeric Parameters................57 2.4.5.3 Undo and Redo Actions....................57 2.4.6 Getting Information and Help..................57 2.4.7 Remote Control......................59 2.4.8 Remote Operation over VNC..................60 3 RF Signal Configuration..............61 Activating RF Signal Output..................
  • Page 8 ® Contents R&S SMA100B How to Generate a Pulse Train Modulated Signal..........108 5 Avionic Standards................110 Required Options...................... 110 About the Avionics Options..................110 5.2.1 VHF Omni Directional Radio Range (VOR)..............111 5.2.2 Instrument Landing System (ILS)................112 5.2.3 Automatic Direction Finder (ADF)................115 VOR Configuration and Settings................
  • Page 9 7.3.2 List Editor........................203 7.3.3 Fill with Sensor......................207 7.3.4 Import/Export List Files....................208 Using Power Sensors....................211 7.4.1 Connecting R&S NRP Power Sensors to the R&S SMA100B........211 7.4.2 NRP Sensor Mapping....................212 7.4.3 NRP Power Viewer......................214 7.4.3.1 About...........................214 7.4.3.2 NRP Power Viewer Settings..................216...
  • Page 10 ® Contents R&S SMA100B 7.4.4 NRP Power Analysis....................222 7.4.4.1 About...........................222 7.4.4.2 Accessing the NRP Power Analysis Functionality............223 7.4.4.3 Required Options......................225 7.4.4.4 Test Setup Example....................225 7.4.4.5 NRP Power Analysis Settings..................226 7.4.4.6 NRP Traces Settings....................226 Traces Settings......................227 Markers Settings......................
  • Page 11 How to Transfer Files from and to the Instrument..........305 10.9.1 Removing File System Protection................305 10.9.2 Accessing the File System of the R&S SMA100B Via ftp........... 307 10.9.3 Accessing the R&S SMA100B File System Via SMB (Samba)........308 10.9.4 Using a USB Storage Device for File Transfer............310 10.9.5...
  • Page 12 ® Contents R&S SMA100B 11.1.3 Defining the RF Signal State On Power On ............... 320 11.1.4 How to Set the Initial Instrument Settings..............321 11.1.4.1 Setting the Keyboard Language..................321 11.1.4.2 Setting the Screen Saver.................... 321 11.2 Organizing Frequently Used Settings as Favorites..........322 11.2.1...
  • Page 13 ® Contents R&S SMA100B 12.3 Remote Control Programs and Libraries..............354 12.3.1 VISA Library........................ 354 12.3.2 Possible Setups and Access Functions..............355 12.4 Remote Access Settings..................357 12.4.1 Network Settings......................358 12.4.2 VISA Resource Strings....................361 12.4.3 GPIB Address Settings....................362 12.4.4...
  • Page 14 ® Contents R&S SMA100B 12.11.3 SCPI Recording Export Settings................. 388 12.12 How to Find Out the SCPI Command Corresponding to the Manual Operation via Show SCPI Command....................390 12.13 How to Find Out the SCPI Command Corresponding to the Manual Operation Using the Online Help....................390...
  • Page 15 ® Contents R&S SMA100B 13.11 HCOPy Subsystem....................438 13.11.1 Hard Copy Settings..................... 439 13.11.2 Automatic Naming.......................441 13.12 KBOard Subsystem....................443 13.13 OUTPut Subsystem....................444 13.14 Power Sensor Measurement Subsystems..............448 13.14.1 CALCulate Subsystem....................449 13.14.2 DISPlay Subsystem....................453 13.14.3 INITiate Command...................... 454 13.14.4 READ Subsystem.......................
  • Page 16 ® Contents R&S SMA100B 13.16.5 SOURce:INPut Subsystem..................598 13.16.6 SOURce:LFOutput Subsystem................... 599 13.16.6.1 LF Generator Settings....................601 13.16.6.2 LF Sweep Settings...................... 609 13.16.7 SOURce:LIST Subsystem...................612 13.16.7.1 List Mode Settings.......................615 13.16.7.2 List Mode File Operation..................... 620 13.16.7.3 List Mode Data Exchange................... 622 13.16.8...
  • Page 17 ® Contents R&S SMA100B 15 Troubleshooting and Error Messages..........702 15.1 Error Messages......................702 15.1.1 Volatile Messages....................... 702 15.1.2 Permanent Messages....................702 15.2 SCPI-Error Messages....................703 15.3 Device-Specific Error Messages................703 15.4 Querying Error Messages..................704 15.5 Resolving Network Connection Failures..............706 15.6 Collecting Information for Technical Support............
  • Page 18 ® Contents R&S SMA100B A.1.5 Status Reporting System.................... 722 A.1.5.1 Hierarchy of the Status Registers................723 A.1.5.2 Structure of a SCPI Status Register................724 A.1.5.3 Status Byte (STB) and Service Request Enable Register (SRE)........726 A.1.5.4 Event Status Register (ESR) and Event Status Enable Register (ESE)..... 727 A.1.5.5...

  • Page 19: Preface

    R&S SMA100B only for its designated purpose. Observe the operating conditions and performance limits stated in the data sheet. The product documentation helps you to use the R&S SMA100B safely and efficiently. Keep the product documentation in a safe place and pass it on to the subsequent users.

  • Page 20: About This Manual

    ● Index Contents and scope This help system describes the full functionality of an R&S SMA100B. Depending on your model and the installed options, some of the functions may not be available on your instrument. User Manual 1178.3834.02 ─ 05...

  • Page 21: Documentation Overview

    1.4.1 Getting Started Manual Introduces the R&S SMA100B and describes how to set up and start working with the product. Includes basic operations, typical measurement examples, and general infor- mation, e.g. safety instructions, etc. A printed version is delivered with the instrument.

  • Page 22: Instrument Security Procedures

    SMA100B Documentation Overview 1.4.4 Instrument Security Procedures Deals with security issues when working with the R&S SMA100B in secure areas. It is available for download on the Internet. 1.4.5 Basic Safety Instructions Contains safety instructions, operating conditions and further important information.

  • Page 23: Getting Started

    Setting Up a Network (LAN) Connection..............28 2.1.1 Putting into Operation This section describes the basic steps to be taken when setting up the R&S SMA100B for the first time. Risk of injury due to disregarding safety information Observe the information on appropriate operating conditions provided in the data sheet to prevent personal injury or damage to the instrument.

  • Page 24: Emi Suppression

    Note the EMC classification in the data sheet. 2.1.1.2 Unpacking and Checking the Instrument Unpack the R&S SMA100B carefully and check the contents of the package. ● Check if all items listed on the delivery note, including this getting started manual, are included in the delivery.

  • Page 25: Accessory List

    Bench top operation If the R&S SMA100B is operated on a bench top, the surface must be flat. The instru- ment can be used in horizontal position, standing on its feet, or with the support feet on the bottom extended.

  • Page 26: Connecting Ac Power

    If the instruments have foldable feet, fold them in completely. Mounting in a rack The R&S SMA100B can be installed in a rack using a rack adapter kit (Order No. see data sheet). The installation instructions are part of the adapter kit.

  • Page 27: Turning The Instrument On And Off

    To turn on the R&S SMA100B Connect the instrument to the AC supply. 2. Turn on the main AC power switch at the rear panel of the R&S SMA100B (position "I" (on)). The instrument is supplied with AC power. Warm-up time for OCXO When the instrument is switched on, the OCXO requires an extended warm-up time (see data sheet).

  • Page 28: Functional Check

    The current setup is saved, the operating system shuts down and sets the instru- ment to standby state. The [On/Standby] LED must be orange. 2. Turn off the main AC power switch at the rear panel of the R&S SMA100B (position "0" (off)). The instrument is no longer supplied with AC power.

  • Page 29: Checking The Supplied Options And Licenses

    698. 2.1.2 Connecting USB Devices The USB interfaces of the R&S SMA100B allow you to connect USB devices, including USB hubs directly to the instrument. Due to the large number of available USB devi- ces, there is almost no limit to the expansions that are possible with the R&S SMA100B.

  • Page 30: Setting Up A Network (Lan) Connection

    A mouse is detected automatically when it is connected. 2.1.3 Setting Up a Network (LAN) Connection The R&S SMA100B is equipped with a network interface and can be connected to an Ethernet LAN (local area network). Provided the appropriate rights have been assigned by the network administrator, the interface can be used, for example: ●...

  • Page 31: Using Computer Names (Hostnames)

    By default, the instrument is configured to use DHCP (dynamic host configuration protocol) configuration and to obtain the whole address information automatically. When connected, the R&S SMA100B displays the address information on the screen. Risk of network connection failure Network cables and cable connectors of poor quality, or failures in the autonegotiation process, can cause network connection failures.

  • Page 32: Assigning The Ip Address

    You can find the serial number at the rear panel of instrument. It is the third part of the device ID printed on the barcode sticker . Example: The default hostname of an R&S SMA100B with a serial number 102030 is SMA100B-102030. To query and change a computer name 1.

  • Page 33: Instrument Tour

    ® Getting Started R&S SMA100B Instrument Tour Risk of network failure Consult your network administrator before performing the following tasks: ● Connecting the instrument to the network ● Configuring the network ● Changing IP addresses Errors can affect the entire network.

  • Page 34: Front Panel Tour

    R&S SMA100B. Most of the connectors are at the rear panel and are described in Chapter 2.2.2, "Rear Panel Tour", on page 39. Figure 2-1: Front panel view of the R&S SMA100B RF Signal Generator with height unit 2HU (option R&S SMAB-B92) 1 = Touchscreen 2 = Utility keys...

  • Page 35: Touchscreen

    ® Getting Started R&S SMA100B Instrument Tour 1 = Touchscreen 2 = Utility keys 3 = [On/Standby] 4 = Function keys 5 = Keypad 6 = Navigation controls 7 = Display keys 8 = USB connector 9 = SD card slot...

  • Page 36: Utility Keys

    For instructions on cleaning the screen, see Chapter 14.1, "Cleaning", on page 686. 2.2.1.2 Utility Keys The utility keys set the R&S SMA100B to a defined state, and provide access to basic settings and information on assistance. Table 2-1: Utility keys Utility Key Assigned functions [Preset]...

  • Page 37: Keypad

    ® Getting Started R&S SMA100B Instrument Tour Table 2-2: Function keys Function key Assigned functions [Freq] Activates frequency entry. [Level] Activates level entry. [Mod on/off] Switches the modulation on and off. [RF on/off] Switches the RF output on and off.

  • Page 38: Navigation Keys

    ® Getting Started R&S SMA100B Instrument Tour Table 2-4: Editing keys Type of key Description [Esc] key Closes all kinds of dialog boxes, if the edit mode is not active. Quits the edit mode, if the edit mode is active. In dialog boxes that contain a "Can- cel"...

  • Page 39: Usb Connector

    The R&S SMA100B supports the use of R&S NRP power sensors in various ways including the use as a power viewer. A power sensor is connected to the R&S SMA100B by inserting the male connector. To disconnect, pull the connector by its sleeve. You cannot disconnect the sensor simply by pulling at the cable or the rear part of the connector.

  • Page 40: Rf 50 Ω

    The application notes are available on the Internet and provide additional information on care and handling of RF connectors. Rohde & Schwarz offers appropriate torque wrenches for various connectors. For ordering information, see the R&S SMA100B data sheet or product brochure. 2.2.1.12 Pulse Signal Connectors Pulse Sync Output signal for synchronizing the pulse generator signal.

  • Page 41: Lf Modulation Connectors

    This section provides an overview of the connectors at the rear panel of the instrument. For technical data of the connectors, refer to the data sheet. Figure 2-4: Rear panel view of the R&S SMA100B RF Signal Generator with height unit 2HU (option R&S SMAB-B92)

  • Page 42: Connectors

    18 = RF output connector 19 = Serial number (six digits in the string 1419.8888.02-<serial number>-<checksum>) Figure 2-5: Rear panel view of the R&S SMA100B RF Signal Generator with height unit 3HU (option R&S SMAB-B93) 1 = IEC 625/IEEE 488 connector...
  • Page 43 Chapter 2.1.2, "Connecting USB Devices", on page 27. The LAN interface can be used to connect the R&S SMA100B to a local network for remote control, remote operation, and data transfer. For details, see Chapter 2.1.3, "Setting Up a Network (LAN) Connection",...
  • Page 44 ® Getting Started R&S SMA100B Instrument Tour For detailed information on the sweep modes and the triggering, see Chapter 6.1, "Sig- nal Generation and Triggering in the Sweep and List Modes", on page 156. Input connector for an EFC (external frequency control) signal for electronic tuning of the internal reference frequency.

  • Page 45: Trying Out The Instrument

    We start to generate a simple unmodulated signal. In this example, the R&S SMA100B can be in its minimal configuration. 1. On the R&S SMA100B front panel, press the [Preset] key to set a defined initial instrument state. 2. Set the frequency: a) In the "Status Bar", tap the "Frequency"...
  • Page 46 4. To activate RF signal output, select "Level" > "RF On" in the tile diagram. The blue colored "RF On" icon indicates that the RF output is activated. The R&S SMA100B provides the 6 GHz signal at the RF A connector at the front panel.
  • Page 47 ® Getting Started R&S SMA100B Trying Out the Instrument Figure 2-6: Generating an unmodulated signal Alternative ways to access the instrument functions To fulfill the same task, you can also use the front panel keys or the setting parameters provided in the frequency and level dialogs.

  • Page 48: Generating An Rf Frequency Sweep Signal

    SMA100B Trying Out the Instrument ® Connect RF of the R&S SMA100B to a signal analyzer, for example R&S FSW, to dis- play the generated signal. For the required settings of the signal analyzer, refer to its user manual or its online help.
  • Page 49 6. In the "General" tab, activate the frequency sweep with "State > On". 7. Close the sweep dialog. (Alternatively, tap the "Home" button to minimize the dialog. The R&S SMA100B indicates the "Sweep" dialog as active dialog in the task bar.) 8.

  • Page 50: Saving And Recalling Settings

    ® Getting Started R&S SMA100B Trying Out the Instrument 2.3.3 Saving and Recalling Settings To restore the results of our measurements later, we save the instrument settings in a file. To save the instrument settings in a file We assume, a test configuration as described in Chapter 2.3.2, "Generating an RF...
  • Page 51 ® Getting Started R&S SMA100B Trying Out the Instrument 4. In the "Save/Recall" dialog, select "Operation Mode > Recall". Navigate to the directory the file is saved in and select the MyTestSignal file. 5. Tap the "Recall" button. All instrument settings are restored and the display resembles Chapter 2.3.2, "Gen-...

  • Page 52: Instrument Control

    All changed parameters are highlighted. See also Chapter 10, "File and Data Management", on page 282. 2.4 Instrument Control This chapter provides an overview on how to work with the R&S SMA100B. It covers the following topics: User Manual 1178.3834.02 ─ 05...

  • Page 53: Possible Ways To Operate The Instrument

    "Remote Operation over VNC", on page 60. 2.4.2 Means of Manual Interaction For the manual interaction with the R&S SMA100B, you have several methods that you can use as an alternative to perform a task: ● Touchscreen: Touchscreen operation is the most direct way to interact. Almost all control ele- ments and actions on the screen are based on the standard operating system con- cept.

  • Page 54: Understanding The Display Information

    The status bar at the top of the screen indicates the RF frequency and the level of the output signal provided to the DUT. You can set both parameters directly here. 2.4.3.2 Tile Diagram The tile diagram is the main entry to the settings of the R&S SMA100B. User Manual 1178.3834.02 ─ 05...

  • Page 55: Taskbar

    ® Getting Started R&S SMA100B Instrument Control Tile Access to: ● "Modulation" Analog and stereo , and pulse modulation settings ● Built in LF generator ● "System Config" "Save/Recall": settings for saving and loading instrument configurations ● "Remote access": Network and emulation settings.

  • Page 56: Additional Display Characteristics

    ® Getting Started R&S SMA100B Instrument Control Active dialogs Indicates the dialog name of each active dialog in a separate button. "Info" key Provides access to status and error messages. Note: The warning symbol signifies a permanent error message. 2.4.3.4...

  • Page 57: Accessing The Functionality

    ® Getting Started R&S SMA100B Instrument Control 2.4.4 Accessing the Functionality All functionalities are provided in dialog boxes as known from computer programs. You can control the instrument intuitively with the touchscreen. This section provides an overview of the accessing methods.

  • Page 58: Entering Data

    ® Getting Started R&S SMA100B Instrument Control 2. To switch to another dialog, press the [Next Window] button. To close a dialog box To close a dialog box, you have the same controls as you know from computers or devices with touchscreen.

  • Page 59: Entering Numeric Parameters

    ® Getting Started R&S SMA100B Instrument Control 2.4.5.1 Entering Numeric Parameters To enter values with the on-screen keypad For numeric settings, the instrument displays the numeric keypad. The units specified correspond to the units of the parameter. 1. Enter the numeric value.
  • Page 60 ® Getting Started R&S SMA100B Instrument Control For further information, you can use the following sources: ● Tooltips give the value range of the parameter. ● The context help provides functional description on a setting. ● The general help explains a dialog box, provides instructions, and general informa- tion.

  • Page 61: Remote Control

    The corresponding help topic is displayed. 2.4.7 Remote Control In addition to working with the R&S SMA100B interactively, located directly at the instrument, it is also possible to operate and control it from a remote PC. The R&S SMA100B supports various methods for remote control: ●...

  • Page 62: Remote Operation Over Vnc

    Thus, remote operation of the instrument is possible. Instrument control from a remote computer To access the basic utility functions of the R&S SMA100B, perform a right mouse click on the block diagram and select "Key Emulation". A key panel to the right of the block diagram gives access to the utility functions provi- ded by the front panel keys.

  • Page 63: Rf Signal Configuration

    Chapter 4, "Analog Modulations", on page 73. The R&S SMA100B allows you to provide the RF signal with constant or varying fre- quencies and/or amplitudes at the output: ● Constant frequency and level (CW/Fixed mode) The RF output signal has the set frequency and level.

  • Page 64: Activating Rf Signal Output

    ® RF Signal Configuration R&S SMA100B How to Set the Frequency and Level The RF signal is based on a list of predefined frequency and level values pairs and step widths. Chapter 6, "List and Sweep Mode", on page 154.
  • Page 65 R&S SMA100B. Examples of downstream instruments are mixers, frequency multipli- ers, amplifiers or attenuators and of their corresponding major parameters offset, multi- plier, amplitude. The R&S SMA100B generates the signal without the downstream parameters, but considers all additional parameters concerning the frequency and level.

  • Page 66: Rf Frequency Settings

    ® RF Signal Configuration R&S SMA100B RF Frequency Settings 3.3 RF Frequency Settings Access: 1. Select "Frequency" > "RF Frequency". 2. Observe the information on the home screen, "Frequency" tile. The "Frequency" tile indicates the reference frequency, current frequency offset and multiplier values, and phase offset value.
  • Page 67 The "Frequency" value displayed in the status bar is the resulting frequency, as it is at the output of the downstream instrument. The frequency at the R&S SMA100B RF out- put is not changed. "RF frequency and level display with a downstream instrument"...

  • Page 68: Rf Level Settings

    The "Frequency" value displayed in the status bar is the resulting frequency, as it is at the output of the downstream instrument. The frequency at the R&S SMA100B RF out- put is not changed. "RF frequency and level display with a downstream instrument"...
  • Page 69 ® RF Signal Configuration R&S SMA100B RF Level Settings In the "RF Level" dialog, you can configure the offset-free level, the level limit, and the step width for varying the level with the rotary knob. 2. Select "User Variation" to set the step width to be used when setting the RF level using the rotary knob.

  • Page 70: Rf State/Rf On

    ® RF Signal Configuration R&S SMA100B RF Level Settings The "Level" tile indicates the level limit, the user correction status and current cor- rection value, current setting characteristics incl. mode. The remote commands required to define the settings are described in Chap- ter 13.16.11, "SOURce:POWer...

  • Page 71: Limit

    The "Level" value displayed in the status bar is the resulting level, as it is at the output of the downstream instrument. The level at the R&S SMA100B RF output is not changed. "RF frequency and level display with a downstream instrument"...

  • Page 72: Mode

    ® RF Signal Configuration R&S SMA100B RF Level Settings "Strictly Monotone" Executes signal level changes monotonically increasing or decreas- ing. The setting makes sure that increasing the level value exclusively results in an increased output level, and vice versa. All electronic switches, which might affect the monotonicity are fixed.

  • Page 73: Rf Phase Settings

    ® RF Signal Configuration R&S SMA100B RF Phase Settings Remote command: on page 636 [:SOURce<hw>]:POWer:RANGe:LOWer? on page 636 [:SOURce<hw>]:POWer:RANGe:UPPer? Readjust Recalculates and adjusts the internal switch positions of the RF chain according to the current level. Remote command: on page 630 [:SOURce<hw>]:POWer:ALC:SONCe...
  • Page 74 ® RF Signal Configuration R&S SMA100B RF Phase Settings 2. Observe the information on the home screen, "Frequency" tile. The "Frequency" tile indicates used reference frequency, current frequency offset and multiplier values, and the delta phase value. The remote commands required to define the settings are described in Chap- ter 13.16.10, "SOURce:PHASe...

  • Page 75: Analog Modulations

    The three basic modulation types FM, AM and PhiM for example, vary one property of the carrier proportional to the instantaneous amplitude of the modulating signal. Signal sources If fully equipped, the R&S SMA100B modulates signals from the following sources: ● Internal modulation source –...
  • Page 76 ® Analog Modulations R&S SMA100B Modulation Types and Signal Sources – High-performance pulse generator Generates single and double pulse, or pulse train signals. ● External modulation source – Amplitude, frequency or phase modulation signals are input at the Ext connec- tor.

  • Page 77: Activating Analog Modulations

    ® Analog Modulations R&S SMA100B Modulation Settings ● The settings of the modulation signal affect all analog modulations that use an internal modulation source. ● You can feed an external LF signal in each of the two paths. ● Using exponential amplitude modulation with an external source, sets the coupling of the corresponding input automatically to DC.

  • Page 78: Pulse Modulation

    ® Analog Modulations R&S SMA100B Modulation Settings The remote commands required to define these settings are described in: ● Chapter 13.16.1.2, "SOURce:AM Subsystem", on page 513 ● Chapter 13.16.1.3, "SOURce:FM Subsystem", on page 519 ● Chapter 13.16.1.4, "SOURce:PM Subsystem", on page 524 ●...

  • Page 79: Fm, Phim And Am Modulation Settings

    ® Analog Modulations R&S SMA100B Modulation Settings The signal is output at the Pulse Video connector. To deactivate the signal output, set "Pulse Generator" > Pulse Output State > "Off". Remote command: on page 532 [:SOURce<hw>]:PULM:STATe Source Selects between the internal "Pulse Generator" or an "External" pulse signal for the modulation.
  • Page 80 ® Analog Modulations R&S SMA100B Modulation Settings Access: ► Select "Modulation" > "Amplitude Modulation/Frequency Modulation/Phase Modu- lation". The "FM", "ΦM" and "AM" tabs contain the parameters per modulation type. Source State..........................79 Source...........................79 settings........................79 └ Deviation......................79 └ Deviation Mode....................80 └...

  • Page 81: State

    ® Analog Modulations R&S SMA100B Modulation Settings └ Deviation Mode....................83 └ Total Depth......................84 └ Ratio Path2/Path1...................84 State Activates a modulation. Note: Some modulations exclude each other and cannot be performed simultaneously. For more information, see data sheet. Remote command: on page 515 [:SOURce<hw>]:AM<ch>:STATe...

  • Page 82: Total Deviation

    Total Deviation. "Fixed Ratio" Couples the deviation ratio of both paths. If you change the deviation of any path, the R&S SMA100B adjusts the value of the other path. Remote command: on page 522 [:SOURce<hw>]:FM:DEViation:MODE Total Deviation ← FM settings...

  • Page 83: Phim Settings

    Deviation. "Fixed Ratio" Couples the deviation ratio of both paths. If you change the deviation of any path, the R&S SMA100B adjusts the value of the other path. Remote command: on page 527 [:SOURce<hw>]:PM:DEViation:MODE Total Deviation ← PhiM settings...

  • Page 84: Mode

    ® Analog Modulations R&S SMA100B Modulation Settings Remote command: on page 528 [:SOURce<hw>]:PM:RATio Mode ← PhiM settings Selects the mode of the phase modulation. "High Bandwidth" The maximum range for modulation bandwidth and PhiM deviation is available. However, phase noise increases at low frequencies, and the range of PhiM deviation is limited.

  • Page 85: Type

    The deviation sum of both paths is 100% in total. When the sum is exceeded, the R&S SMA100B reports a settings conflict, but does not change the settings. "Uncoupled" Enables you to adjust the deviation depth for each path independ- ently.

  • Page 86: Pulse Generator

    Total Depth. "Fixed Ratio" Couples the deviation ratio of both paths. If you change the depth of any path, the R&S SMA100B adjusts the value of the other path. Remote command: on page 518 [:SOURce<hw>]:AM:DEViation:MODE Total Depth ← AM settings...

  • Page 87: Pulse Generator > General Settings

    ® Analog Modulations R&S SMA100B Modulation Settings Access: ► Select "Modulation" > "Pulse Modulation > Pulse Generator". The "Pulse Generator" tab contains the settings for creating the pulse modulation signal internally. ● Pulse Generator > General Settings............... 85 ● Pulse Generator > Pulse Train Settings..............89...
  • Page 88 ® Analog Modulations R&S SMA100B Modulation Settings Pulse Mode Sets the operating mode of the pulse generator. Depending on the selection, the instru- ment displays the associated parameters. "Single" Generates a single pulse in one pulse period. "Double" Generates two pulses in one pulse period.
  • Page 89 ® Analog Modulations R&S SMA100B Modulation Settings "Ext Triggered" Generates the pulse signal each time an external trigger event occurs. Example: Generation of single pulse signal ("Pulse Mode = Sin- gle") using "Trigger Mode = Ext Triggered" = External trigger signal input with "Trigger Input Polarity = Normal" (the positive...
  • Page 90 ® Analog Modulations R&S SMA100B Modulation Settings = Pulse signal = Trigger signal during double pulse generation is without effect Δt = Trigger delay between the trigger and the sync signal start; see data sheet delay = "Double Pulse Delay = 200 ns"; the first pulse starts without a delay = "Double Pulse Width = 100 ns"...

  • Page 91: Pulse Generator > Pulse Train Settings

    ® Analog Modulations R&S SMA100B Modulation Settings Double Pulse Width Sets the width of the second pulse. Remote command: on page 532 [:SOURce<hw>]:PULM:DOUBle:WIDTh Pulse Delay Sets the pulse delay. The pulse delay determines the time that elapses after a trigger event before pulse modulation starts.
  • Page 92 ® Analog Modulations R&S SMA100B Modulation Settings 2. Select "Pulse Train Data". 3. Select an existing file or select "New" to create one. 4. Define the filename. Select "Edit Pulse Train Data", if the file is empty or to control and change the val- ues.
  • Page 93 ® Analog Modulations R&S SMA100B Modulation Settings Pulse train ASCII file format Files describing pulse trains are simple files in text or comma-separated value (CSV) file format. The filename is user-definable; the file extension is *.csv or *.txt. The file contains a list of pulse definition values, one row per pulse; a new line indicator separates the pulses.
  • Page 94 ® Analog Modulations R&S SMA100B Modulation Settings "Count" Sets the number of repetitions of an "On-/ Off-Time" value pair. Pulses with "Count = 0" are ignored. Use this method to skip value pairs temporarily, without deleting them from the table.

  • Page 95: Import/Export List Files

    ® Analog Modulations R&S SMA100B Modulation Settings To fill the table, select "Fill". Note: Once you enter a value or fill a column, the editor automatically adds preset val- ues in the other columns. This functionality protects against data loss, otherwise incomplete rows will be lost when saving.
  • Page 96 ® Analog Modulations R&S SMA100B Modulation Settings The "Import/Export" dialog contains all functions and settings to import externally created list data or to export it accordingly. You can process and store a list in the formats *.txt (ASCII), or *.csv (plain text with identical sequence of fields). The table separators and the decimal floating point numbers are customizable.

  • Page 97: Pulse Graph

    ® Analog Modulations R&S SMA100B Modulation Settings Where: ● "Select ASCII Source": defines the file to be loaded (imported) ● "Select ASCII Destination": selects the filename under that the loaded file is saved Remote command: on page 623 [:SOURce<hw>]:LIST:DEXChange:AFILe:CATalog? on page 623 [:SOURce<hw>]:LIST:DEXChange:AFILe:SELect...
  • Page 98 ® Analog Modulations R&S SMA100B Modulation Settings The height of the bars corresponds to the selected amplitude of the pulse signal. File Name Indicates the name of the pulse train data file. To create or select a file, see "Pulse Train Data"...

  • Page 99: Pulse External / Trigger Settings

    ® Analog Modulations R&S SMA100B Modulation Settings 4.4.5 Pulse External / Trigger Settings Access: ► Select "Modulation" > "Pulse Modulation > Pulse External / Trigger". The dialog specifies some characteristics of the Pulse Ext connector. This connector is common for the pulse generator and the pulse modulator. For an overview, see "Input and output connectors"...

  • Page 100: Fm, Phim And Am Modulation Sources

    ® Analog Modulations R&S SMA100B Modulation Settings Show Connector Accesses a dialog that displays the physical location of the selected connector on the front/rear panel of the instrument. 4.4.6 FM, PhiM and AM Modulation Sources Access: ► Select "Modulation > Modulation Sources".
  • Page 101 ® Analog Modulations R&S SMA100B Modulation Settings The internal LF signal can the modulation signal source for any of the analog mod- ulations. The LF signal applies to all modulations which use the internal modulation signal. Therefore, any modification of the LF signal immediately affects all currently active modulations.
  • Page 102 ® Analog Modulations R&S SMA100B Modulation Settings "Pulse" 1 = Pulse period 2 = Pulse width "Triangle" 1 = Triangle period 2 = Triangle rise "Trapezoid" 1 = Trapezoid period 2 = Trapezoid rise 3 = Trapezoid fall 4 = Trapezoid high...
  • Page 103 ® Analog Modulations R&S SMA100B Modulation Settings Period Sets the repetition rate of the generated LF signal for triangle, trapezoid or pulse shapes, see Shape. The period of sine signals is calculated from the selected Frequency Remote command: on page 607 [:SOURce<hw>]:LFOutput<ch>:SHAPe:TRAPeze:PERiod...

  • Page 104: Source > External Settings

    ® Analog Modulations R&S SMA100B Modulation Settings 4.4.6.2 Source > External Settings Access: ► Select "Modulation" > "Modulation Sources > External". The "External" settings section contains all parameters required to configure the signal of an externally supplied LF signal. Settings Coupling (AC/DC).......................

  • Page 105: Source > Noise Generator Settings

    ® Analog Modulations R&S SMA100B Modulation Settings Bandwidth Displays the maximum bandwidth of the external LF signal. Remote command: on page 602 [:SOURce]:LFOutput<ch>:BANDwidth? Show Connector Accesses a dialog that displays the physical location of the selected connector on the front/rear panel of the instrument.

  • Page 106: Lf Signal Output Settings

    ® Analog Modulations R&S SMA100B Modulation Settings Remote command: on page 625 [:SOURce<hw>]:NOISe:BANDwidth|BWIDth on page 625 [:SOURce<hw>]:NOISe:BWIDth:STATe 4.4.7 LF Signal Output Settings Access: ► Select "Modulation" > "LF Output". In the "LF Output" tab, you can configure the signal at the LF outputs, determine the output voltage or add a DC offset.
  • Page 107 ® Analog Modulations R&S SMA100B Modulation Settings Remote command: on page 604 [:SOURce]:LFOutput<ch>[:STATe] Source Select the sources for the signal output at the LF connector. If you activate path 1 and 2, those sources are added. Use the "Show Connector" function to find out where this connector is located.

  • Page 108: Overview

    ® Analog Modulations R&S SMA100B Modulation Settings Noise Level ← Noise Level Indicates the level of the noise signal per Hz within the total bandwidth (absolute). Remote command: on page 626 [:SOURce<hw>]:NOISe:LEVel[:ABSolute]? 4.4.8 Overview Option: AM and FM/PM require R&S SMAB-K720 Access: ►...

  • Page 109: How To Generate An Amplitude Modulated Signal

    ® Analog Modulations R&S SMA100B How to Generate an Amplitude Modulated Signal To generate a two-tone signal composed form the two paths of the same modu- lation type, activate both paths. ● The "FM" box allows switching to "PhiM", but those modulations are mutually exclusive.

  • Page 110: How To Generate A Pulse Modulated Signal

    ® Analog Modulations R&S SMA100B How to Generate a Pulse Train Modulated Signal 5. Set "Level > RF ON" to enable signal output. 4.6 How to Generate a Pulse Modulated Signal The following example uses the internal pulse generator. To set the frequency and level of the RF signal 1.
  • Page 111 ® Analog Modulations R&S SMA100B How to Generate a Pulse Train Modulated Signal To configure the pulse generator 1. Select "Modulation" > "Pulse Generator". 2. Select "Pulse Mode = Train". 3. Select "Pulse Train Data". Accesses the standard function for file handling.

  • Page 112: Avionic Standards

    ® Avionic Standards R&S SMA100B About the Avionics Options 5 Avionic Standards The R&S SMA100B supports avionic standards VOR, ILS and ADF. Contents ● Required Options....................110 ● About the Avionics Options................... 110 ● VOR Configuration and Settings................116 ●...

  • Page 113: Vhf Omni Directional Radio Range (Vor)

    ® Avionic Standards R&S SMA100B About the Avionics Options 5.2.1 VHF Omni Directional Radio Range (VOR) Very high frequency (VHF) omnidirectional radio range (VOR) is used for radio naviga- tion and helps aircraft to determine their position and stay on course.

  • Page 114: Instrument Landing System (Ils)

    102Y 115.55 116Y 116.95 Related Settings For VOR settings at the R&S SMA100B, see Chapter 5.3, "VOR Configuration and Settings", on page 116. 5.2.2 Instrument Landing System (ILS) The instrument landing system is used during the landing approach and monitors the correct approach path to the runway.
  • Page 115 ® Avionic Standards R&S SMA100B About the Avionics Options Glide Slope The glide slope transmitter is located near the end of the runway (nearest to the start of the aircraft approach). Typically, vertically aligned antennas transmit two intersecting main beams on top of...
  • Page 116 ® Avionic Standards R&S SMA100B About the Avionics Options ILS ICAO Frequencies The individual values in Table 5-2 are: ● Chan. = ICAO channel number ● LOC Freq. = ILS localizer frequency (MHz) ● GS Freq. = ILS glide slope frequency (MHz) Table 5-2: ILS glide slope and localizer ICAO standard frequencies (MHz) and channels Chan.

  • Page 117: Automatic Direction Finder (Adf)

    Middle marker flashes AMBER in the cockpit at 1300 Hz (“hurried” tone). ● Inner marker flashes WHITE in the cockpit at 3000 Hz (“urgent” tone). Related Settings For ILS settings at the R&S SMA100B, see the following sections: ● Chapter 5.4.2, "ILS Glide Slope Settings", on page 127 ●...

  • Page 118: Vor Configuration And Settings

    ® Avionic Standards R&S SMA100B VOR Configuration and Settings Related Settings For ADF settings at the R&S SMA100B, see Chapter 5.5, "ADF Configuration and Set- tings", on page 148. 5.3 VOR Configuration and Settings Option: R&S SMAB-K25 Access: ► Select "Modulation > Avionic Standards > VOR".
  • Page 119 "Avionic: ADF" for enabled ADF modulation Changing a parameter in the avionic standards causes an instant signal change in the R&S SMA100B. There is no extra measurement cycle to calculate the RMS value of the baseband signal to set the correct RF level.
  • Page 120 ® Avionic Standards R&S SMA100B VOR Configuration and Settings Remote command: on page 546 <subsystem>:PRESet Save/Recall Accesses the "Save/Recall" dialog, that is the standard instrument function for saving and recalling the complete dialog-related settings in a file. The provided navigation possibilities in the dialog are self-explanatory.

  • Page 121: Signal Settings

    ® Avionic Standards R&S SMA100B VOR Configuration and Settings "EXT (MOD AM)" Selects the external source. The external signal is added to the inter- nal signal. Switching off the internal source is not possible. The exter- nal signal is input via the Ext connector. The sensitivity is 10 mV per percent modulation depth.
  • Page 122 ® Avionic Standards R&S SMA100B VOR Configuration and Settings "Var" Amplitude modulation of the output signal with the VAR signal compo- nent (30Hz signal content) of the VOR signal. The modulation depth corresponds to the value set under Depth. "Subcarrier"...

  • Page 123: Position Settings

    ® Avionic Standards R&S SMA100B VOR Configuration and Settings 5.3.3 Position Settings Access: ► Select "VOR > Position". This dialog provides access to position settings related to the VOR modulation sig- nal. Settings Bearing Angle......................121 Direction........................121 Bearing Angle Sets the phase angle between the 30 Hz VAR signal and the 30 Hz reference signal.

  • Page 124: Com/Id Settings

    ® Avionic Standards R&S SMA100B VOR Configuration and Settings 5.3.4 COM/ID Settings Access: ► Select "VOR > COM/ID" This dialog comprises COM/ID signal settings related to the VOR signal. Settings COM/ID State......................122 Code..........................122 Period..........................123 Frequency........................123 Depth...........................123 Time Schema......................123 Length........................123...
  • Page 125 ® Avionic Standards R&S SMA100B VOR Configuration and Settings The COM/ID tone is sent according to the selected code, see Chapter D, "Morse Code Settings", on page 740. If no coding is set, the COM/ID tone is sent uncoded (key down).

  • Page 126: Ils Configuration And Settings

    ® Avionic Standards R&S SMA100B ILS Configuration and Settings Symbol Space Requires "Time Schema > User". Sets the length of the Morse code symbol space. Remote command: on page 578 [:SOURce<hw>]:VOR:COMid:SYMBol Letter Space Requires "Time Schema > User". Sets the length of a Morse code letter space.
  • Page 127 "Avionic: ADF" for enabled ADF modulation Changing a parameter in the avionic standards causes an instant signal change in the R&S SMA100B. There is no extra measurement cycle to calculate the RMS value of the baseband signal to set the correct RF level.
  • Page 128 ® Avionic Standards R&S SMA100B ILS Configuration and Settings Settings State..........................126 Set To Default......................126 Save/Recall......................... 126 Component......................126 AM........................127 State Activates the avionic standard. Activation of the standard deactivates a previously active avionic standard. The "VOR/ILS > Carrier Frequency" setting is applied automatically to the "RF >...

  • Page 129: Ils Glide Slope Settings

    ® Avionic Standards R&S SMA100B ILS Configuration and Settings Remote command: on page 553 [:SOURce<hw>]:ILS:TYPE EXT AM Enables/disables additional modulation from an external source. The external signal is input via the Ext connector. "OFF" Selects the internal modulation source for VOR/ILS glide slope/ILS localizer modulation.
  • Page 130 ® Avionic Standards R&S SMA100B ILS Configuration and Settings 2. Select "ILS > General". This dialog comprises carrier frequency settings related to the ILS glide slope com- ponent of the ILS signal. Settings Carrier Frequency Mode..................... 128 Carrier Frequency....................... 128 ICAO Channel......................
  • Page 131 ® Avionic Standards R&S SMA100B ILS Configuration and Settings Remote command: on page 556 [:SOURce<hw>]:ILS[:GS|GSLope]:FREQuency ICAO Channel Requires "Carrier Frequency Mode > ICAO". Sets the ICAO channel and the corresponding transmitting frequency. If avionic standard modulation is activated and you change the "RF Frequency", the frequency value of the closest ICAO channel is applied automatically.

  • Page 132: Signal Settings

    ® Avionic Standards R&S SMA100B ILS Configuration and Settings 5.4.2.2 Signal Settings Access: 1. Select "ILS Component > Glide Slope", see Chapter 5.4.2, "ILS Glide Slope Set- tings", on page 127. 2. Select "ILS > Signal". This dialog comprises modulation signal settings related to the ILS glide slope component of the ILS signal.

  • Page 133: Amplitude Settings

    ® Avionic Standards R&S SMA100B ILS Configuration and Settings "150 Hz" Amplitude modulation of the output signal with the lower lobe signal component (150 Hz signal content) of the ILS glide slope signal. The modulation depth of the 150 Hz signal results from the settings of...
  • Page 134 ® Avionic Standards R&S SMA100B ILS Configuration and Settings 2. Select "ILS > Amplitude". This dialog comprises amplitude settings related to the ILS glide slope component of the ILS signal. Settings Sum of Depth......................132 FlyMode........................132 Step........................133 Current....................... 133 Depth.........................
  • Page 135 ® Avionic Standards R&S SMA100B ILS Configuration and Settings "Down" The 90 Hz modulation signal is predominant, the DDM value is posi- tive (the airplane is too high, it must descend). Remote command: on page 554 [:SOURce<hw>]:ILS[:GS|GSLope]:DDM:DIRection DDM Step Selects the variation of the DDM values.

  • Page 136: Ils Localizer Settings

    ® Avionic Standards R&S SMA100B ILS Configuration and Settings The DDM value in percent is calculated as follows: ● "DDM Polarity > 90 Hz - 150 Hz": DDM = [ AM (90 Hz) - AM (150 Hz) ] ● "DDM Polarity > 150 Hz - 90 Hz":...
  • Page 137 ® Avionic Standards R&S SMA100B ILS Configuration and Settings 2. Select "ILS > General". This dialog comprises carrier frequency settings related to the ILS localizer compo- nent of the ILS signal. Settings Carrier Frequency Mode..................... 135 Carrier Frequency....................... 135 ICAO Channel......................

  • Page 138: Signal Settings

    ® Avionic Standards R&S SMA100B ILS Configuration and Settings ICAO Channel Requires "Carrier Frequency Mode > ICAO". Sets the ICAO channel and the corresponding transmitting frequency. If avionic standard modulation is activated and you change the "RF Frequency", the frequency value of the closest ICAO channel is applied automatically. The "ICAO Channel"...
  • Page 139 ® Avionic Standards R&S SMA100B ILS Configuration and Settings 2. Select "ILS > Signal". This dialog comprises audio signal and modulation settings related to the ILS local- izer component of the ILS signal. Settings Operating Mode......................137 polarity....................... 138 Left Frequency......................

  • Page 140: Amplitude Settings

    ® Avionic Standards R&S SMA100B ILS Configuration and Settings Remote command: on page 567 [:SOURce<hw>]:ILS:LOCalizer:MODE DDM polarity Defines the polarity for DDM calculation (see "DDM Depth" on page 140). Remote command: on page 564 [:SOURce<hw>]:ILS:LOCalizer:DDM:POLarity Left Frequency Sets the modulation frequency of the antenna lobe arranged at the left viewed from the air plane.
  • Page 141 ® Avionic Standards R&S SMA100B ILS Configuration and Settings 2. Select "ILS > Amplitude". This dialog comprises amplitude settings related to the ILS localizer component of the ILS signal. Settings FlyMode........................139 Sum of Depth......................139 DDM - SDM Coupling....................140 Step........................140...
  • Page 142 ® Avionic Standards R&S SMA100B ILS Configuration and Settings The RMS modulation depth of the sum signal depends on the phase setting of both modulation tones. The "Sum of Depth" and "COM/ID > Depth" must be smaller than 100 %.

  • Page 143: Com/Id Settings

    ® Avionic Standards R&S SMA100B ILS Configuration and Settings DDM Logarithmic Sets the DDM value in dB. The dB value is calculated according to: DDM dB = 20 × LOG [(SDM + DDM × 100 %) / (SDM - DDM × 100 %)] A variation of the value automatically leads to a variation of the DDM value and the instrument current.
  • Page 144 ® Avionic Standards R&S SMA100B ILS Configuration and Settings This dialog comprises COM/ID settings related to the ILS localizer component of the ILS signal. Settings COM/ID State......................142 Code..........................142 Frequency........................142 Period..........................142 Depth...........................142 Time Schema......................143 Length........................143 Dash Length .......................143 Symbol Space ......................

  • Page 145: Ils Marker Beacons Settings

    ® Avionic Standards R&S SMA100B ILS Configuration and Settings Time Schema Sets the time schema of the Morse code for the COM/ID signal. ● "Standard" The set dot length determines the length of the dash, the symbol space and letter space of the Morse code.

  • Page 146: General Settings

    ® Avionic Standards R&S SMA100B ILS Configuration and Settings Settings ● General Settings....................144 ● Signal Settings...................... 145 ● COM/ID Settings....................146 5.4.4.1 General Settings Access: 1. Select "ILS Component > Marker Beacons", see Chapter 5.4.4, "ILS Marker Bea- cons Settings",...

  • Page 147: Signal Settings

    ® Avionic Standards R&S SMA100B ILS Configuration and Settings Remote command: on page 572 [:SOURce<hw>][:ILS]:MBEacon:FREQuency 5.4.4.2 Signal Settings Access: 1. Select "ILS Component > Marker Beacons", see Chapter 5.4.4, "ILS Marker Bea- cons Settings", on page 143. 2. Select "ILS > Signal".

  • Page 148: Com/Id Settings

    ® Avionic Standards R&S SMA100B ILS Configuration and Settings "ON" Modulation of pulsed marker signals (morse coding). The duty cycle, i.e. the marker on- and off-times, depend on the marker signal fre- quency (Table 5-3). Table 5-3: Morse coding for ILS marker beacons marker signals...
  • Page 149 ® Avionic Standards R&S SMA100B ILS Configuration and Settings Settings COM/ID State......................147 Code..........................147 Period..........................147 Frequency........................147 Depth...........................147 Time Schema......................147 Length........................148 Dash Length........................148 Symbol Space ......................148 Letter Space .......................148 COM/ID State Enables/disables the COM/ID signal. See also Chapter D, "Morse Code Settings",...

  • Page 150: Adf Configuration And Settings

    ® Avionic Standards R&S SMA100B ADF Configuration and Settings The set dot length determines the length of the dash, the symbol space and letter space of the Morse code. ● "User" You can set each length value separately. Remote command: on page 572 [:SOURce<hw>][:ILS]:MBEacon:COMid:TSCHema...

  • Page 151: General Settings

    Change the carrier frequency to a value within the specified frequency range. Changing a parameter in the avionic standards causes an instant signal change in the R&S SMA100B. There is no extra measurement cycle to calculate the RMS value of the baseband signal to set the correct RF level.
  • Page 152 ® Avionic Standards R&S SMA100B ADF Configuration and Settings Settings State..........................150 Set To Default......................150 Save/Recall......................... 150 State Activates the avionic standard. Activation of the standard deactivates a previously active avionic standard. The "VOR/ILS > Carrier Frequency" setting is applied automatically to the "RF >...

  • Page 153: Com/Id Settings

    ® Avionic Standards R&S SMA100B ADF Configuration and Settings 5.5.2 COM/ID Settings Access: ► Select "ADF > COM/ID". This dialog comprises COM/ID signal settings related to the ADF signal. Settings COM/ID State......................151 Code..........................151 Period..........................152 Frequency........................152 Depth...........................152 Time Schema......................152 Length........................152...
  • Page 154 ® Avionic Standards R&S SMA100B ADF Configuration and Settings If no coding is set, the COM/ID tone is sent uncoded (key down). If no coding is set, the COM/ID tone is sent uncoded (key down). Remote command: on page 548 [:SOURce<hw>]:ADF:COMid:CODE...
  • Page 155 ® Avionic Standards R&S SMA100B ADF Configuration and Settings Sets the length of the Morse code symbol space. Remote command: on page 551 [:SOURce<hw>]:ADF:COMid:SYMBol Letter Space Requires "Time Schema > User". Sets the length of a Morse code letter space.

  • Page 156: List And Sweep Mode

    A signal generated with varying parameters scans a certain range of varying values of a parameter, with defined start and end points, and can be repeated cyclically. The R&S SMA100B supports two basic methods: ● Sweep mode The instrument generates an RF signal which varies its frequency or level values in discrete steps between the start and end values.
  • Page 157 ® List and Sweep Mode R&S SMA100B Figure 6-2: Schematic representation of a signal generated in list mode (global dwell time) The list mode is especially useful in high-speed measurements with fast changing frequency and level settings. Note that the shown diagrams represent the behaviour in theory. In real signal genera- tion, the instruments usually have a blank time when the frequency or level changes.

  • Page 158: Signal Generation And Triggering In The Sweep And List Modes

    If the dwell time in sweep or list mode is too short or external trigger signals come too fast, the signal generation delays. As the delay increases, the R&S SMA100B signals an overrun, or even stops sweep or list mode signal generation, if the delay gets too long.
  • Page 159 ® List and Sweep Mode R&S SMA100B Signal Generation and Triggering in the Sweep and List Modes Auto mode (Sweep/List) Figure 6-3: Auto mode (Sweep/List) ● The instrument generates the signal continuously. ● Trigger mode "Auto" is prerequisite (default). It causes the continuous generation of the sweep signal.
  • Page 160 ® List and Sweep Mode R&S SMA100B Signal Generation and Triggering in the Sweep and List Modes Single / Extern Single mode (Sweep/List) Figure 6-4: Single / Extern Single mode (sweep / list ) In single mode, you can specify, that the signal returns to the start value when a sweep cycle has been completed.
  • Page 161 ® List and Sweep Mode R&S SMA100B Signal Generation and Triggering in the Sweep and List Modes Table 6-2: Cross-reference between manual and remote control in Single / Extern Single modes (Sweep/List) Manual control mode: Remote commands "Single / Extern Single"...
  • Page 162 ® List and Sweep Mode R&S SMA100B Signal Generation and Triggering in the Sweep and List Modes ● Trigger sources: – The rotary knob at the front panel. – The [Arrow] keys at the front panel. – The corresponding remote control commands.
  • Page 163 ® List and Sweep Mode R&S SMA100B Signal Generation and Triggering in the Sweep and List Modes Extern Start/Stop mode (sweep) Figure 6-6: Extern Start/Stop mode (sweep) ● The instrument generates the signal continuously. ● Trigger mode "Auto" and "Sweep > State = On" are prerequisite.
  • Page 164 ® List and Sweep Mode R&S SMA100B Signal Generation and Triggering in the Sweep and List Modes Manual mode (Sweep/List) The manual mode only applies to remote control. It is not visible in the graphical user interface of the instrument and is described here for completeness.

  • Page 165: About Sweep Mode

    ® List and Sweep Mode R&S SMA100B About Sweep Mode The Retrace function Retrace is a function especially designed for "Single" sweep modes, when the sweep signal follows a sawtooth shape. Working in this mode, the instrument performs a sin- gle sweep cycle when a trigger event occurs.

  • Page 166: Correlating Parameters In Sweep Mode

    About Sweep Mode Configuration and operation of sweep mode signals ● The R&S SMA100B generates a sweep signal by varying one of the following parameters: the RF frequency, the LF frequency or the RF level. ● In all sweep modes, you can perform a complete sweep cycle once, repeat the cycle continuously or step through it gradually.
  • Page 167 ® List and Sweep Mode R&S SMA100B About Sweep Mode Sweep range The sweep range is defined by a start and an end value. How the remaining parame- ters correlate is shown below. Offset = 0 Sweep Range = f...

  • Page 168: Sweep Signal Shapes

    STARt STOP retained. 6.2.2 Sweep Signal Shapes The R&S SMA100B supports the following sweep shapes: ● Sawtooth The sweep sequence resembles a sawtooth. One sweep runs from start to stop frequency, or level value respectively. Each subsequent sweep starts again at the start value.

  • Page 169: About List Mode

    ® List and Sweep Mode R&S SMA100B About List Mode Figure 6-9: Sweep signal triangle shape 1 = Start value 2 = Stop value 3 = Step size The current frequency or level of an RF frequency, level or LF frequency sweep is determined by the shape (e.g.

  • Page 170: Significant Parameters And Functions

    ® List and Sweep Mode R&S SMA100B Significant Parameters and Functions ● Externally Create a list file as a CSV file with Microsoft Excel, with a Notepad or a similar tool and save it with the predefined extension. Transfer the file to and load it into the instrument.

  • Page 171: Sweep Mode Settings

    Temporary blanking applies to all operating modes. Live list processing mode The R&S SMA100B generates the signal directly from the value pairs in the database, and adjusts the hardware settings accordingly. The current instrument state and thus any change during the signal generation directly affects the RF signal. The temporary memory is not used.

  • Page 172: General Sweep Settings

    ® List and Sweep Mode R&S SMA100B Sweep Mode Settings Access: 1. Select "Sweep" > "RF Frequency Sweep" 2. Select "Sweep" > "RF Level Sweep" 3. Select "Sweep" > "LF Frequency Sweep" The remote commands required to define these settings are described in: ●...
  • Page 173 ® List and Sweep Mode R&S SMA100B Sweep Mode Settings Settings Sweep Type ....................... 171 State (RF frequency sweep)..................171 State (RF level sweep)....................171 State (LF frequency sweep)..................171 Current Frequency...................... 172 Current Level.......................172 Mode........................... 172 Retrace........................173 Shape..........................173 Spacing........................174 Sweep Time .......................
  • Page 174 ® List and Sweep Mode R&S SMA100B Sweep Mode Settings Remote command: on page 603 [:SOURce<hw>]:LFOutput:FREQuency:MODE Current Frequency In "RF/LF Frequency Sweep" mode, displays the current frequency. Mode = "Step", the parameter is editable and you can enter the next frequency step.
  • Page 175 ® List and Sweep Mode R&S SMA100B Sweep Mode Settings Retrace For "Shape = Sawtooth" and "Mode = Single/External Single", enables changing the signal to the start value while it is waiting for the next trigger event. It returns to the start level or start frequency until the next trigger is applied.
  • Page 176 ® List and Sweep Mode R&S SMA100B Sweep Mode Settings "Triangle" The sweep runs from start to stop value and back, i.e. the shape of the sweep resembles a triangle. Each subsequent sweep starts at the start frequency. The triangle shape is only available for Sweep Type >...

  • Page 177: Frequency Range Settings

    Note: The minimum dwell time varies, depending on the phase noise options (Option: R&S SMAB-B709, R&S SMAB-B710/-B710N or R&S SMAB-B711/-B711N) the instru- ment is equipped with. See the data sheet for the specifications. In case of considerable overrun conditions, the R&S SMA100B turns off the sweep mode. See also Chapter 6.4, "Significant Parameters and...
  • Page 178 ® List and Sweep Mode R&S SMA100B Sweep Mode Settings Settings Start Frequency/Stop Frequency ................176 Center Frequency ...................... 176 Span..........................176 Spacing........................176 Step Linear/Step Logarithmic ..................177 Start Frequency/Stop Frequency Defines the frequency sweep range by setting the start and end values.

  • Page 179: Level Range Settings

    ® List and Sweep Mode R&S SMA100B Sweep Mode Settings "Linear" Takes the frequency value entered as absolute value in Hz. "Logarithmic" Takes the value entered as a logarithmic value, i.e. as a constant fraction of the current frequency in %.
  • Page 180 ® List and Sweep Mode R&S SMA100B Sweep Mode Settings Settings Start Level / Stop Level ....................178 Spacing........................178 Step ..........................178 Setting Characteristics ....................178 Start Level / Stop Level Defines the RF level sweep range by setting the start and end values.

  • Page 181: Output Settings

    ® List and Sweep Mode R&S SMA100B Sweep Mode Settings "Strictly Monotone" Executes signal level changes monotonically increasing or decreas- ing. The setting makes sure that increasing the level value exclusively results in an increased output level, and vice versa.

  • Page 182: Edit Marker Settings

    ® List and Sweep Mode R&S SMA100B Sweep Mode Settings The R&S SMA100B supplies the signal at the V/GHz X-Axis connector. "0,25 V/GHz" / Supplies the voltage proportional to the set frequency, derived from "0,5 V/GHz" / the selected setting.
  • Page 183 You can define up to 10 markers, and assign one of them to the output at a time. When the sweep run has reached the marker frequency, the R&S SMA100B acti- vates the marker signal and supplis it at the Marker User1 connector. The duration of the active signal corresponds to the dwell time of a step.

  • Page 184: List Mode Settings

    ® List and Sweep Mode R&S SMA100B List Mode Settings Marker Polarity Sets the polarity of the marker signal. The duration of the active signal is equal to the dwell time of a step. Remote command: on page 652 [:SOURce<hw>]:SWEep:MARKer:OUTPut:POLarity...

  • Page 185: General Settings

    ® List and Sweep Mode R&S SMA100B List Mode Settings 6.6.1 General Settings Access: ► Select "Sweep" > "List mode". In the "General" tab, you can configure the trigger and dwell time modes for list processing and activate signal generation.
  • Page 186 615 [:SOURce<hw>]:LIST:DWELl:MODE Global Dwell Time Sets the dwell time for Dwell Time Mode > "Global". Note: In case of considerable overrun conditions, the R&S SMA100B turns off the list mode. See also "Dwell time" on page 168. Remote command: on page 615 [:SOURce<hw>]:LIST:DWELl...

  • Page 187: List Mode Data Settings

    ® List and Sweep Mode R&S SMA100B List Mode Settings "Negative" The falling edge of the trigger signal triggers the instrument. Remote command: on page 599 [:SOURce]:INPut:TRIGger:SLOPe Reset Resets the list to the starting point. Remote command: on page 622 [:SOURce<hw>]:LIST:RESet...

  • Page 188: Import/Export Settings

    ® List and Sweep Mode R&S SMA100B List Mode Settings Edit List Mode Data Opens the editor to insert and save data lists with RF frequency, power and dwell time values, see Chapter 6.7, "List Editor", on page 188. You find this function also in standard file select dialog, accessed via...
  • Page 189 ® List and Sweep Mode R&S SMA100B List Mode Settings Settings Mode .......................... 187 ASCII File Settings...................... 187 Select (ASCII) Source/Select (ASCII) Destination............187 Select Source/Select ASCII Destination..............188 Import / Export......................188 Mode Selects import or export of a data list file. The provided parameters vary according to the selected mode.

  • Page 190: List Editor

    ® List and Sweep Mode R&S SMA100B List Editor Remote command: on page 623 [:SOURce<hw>]:LIST:DEXChange:AFILe:CATalog? on page 623 [:SOURce<hw>]:LIST:DEXChange:AFILe:SELect on page 588 [:SOURce<hw>]:CORRection:DEXChange:AFILe:CATalog? on page 589 [:SOURce<hw>]:CORRection:DEXChange:AFILe:SELect on page 539 [:SOURce<hw>]:PULM:TRAin:DEXChange:AFILe:CATalog? on page 539 [:SOURce<hw>]:PULM:TRAin:DEXChange:AFILe:SELect Select Source/Select ASCII Destination In "Mode > Export", access the file select dialog that provides standard file handling functions.
  • Page 191 ® List and Sweep Mode R&S SMA100B List Editor Access to "Edit List Mode Data": ► "Sweep" > "List Mode" > "List Mode Data" > "Edit List Mode Data" The editor for list mode data provides a table with RF frequency and power values and standard navigation functions.
  • Page 192 ® List and Sweep Mode R&S SMA100B List Editor All columns in a row must contain values. Cells with missing values are therefore filled automatically, using the value of the previous row. If you use global dwell time in list mode, consider also that the instrument uses the...
  • Page 193 ® List and Sweep Mode R&S SMA100B List Editor Edit ← Data handling keys Enables you to insert, or delete a row or ranges within a list, and provides access to a dialog for automatic filling, see " Fill... "...

  • Page 194: How To Generate A Signal In List Or Sweep Mode

    ® List and Sweep Mode R&S SMA100B How to Generate a Signal in List or Sweep Mode 6.8 How to Generate a Signal in List or Sweep Mode This section shows you how to configure a varying RF output signal for both, the list and sweep modes.
  • Page 195 ® List and Sweep Mode R&S SMA100B How to Generate a Signal in List or Sweep Mode To configure the list mode and start signal generation 1. In the "General" tab, select "List Mode > Auto". 2. Select "Dwell Time Mode > From List".

  • Page 196: Improving Level Performance

    R&S SMA100B Attenuator 7 Improving Level Performance To adapt the RF output signal to specific needs in your application, the R&S SMA100B offers different functions: ● Attenuator The R&S SMA100B is equipped with a step attenuator that enables you to vary the amplitude of the RF signal in a wide range.

  • Page 197: Attenuator Settings

    ® Improving Level Performance R&S SMA100B Attenuator ● Uninterrupted level settings with constant VSWR A fix attenuation value is required for obtaining uninterrupted level settings with constant VSWR. The configuration "RF Off Mode > Unchanged" ensures that constant VSWR is maintained if you turn the signal off and on again.

  • Page 198: Reverse Power Protection

    The RF input is activated when the overload protection is reset. Remote command: on page 448 :OUTPut<hw>:PROTection:TRIPped? on page 447 :OUTPut<hw>:PROTection:CLEar 7.2 Automatic Level Control (ALC) The R&S SMA100B is equipped with an automatic level control (ALC) unit to obtain best RF level accuracy. User Manual 1178.3834.02 ─ 05...
  • Page 199 If pulse modulation is applied, this mode ensures fast level setting even with nar- row pulses at low repetition rate. The R&S SMA100B displays the level control setting as a status message in the info line. User Manual 1178.3834.02 ─ 05...

  • Page 200: Alc Settings

    ® Improving Level Performance R&S SMA100B Automatic Level Control (ALC) 7.2.1 ALC Settings Access: ► Select "Level" > "Automatic Level Control". In the "ALC" dialog, you can configure the settings for the automatic level control of the RF signal to achieve optimal accuracy.

  • Page 201: User Correction

    RF cable, to achieve a precise target input level at the DUT. The signal at the RF outputs of the R&S SMA100B is flat. However, the DUT is usually not connected directly to the outputs of the instrument but rather via connecting cables.
  • Page 202 = Obtain the correction data by inverting the collected data; load the correction parameters in the R&S SMA100B = In the R&S SMA100B, the RF signal is pre-processed with the correction values so that the signal at the outputs is the inverted version of the external losses...

  • Page 203: User Correction Settings

    ® Improving Level Performance R&S SMA100B User Correction UCOR file format Files containing correction data are simple files in text or comma-separated value (CSV) file format. The filename is user-definable; the file extension is *.ucor. The file contains a list of correction values, one row per frequency and correction value pair;...
  • Page 204 Data......................... 203 Edit UCOR Data......................203 State Activates user correction. The R&S SMA100B displays the status icon "Lev Ucor" in the "Level" panel. Remote command: on page 587 [:SOURce<hw>]:CORRection[:STATe] User Correction Indicates the corrected level value for a specific frequency point.

  • Page 205: List Editor

    ® Improving Level Performance R&S SMA100B User Correction Remote command: on page 586 [:SOURce<hw>]:CORRection:VALue? UCOR Data Accesses the standard "File Select" function of the instrument. The provided navigation possibilities in the dialog are self-explanatory. Files with user correction values are files with predefined file extension *.uco. When a file is selected, the dialog indicates the filename.
  • Page 206 ® Improving Level Performance R&S SMA100B User Correction Access to "Edit List Mode Data": ► "Sweep" > "List Mode" > "List Mode Data" > "Edit List Mode Data" The editor for list mode data provides a table with RF frequency and power values and standard navigation functions.
  • Page 207 ® Improving Level Performance R&S SMA100B User Correction All columns in a row must contain values. Cells with missing values are therefore filled automatically, using the value of the previous row. If you use global dwell time in list mode, consider also that the instrument uses the...
  • Page 208 ® Improving Level Performance R&S SMA100B User Correction Edit ← Data handling keys Enables you to insert, or delete a row or ranges within a list, and provides access to a dialog for automatic filling, see " Fill... " on page 92.

  • Page 209: Fill With Sensor

    ® Improving Level Performance R&S SMA100B User Correction 7.3.3 Fill with Sensor Access: 1. Select "Level" > "User Correction". 2. Select "UCOR Data > navigate to the file *.ucor > Select". 3. Select "Edit UCOR Data > Fill With Sensor...".

  • Page 210: Import/Export List Files

    ® Improving Level Performance R&S SMA100B User Correction When unchecked, the zeroing procedure is skipped. However, the RF signal level might be blanked shortly. This setting is useful if blanking of RF is undesirable or the absence of power at the sensor cannot be guaranteed.
  • Page 211 ® Improving Level Performance R&S SMA100B User Correction 2. Select "Import/Export". Figure 7-3: Im-/Export dialog (example with UCOR settings) The "Import/Export" dialog contains all functions and settings to import externally created list data or to export it accordingly. You can process and store a list in the formats *.txt (ASCII), or *.csv (plain text with identical sequence of fields).
  • Page 212 ® Improving Level Performance R&S SMA100B User Correction "Column Separator" Sets the separator between the columns in an ASCII table. Available are: "Tab", "Semicolon", "Comma" or "Space". Remote command: on page 623 [:SOURce<hw>]:LIST:DEXChange:AFILe:EXTension on page 624 [:SOURce<hw>]:LIST:DEXChange:AFILe:SEParator:DECimal on page 624 [:SOURce<hw>]:LIST:DEXChange:AFILe:SEParator:COLumn...

  • Page 213: Using Power Sensors

    S-parameter correction and return the measurement results to the generator. The R&S SMA100B works with any sensor of the R&S NRP series and can perform up to four power measurements simultaneously.

  • Page 214: Nrp Sensor Mapping

    On connection, the R&S SMA100B immediately starts the measurement of a detected R&S NRP power sensor. If you perform an instrument preset ([Preset] key or *RST), the R&S SMA100B stops the measurements. The connection and the mapping of the power sensors remain, the measurements must be restarted.
  • Page 215 USB interfaces, is detected automatically and added to the list. Vice versa, the R&S SMA100B removes a sensor from the list, when it is disconnected. R&S NRP sensors that are connected via LAN or use the USBTMC protocol are not automatically detected.

  • Page 216: Nrp Power Viewer

    Remote command: on page 501 :SLISt:SCAN[:STATe] 7.4.3 NRP Power Viewer The R&S SMA100B features the power viewer function for measuring or monitoring signals with R&S NRP power sensors. 7.4.3.1 About The R&S SMA100B can perform up to four power measurements simultaneously.
  • Page 217 ® Improving Level Performance R&S SMA100B Using Power Sensors Depending on the R&S NRP power sensor type, the manual setting of the filter length varies in resolution: ● Resolution = 1 for the R&S NRPxx power sensor family ● Resolution = 2 for R&S NRP-Zxx power sensors, with n = 1 to 16...

  • Page 218: Nrp Power Viewer Settings

    ® Improving Level Performance R&S SMA100B Using Power Sensors Related settings and functions ● Measurements-related settings, like results, filter, filter length: Chapter 7.4.3.2, "NRP Power Viewer Settings", on page 216 ● Software version of the connected power sensor: on page 510 :SENSe<ch>[:POWer]:TYPE?
  • Page 219 ® Improving Level Performance R&S SMA100B Using Power Sensors The "Overview" tab shows the list of detected sensors, and provides a separate tab per sensor. A sensor tab contains all parameters for configuring the sensor settings, like aver- age or peak display, reference source, filter and level offset.
  • Page 220 ® Improving Level Performance R&S SMA100B Using Power Sensors └ Aperture Time....................221 └ S-Parameter ....................221 └ Enable Logging..................... 221 Sensor type and serial number Indicates the type and the serial number of a selected R&S NRP power sensor, and the channel the sensor is assigned to.
  • Page 221 If you have a frequency converting device between the generator and the DUT. If the frequency converter doubles the frequency, you can set twice the frequency in the R&S SMA100B. The R&S power sen- sor considers this RF frequency setting.
  • Page 222 ® Improving Level Performance R&S SMA100B Using Power Sensors "Auto" Selects the filter length automatically and adjusts it to the measured value. The value is indicated with the parameter Filter Length. When high output power is applied, the filter length and therefore the measurement time can be short.
  • Page 223 ® Improving Level Performance R&S SMA100B Using Power Sensors Default Aperture Time ← Sensor settings The sensor default setting is sufficient. Disable this parameter to specify a user-defined aperture time per sensor, if, for example, the readings vary. To obtain stable readings, set the Aperture Time exactly to one modulation period.

  • Page 224: Nrp Power Analysis

    Using Power Sensors 7.4.4 NRP Power Analysis With a connected R&S NRP power sensor, the R&S SMA100B enables the analysis of power measurements of DUTs. You can analyze the measured power under frequency, power and time aspects, while the instrument supports you with marker, graphic and reference value functions.

  • Page 225: Accessing The Nrp Power Analysis Functionality

    ® Improving Level Performance R&S SMA100B Using Power Sensors 7.4.4.2 Accessing the NRP Power Analysis Functionality Access: ► Select "Clk Syn/Power Sens" > "NRP Power Analysis". Figure 7-4: Power analysis window 1 = Buttons for accessing the "NRP Power Viewer" settings...
  • Page 226 ® Improving Level Performance R&S SMA100B Using Power Sensors Figure 7-5: Power analysis context-sensitive menu In the context-sensitive menu you can access: ● "Start Continuous/Stop (Power Analysis)": Triggers/stops the power analysis mea- surement ● "Next Window (Hardkey)": Switches between the measurement views that are enabled in the following order: –...

  • Page 227: Required Options

    Starts and stops the power analysis measurement. Depending on the selected mea- surement mode, the label varies. 7.4.4.3 Required Options The R&S SMA100B base unit equipped with the following options: ● Power Analysis (R&S SMAB-K28) Requires an external R&S NRP power sensor. For more information, see the data sheet.

  • Page 228: Nrp Power Analysis Settings

    ® Improving Level Performance R&S SMA100B Using Power Sensors 7. Press "Start Cont." to trigger the measurement. 7.4.4.5 NRP Power Analysis Settings Open the required dialog for configuring the NRP power analysis settings. 7.4.4.6 NRP Traces Settings Access: 1. Select "Clk Syn/Power Sens" > "NRP Power Analysis".

  • Page 229: Traces Settings

    2. Select "Save To Ref". 3. Select "Trace 1" and "Indication Ref.". 4. Select "Diagram". The R&S SMA100B indicates two identical traces. 5. Select "Start single". Triggers a new measurement cycle with sensor 2. You can compare the resulting measurement trace with the former measurement, which is displayed as reference trace.
  • Page 230 ® Improving Level Performance R&S SMA100B Using Power Sensors Save to Ref - Trace Power Analysis Saves the selected trace as reference trace. Only one reference trace is available at a time. Remote command: on page 489 :TRACe<ch>[:POWer]:SWEep:COLor Define Reference - Trace Power Analysis Opens a dialog for defining a linear reference curve.

  • Page 231: Markers Settings

    ® Improving Level Performance R&S SMA100B Using Power Sensors Determine T<ch> in the entry field next to "Tx", and then select T<ch> Operand1 Operand2 the second entry field right to it. The result ("T<ch> ") is assigned to the above selected "Trace". If switched on, the result graph shows the resulting curve.

  • Page 232: Configure Settings

    ® Improving Level Performance R&S SMA100B Using Power Sensors 3. Select the "Markers" tab. This dialog comprises the markers settings display on the respective trace dia- gram. Marker x Visible - Power Analysis Selects if the respective marker and the marker list are shown in the diagram.

  • Page 233: Configure Measurement

    Power versus power measurement (power sweep, AM/AM). "Time" Power versus time measurement (envelope power measurement as a function of time, NRP trace mode). The R&S SMA100B samples power over a time interval and assigns the internal power values that have been determined to several points.
  • Page 234 It is possible, that the measurement cannot be performed over the complete time range because of limitations due to sensor settings. In this case, the R&S SMA100B gener- ates an error message.
  • Page 235 ® Improving Level Performance R&S SMA100B Using Power Sensors Remote command: on page 467 :SENSe[:POWer]:SWEep:FREQuency:STEPs on page 480 :SENSe[:POWer]:SWEep:POWer:STEPs on page 485 :SENSe[:POWer]:SWEep:TIME:STEPs Timing - Power Analysis Selects the timing mode. This parameter is only available for Configure Measurement > "Frequency"/"Power".

  • Page 236: Configure Diagram

    ® Improving Level Performance R&S SMA100B Using Power Sensors "Logarithmic" Power versus frequency In a logarithmic sweep, the frequency is swept in equidistant steps on a logarithmic scale. The x-axis is a logarithmic frequency axis. Remote command: on page 467...
  • Page 237 ® Improving Level Performance R&S SMA100B Using Power Sensors The "Configure Diagram" covers the parameters for scaling the y-axis and the appear- ance of the diagram. Min - Max Level - Power Analysis Selects the minimum and maximum value of the y-axis.

  • Page 238: Configure Gate Mode

    ® Improving Level Performance R&S SMA100B Using Power Sensors "Float (Coarse/Fine)" Auto scale is activated, that means this parameter automatically selects the appropriate scaling of the y-axis so that the trace is always visible. The range is either expanded, when a value is out of the right/left end-of-scale value or it is reduced when the trace fits into a smaller scale area.
  • Page 239 ® Improving Level Performance R&S SMA100B Using Power Sensors Almost all R&S NRP sensors also support time gated measurements of peak and aver- age power (see the data sheet or operating manual of the respective sensor). Two user-configurable gates can be assigned to one of the traces. Both gates are active at the same time.

  • Page 240: Configure Sensors

    ® Improving Level Performance R&S SMA100B Using Power Sensors State - Gate Enables time gated measurement. The measurement is started with the "Start" button in the main measurement diagram. Both gates are active at one time. The gate borders and the measurement values (average and peak power) are indica- ted in/below the measurement diagram.
  • Page 241 ® Improving Level Performance R&S SMA100B Using Power Sensors The "Configure Sensors" dialog provides specific parameters for the power sensor. This part of the dialog can differ from the following description depending on the sensor used. Refer to the manual of the power sensor in this case.
  • Page 242 ® Improving Level Performance R&S SMA100B Using Power Sensors Remote command: :SENSe<ch>[:POWer]:SWEep:FREQuency[:SENSor]:OFFSet:STATe on page 457 on page 461 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:OFFSet:STATe on page 461 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:OFFSet:STATe Level Offset - Power Analysis Sets the level offset at the sensor input. To consider the value, activate the offset.

  • Page 243: Configure Pulse Data

    ® Improving Level Performance R&S SMA100B Using Power Sensors Remote command: :SENSe<ch>[:POWer]:SWEep:FREQuency[:SENSor]:SRANge:STARt on page 458 Max Frequency - Power Analysis This parameter is only available for Configure Measurement > "Frequency" and Separate Frequency- Power Analysis > "Active". Sets the maximum frequency of the measurement.
  • Page 244 Using Power Sensors The sensor calculates the pulse parameters from each measurement and delivers the results to the R&S SMA100B. The indication state of the parameters also affects the save function. Storing the mea- surement diagram as hardcopy includes the parameters selected in this dialog.
  • Page 245 ® Improving Level Performance R&S SMA100B Using Power Sensors State - Pulse Data Analysis Enables pulse data analysis. The measurement is started with the "Start Cont." button in the main measurement diagram. Remote command: on page 461 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:PULSe:STATe Base - Pulse Data Analysis Selects how the threshold parameters are calculated, either voltage related or power related.
  • Page 246 ® Improving Level Performance R&S SMA100B Using Power Sensors Distal - Pulse Data Analysis Sets the upper reference level in terms of percentage of the overall pulse level (power or voltage related). The distal power defines the end of the rising edge and the start of the falling edge of the pulse.
  • Page 247 ® Improving Level Performance R&S SMA100B Using Power Sensors Notifications - Pulse Data Analysis Selects the pulse parameters to be indicated below the measurement diagram. Duty Cycle ← Notifications - Pulse Data Analysis Indicates the ratio between the pulse duration (τ) and the pulse period (T) of the mea- sured pulse signal in per cent: User Manual 1178.3834.02 ─...
  • Page 248 ® Improving Level Performance R&S SMA100B Using Power Sensors Duty Cycle = (pulse duration / pulse period) * 100 Remote command: on page 492 :TRACe<ch>[:POWer]:SWEep:MEASurement:PULSe:DCYCle? :TRACe<ch>[:POWer]:SWEep:MEASurement:PULSe:DCYCle:DISPlay: on page 493 ANNotation[:STATe] Pulse Width ← Notifications - Pulse Data Analysis Indicates the pulse duration of the pulse data measurement in seconds.
  • Page 249 ® Improving Level Performance R&S SMA100B Using Power Sensors Pulse Start Time / Pulse Stop Time ← Transition Times - Pulse Data Analysis Displays the time when the pulse signal crosses the medial reference level. Remote command: :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:NEGative: on page 492 OCCurrence? :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:NEGative:...

  • Page 250: Configure Trigger

    ® Improving Level Performance R&S SMA100B Using Power Sensors Pulse Power - Pulse Data Analysis Selects which pulse power parameters are indicated in the diagram (pulse data view only). Top / Base Power ← Pulse Power - Pulse Data Analysis Indicate the pulse top and base level of the analyzed signal in dBm.
  • Page 251 ® Improving Level Performance R&S SMA100B Using Power Sensors Power Sensor - Power Analysis Selects the power sensor to be set if more than one sensor is connected to the instru- ment. Remote command: n.a. In remote control the sensor is selected via the numeric suffix in the sense key word of the command, for example SENSe2:POWer:SWEep:….

  • Page 252: Next Window List

    ® Improving Level Performance R&S SMA100B Using Power Sensors Remote command: :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:TRIGger:HYSTeresis on page 464 Drop out Time - Power Analysis Determines the minimum time for which the signal must be below (above) the power level defined by Level - Power Analysis...
  • Page 253 ® Improving Level Performance R&S SMA100B Using Power Sensors The "Next Window List" dialog provides functions to activate only the required "Views" on the checkboxes to the right. Standard View Shows the graph and the button bar at the left for frequency power and level sweep measurement.
  • Page 254 ® Improving Level Performance R&S SMA100B Using Power Sensors Remote command: :TRACe[:POWer]:SWEep:MEASurement:STANdard:DISPlay:ANNotation[: on page 497 STATe] Marker View Shows the graph and the corresponding marker values at the bottom for frequency power and level sweep measurement. Up to four markers can be used to display the current power according to the position of the marker.
  • Page 255 ® Improving Level Performance R&S SMA100B Using Power Sensors Remote command: :TRACe[:POWer]:SWEep:MEASurement:PULSe:DISPlay:ANNotation[: on page 497 STATe] Full Screen Shows the graph in fullscreen, and fades out buttons and list values for frequency power and level sweep measurement. User Manual 1178.3834.02 ─ 05...

  • Page 256: Creating Screenshots Of Power Analysis Settings

    ® Improving Level Performance R&S SMA100B Using Power Sensors Remote command: :TRACe[:POWer]:SWEep:MEASurement:FULLscreen:DISPlay:ANNotation[: on page 496 STATe] 7.4.4.8 Creating Screenshots of Power Analysis Settings The power analysis save function enables you to save current settings in a file. To document the most important settings for a performed signal generation, you can also save a hardcopy of the current display.
  • Page 257 ® Improving Level Performance R&S SMA100B Using Power Sensors Remote command: on page 478 :SENSe[:POWer]:SWEep:HCOPy[:EXECute] on page 473 :SENSe[:POWer]:SWEep:HCOPy:FILE[:NAME] on page 475 :SENSe[:POWer]:SWEep:HCOPy:FILE[:NAME]:AUTO:STATe on page 474 :SENSe[:POWer]:SWEep:HCOPy:FILE[:NAME]:AUTO:FILE? Format - Power Analysis Selects the file format. Several bitmap graphic formats are offered. In addition, format *.csv is available which stores the measurement values as ASCII data.
  • Page 258 ® Improving Level Performance R&S SMA100B Using Power Sensors Format - Power Analysis Selects the file format. Several bitmap graphic formats are offered. In addition, format *.csv is available which stores the measurement values as ASCII data. You can refine the csv settings further, see "CSV Options"...
  • Page 259 ® Improving Level Performance R&S SMA100B Using Power Sensors Clear Parth Deletes all image files with extensions "bmp", "img", "png", "xpm" and "csv" in the directory set for automatic naming. Remote command: :SENSe[:POWer]:SWEep:HCOPy:FILE[:NAME]:AUTO:DIRectory:CLEar on page 474 Prefix, Year, Month, Day, Instrument Name A selection of the prefix, year, month, day and instrument name are included in the file name.
  • Page 260 ® Improving Level Performance R&S SMA100B Using Power Sensors 4. Set "Format" > "CSV". 5. Select "Options". 6. Select the "CSV Options" tab. If file format *.csv is selected, the trace data is saved as an ASCII file with separated values.
  • Page 261 ® Improving Level Performance R&S SMA100B Using Power Sensors Example: Trace1,X[Hz]: 10000.0; 10010.0; 10020.0; 10030.0; ... Trace1,Y[dBm]: -20.09; -19.17; -18.19; -15.43; ... Trace2,X[Hz]: 10000.0; 10010.0; 10020.0; 10030.0; ... Trace2,Y[dBm]: -19.09; -18.17; -17.19; -14.43; ... Trace3,X[Hz]: 10000.0; 10010.0; 10020.0; 10030.0; ...

  • Page 262: How To Save A Hardcopy Of The Power Analysis Window

    ® Improving Level Performance R&S SMA100B Using Power Sensors Remote command: on page 472 :SENSe[:POWer]:SWEep:HCOPy:DEVice:LANGuage:CSV:HEADer How to Save a Hardcopy of the Power Analysis Window 1. Select "Clk Syn/Power Sens" > "NRP Power Analysis". 2. In the diagram window, open the context-sensitive menu.

  • Page 263: How To Setup A Frequency Sweep Measurement

    ® Improving Level Performance R&S SMA100B Using Power Sensors In the "Automatic Naming" tab: a) To change the default directory the file is saved in, select "Path" and define a path and a filename. For example, select the default directory /var/user.

  • Page 264: How To Setup A Power Sweep Measurement

    ® Improving Level Performance R&S SMA100B Using Power Sensors 3. Set "Mode" > "Frequency". 4. Configure the measurement: a) Set "Min = 8KHz". b) Set "Max = 6Ghz". c) Set "Steps = 200". 5. Select the "Configure Diagram" tab. Configure the diagram, see Chapter 7.4.4.12,...

  • Page 265: How To Setup A Pulse Measurement

    ® Improving Level Performance R&S SMA100B Using Power Sensors 10. Close the "Configure" dialog. 11. Press "Start Cont" to start the measurement. 7.4.4.11 How to Setup a Pulse Measurement Prerequisites: the sensor is connected to the instrument and configured, see Chap- ter 7.4, "Using Power...

  • Page 266: How To Configure The Power Analysis Diagram

    Power Sensor Using a R&S NRP power sensor and the user correction function of the instrument, you can compensate external frequency responses. The R&S SMA100B utilizes the readings of the power sensor and creates a correction value table for controlling the output level during operation.
  • Page 267 How to Calibrate the Power Level with an R&S NRP Power Sensor To configure and calibrate the R&S NRP in the R&S SMA100B Provided the power sensor is connected to the R&S SMA100B and is assigned to a sensor channel, we recommend that you calibrate and configure the power sensor in the "NRP Power Viewer"...
  • Page 268 The "Fill User Correction Data With Sensor" dialog provides an overview of the sensor configuration. 9. Select "Execute". The R&S SMA100B successively sets each frequency point, reads the measured power of the sensor and fills in the value in the correction table. User Manual 1178.3834.02 ─ 05...
  • Page 269 5. To view the file content, select "Edit UCOR Data". 6. Select "UCOR Data > State > On" to apply the user correction values. When you activate the RF output, the R&S SMA100B considers the user correction data and adjusts the signal level accordingly to compensate external frequency responses.

  • Page 270: Reference Oscillator

    Using the Reference Frequency for Instruments Synchronization 8 Reference Oscillator The R&S SMA100B is equipped with an internal reference oscillator that generates a reference frequency of 10 MHz. It is used as internal reference source for the synthe- sizer. Alternatively, you can apply an external reference signal. If equipped with the required options, the R&S SMA100B can process external reference frequency in the...
  • Page 271 External Tuning Slope = "Low" Figure 8-1: Synchronizing instruments using the internal 10 MHz reference signal of the R&S SMA100B = External frequency control EFC,Ref In,Ref Out = Connectors In phase noise measurement systems, for example, you can also use the EFC (exter- nal frequency control) function and shift the frequency.
  • Page 272 ® Reference Oscillator R&S SMA100B Using the Reference Frequency for Instruments Synchronization If the EFC is applied in combination with an external PLL (phase locked loop), the PLL bandwidth must be smaller than the bandwidth of the external tuning signal.

  • Page 273: Reference Frequency Settings

    ® Reference Oscillator R&S SMA100B Reference Frequency Settings ● Variable Reference Frequency = "Variable" ● External Reference Frequency = current external frequency ● Reference Output = "Input Signal (loop through)" or specify the reference fre- quency the synchronized instrument supports ●...
  • Page 274 ® Reference Oscillator R&S SMA100B Reference Frequency Settings In the "Reference Frequency" tab, you can select the signal source of the reference frequency and define the frequency of an external reference signal. 2. Observe the information on the home screen, "Frequency" tile.
  • Page 275 Uses an external reference signal. The frequency of the external reference signal must be set with the parameter "External Reference Frequency". Note: If the external reference is missing, the R&S SMA100B issues a warning message and indicates the icon (external reference missing).
  • Page 276 ® Reference Oscillator R&S SMA100B Reference Frequency Settings "10 MHz, 100 MHz, 1GHz" Selects the external reference frequency. Remote command: on page 640 [:SOURce]:ROSCillator:EXTernal:FREQuency Variable Reference Frequency Option: R&S SMAB-K704 Sets the variably settable external reference frequency. Remote command: on page 640...

  • Page 277: Reference Output Settings

    ® Reference Oscillator R&S SMA100B Reference Output Settings EFC is a function that transforms an external tuning voltage into frequency shift, where the value range of the resulting frequency is a technical characteristic listed in the data sheet. See the data sheet also for information on the sensitivity, input voltage range, impe- dance and maximum bandwidth for external tuning signal.

  • Page 278: Adjustment Settings

    ® Reference Oscillator R&S SMA100B Adjustment Settings "1 GHz" Outputs a 1 GHz signal. "Input Signal (loop through)" Forwards the external reference frequency to the output directly. Remote command: on page 641 [:SOURce]:ROSCillator:OUTPut:FREQuency:MODE on page 642 [:SOURce]:ROSCillator:OUTPut:ALTernate:FREQuency:MODE Show Connector Accesses a dialog that displays the physical location of the selected connector on the front/rear panel of the instrument.
  • Page 279 ® Reference Oscillator R&S SMA100B Adjustment Settings Remote command: on page 642 [:SOURce]:ROSCillator[:INTernal]:ADJust:VALue User Manual 1178.3834.02 ─ 05...

  • Page 280: Clock Synthesis

    ® Clock Synthesis R&S SMA100B 9 Clock Synthesis The clock synthesis provides a separate system clock with a freely selectable fre- quency for test setups that require an additional clock reference. For example, in a test setup that uses an A/D converter, the required system clock for data sampling can be provided without the need of additional signal generator.
  • Page 281 ® Clock Synthesis R&S SMA100B 3. Observe the information on the home screen, "Clk Syn/Power Sens" tile. The "Clk Syn/Power Sens" tile indicates that clock synthesis is activated and gives an overview of the key parameters. Settings State ...........................279 Output Type.........................279...
  • Page 282 ® Clock Synthesis R&S SMA100B "Single-Ended/Differential Sine" Sine signals with user-definable amplitude. "Differential Square" Squared signal with fixed amplitude. "CMOS" CMOS-like signal with user-definable amplitude and limited frequency range. Remote command: on page 426 :CSYNthesis:OTYPe Frequency Sets the frequency of the generated clock signal.
  • Page 283 ® Clock Synthesis R&S SMA100B Remote command: on page 427 :CSYNthesis:OFFSet:STATe DC Offset Sets the value of the DC offset for both clock synthesis signal outputs. Remote command: on page 427 :CSYNthesis:OFFSet Voltage Output Type = "CMOS", sets the high-level of the output signal.

  • Page 284: File And Data Management

    About the File System 10 File and Data Management The R&S SMA100B uses files to save all instrument data. The instrument allows you to store and to load instrument settings, and to import and to export user data for pro- cessing in another instrument or later.

  • Page 285: Manager

    The /var/volatile directory serves as a RAM drive and can be used to protect sensitive information. The data is available temporarily. If option R&S SMAB-B85 is installed, the R&S SMA100B maps the user directory to the removable memory. If a memory is mounted, user data is saved there. Otherwise user data is redirected to the volatile memory.

  • Page 286: File Handling

    They are reserved by the operating system. File extensions The R&S SMA100B distinguishes the files according to their extensions; each type of file is assigned a specific file content and also a specific file extension. The extension is usually of no consequence to you since access to the files occurs in the individual dialogs where only the relevant type of file is available.

  • Page 287: Restoring The (Default) Instrument Configuration

    The R&S SMA100B has various options to set default settings, see Figure 10-1. You can preset the R&S SMA100B to an initial state at any time as a known starting point for configurations. It is often useful as a first step in troubleshooting when unusual results arise.
  • Page 288 ® File and Data Management R&S SMA100B Restoring the (Default) Instrument Configuration Overview of the characteristics of the preset functions Select the preset option that most fits to your particular application: ● [Preset] It is the most frequently used function.

  • Page 289: Preset, Set To Default And Factory Preset Settings

    294) Mark / Do not mark parameters changed from preset To survey the current state of the settings concerning default values, the R&S SMA100B offers a feature that visually identifies deviations from the default val- ues. For more information, see Chapter 10.2.2, "How to Identify Parameters Which Are Not...

  • Page 290: How To Identify Parameters Which Are Not In A Preset State

    To activate this display: 1. Open the context-sensitive menu (touch and hold the screen anywhere in the GUI of the R&S SMA100B). 2. Select "Mark all parameters changed from preset". If enabled, the corresponding settings are marked. Example:...

  • Page 291: Reference

    ® File and Data Management R&S SMA100B Restoring the (Default) Instrument Configuration 2. Save the settings as a file with the predefined filename UserPreset.savrcltxt. Save this file in the directory /var/user/. The filename UserPreset.savrcltxt and the directory /var/user/ are man- datory.

  • Page 292: Protecting Data

    Security settings are never reset. Resets all parameters and switching states, and closes all opened dialogs. 10.3 Protecting Data During operation, the R&S SMA100B saves user data permanently in the user direc- tory, see "File storage location" on page 283.

  • Page 293: Saving And Recalling Instrument Settings

    Or, in a test setup with more than one signal gen- erator, you want to transfer the used settings to another R&S SMA100B. In these cases, you can save and recall instrument and user settings, and possibly other related data.
  • Page 294 ® File and Data Management R&S SMA100B Saving and Recalling Instrument Settings 2. Select "Operation Mode > Save or Recall" to access the corresponding settings. The provided settings for both operations are similar and closely related. Settings: Operation Mode......................292 Directory, File List and Filename.................
  • Page 295 587 [:SOURce]:CORRection:CSET:CATalog? Recent files Displays the files last used. Show SCPI List Opens the "SCPI List", which lists the current settings of the R&S SMA100B as SCPI commands. The R&S SMA100B provides this function for Operation Mode > SCPI-Export.

  • Page 296: How To Save And Recall Instrument Settings

    ® File and Data Management R&S SMA100B Saving and Recalling Instrument Settings Remote command: on page 593 [:SOURce<hw>]:FREQuency[:CW|FIXed]:RCL Exclude Level The current level is retained when a stored instrument setting is loaded. Remote command: on page 635 [:SOURce<hw>]:POWer[:LEVel][:IMMediate]:RCL Recall Restores the selected configuration.

  • Page 297: Accessing Files With User Data

    ® File and Data Management R&S SMA100B Accessing Files with User Data 5. Select "Recall Immediate 1" The instrument is restored to the previous state. 6. Select "Recall Immediate 2" to switch to the settings stored in the second file.
  • Page 298 ® File and Data Management R&S SMA100B Accessing Files with User Data Tip: The name of the dialog is context-sensitive and differs depending on the par- ticular function this dialog is from. However, the provided functions are similar. 2. To load an existing file: Navigate through the file system.

  • Page 299: Exporting Remote Command Lists

    ® File and Data Management R&S SMA100B Exporting Remote Command Lists You access this generic standard function each time you perform one of the following: ● Save or load (settings) files ● Define a folder in that these files are saved ●...

  • Page 300: Loading, Importing And Exporting Lists

    File and Data Management R&S SMA100B Using the File Manager The R&S SMA100B also offers an SCPI macro recorder with code generator that is used to record manual settings and create an executable script, see Chapter 12.14, "How to Record / Create SCPI Lists",...

  • Page 301: File Manager Settings

    The "File Manager" dialog provides all standard functions required for file manage- ment. It displays the contents of the selected folder on the R&S SMA100B and pro- vides functions to rename, delete, copy, or move individual files. 10.8.1 File Manager Settings Access: ►...

  • Page 302: Map Network Share Settings

    ® File and Data Management R&S SMA100B Using the File Manager Map Network Share Accesses the Map Network Share Settings dialog where you can map one or more network folders. See also Chapter 10.8.4, "How to Map a Network Folder", on page 302.
  • Page 303 ® File and Data Management R&S SMA100B Using the File Manager The "Map Network Share" dialog provides settings that are similar to the standard Win- dows Explorer function "Map network drive". These settings help you to create up to 10 "shortcuts"...

  • Page 304: How To Display All Saved Files

    2. Navigate to /var/volatile/. 10.8.4 How to Map a Network Folder Possibly you would like to transfer instrument or user settings to another R&S SMA100B, distribute waveform files to several instruments or you have to access User Manual 1178.3834.02 ─ 05...
  • Page 305 SMA100B Using the File Manager frequently the same network drive. In these cases, on a R&S SMA100B connected to a LAN you can create a shortcut to this network folder or this computer. For information on how to set up a LAN connection, refer to: ●...
  • Page 306 ® File and Data Management R&S SMA100B Using the File Manager 6. Close the "Map Network Share" dialog. The navigation tree in the "File Manager" dialog displays the mapped network folder as /shares/Setups. User Manual 1178.3834.02 ─ 05...

  • Page 307: How To Transfer Files From And To The Instrument

    Mainly because of security reasons, the access to the file system of your R&S SMA100B can be denied, because one or all these access methods are deliber- ately disabled. Access to the file system via LAN and/or USB requires that the corre- sponding service is enabled and a write access to the file system is enabled.
  • Page 308 ® File and Data Management R&S SMA100B How to Transfer Files from and to the Instrument ● Enable the corresponding service or interface To enable write permission on the file system 1. Select "System Config > Setup > Security > Security > General"...

  • Page 309: Accessing The File System Of The R&S Sma100B Via Ftp

    10.9.2 Accessing the File System of the R&S SMA100B Via ftp If the R&S SMA100B is connected to a LAN, you can use file transfer protocol (ftp) to access the file system and to transfer files from and to the instrument.

  • Page 310: Accessing The R&S Sma100B File System Via Smb (Samba)

    Open the /var/user/ directory. The dialog displays the /var/user/test ftp directory. 10.9.3 Accessing the R&S SMA100B File System Via SMB (Samba) The SMB (Samba) protocol is an alternative way to access the file system of the instru- ment from a remote PC. This protocol works if both the instrument and the PC are con- nected to a LAN.
  • Page 311 The user directory corresponds to the /var/user/ directory of the instrument; the volatile directory - to the /var/volatile directory. To map the R&S SMA100B as a network drive to the remote PC We assume that the instrument and the remote PC are connected to a LAN.

  • Page 312: Using A Usb Storage Device For File Transfer

    LAN, you can create a shortcut on the instruments to the file server. To access the file server 1. On each R&S SMA100B, map the required directory of the file server to the instru- ment. Perform the steps described in Chapter 10.8.4, "How to Map a Network...

  • Page 313: Creating Screenshots Of Current Settings

    SMA100B Creating Screenshots of Current Settings 2. On each R&S SMA100B, use the same alias name for the directory of the file server, i.e. enter the same "Local Folder" (in this example Setups). On any of the R&S SMA100B, you access the file server directly from the "File Manager"...
  • Page 314 ® File and Data Management R&S SMA100B Creating Screenshots of Current Settings The remote commands required to define these settings are described in Chap- ter 13.11, "HCOPy Subsystem", on page 438. Settings: File..........................312 Format.........................312 Options........................312 Save..........................312 Hardcopy Options >...
  • Page 315 ® File and Data Management R&S SMA100B Creating Screenshots of Current Settings Automatic Naming ← Hardcopy Options > Common If enabled, creates the output filenames automatically according to the rules set with Hardcopy Options > Automatic Naming settings. Remote command:...
  • Page 316 ® File and Data Management R&S SMA100B Creating Screenshots of Current Settings Provided are the following settings: Path... ← Hardcopy Options > Automatic Naming Selects the directory. Note: To select the destination path, specify also a filename. Otherwise an error mes- sage is displayed and selection is canceled.

  • Page 317: How To Save A Hardcopy Of The Display

    ® File and Data Management R&S SMA100B Creating Screenshots of Current Settings 10.10.2 How to Save a Hardcopy of the Display 1. Select "System Config > Setup > User Interface > Hardcopy". 2. To define the output format, select "Format > JPG".
  • Page 318 ® File and Data Management R&S SMA100B Creating Screenshots of Current Settings c) Print the selected file. For more information, refer to the online help of the operating system. User Manual 1178.3834.02 ─ 05...

  • Page 319: General Instrument Functions

    Allows you to adjust the display and keyboard language settings. ● Chapter 11.3, "Managing Licenses and License Keys", on page 328 If you have purchased an additional option for the R&S SMA100B, you can enable it using a license key. ● Chapter 10.2, "Restoring the (Default) Instrument Configuration",...

  • Page 320: Display And Keyboard Settings

    Settings", on page 319 ● Determine the state of the RF signal, and the level display in the status bar when you turn on the R&S SMA100B, see Chapter 11.1.3, "Defining the RF Signal State On Power On ", on page 320.

  • Page 321: Display Update Settings

    ® General Instrument Functions R&S SMA100B Customizing the User Interface Screen Saver Activates the screensaver. If activated, the display including backlight is switched off after the selected Wait Time elapses and if no entries via touch panel, front panel, external mouse, or external key-...

  • Page 322: Defining The Rf Signal State On Power On

    11.1.3 Defining the RF Signal State On Power On As additional functions for the level settings, you can determine the state of the RF sig- nal, and the level display in the status bar when you turn on the R&S SMA100B. Power-On/EMF settings Access: ►...

  • Page 323: How To Set The Initial Instrument Settings

    631 [:SOURce<hw>]:POWer:EMF:STATe 11.1.4 How to Set the Initial Instrument Settings This section describes how to set up the R&S SMA100B initially. 11.1.4.1 Setting the Keyboard Language You can select the language of the external keyboard connected to the instrument.

  • Page 324: Organizing Frequently Used Settings As Favorites

    ® General Instrument Functions R&S SMA100B Organizing Frequently Used Settings as Favorites 4. Define the "Wait Time" in minutes. The instrument turns off the display after the defined period of time. 5. To reactivate the display, tap the screen or press any key on the front panel.

  • Page 325: Using The User Menu For Fast Adjustments

    "Recall Setup" If the "Recall Setup" is the only one user action assigned to the [★ (User)] key, pressing this key triggers the R&S SMA100B to load immediately the user-defined preset file. 11.2.1 Using the User Menu for Fast Adjustments By default, there is one predefined action assigned to the [★...
  • Page 326 ® General Instrument Functions R&S SMA100B Organizing Frequently Used Settings as Favorites c) Open the context menu and select "Add to User Menu". A favorites icon indicates that the parameter is used in the "User Menu". The "User Menu" indication in the task bar confirms that "User Menu" with favorites is created.

  • Page 327: Define User Key Actions Settings

    ® General Instrument Functions R&S SMA100B Organizing Frequently Used Settings as Favorites Settings Clear User Menu Removes all entries from the "User Menu" at once. 11.2.2 Define User Key Actions Settings Access: ► Select "System Configuration > Setup > User Interface > Define User Key".

  • Page 328: Assigning Actions To The [★ (User)] Key

    ® General Instrument Functions R&S SMA100B Organizing Frequently Used Settings as Favorites "Open Dialog" Quick access to the selected dialog. Select Depending on the selected "Wizard", provides access to: ● The standard "File Select" function for loading of an SCPI script or setup file ●...
  • Page 329 ® General Instrument Functions R&S SMA100B Organizing Frequently Used Settings as Favorites 3. To create an action: a) Specify the "Name". b) Select "Wizard > Open Dialog" c) Select "Select" and select the dialog ID from the list The corresponding SCPI command is automatically displayed and can be later modified.

  • Page 330: Managing Licenses And License Keys

    The required version is specified in the delivery. If your instrument works with a former firmware version, update the firmware before enabling the software option. The firmware update is described in the R&S SMA100B service manual. 11.3.1 Manage License Keys Settings This dialog is the central dialog for licenses registration and performing the required instrument-related steps during the process of unregistration.
  • Page 331 ® General Instrument Functions R&S SMA100B Managing Licenses and License Keys In the "New License" tab, you can activate licenses for newly purchased or newly registered options. The "Installed License Keys" tab enables you to cancel already registered options, or move licenses.

  • Page 332: How To Move A Portable License

    ® General Instrument Functions R&S SMA100B Managing Licenses and License Keys Installed License Keys Access: select "System Config > Setup > Instrument Assembly > Manage License Keys > Installed License Keys". Comprises information on the installed options. Show Inactive ← Installed License Keys...
  • Page 333 ® General Instrument Functions R&S SMA100B Managing Licenses and License Keys We assume knowledge about the handling of the R&S License Manager online tool and the description of the whole process. 1. Open your browser. Enter https://extranet.rohde-schwarz.com/service. Select "Manage Licenses > Move Portable License".

  • Page 334: Using The Security Settings

    SMA100B Using the Security Settings 11.4 Using the Security Settings The protection function of the R&S SMA100B offers several levels to activate particular functions like self-test or tests for service purposes specifically. Protection The five protection levels are automatically active on startup, the protection levels, that means all protected functions are locked.

  • Page 335: Protection Level Settings

    Remote control via LAN interface requires that the interface is activated, but you can enable the required services specifically. ● User interface prevents front panel operation and/or reading the display. For more information, see the document R&S SMA100B Instrument Security Proce- dures. 11.4.1 Protection Level Settings Access: ►...

  • Page 336: Setting Security Parameters

    ® General Instrument Functions R&S SMA100B Using the Security Settings Remote command: on page 661 :SYSTem:PROTect<ch>[:STATe] 11.4.2 Setting Security Parameters Access: ► Select "System Config > Setup > Security > Security > General". In the "General" tab, you can determine the security level for firmware updates, and configure the security settings for the mass memory and manual operation.

  • Page 337: Disk & Memory Security Settings

    332 for more information on the security concept. ● The release notes for details on signature verification when installing new or former firmware versions, available at www.rohde-schwarz.com/firmware/sma100b. "Confirm Unsigned" Performs the signature verification. If the check detects any discrepancies, the instrument issues a warn- ing message.
  • Page 338 ® General Instrument Functions R&S SMA100B Using the Security Settings The "Disk & Memory" tab secures controlled access to the mass memory and pre- vents information from leaving a secure environment. The remote commands available to control security settings are described in Chap- ter 13.17, "SYSTem...

  • Page 339: Manual Operation Security Settings

    ® General Instrument Functions R&S SMA100B Using the Security Settings If the instrument is subject to high security, and you have not enabled the volatile mode, the internal flash memory holds user-data, i.e. id poses a security risk. The sani- tizing function makes sure that no user information is stored on the instrument when it leaves the secure environment.
  • Page 340 ® General Instrument Functions R&S SMA100B Using the Security Settings To apply the change: enter the security password and confirm with "Accept". Otherwise the change has no effect. Remote command: on page 434 :DISPlay:ANNotation:AMPLitude User Interface Allows you to lock the controls for manual operation and the display individually.
  • Page 341 ® General Instrument Functions R&S SMA100B Using the Security Settings "Disabled" Locks the display and all controls for the manual operation of the instrument. This security feature protects the instrument against unauthorized reading and access, for example when you operate the instrument via remote control.

  • Page 342: Configuring Lan Services

    ® General Instrument Functions R&S SMA100B Using the Security Settings 11.4.3 Configuring LAN Services Access: ► Select "System Config > Setup > Security > Security > LAN Services". In the "LAN Services" dialog, you can individually enable or disable the supported LAN interface services.

  • Page 343: Password Management

    "SMB (Samba)" Activates access to SMB (Server Message Block), used for providing shared access to files, printers and serial ports of a network. See also Chapter 10.9.3, "Accessing the R&S SMA100B File System Via SMB (Samba)", on page 308. "Avahi (Zeroconf)"...
  • Page 344 ® General Instrument Functions R&S SMA100B Using the Security Settings In this tab, you can assign the security and a user-defined password. 2. Select "System Config > Setup > Security > Security > Password Management > Security Password". A new password does not take effect until you confirm it with the corresponding "Change Password"...
  • Page 345 ® General Instrument Functions R&S SMA100B Using the Security Settings User Name Indicates the user name used for access to the Linux operating system and valid for VNC, FTP and SMB (Samba) access. User Password Access: select "System Config > Setup > Security > Security > Password Management >...

  • Page 346: Undoing Or Restoring Actions

    ® General Instrument Functions R&S SMA100B Undoing or Restoring Actions 11.5 Undoing or Restoring Actions "Undo" is a function that removes the effect of the last action on the instrument and reverts it to an older state. Conversely, "Redo" restores a previously undone action.

  • Page 347: Shutting Down And Rebooting The Instrument

    ® General Instrument Functions R&S SMA100B Shutting Down and Rebooting the Instrument History List Lists the performed actions, provided "Undo/Redo" state is "On". Clear History Deletes the recorded list of the performed steps. Apply Performs the "Undo/Redo". If you select a previously performed action of the list, all subsequent actions are undone.

  • Page 348: Network Operation And Remote Control

    As an alternative to the interactive operation directly at the instrument, you can operate the R&S SMA100B also from a remote location. Figure 12-1 shows the possibilities of the physical connection (interfaces) for the remote access.
  • Page 349 ® Network Operation and Remote Control R&S SMA100B Overview of Remote Access Modes Remote control (SCPI) ● A remote PC controls the instrument, usually via VISA (Virtual Instrument Software Architecture) interfaces. ● Remote control disables the manual operation of the instrument; you can set differ- ent lock states.

  • Page 350: Remote Control Interfaces And Protocols

    ® Network Operation and Remote Control R&S SMA100B Remote Control Interfaces and Protocols Remote device VNC client Requirements Characteristics ● Dedicated client App Smart device App must be installed. Fast, supports several options like full screen mode or auto-login. (Tablet/ smartphone) ●...

  • Page 351: Lan Interface

    ® Network Operation and Remote Control R&S SMA100B Remote Control Interfaces and Protocols Rohde & Schwarz provides the standardized I/O software library R&S VISA for com- munication with the instruments via TCP/IP (LAN: HiSLIP, VXI-11 and raw socket) or USB (USBTMC) interfaces.
  • Page 352 ® Network Operation and Remote Control R&S SMA100B Remote Control Interfaces and Protocols TCPIP = designates the network protocol host address = designates the IP address or hostname of the instrument [::LAN device name] = defines the protocol and the instance number of a subinstrument...

  • Page 353: Hislip Protocol

    ® Network Operation and Remote Control R&S SMA100B Remote Control Interfaces and Protocols See also Chapter 12.2.1.4, "Socket Communication", on page 351. 12.2.1.2 HiSLIP Protocol The HiSLIP (High Speed LAN Instrument Protocol) is the successor protocol for VXI-11 for TCP-based instruments specified by the IVI foundation. The protocol uses two TCP sockets for a single connection - one for fast data transfer, the other for non- sequential control commands (e.g.

  • Page 354: Usb Interface

    IP address or the host name of the instrument and the number of the port configured for remote-control. All R&S SMA100B use port number 5025 for this purpose. The port is configured for communication on a command-to-command basis and for remote control from a program.

  • Page 355: Gpib Interface (Iec/Ieee Bus Interface)

    12.2.4 LXI Browser Interface The LXI browser interface allows easy configuration of the LAN and remote control of the R&S SMA100B without additional installation requirements. The instrument's LXI browser interface works correctly with all W3C compliant browsers. Chapter 12.17.1, "LXI Functionality",...

  • Page 356: Remote Control Programs And Libraries

    ® Network Operation and Remote Control R&S SMA100B Remote Control Programs and Libraries the R&S SMA100B are described in Chapter 12.5.1, "LXI Status Settings", on page 367. 12.3 Remote Control Programs and Libraries This section shows how the remote-control programs access the instrument, and the libraries they require for the appropriate interface protocols.

  • Page 357: Possible Setups And Access Functions

    ● Remote control (application) program using VISA Figure 12-3: Application program using VISA Protocol Remote control program Socket viOpen (..., "TCPIP:SMA100B-102030::5025::SOCKET", ...) viPrintf (..., "SOUR:FREQ 2GHz\n") VXI-11 viOpen (..., "TCPIP:SMA100B-102030::inst0::INSTR", ...) viPrintf (..., "SOUR:FREQ 2GHz\n") HiSLIP viOpen (..., "TCPIP:SMA100B-102030::hislip0::INSTR", ...) viPrintf (..., "SOUR:FREQ 2GHz\n")
  • Page 358 R&S SMA100B Remote Control Programs and Libraries Figure 12-4: Application using instrument driver (VISA available) Protocol Remote control program Socket rssma_init ("TCPIP:SMA100B-102030::5025::SOCKET", ...) rssma_SetFrequency (..., 2e9) VXI-11 rssma_init ("TCPIP:SMA100B-102030::inst0::INSTR", ...) rssma_SetFrequency (..., 2e9) HiSLIP rssma_init ("TCPIP:SMA100B-102030::hislip0::INSTR", ...) rssma_SetFrequency (..., 2e9) USBTMC rssma_init ("USB::0x0AAD::0x01DD::100001::INSTR", ...)

  • Page 359: Remote Access Settings

    About instrument emulations You can also remotely control the R&S SMA100B via the command set of another sig- nal generator, as, for example, of an HP generator. With this function you can, for example, replace a signal generator with an R&S SMA100B in an automated test setup, without adjusting the command scripts used.

  • Page 360: Network Settings

    ® Network Operation and Remote Control R&S SMA100B Remote Access Settings 12.4.1 Network Settings Risk of network failure Consult your network administrator before performing the following tasks: ● Connecting the instrument to the network ● Configuring the network ● Changing IP addresses Errors can affect the entire network.
  • Page 361 665 :SYSTem:COMMunicate:NETWork[:COMMon]:HOSTname Workgroup Sets the individual windows workgroup name of the R&S SMA100B. This parameter is required in case the instrument is integrated in a windows network. This function is password-protected. Unlock the protection level 1 to access it.
  • Page 362 IP Address Displays the IP address of the instrument in the network. By default, the R&S SMA100B is configured to use dynamic TCP/IP configuration and to obtain the whole address information automatically. If the network does not support DHCP or the attempt does not succeed, the instrument tries to obtain the IP address via Zeroconf (APIPA) protocol.

  • Page 363: Visa Resource Strings

    Network Operation and Remote Control R&S SMA100B Remote Access Settings MAC Address Indicates the MAC (Media Access Control) address, a unique identifier of the network adapter in the R&S SMA100B. Remote command: on page 664 :SYSTem:COMMunicate:NETWork:MACaddress 12.4.2 VISA Resource Strings Access: ►...

  • Page 364: Gpib Address Settings

    (see recommended extras in the data sheet) and a serial crossover (null modem) cable. A USB connection requires the Visa library to be installed on the controller. Visa detects and configures the R&S SMA100B automatically when the USB connection is established.

  • Page 365: Instrument Emulations Settings

    The remote commands required to configure the emulation settings remotely are described in Chapter 13.17, "SYSTem Subsystem", on page 653. Language Selects the instrument whose remote command set is emulated by the R&S SMA100B. Remote command: on page 669 :SYSTem:LANGuage Mode Selects the way the instrument identification is performed.

  • Page 366: Active Connections Settings

    ® Network Operation and Remote Control R&S SMA100B Remote Access Settings Set to Default In "Mode > User Defined", resets the *IDN and *OPT strings. Remote command: on page 668 :SYSTem:IDENtification:PRESet IDN String Indicates the identification string of the instrument when queried with the common command *IDN?.

  • Page 367: Qr Code

    ® Network Operation and Remote Control R&S SMA100B Remote Access Settings The "Active Connections" dialog indicates all active SCPI and TCP/IP connections. Show Remote Connections in Taskbar Displays the currently active connections in the taskbar. SCPI Connections Shows the active VISA resource string of the interface via which the instrument is remotely controlled.

  • Page 368: Lxi Settings

    Device", on page 398. 12.5 LXI Settings On the R&S SMA100B the LXI functionality is already installed and enabled, see Status Settings. Thus, the instrument can be accessed via any web browser (like the Microsoft Internet Explorer) to perform the following tasks: ●...

  • Page 369: Lxi Status Settings

    ® Network Operation and Remote Control R&S SMA100B LXI Settings 12.5.1 LXI Status Settings Access: ► Select "System Config > Setup > Remote Access > LXI Status...". The "LXI - Status" dialog shows the parameters of the LAN connection. Alternatively, you can change the LAN settings using the LXI web browser interface, Chapter 12.5.2.1, "LAN...

  • Page 370: Lxi Browser Settings

    ® Network Operation and Remote Control R&S SMA100B LXI Settings Parameter Value ICMP ping Enabled Password for LAN configuration LxiWebIfc The LAN reset also resets the following parameters for the Signal Generator: Parameter Hostname Instrument-specific hostname Description Vector signal generator...

  • Page 371: Lan Configuration

    ® Network Operation and Remote Control R&S SMA100B LXI Settings – www.rohde-schwarz.com opens the Rohde & Schwarz homepage. ● "Data Sheet" Provides the data sheet with the specification data of the instrument at the time of delivery, see "Data Sheet"...

  • Page 372: Advanced Config

    ® Network Operation and Remote Control R&S SMA100B LXI Settings Changing the LAN configuration This function is password-protected. Unlock the protection level 1 to access it. Note: We recommend that you change the default password before connecting the instrument to a network.

  • Page 373: Ping Client

    2. Select "Submit". SCPI Remote Trace The remote trace functionality allows you to trace input and output strings at the remote control interface of the R&S SMA100B, see Chapter 12.9, "Tracing SCPI Com- mands and Messages Exchanged via the LXI Web Browser Interface",...

  • Page 374: Data Sheet

    ® Network Operation and Remote Control R&S SMA100B LXI Settings To trace and display messages, switch on "logging" and "live mode" in the toolbar. Toolbars The toolbar at the top of the dialog provides basic settings and functions. ● "Live mode" / "logging": If logging is switched on, messages are traced. They are...

  • Page 375: How To Find The Visa Resource String

    ® Network Operation and Remote Control R&S SMA100B How to Find the VISA Resource String 12.6 How to Find the VISA Resource String ► Select "System Config > Remote Access > VISA Resource Strings". The dialog shows all specified resource strings of the supported remote control interfaces.

  • Page 376: How To Change The Gpib Instrument Address

    ® Network Operation and Remote Control R&S SMA100B How to Set Up a Remote Control Connection ● For information on how to assign the IP address manually, see Chapter 2.1.3.3, "Assigning the IP Address", on page 30. ● Also note that using the RS232 serial interface via USB requires the USB serial adapter R&S TS-USB1.

  • Page 377: Establishing A Remote Control Connection Over The Lxi Browser Interface

    12.8.1 Establishing a Remote Control Connection over the LXI Browser Interface Via the LXI browser interface to the R&S SMA100B one or more users can control the instrument remotely from another PC without additional installation. Most instrument controls are available via the front panel simulation. File upload and download between the instrument and the remote PC is also available.

  • Page 378: Establishing A Remote Control Connection Over Lan Using Vxi-11 Protocol

    In this example, the I/O software library R&S VISA from Rohde & Schwarz is used to set up a LAN remote control link and remotely control the R&S SMA100B. R&S VISA is running on a controller PC with Windows operating system. When the connection is set up, you can send commands to the instrument and receive the responses.
  • Page 379 ® Network Operation and Remote Control R&S SMA100B How to Set Up a Remote Control Connection 3. In the menu bar, select "Choose VISA Implementation > Rohde & Schwarz Visa" and confirm with "OK". 4. In the menu bar, select "Find Resource" to search for the instrument in the LAN.
  • Page 380 "Resource" field of the main application window. 7. As an alternative to the IP address, you can assign an alias name to the R&S SMA100B: a) In the menu bar, select "RsVisaConfig". b) In the toolbar, select "+" to access the "VISA Resource String Composer".
  • Page 381 "OK". The "Alias" name is assigned. d) Close the dialog. The R&S SMA100B is registered in the program. It can be addressed via the resource string or alias name. 8. In the main window, select "Connect".
  • Page 382 ® Network Operation and Remote Control R&S SMA100B How to Set Up a Remote Control Connection 2. In the R&S VISA "Basics" tab, enter an SCPI command, e.g. "*IDN?". Confirm with "Query". The instrument is switched to remote control when it receives a command from the controller.

  • Page 383: Setting Up A Remote Control Connection Over Lan Using Socket Communication

    To control the software, only a Telnet program is required. The Telnet program is part of every operating system. 1. To establish a Telnet connection with the R&S SMA100B, start the Telnet program. Enter the socket address. The socket address is a combination of the IP address or the hostname of the R&S SMA100B and the number of the port configured for remote-control via Telnet.

  • Page 384: Setting Up A Remote Control Connection Over Gpib

    ® Network Operation and Remote Control R&S SMA100B How to Set Up a Remote Control Connection 2. Note that Telnet does not reflect your first entry. Insert a command, e.g. *IDN and confirm with "Enter". 3. Observe the screen. A response on the query confirms that the connection is working. The client dis- plays all subsequent inputs and responses.

  • Page 385: Setting Up A Remote Control Connection Over Usb

    3. To return to manual operation, press the [Local] key. 12.9 Tracing SCPI Commands and Messages Exchanged via the LXI Web Browser Interface The remote trace functionality allows you to trace commands and messages exchanged via a remote control interface of the R&S SMA100B. User Manual 1178.3834.02 ─ 05...

  • Page 386: How To Return To Manual Operation

    To activate the SCPI remote trace: 1. Start a web browser that supports HTML5 (W3C compliant). 2. Enter the IP address of the R&S SMA100B in the browser's address bar. The R&S SMA100B's welcome page is displayed. 3. In the navigation pane, select "Diagnostics > SCPI Remote Trace".

  • Page 387: Automating Tasks With Remote Command Scripts

    ® Network Operation and Remote Control R&S SMA100B Automating Tasks with Remote Command Scripts The command switches directly to manual operation. ● VISA function viGpibControlREN() This function switches directly to manual operation. 12.11 Automating Tasks with Remote Command Scripts To achieve fast configuration, make complex test setups or repeating measurements reproducible, you can automate the required settings with scripts.
  • Page 388 ® Network Operation and Remote Control R&S SMA100B Automating Tasks with Remote Command Scripts – Automatically record all performed steps The instrument records the SCPI command and settings value of each step you perform, and then writes the commands to the file system, see...

  • Page 389: Show Scpi Command

    When converted, you can save the script in a file with an extension corresponding to the programming language. The R&S SMA100B provides the following predefined code templates by default: ● Plain SCPI Represents SCPI base format, that is ASCII format, saved as text file (*.txt).

  • Page 390: Displaying An Scpi List

    ® Network Operation and Remote Control R&S SMA100B Automating Tasks with Remote Command Scripts 12.11.2 Displaying an SCPI List The instrument displays a recorded SCPI list and thus provides viewing the recorded results before exporting. ► Depending on the starting point, you can access the "SCPI Recording List" dialog as follows: ●...
  • Page 391 ® Network Operation and Remote Control R&S SMA100B Automating Tasks with Remote Command Scripts Access: 1. Select "Show SCPI Recording List" in the context-sensitive menu. The "SCPI Recording List" dialog opens. 2. Select "Export". The "SCPI Recording Export" dialog contains all functions required for export of command lists to a file.

  • Page 392: How To Find Out The Scpi Command Corresponding To The Manual Operation Via Show Scpi Command

    ® Network Operation and Remote Control R&S SMA100B How to Find Out the SCPI Command Corresponding to the Manual Operation Using the Online Help You can export recorded SCPI lists to files (see File and Export), that can be modified.

  • Page 393: How To Record / Create Scpi Lists

    ® Network Operation and Remote Control R&S SMA100B How to Record / Create SCPI Lists How to find the corresponding GUI function to a command Conversely, if you are looking for a function in the GUI, which belongs to a SCPI, you find it via a cross-reference in the online help and in the user manual.
  • Page 394 ® Network Operation and Remote Control R&S SMA100B How to Record / Create SCPI Lists 2. For selectively recording your steps: a) Set the parameter. b) Open the context-sensitive menu. c) Select "Add SCPI Command to Recording List" Tip: You cannot see "Add SCPI ..." in the menu? A possible reason is opening the menu outside of a dialog or input field, for example in a block diagram.
  • Page 395 ® Network Operation and Remote Control R&S SMA100B How to Record / Create SCPI Lists The instrument opens the standard file select dialog, see Chapter 10.4.1, "Save/ Recall Settings", on page 291. 2. In the "Format" entry field, select the source code.

  • Page 396: How To Convert And Save Scpi Lists

    ® Network Operation and Remote Control R&S SMA100B How to Convert and Save SCPI Lists Such entries are also detected during execution. The instrument recognizes these incomplete commands and displays an error message. ● A preset has been executed, but several standards subsequently perform some internal settings that are also assigned to the list with "SCPI Export".

  • Page 397: How To Set Up Remote Operation Via Vnc

    12.16.1 Setting Up a Remote Operation from a Desktop System 12.16.1.1 Using a Web Browser The R&S SMA100B supports remote operation via VNC with any web browser, like Windows Internet Explorer or Mozilla Firefox for instance, or alternatively, an HTML5 web browser.

  • Page 398: Using A Vnc Client Software

    ® Network Operation and Remote Control R&S SMA100B How to Set Up Remote Operation via VNC 3. Enter the password and confirm with "OK". The default password is instrument. After the connection is established, the current screen of the signal generator is displayed and the instrument can be remotely operated from the remote computer.
  • Page 399 ® Network Operation and Remote Control R&S SMA100B How to Set Up Remote Operation via VNC 3. Select "VNC Server" and enter the IP address of the instrument. 4. To initialize the connection, select "Connect". A dialog opens requesting the password.

  • Page 400: Setting Up A Remote Operation From A Smart Device

    Figure 12-7: Example of a network configuration for remote operation with a smart device As shown in the figure, the R&S SMA100B and the WLAN router are connected to the LAN router. The smart device accesses the Rohde & Schwarz instrument via the WLAN router.

  • Page 401: Using A Vnc App

    12.16.2.1 Using a VNC App Using a VNC App enables the smart device to access the R&S SMA100B via WLAN. The VNC Apps are available from various manufacturers of the smart devices. The list of supported devices is different according to the smart device. Refer to the manufac- turer's website to find out whether a VNC App is available for your device, and how it is installed.

  • Page 402: Special Mode Qr Code

    1. Install the required QR code reader software on your device. 2. Start the reader. 3. On the R&S SMA100B, select "System Config > Remote Access". 4. In the "Remote Access" dialog, select the "QR-Code" tab. 5. Scan the QR code of the instrument with your smart device.

  • Page 403: References

    GPIB. Like GPIB, LXI determines and standardizes the way the instrument behaves in a LAN. The LXI implementation in the R&S SMA100B allows you to change certain LAN set- tings, to reset the LAN connection, and to identify the instrument.
  • Page 404 ® Network Operation and Remote Control R&S SMA100B References Command Function #EXTENSION_START Defines the output file extension. #EXTENSION_END #INIT_CODE_START Contains initial entries, such as included files and libraries, buffer size, commands for synchronization, #INIT_CODE_END or creating a VISA session. All entries between start and end are written once at the beginning of the output file.

  • Page 405: Remote Control States

    ® Network Operation and Remote Control R&S SMA100B References length = length+1; viWrite (handle, writeBuffer, length, VI_NULL); //read result viRead(handle, readBuffer, 100, &readCount); int main (int argc, char *argv[]) if (InitCVIRTE (0, argv, 0) == 0) return -1; /* out of memory */ //create a VISA session and return a handle to it viOpenDefaultRM (&defaultRM);...
  • Page 406 ® Network Operation and Remote Control R&S SMA100B References Table 12-3: Remote control status icons GUI symbol Transition to remote control state... Transition to manual operation...(local state) ● &GTR (controller) &GTL (controller) ● Tap the "Remote" icon (display) Remote control, but usable front panel keys.

  • Page 407: Remote Control Commands

    ● Conformity Commands that are taken from the SCPI standard are indicated as SCPI con- firmed. All commands used by the R&S SMA100B follow the SCPI syntax rules. ● Asynchronous commands A command which does not automatically finish executing before the next com- mand starts executing (overlapping command) is indicated as an Asynchronous command.

  • Page 408: Programming Examples

    The corresponding sections of the same title provide simple programming examples for the R&S SMA100B. The purpose of the examples is to present all commands for a given task. In real applications, one would rather reduce the examples to an appropri- ate subset of commands.
  • Page 409 ® Remote Control Commands R&S SMA100B Common Commands ..........................410 *TRG ........................... 410 *TST? ..........................410 *WAI *CLS Clear status Sets the status byte (STB), the standard event register (ESR) and the EVENt part of the QUEStionable and the OPERation registers to zero. The command does not alter the mask and transition parts of the registers.
  • Page 410 ® Remote Control Commands R&S SMA100B Common Commands *IST? Individual status query Returns the contents of the IST flag in decimal form. The IST flag is the status bit which is sent during a parallel poll. Return values: <ISTflag> 0 | 1...
  • Page 411 ® Remote Control Commands R&S SMA100B Common Commands Determines whether the contents of the ENABle registers are preserved or reset when the instrument is switched on. Thus a service request can be triggered when the instru- ment is switched on, if the status registers ESE and SRE are suitably configured. The query reads out the contents of the "power-on-status-clear"...
  • Page 412 ® Remote Control Commands R&S SMA100B Common Commands *SRE <Contents> Service request enable Sets the service request enable register to the indicated value. This command deter- mines under which conditions a service request is triggered. Parameters: <Contents> Contents of the service request enable register in decimal form.

  • Page 413: Preset Commands

    ® Remote Control Commands R&S SMA100B Preset Commands Prevents servicing of the subsequent commands until all preceding commands have been executed and all signals have settled (see also command synchronization and *OPC). Usage: Event 13.4 Preset Commands The preset commands are not bundled in one subsystem. Therefore, they are listed separately in this section.

  • Page 414: Mmemory Subsystem

    The /var/volatile directory serves as a RAM drive and can be used to protect sensitive information. The data is available temporarily. If option R&S SMAB-B85 is installed, the R&S SMA100B maps the user directory to the removable memory. If a memory is mounted, user data is saved there. Otherwise user data is redirected to the volatile memory.

  • Page 415: File Naming Conventions

    The file and the optional file extension are separated by a period sign. The R&S SMA100B distinguishes the files according to their extensions; each type of file is assigned a specific file content and hence a specific file extension. Refer to Chapter C, "Extensions for User...

  • Page 416: Accessing Files In The Default Or In A Specified Directory

    The subsequent commands for file handling (select, delete, read out files in the directory, etc.) require only specification of the filename. File extension can be omitted; after syntax evaluation of the used command, the R&S SMA100B filters out the relevant files.

  • Page 417: Programming Examples

    ® Remote Control Commands R&S SMA100B MMEMory Subsystem 13.5.3 Programming Examples Example: Storing and loading current settings This example shows two ways of how to store the current instrument setting in the file settings.savrcltxt in the directory /var/user/savrcl. Before the instrument settings can be stored in a file, they have to be stored in an inter- mediate memory using common command *SAV <number>.
  • Page 418 ® Remote Control Commands R&S SMA100B MMEMory Subsystem // the subdirectories "test" and "temp" // as well as the files "settings.savrcltxt" and "list.lsw" // query only the subdirectories of the current or specified directory MMEMory:DCATalog? "/var/user" // ".","..","Log","temp","test" // query only number of subdirectories in the current or specified directory MMEMory:DCATalog:LENGth? "/var/user"...

  • Page 419: Remote Control Commands

    ® Remote Control Commands R&S SMA100B MMEMory Subsystem 13.5.4 Remote Control Commands ......................417 :MMEMory:CATalog? ..................417 :MMEMory:CATalog:LENGth? ....................418 :MMEMory:CDIRectory ......................418 :MMEMory:COPY ......................419 :MMEMory:DATA ....................419 :MMEMory:DCATalog? ..................420 :MMEMory:DCATalog:LENGth? ......................420 :MMEMory:DELete ....................420 :MMEMory:LOAD:STATe ....................420 :MMEMory:MDIRectory ......................421 :MMEMory:MOVE ......................421 :MMEMory:MSIS ....................
  • Page 420 ® Remote Control Commands R&S SMA100B MMEMory Subsystem Query parameters: <Path> string String parameter to specify the directory. If the directory is omit- ted, the command queries the content of the current directory, queried with command. :MMEMory:CDIRectory Return values: <FileCount>...
  • Page 421 ® Remote Control Commands R&S SMA100B MMEMory Subsystem :MMEMory:DATA <Filename>, <BinaryBlock> :MMEMory:DATA? <Filename> The setting command writes the block data <BinaryBlock> to the file identified by <Filename>. Tip: Use this command to read/transfer stored instrument settings or waveforms directly from/to the instrument.
  • Page 422 ® Remote Control Commands R&S SMA100B MMEMory Subsystem :MMEMory:DCATalog:LENGth? [<Path>] Returns the number of subdirectories in the current or specified directory. Query parameters: <Path> String parameter to specify the directory. If the directory is omit- ted, the command queries the contents of the current directory, to be queried with command.
  • Page 423 ® Remote Control Commands R&S SMA100B MMEMory Subsystem Setting parameters: <Directory> string String parameter to specify the new directory. Usage: Event Manual operation: "Create New Directory" on page 300 :MMEMory:MOVE <SourceFile>, <DestinationFile> Moves an existing file to a new location or, if no path is specified, renames an existing file.

  • Page 424: Calibration Subsystem

    ® Remote Control Commands R&S SMA100B CALibration Subsystem Setting parameters: <savrcl_state_nr> Corresponds to the specific <number> defined with the *SAV command, e.g. *SAV 4. <file_name> String parameter to specify the file name with extension *.savrcltxt. Usage: Event Manual operation: "Save"...
  • Page 425 ® Remote Control Commands R&S SMA100B CALibration Subsystem ..................424 :CALibration<hw>:ALL:TIME? ................. 424 :CALibration:DATA:FACTory:DATE? ................425 :CALibration<hw>:CONTinueonerror :CALibration:ALL[:MEASure]? [<Force>] Starts all internal adjustments that do not need external measuring equipment. NOTICE: Risk of DUT damage During level adjustments, the instrument temporarily applies high power at the RF out- put.
  • Page 426 ® Remote Control Commands R&S SMA100B CALibration Subsystem Return values: <CalInfoText> string Example: CAL:ALL:INF? "Instrument is calibrated, no adjustment required." "UNCAL, instrument is warming up." "UNCAL, Please perform full adjustment after warming up." "UNCAL, Please perform full adjustment." Usage: Query only Manual operation: "Information"...

  • Page 427: Csynthesis Subsystem

    ® Remote Control Commands R&S SMA100B CSYNthesis Subsystem Usage: Query only Manual operation: "Last Factory Calibration" on page 699 :CALibration<hw>:CONTinueonerror <State> Continues the calibration even though an error was detected. By default adjustments are aborted on error. Suffix: <hw> Optional suffix Parameters: <State>...
  • Page 428 ® Remote Control Commands R&S SMA100B CSYNthesis Subsystem ......................426 :CSYNthesis:STATe ...................... 426 :CSYNthesis:OTYPe ....................426 :CSYNthesis:FREQuency ...................... 427 :CSYNthesis:POWer ....................427 :CSYNthesis:OFFSet:STATe ......................427 :CSYNthesis:OFFSet ....................428 :CSYNthesis:VOLTage ...................... 428 :CSYNthesis:PHASe ..................428 :CSYNthesis:PHASe:REFerence .................. 429 :CSYNthesis:POWer:STEP:MODE ................429 :CSYNthesis:FREQuency:STEP:MODE ................. 429 :CSYNthesis:POWer:STEP[:INCRement] ..................
  • Page 429 ® Remote Control Commands R&S SMA100B CSYNthesis Subsystem UP|DOWN Varies the frequency step by step. The frequency is increased or decreased by the value set with the command :CSYNthesis:FREQuency:STEP. Range: 100E3 to 1.5E9 Increment: 0.001 *RST: 10E6 Example: Chapter 13.7, "CSYNthesis Subsystem",...
  • Page 430 ® Remote Control Commands R&S SMA100B CSYNthesis Subsystem Parameters: <Offset> float Range: -5 to 5 Increment: 0.001 *RST: Example: Chapter 13.7, "CSYNthesis Subsystem", on page 425. Manual operation: " DC Offset " on page 281 :CSYNthesis:VOLTage <Voltage> Sets the voltage for the CMOS signal.
  • Page 431 ® Remote Control Commands R&S SMA100B CSYNthesis Subsystem :CSYNthesis:POWer:STEP:MODE <Mode> :CSYNthesis:FREQuency:STEP:MODE <Mode> Defines the type of step size to vary the frequency and level at discrete steps. Parameters: <Mode> DECimal | USER DECimal Increases or decreases the level in steps of 10.

  • Page 432: Diagnostic Subsystem

    The test functions are intended for services purposes. They are thus password-protected functions. Unlock the corresponding protection level to access them, see :SYSTem:PROTect<ch>[:STATe] For more information, see R&S SMA100B Service Manual. Common suffixes The following common suffixes are used in remote commands: Suffix...
  • Page 433 Query only Manual operation: "Assembly" on page 699 :DIAGnostic<hw>:POINt:CATalog? Queries the test points available in the instrument. For more information, see R&S SMA100B Service Manual. Return values: <Catalog> string List of comma-separated values, each representing a test point Example: Example "Programming example"...

  • Page 434: Display Subsystem

    DISPlay Subsystem :DIAGnostic<hw>[:MEASure]:POINt? <Name> Triggers the voltage measurement at the specified test point and returns the measured voltage. For more information, see R&S SMA100B Service Manual. Query parameters: <Name> <test point identifier> Test point name, as queried with the command DIAGnostic<hw>:POINt:CATalog?
  • Page 435 ® Remote Control Commands R&S SMA100B DISPlay Subsystem The dialog ID is also required to define user key actions. Chapter 11.2.3, "Assigning Actions to the [★ (User)] Key", on page 326. // Query the dialog IDs of all open dialogs...
  • Page 436 ® Remote Control Commands R&S SMA100B DISPlay Subsystem Parameters: <State> 0 | 1 | OFF | ON *RST: n.a. (factory preset: 0) Example: Example "Activating screen saver mode and display update" on page 432 Manual operation: "Screen Saver" on page 319 :DISPlay:BRIGhtness <BRIGhtness>...
  • Page 437 ® Remote Control Commands R&S SMA100B DISPlay Subsystem Parameters: <State> 0 | 1 | OFF | ON *RST: n.a. (factory preset: 1) Example: Example "Activating screen saver mode and display update" on page 432 Manual operation: "Annotation Amplitude" on page 337 :DISPlay:ANNotation:FREQuency <State>...
  • Page 438 ® Remote Control Commands R&S SMA100B DISPlay Subsystem <Optional parts> String of $<X> values, where <X> is a character, interpreted as follows: $q<DialogQualifier>: optional dialog qualifier, usually the letter A or B, as displayed in the dialog title. $i<Instances>: comma-separated list of instance indexes, given in the order h,c,s,d,g,u,0.

  • Page 439: Format Subsystem

    The commands in the FORMat subsystem determine the format of data returned by the R&S SMA100B to the controller. This affects all query commands that return a list of numerical data or block data, noted in the descriptions of the commands. The set data format applies to both paths.

  • Page 440: Hcopy Subsystem

    ® Remote Control Commands R&S SMA100B HCOPy Subsystem BINary|HEXadecimal|OCTal Returns the register content either as a binary, hexadecimal or octal number. According to the selected format, the number starts with #B (binary), #H (hexadecimal) or #O (octal). *RST: ASCii Example: FORM:SREG HEX returns the register content as a hexadecimal number.

  • Page 441: Hard Copy Settings

    ® Remote Control Commands R&S SMA100B HCOPy Subsystem // ****************************************************************** // Configure hard copy options, set automatic naming rules // An automatically generated file name consists of: // <Prefix><YYYY><MM><DD><Number>.<Format> // ****************************************************************** :HCOPy:DEVice:LANGuage BMP // defines output format *.bmp :HCOPy:REGion DIALog // selects the region to be copied :HCOPy:FILE:AUTO:DIR "/usb/HCopy"...
  • Page 442 ® Remote Control Commands R&S SMA100B HCOPy Subsystem :HCOPy:DATA? Transfers the hard copy data directly as a NByte stream to the remote client. Return values: <Data> block data Example: Example "Store a hard copy of the display" on page 438...

  • Page 443: Automatic Naming

    ® Remote Control Commands R&S SMA100B HCOPy Subsystem :HCOPy[:EXECute] Generates a hard copy of the current display. The output destination is a file. Example: Example "Store a hard copy of the display" on page 438 Usage: Event Manual operation: "Save"...
  • Page 444 ® Remote Control Commands R&S SMA100B HCOPy Subsystem :HCOPy:FILE[:NAME]:AUTO:DIRectory:CLEar Deletes all files with extensions *.bmp, *.jpg, *.png and *.xpm in the directory set for automatic naming. Example: Example "Store a hard copy of the display" on page 438 Usage: Event Manual operation: "Clear Path"...

  • Page 445: Kboard Subsystem

    Queries the number that is used as part of the file name for the next hard copy in auto- matic mode. At the beginning, the count starts at 0. The R&S SMA100B searches the specified out- put directory for the highest number in the stored files. It increases this number by one to achieve a unique name for the new file.

  • Page 446: Output Subsystem

    ® Remote Control Commands R&S SMA100B OUTPut Subsystem Parameters: <Layout> CHINese | DANish | DUTCh | DUTBe | ENGLish | ENGUK | FINNish | FRENch | FREBe | FRECa | GERMan | ITALian | JAPanese | KORean | NORWegian | PORTuguese | RUSSian |...
  • Page 447 ® Remote Control Commands R&S SMA100B OUTPut Subsystem :OUTPut<hw>[:STATe] <State> Activates the RF output signal. Parameters: <State> 0 | 1 | OFF | ON *RST: Example: OUTP ON Activates the RF output. Manual operation: "RF State/RF ON" on page 62 :OUTPut<hw>[:STATe]:PON <Pon>...
  • Page 448 "RF output impedance" on page 62 :OUTPut:FPRoportional:SCALe <OutpSelScale> Selects the mode the voltage is supplied depending on the frequency. The R&S SMA100B supplies the signal at the V/GHz X-Axis connector. Parameters: <OutpSelScale> S0V25 | S0V5 | S1V0 | XAXis S0V25|S0V5|S1V0 Supplies the voltage proportional to the set frequency, derived from the selected setting.
  • Page 449 ® Remote Control Commands R&S SMA100B OUTPut Subsystem Options: R&S SMAB-B28 Manual operation: " V/GHz / X-Axis " on page 179 :OUTPut:USER:MARKer <SelUserMarker> Selects the signal for output at the Marker User1 connector. Parameters: <SelUserMarker> MARK | USER MARK Assigns a marker signal to the output.

  • Page 450: Power Sensor Measurement Subsystems

    ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Manual operation: "Overload" on page 196 :OUTPut<hw>:PROTection:TRIPped? Queries the state of the protective circuit. Return values: <Tripped> 0 | 1 | OFF | ON *RST: Example: OUTP:PROT:TRIP queries the state of the protective circuit of the RF output.

  • Page 451: Calculate Subsystem

    Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Power and Pulse Data Analysis, Gated Measurements (option R&S SMA100B- K28) The power analysis measurement commands are subsumed under the SENSe[:POWer]:SWEep:… commands. Three measurement modes are available: Frequency, Power and Time.
  • Page 452 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems :CALCulate[:POWer]:SWEep:FREQuency:MATH<ch>:SUBTract <Subtract> Subtracts the operands 1 and 2 and assigns the result to the selected trace in "Fre- quency" measurement mode. Parameters: <Subtract> T1T1 | T1T2 | T1T3 | T1T4 | T1REf | T2T1 | T2T2 | T2T3 | T2T4 |...
  • Page 453 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems :CALCulate[:POWer]:SWEep:TIME:GATE<ch>:AVERage? Queries the average power value of the time gated measurement. Return values: <Average> float Range: -1000 to 1000 Increment: 1E-12 *RST: Example: SENS:SWE:MODE TIME Activates time mode for power analysis.
  • Page 454 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Example: SENS:SWE:MODE TIME Activates time mode for power analysis. CALC:SWE:TIME:GATE:STAT ON Activates time gated measurement. SENS:SWE:INIT Activates a single power analysis measurement. CALC:SWE:TIME:GATE2:MAX? Queries the peak power in time gate 2 for trace 1 (=default).

  • Page 455: Display Subsystem

    ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems :CALCulate[:POWer]:SWEep:TIME:MATH<ch>:STATe <State> Activates the trace mathematics mode for "Time" measurement. This feature enables you to calculate the difference between the measurement values of two traces. For fur- ther calculation, a math result can also be assigned to a trace.

  • Page 456: Initiate Command

    ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems :DISPlay[:WINDow][:POWer]:SWEep:GRID:STATe <State> Indicates a grid in the diagram. Parameters: <State> 0 | 1 | OFF | ON *RST: Example: DISP:SWE:GRID:STAT OFF Deactivates the indication of a grid in the diagram area.

  • Page 457: Sense Subsystem

    ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Return values: <Power> string Example: SENS:UNIT DBM selects unit dBm for presentation of measurement result. READ1? queries the measurement result of the sensor connected to the SENSOR interface. Response: -45.6246576745440230 -45.6 dBm were measured at the given frequency.
  • Page 458 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems ........466 :SENSe[:POWer]:SWEep:FREQuency:REFerence:DATA:XVALues ........466 :SENSe[:POWer]:SWEep:FREQuency:REFerence:DATA:YVALues ..............466 :SENSe[:POWer]:SWEep:FREQuency:RMODe ...........467 :SENSe[:POWer]:SWEep:FREQuency:SPACing[:MODE] ..............467 :SENSe[:POWer]:SWEep:FREQuency:STARt ..............467 :SENSe[:POWer]:SWEep:FREQuency:STEPs ..............468 :SENSe[:POWer]:SWEep:FREQuency:STOP ............468 :SENSe[:POWer]:SWEep:FREQuency:TIMing[:MODE] ............468 :SENSe[:POWer]:SWEep:FREQuency:YSCale:AUTO ..........469 :SENSe[:POWer]:SWEep:FREQuency:YSCale:AUTO:RESet ..........469 :SENSe[:POWer]:SWEep:FREQuency:YSCale:MAXimum ..........469 :SENSe[:POWer]:SWEep:FREQuency:YSCale:MINimum .................470...
  • Page 459 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems ............482 :SENSe[:POWer]:SWEep:POWer:YSCale:MINimum ................... 483 :SENSe[:POWer]:SWEep:RMODe ............483 :SENSe[:POWer]:SWEep:TIME:AVERage[:COUNt] ...........483 :SENSe[:POWer]:SWEep:TIME:REFerence:DATA:COPY ..........484 :SENSe[:POWer]:SWEep:TIME:REFerence:DATA:POINts? ..........484 :SENSe[:POWer]:SWEep:TIME:REFerence:DATA:XVALues ..........484 :SENSe[:POWer]:SWEep:TIME:REFerence:DATA:YVALues ................484 :SENSe[:POWer]:SWEep:TIME:RMODe .............485 :SENSe[:POWer]:SWEep:TIME:SPACing[:MODE] ................485 :SENSe[:POWer]:SWEep:TIME:STARt ................485 :SENSe[:POWer]:SWEep:TIME:STEPs ................
  • Page 460 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Options: Option R&S SMAB-K28 Manual operation: " Level Offset State- Power Analysis " on page 239 :SENSe<ch>[:POWer]:SWEep:FREQuency[:SENSor]:SRANge:STARt <Start> Sets the start frequency for the frequency power analysis with separate frequencies.
  • Page 461 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Parameters: <State> 0 | 1 | OFF | ON *RST: Example: SENS2:SWE:FREQ:SENS:SRAN ON Activates use of a separate frequency range for frequency ver- sus power measurement for sensor 2. SENS2:SWE:FREQ:SENS:STAR 2.0GHZ Sets a sweep start at 2 GHz irrespective of the current signal generator frequency settings.
  • Page 462 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems :SENSe<ch>[:POWer]:SWEep:POWer[:SENSor]:SFRequency <SFRequency> Defines the separate frequency used for power vs. power measurement. Parameters: <SFRequency> float Range: 0 to 1E12 Increment: 1 *RST: Example: SENS1:SWE:POW:SENS:SFR 2GHz The measurement is performed at 2 GHz Manual operation: "...
  • Page 463 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:OFFSet:STATe <State> Activates a level offset at the sensor input. Define the appropriate value with the com- mand on page 460. :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:OFFSet Parameters: <State> 0 | 1 | OFF | ON...
  • Page 464 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:PULSe:THReshold:POWer: HREFerence <HReference> Sets the upper reference level in terms of percentage of the overall pulse level (power or voltage). The distal power defines the end of the rising edge and the start of the fall- ing edge of the pulse.
  • Page 465 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Parameters: <Reference> float Range: 0.0 to 100.0 Increment: 0.01 *RST: 50.0 Example: SENS1:SWE:TIM:PULS:THR:REF 40 Sets the medial reference level to 40% of the overall pulse level. Options: Option R&S SMAB-K28 Manual operation: "...
  • Page 466 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Manual operation: " Auto Set - Power Analysis " on page 250 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:TRIGger:DTIMe <DTime> Determines the minimum time for which the signal must be below (above) the power level defined by level and hysteresis before triggering can occur again.
  • Page 467 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Parameters: <TriggerSlope> POSitive | NEGative *RST: POSitive Example: SENS1:SWE:TIME:TRIG:SLOP POS The positive edge of a trigger signal is active. Options: Option R&S SMAB-K28 Manual operation: " Slope - Power Analysis "...
  • Page 468 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Usage: Event Manual operation: "Save To Ref" on page 228 :SENSe[:POWer]:SWEep:FREQuency:REFerence:DATA:POINts? Queries the number of points from the reference curve in "Frequency" measurement. Return values: <Points> integer Range: 10 to 1000...
  • Page 469 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Parameters: <RMode> SINGle | CONTinuous *RST: CONTinuous Example: SENS:SWE:FREQ:RMOD SING Selects single measurement Manual operation: " Execution - Power Analysis " on page 234 :SENSe[:POWer]:SWEep:FREQuency:SPACing[:MODE] <Mode> Selects the spacing for the frequency power analysis.
  • Page 470 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems :SENSe[:POWer]:SWEep:FREQuency:STOP <Stop> Sets the stop frequency for the frequency mode. Parameters: <Stop> float Range: 0 to 1E12 *RST: 22GHZ Example: SENS:SWE:FREQ:STOP 20.0GHZ Sets the sweep stop to 20 GHz Manual operation: "Max - Power Analysis"...
  • Page 471 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems CFLoating | FFLoating Auto scale is activated. The scaling of the Y-axis is selected in such a way, that the trace is always visible. To this end, the range is either expanded if the minimum or maximum values of the trace move outside the current scale or scaled down if the trace fits into a reduced scale.
  • Page 472 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Parameters: <Minimum> float Range: -200 to 100 Increment: 0.01 *RST: Example: SENS:SWE:FREQ:YSC:MIN -10DB Sets -10 dBm as the lower limit of the measurement diagram. Manual operation: " Min - Max Level - Power Analysis "...
  • Page 473 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Example: SENS:SWE:HCOP:DEV:LANG:CSV:ORI VERT selects horizontal orientation SENS:SWE:HCOP:DATA? queries the measurement data of the current traces Response: #2681009500000;-9.5; 1019000000;-9.7; 1028500000;-6.3; 1038000000;-2.5; for vertical representation the length of the data block is 68...
  • Page 474 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Parameters: <DPoint> DOT | COMMa *RST: Example: SENS:SWE:HCOP:DEV:LANG CSV Selects output format *.csv. SENS:SWE:HCOP:DEV:LANG:CSV:DPO DOT Selects character dot for being used as decimal point. Manual operation: "Decimal Point" on page 259 :SENSe[:POWer]:SWEep:HCOPy:DEVice:LANGuage:CSV:HEADer <Header>...
  • Page 475 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Parameters: <Separator> TABulator | SEMicolon | COMMa | BLANk *RST: COMMa Example: SENS:SWE:HCOP:DEV:LANG CSV Selects output format *.csv. SENS:SWE:HCOP:DEV:LANG:CSV:SEP TAB A tab separates the values. Manual operation: "Separator" on page 259 :SENSe[:POWer]:SWEep:HCOPy:DEVice:SIZE <Size>...
  • Page 476 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems :SENSe[:POWer]:SWEep:HCOPy:FILE[:NAME]:AUTO:DIRectory <Directory> Defines the directory into which the hardcopy files are stored if auto naming is activa- ted (SENS:SWE:HCOP:FILE:AUTO:STAT ON). Parameters: <Directory> string Example: SENS:SWE:HCOP:FILE:AUTO:DIR 'var/nrp' Hardcopy file are stored in directory var/nrp if automatic nam- ing is activated.
  • Page 477 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Example: SENS:SWE:HCOP:DEV:LANG BMP Selects output format *.bmp. SENS:SWE:HCOP:FILE:AUTO:DIR 'var/nrp' Hardcopy files are stored in directory var/nrp if automatic naming is activated. SENS:SWE:HCOP:FILE:AUTO:PREF 'sens1' The file name starts with the prefix sens1. The usage of auto- matic naming with prefix and date in the file name is preset (…:STAT ON).
  • Page 478 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Parameters: <State> 0 | 1 | OFF | ON *RST: Example: SENS:SWE:HCOP:FILE:AUTO:DAY:STAT OFF Deactivates the usage of the day in the automatic file name. Manual operation: "Prefix, Year, Month, Day, Instrument Name"...
  • Page 479 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems :SENSe[:POWer]:SWEep:HCOPy:FILE[:NAME]:AUTO[:FILE]:PREFix <Prefix> Sets the prefix part in the automatic file name. Parameters: <Prefix> string Example: SENS:SWE:HCOP:FILE:AUTO:PREF 'sensor' The prefix sensor is used in the automatically generated file name of the hardcopy file.
  • Page 480 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Manual operation: "Prefix, Year, Month, Day, Instrument Name" on page 257 :SENSe[:POWer]:SWEep:HCOPy[:EXECute] Triggers the generation of a hardcopy of the current measurement diagram. The data is written into the file selected/created with the :SENSe[:POWer]:SWEep:HCOPy: on page 473 command.
  • Page 481 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Usage: Event Manual operation: "Save To Ref" on page 228 :SENSe[:POWer]:SWEep:POWer:REFerence:DATA:POINts? Queries the number of points from the reference curve in "Power" measurement. Return values: <Points> integer Range: 10 to 1000...
  • Page 482 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Example: SENS:SWE:POW:RMOD SING Selects single measurement. Manual operation: " Execution - Power Analysis " on page 234 :SENSe[:POWer]:SWEep:POWer:SPACing[:MODE] <Mode> Selects the spacing for the frequency power analysis. Parameters: <Mode> LINear...
  • Page 483 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Parameters: <Stop> float Range: -145 to 20 Increment: 0.01 *RST: Example: SENS:SWE:POW:STOP 20.0DBM Sets the stop level to 20 dBm. :SENSe[:POWer]:SWEep:POWer:TIMing[:MODE] <Mode> Selects the timing mode of the measurement. Parameters: <Mode>...
  • Page 484 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems CFLoating | FFLoating Auto scale is activated. The scaling of the Y-axis is selected in such a way, that the trace is always visible. To this end, the range is either expanded if the minimum or maximum values of the trace move outside the current scale or scaled down if the trace fits into a reduced scale.
  • Page 485 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Parameters: <Minimum> float Range: -200 to 100 Increment: 0.01 *RST: Example: SENS:SWE:POW:YSC:MIN -10DBM Sets -10 dBm as the lower limit of the measurement diagram. Manual operation: " Min - Max Level - Power Analysis "...
  • Page 486 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems :SENSe[:POWer]:SWEep:TIME:REFerence:DATA:POINts? Queries the number of points from the reference curve in "Time" measurement. Return values: <Points> integer Range: 10 to 1000 *RST: Example: SENS:POW:SWE:TIME:REF:DATA:POIN? Queries the number of points from the reference curve in time mode.
  • Page 487 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Manual operation: " Execution - Power Analysis " on page 234 :SENSe[:POWer]:SWEep:TIME:SPACing[:MODE] <Mode> Queries the sweep spacing for the power versus time measurement. The spacing is fixed to linear. Parameters: <Mode>...
  • Page 488 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Parameters: <Stop> float Range: 0 to 2 Increment: 1E-12 *RST: 1E-3 Example: SENS:SWE:TIME:STOP 1ms Sets the stop time to 1 ms. Manual operation: "Max - Power Analysis" on page 232 :SENSe[:POWer]:SWEep:TIME:TEVents <TriggerTEvents>...
  • Page 489 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems CFLoating | FFLoating Auto scale is activated. The scaling of the Y-axis is selected in such a way, that the trace is always visible. To this end, the range is either expanded if the minimum or maximum values of the trace move outside the current scale or scaled down if the trace fits into a reduced scale.

  • Page 490: Trace Subsystem

    ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Parameters: <Minimum> float Range: -200 to 100 Increment: 0.01 *RST: Example: SENS:SWE:TIME:YSC:MIN -10DBM Sets -10 dBm as the lower limit of the measurement diagram. Manual operation: " Min - Max Level - Power Analysis "...
  • Page 491 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems :TRACe<ch>[:POWer]:SWEep:MEASurement:POWer:LREFerence:DISPlay: ....................493 ANNotation[:STATe] :TRACe<ch>[:POWer]:SWEep:MEASurement:POWer:MAXimum:DISPlay:ANNotation[: ........................493 STATe] :TRACe<ch>[:POWer]:SWEep:MEASurement:POWer:MINimum:DISPlay:ANNotation[: ........................493 STATe] :TRACe<ch>[:POWer]:SWEep:MEASurement:POWer:REFerence:DISPlay:ANNotation[: ........................493 STATe] :TRACe<ch>[:POWer]:SWEep:MEASurement:POWer:PULSe:TOP:DISPlay: ....................493 ANNotation[:STATe] :TRACe<ch>[:POWer]:SWEep:MEASurement:PULSe:SEParation:DISPlay:ANNotation[: ........................493 STATe] :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:NEGative:DURation:DISPlay: ....................493 ANNotation[:STATe] :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:NEGative:OCCurrence: ................. 493 DISPlay:ANNotation[:STATe] :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:NEGative:OVERshoot: ................. 493 DISPlay:ANNotation[:STATe] :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:POSitive:DURation:DISPlay: ....................493...
  • Page 492 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems :TRACe<ch>[:POWer]:SWEep:COPY <Copy> Stores the selected trace data as reference trace. Setting parameters: <Copy> REFerence Example: TRAC2:SWE:COPY REF Stores the current trace2 as reference trace' TRAC1:SWE:FEED REF Assigns the reference trace to trace 1.
  • Page 493 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems :TRACe<ch>[:POWer]:SWEep:DATA:YSValue? <XValue> For a given x-axis value, queries the measurement (y-axis) value of the selected trace of the current power analysis. Query parameters: <XValue> float Return values: <YSValue> float Increment: 1E-9 Example: TRACe1:SWE:DATA:YSValue? 2.3...
  • Page 494 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Example: TRAC2:SWE:COPY REF Stores trace2 as reference trace. TRAC1:SWE:FEED REF Assigns the reference trace to trace 1. TRAC1:SWE:STAT ON Assigns the reference trace to trace 1. SENS:SWE:RMOD SING Selects single measurement...
  • Page 495 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Options: Option R&S SMAB-K28 Manual operation: "Overshoot (Rising Edge / Falling Edge)" on page 247 :TRACe<ch>[:POWer]:SWEep:MEASurement:PULSe:DCYCle:DISPlay: ANNotation[:STATe] <State> :TRACe<ch>[:POWer]:SWEep:MEASurement:PULSe:DURation:DISPlay: ANNotation[:STATe] <State> :TRACe<ch>[:POWer]:SWEep:MEASurement:PULSe:PERiod:DISPlay: ANNotation[:STATe] <State> :TRACe<ch>[:POWer]:SWEep:MEASurement:POWer:AVERage:DISPlay: ANNotation[:STATe] <State> :TRACe<ch>[:POWer]:SWEep:MEASurement:POWer:PULSe:BASE:DISPlay: ANNotation[:STATe] <State>...
  • Page 496 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Example: TRAC:SWE:MEAS:TRAC2:PULS:PER:DISP:ANN ON Selects the pulse period to be indicated in the display. TRAC:SWE:MEAS:PULS:DISP:ANN ON Activates indication of the selected pulse data in the display. Options: Option R&S SMAB-K28 Manual operation: "Overshoot (Rising Edge / Falling Edge)"...
  • Page 497 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Parameters: <HReference> float Range: 0.0 to 100.0 Increment: 0.01 *RST: 90.0 Example: TRAC2:SWE:PULS:THR:POW:HREF? Queries the upper reference level of trace 2. Manual operation: " Distal - Pulse Data Analysis "...
  • Page 498 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Parameters: <State> OFF | ON | HOLD *RST: The preset value for each trace is evaluated during runtime as follows: If a sensor is plugged into the generator whose number corresponds to the trace number, this sensor is used to feed the trace and the state of the trace is ON;...
  • Page 499 ® Remote Control Commands R&S SMA100B Power Sensor Measurement Subsystems Example: TRAC:SWE:MEAS:GATE:DISP:ANN ON The diagram also shows the gate information. Options: Option R&S SMAB-K28 Manual operation: " State - Gate " on page 238 :TRACe[:POWer]:SWEep:MEASurement:MARKer:DISPlay:ANNotation[:STATe] <State> Activates the indication of the markers and the marker list in the measurement diagram and in the hardcopy file.

  • Page 500: Sense, Read, Initiate And Slist Subsystems

    13.15 SENSe, READ, INITiate and SLISt Subsystems These subsystems contain the commands for configuring the power measurements with R&S NRP power sensor connected to the R&S SMA100B. The local state is set with the INIT command. Switching off the local state enhances the measurement performance.
  • Page 501 ® Remote Control Commands R&S SMA100B SENSe, READ, INITiate and SLISt Subsystems Programming examples Example: Detecting and assigning a power sensor SLISt:LIST? // Response: "NRP33SN-V-900007-USB Legacy","NRP-Z211-900001-USB Legacy" // list of automatically detected sensors SLISt:SCAN:STATe 1 // searches for sensors connected in the LAN or via the USBTMC protocol...
  • Page 502 ® Remote Control Commands R&S SMA100B SENSe, READ, INITiate and SLISt Subsystems Example: Performing a power measurement with a fixed filter Prerequisite: The sensor is connected to the instrument and mapped to the first sensor channel. SENSe1:SOURce RF //Sensor measures the power of the RF signal...
  • Page 503 ® Remote Control Commands R&S SMA100B SENSe, READ, INITiate and SLISt Subsystems ................. 507 :SENSe<ch>[:POWer]:FILTer:TYPE ..................508 :SENSe<ch>[:POWer]:FREQuency ................508 :SENSe<ch>[:POWer]:LOGGing:STATe ..................509 :SENSe<ch>[:POWer]:OFFSet ................509 :SENSe<ch>[:POWer]:OFFSet:STATe ................... 509 :SENSe<ch>[:POWer]:SNUMber? ..................509 :SENSe<ch>[:POWer]:SOURce ................. 510 :SENSe<ch>[:POWer]:STATus[:DEVice]? ...................510 :SENSe<ch>[:POWer]:SVERsion? ..................510 :SENSe<ch>[:POWer]:TYPE? ...................511 :SENSe<ch>[:POWer]:ZERO :SLISt[:LIST]? Returns a list of all detected sensors in a comma-separated string.
  • Page 504 ® Remote Control Commands R&S SMA100B SENSe, READ, INITiate and SLISt Subsystems Parameters: <Mapping> SENS1 | SENSor1 | SENS2 | SENSor2 | SENS3 | SENSor3 | SENS4 | SENSor4 | UNMapped Sensor channel. *RST: UNMapped Example: Example "Detecting and assigning a power sensor"...
  • Page 505 ® Remote Control Commands R&S SMA100B SENSe, READ, INITiate and SLISt Subsystems Note: This command does not affect the local state, i.e. you can get results with local state on or off. For long measurement times, we recommend that you use an SRQ for command synchronization (MAV bit).
  • Page 506 ® Remote Control Commands R&S SMA100B SENSe, READ, INITiate and SLISt Subsystems To specify a user-defined value, use the command :SENSe<ch>[:POWer]: on page 504. APERture:TIMe Parameters: <UseDefAp> 0 | 1 | OFF | ON *RST: Example: Example "Performing a power measurement with a fixed fil- ter"...
  • Page 507 ® Remote Control Commands R&S SMA100B SENSe, READ, INITiate and SLISt Subsystems :SENSe<ch>[:POWer]:CORRection:SPDevice:LIST? Queries the list of the S-parameter data sets that have been loaded to the power sen- sor. Return values: <List> string list *RST: Usage: Query only Manual operation: "...
  • Page 508 ® Remote Control Commands R&S SMA100B SENSe, READ, INITiate and SLISt Subsystems Example: SENS1:FILT:TYPE AUTO Selects auto filter. SENS1:FILT:LENG:AUTO? Queries the automatically set filter length. Response: 1024 Usage: Query only Manual operation: "Filter Length" on page 220 :SENSe<ch>[:POWer]:FILTer:LENGth[:USER] <User> Selects the filter length for USER.
  • Page 509 ® Remote Control Commands R&S SMA100B SENSe, READ, INITiate and SLISt Subsystems :SENSe<ch>[:POWer]:FILTer:NSRatio:MTIMe <MTime> Sets an upper limit for the settling time of the auto-averaging filter in the NSRatio mode and thus limits the length of the filter. The filter type is set with command SENSe<ch>[:POWer]:FILTer:TYPE.
  • Page 510 ® Remote Control Commands R&S SMA100B SENSe, READ, INITiate and SLISt Subsystems NSRatio Selects the filter length (averaging factor) according to the crite- rion that the intrinsic noise of the sensor (2 standard deviations) does not exceed the specified noise content. You can define the noise content with command :SENSe<ch>[:POWer]:FILTer:...
  • Page 511 ® Remote Control Commands R&S SMA100B SENSe, READ, INITiate and SLISt Subsystems :SENSe<ch>[:POWer]:OFFSet <Offset> Sets a level offset which is added to the measured level value after activation with command :SENSe<ch>[:POWer]:OFFSet:STATe. The level offset allows, e.g. to consider an attenuator in the signal path.
  • Page 512 ® Remote Control Commands R&S SMA100B SENSe, READ, INITiate and SLISt Subsystems Note: When measuring the RF signal, the sensor considers the corresponding correc- tion factor at that frequency, and uses the level setting of the instrument as reference level.

  • Page 513: Source Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem Manual operation: "Sensor type and serial number" on page 218 :SENSe<ch>[:POWer]:ZERO Performs zeroing of the sensor. Zeroing is required after warm-up, i.e. after connecting the sensor. Note: Switch off or disconnect the RF power source from the sensor before zeroing.

  • Page 514: Analog Modulation Subsystems

    ® Remote Control Commands R&S SMA100B SOURce Subsystem 13.16.1 Analog Modulation Subsystems Option: see Chapter 4.1, "Required Options", on page 73. The subsystems in this section describe all commands for analog modulation of the RF signal. Divided in separate sections, you can configure amplitude modulation (AM), fre- quency modulation (FM) , phase modulation (PhiM) and pulse modulation (PULM).

  • Page 515: Source:am Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem 13.16.1.2 SOURce:AM Subsystem Option: R&S SMAB-K720 The AM subsystem contains the commands for setting the amplitude modulation and also the broadband amplitude modulation. The following examples show some variants for generating AM signals.
  • Page 516 ® Remote Control Commands R&S SMA100B SOURce Subsystem SOURce1:AM1:RATio 100 SOURce1:AM2:DEPTh:LINear 25 // Query the deviation depth of modulation signal in the first path SOURce1:AM1:DEPTh:LINear? // Response: SOURce1:AM1:STATe 1 SOURce1:AM2:STATe 1 Example: Using an external signal source Using an external signal source, you can additionally determine whether you want to use only the AC component of the external modulation signal.
  • Page 517 ® Remote Control Commands R&S SMA100B SOURce Subsystem // Activating the external exponential AM changes the coupling // in this example for EXT2 INPut:MODext:COUPling2 DC // Configure the modulation settings // Switch on AM and RF signal output SOURce1:AM1:STATe 1...
  • Page 518 ® Remote Control Commands R&S SMA100B SOURce Subsystem LF1|LF2 Uses an internally generated LF signal. EXT1|EXT2 Uses an externally supplied LF signal. NOISe Uses the internally generated noise signal. INTernal Uses the internally generated signal of LF1. EXTernal Uses an external LF signal (EXT1).
  • Page 519 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:AM<ch>:DEPTh:EXPonential <DepthExp> Sets the depth of the exponential amplitude modulation in dB/volt. Parameters: <DepthExp> float Range: 0 to 100 Increment: 0.01 *RST: Example: Example "Creating an amplitude modulated RF signal" on page 513. Similar to DEPTh.
  • Page 520 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:AM:DEViation:MODE <AmDevMode> Selects the coupling mode. The coupling mode parameter also determines the mode for fixing the total depth. Parameters: <AmDevMode> UNCoupled | TOTal | RATio UNCoupled Does not couple the LF signals.

  • Page 521: Source:fm Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:AM<ch>:SENSitivity[:LINear] <Sensitivity> LIN, sets the sensitivity of the external signal source [:SOURce<hw>]:AM:TYPE for amplitude modulation. Parameters: <Sensitivity> float Range: 0 to 100 Increment: 0.1 *RST: Example: Example "Using an external signal source"...
  • Page 522 ® Remote Control Commands R&S SMA100B SOURce Subsystem SOURce1:LFOutput1:FREQuency 20000 // Configure the frequency modulation settings and switch FM on SOURce1:FM1:SOURce LF1 SOURce1:FM1:DEViation 1000 SOURce1:FM:RATio 40 SOURce1:FM:MODe LNOise SOURce1:FM1:STATe 1 // Switch on LF and RF signal output SOURce1:LFOutput1:STATe 1...
  • Page 523 ® Remote Control Commands R&S SMA100B SOURce Subsystem // Set RF frequency and amplitude SOURce1:FREQuency:CW 6000000000 SOURce1:POWer:LEVel:IMMediate:AMPLitude -25 // Configure the frequency modulation settings and switch FM on SOURce1:FM1:SOURce EXT1 SOURce1:FM1:DEViation 5000 // Query the input sensitivity at the external modulation input...
  • Page 524 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Deviation> float The maximum deviation depends on the RF frequency and the selected modulation mode (see data sheet). Range: 0 to max Increment: 0.01 *RST: Example: Example "Creating a frequency modulated RF signal"...
  • Page 525 ® Remote Control Commands R&S SMA100B SOURce Subsystem TOTal Couples the deviation of both paths. RATio Couples the deviation ratio of both paths *RST: UNCoupled Example: Example "Using combined LF signals" on page 520. Manual operation: "Deviation Mode" on page 80 [:SOURce<hw>]:FM:DEViation:SUM <FmDevSum>...

  • Page 526: Source:pm Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem *RST: HBANdwidth Example: Example "Creating a frequency modulated RF signal" on page 519. Manual operation: "Mode" on page 80 [:SOURce<hw>]:FM:SENSitivity? Queries the sensitivity of the externally supplied signal for frequency modulation. The sensitivity depends on the set modulation deviation.
  • Page 527 ® Remote Control Commands R&S SMA100B SOURce Subsystem SOURce1:PM1:RATio 40 SOURce1:PM1:MODE HBAN // Alternatively configure the phase modulation settings for an // external modulation source and query the input sensitivity. SOURce1:PM1:SOURce EXT1 // SOURce1:PM1:SOURce EXTernal SOURce1:PM1:DEViation 1 SOURce1:PM1:SENSitivity? // Response: 1 // since the voltage value for full modulation is 1V, // the resulting sensitivity is precisely 1RAD/V.
  • Page 528 ® Remote Control Commands R&S SMA100B SOURce Subsystem ..................526 [:SOURce<hw>]:PM<ch>:STATe .................. 526 [:SOURce<hw>]:PM<ch>:SOURce .................... 527 [:SOURce<hw>]:PM:MODE ................527 [:SOURce<hw>]:PM:DEViation:MODE ................527 [:SOURce<hw>]:PM:DEViation:SUM ....................528 [:SOURce<hw>]:PM:RATio ..................528 [:SOURce<hw>]:PM:SENSitivity? ..................528 [:SOURce]:PM<ch>[:DEViation] [:SOURce<hw>]:PM<ch>:STATe <State> Activates phase modulation. Activation of phase modulation deactivates frequency modulation.
  • Page 529 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:PM:MODE <Mode> Selects the mode for the phase modulation. Parameters: <Mode> HBANdwidth | HDEViation | LNOise HBANdwidth Sets the maximum available bandwidth. HDEViation Sets the maximum range for ΦM deviation. LNOise Selects a phase modulation mode with phase noise and spuri- ous characteristics close to CW mode.

  • Page 530: Source:pulm Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem Manual operation: "Total Deviation" on page 81 [:SOURce<hw>]:PM:RATio <Ratio> Sets the deviation ratio (path2 to path1) in percent. Parameters: <Ratio> float Range: 0 to 100 Increment: 0.01 *RST: Example: Example "Performing phase modulation"...

  • Page 531: Pulse Modulation Settings

    ® Remote Control Commands R&S SMA100B SOURce Subsystem ● Pulse Modulation Settings..................529 ● Pulse Train Settings....................534 ● Pulse Train Data Exchange.................. 537 Pulse Modulation Settings With the commands described in this section, you can configure the settings for pulse modulation, select the trigger mode and determine delay times for the pulse modula- tion signal.
  • Page 532 ® Remote Control Commands R&S SMA100B SOURce Subsystem SOURce:PULM:STATe 1 OUTPut1:STATe 1 The following commands are available: ..................530 [:SOURce<hw>]:PULM:MODE ................530 [:SOURce<hw>]:PULM:TRIGger:MODE ........... 531 [:SOURce]:PULM[:INTernal][:TRAin]:TRIGger:IMMediate ..................531 [:SOURce<hw>]:PULM:PERiod ..................531 [:SOURce<hw>]:PULM:WIDTh ..................531 [:SOURce<hw>]:PULM:DELay ................532 [:SOURce<hw>]:PULM:DOUBle:DELay ................532 [:SOURce<hw>]:PULM:DOUBle:WIDTh ................
  • Page 533 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Mode> AUTO | EXTernal | EGATe | SINGle | ESINgle *RST: AUTO Example: Example "Perform pulse modulation" on page 529. Manual operation: "Trigger Mode" on page 86 [:SOURce]:PULM[:INTernal][:TRAin]:TRIGger:IMMediate SINGle, triggers the pulse generator.
  • Page 534 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Delay> float *RST: Example: Example "Perform pulse modulation" on page 529. Manual operation: "Pulse Delay" on page 89 [:SOURce<hw>]:PULM:DOUBle:DELay <Delay> Sets the delay from the start of the first pulse to the start of the second pulse.
  • Page 535 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:PULM:SOURce <Source> Selects between the internal (pulse generator) or an external pulse signal for the mod- ulation. Parameters: <Source> INTernal | EXTernal *RST: INTernal Example: Example "Perform pulse modulation" on page 529.

  • Page 536: Pulse Train Settings

    ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:PULM:POLarity <Polarity> Sets the polarity of the externally applied modulation signal. Parameters: <Polarity> NORMal | INVerted NORMal Suppresses the RF signal during the pulse pause. INVerted Suppresses the RF signal during the pulse.
  • Page 537 ® Remote Control Commands R&S SMA100B SOURce Subsystem Example: Generating a pulse train signal The following settings are required to perform pulse train modulation. Always create and select pulse train data list first before you activate the pulse train mode.
  • Page 538 ® Remote Control Commands R&S SMA100B SOURce Subsystem ............. 537 [:SOURce<hw>]:PULM:TRAin:OFFTime:POINts? .................537 [:SOURce<hw>]:PULM:TRAin:REPetition ................537 [:SOURce<hw>]:PULM:TRAin:SELect [:SOURce<hw>]:PULM:TRAin:CATalog? Queries the available pulse train files in the specified directory. Return values: <Catalog> string List of list filenames, separated by commas Example: Example "Generating a pulse train signal"...

  • Page 539: Pulse Train Data Exchange

    ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:PULM:TRAin:REPetition:POINts? [:SOURce<hw>]:PULM:TRAin:ONTime:POINts? [:SOURce<hw>]:PULM:TRAin:OFFTime:POINts? Queries the number of on and off time entries and repetitions in the selected list. Return values: <Points> integer Range: 0 to INT_MAX *RST: Example: Example "Generating a pulse train signal"...
  • Page 540 ® Remote Control Commands R&S SMA100B SOURce Subsystem SOURce1:PULM:STATe 1 SOURce1:PULM:TRAin:DEXChange:MODE EXP SOURce1:PULM:TRAin:DEXChange:AFILe:EXTension TXT SOURce1:PULM:TRAin:DEXChange:AFILe:SEParator:DECimal DOT SOURce1:PULM:TRAin:DEXChange:AFILe:SEParator:COLumn SEM SOURce1:PULM:TRAin:DEXChange:AFILe:SEParator:COLumn COMM SOURce1:PULM:TRAin:DEXChange:SELect "/var/user/pt.pulstrn" SOURce1:PULM:TRAin:DEXChange:AFILe:SELect "/var/user/pt_script.txt" SOURce1:PULM:TRAin:DEXChange:EXECute The following commands are available: ............538 [:SOURce<hw>]:PULM:TRAin:DEXChange:MODE ..........538 [:SOURce<hw>]:PULM:TRAin:DEXChange:AFILe:EXTension ....... 539 [:SOURce<hw>]:PULM:TRAin:DEXChange:AFILe:SEParator:DECimal ....... 539 [:SOURce<hw>]:PULM:TRAin:DEXChange:AFILe:SEParator:COLumn...
  • Page 541 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:PULM:TRAin:DEXChange:AFILe:SEParator:DECimal <Decimal> Sets "." (decimal point) or "," (comma) as the decimal separator used in the ASCII data with floating-point numerals. Parameters: <Decimal> DOT | COMMa *RST: Example: "Pulse Train Data Exchange"...

  • Page 542: Avionic Standards Subsystems

    ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:PULM:TRAin:DEXChange:SELect <Filename> Selects the ASCII file for import or export, containing a pulse train list. Parameters: <Filename> string Filename or complete file path; file extension can be omitted. Example: "Pulse Train Data Exchange"...

  • Page 543: Programming Examples

    ® Remote Control Commands R&S SMA100B SOURce Subsystem Example: SCPI command <subsystem>:SETTing:STATe: ● Entry Standard = ADF SOURce:ADF:STATe ● Entry Standard = ILS SOURce:ILS:STATe ● Entry Standard = VOR SOURce:VOR:STATe ● Invalid command <Subsystem>:STAT Contents ● Programming Examples..................541 ● General Commands....................
  • Page 544 ® Remote Control Commands R&S SMA100B SOURce Subsystem Example: Configure and generate a ADF signal SOURce1:ADF:PRESet // Configure ADF COM/ID settings. SOURce1:ADF:COMid:PERiod 9 SOURce1:ADF:COMid:FREQuency 1020 SOURce1:ADF:COMid:DEPTh 11 SOURce1:ADF:COMid:TSCHema USER SOURce1:ADF:COMid:DOT 0.11 SOURce1:ADF:COMid:DASH 0.29 SOURce1:ADF:COMid:SYMBol 0.11 SOURce1:ADF:COMid:LETTer 0.29 SOURce1:ADF:COMid:STATe 1 SOURce1:ADF:STATe 1...
  • Page 545 ® Remote Control Commands R&S SMA100B SOURce Subsystem SOURce1:ILS:STATe 1 Example: Configure and generate an ILS localizer signal SOURce1:ILS:PRESet // Configure ILS localizer general settings. SOURce1:ILS:TYPE LOC SOURce1:ILS:LOCalizer:FREQuency:MODE USER SOURce1:ILS:LOCalizer:FREQuency 108100000 SOURce1:ILS:LOCalizer:FREQuency:SYNChronize 1 SOURce1:ILS:GS:FREQuency? // 108100000 SOURce1:ILS:LOCalizer:FREQuency:MODE ICAO SOURce1:ILS:LOCalizer:ICAO:CHANnel CH26Y...
  • Page 546 ® Remote Control Commands R&S SMA100B SOURce Subsystem SOURce1:ILS:STATe 1 Example: Configure and generate an ILS marker beacons signal SOURce:ILS:PRESet // Configure ILS marker beacons general settings. SOURce1:ILS:TYPE MBE SOURce1:ILS:MBEacon:FREQuency:MODE USER SOURce1:ILS:MBEacon:FREQuency 75000000 SOURce1:ILS:MBEacon:MARKer:FREQuency 400 SOURce1:ILS:MBEacon:MARKer:DEPTh 95 SOURce1:ILS:MBEacon:MARKer:PULSed? // 0 // Configure ILS marker beacons COM/ID settings.

  • Page 547: General Commands

    ® Remote Control Commands R&S SMA100B SOURce Subsystem // Configure VOR position settings. SOURce1:VOR:BANGle 1 SOURce1:VOR:BANGle:DIRection FROM // Configure VOR COM/ID settings. SOURce1:VOR:COMid:PERiod 9 SOURce1:VOR:COMid:FREQuency 1020 SOURce1:VOR:COMid:DEPTh 11 SOURce1:VOR:COMid:TSCHema USER SOURce1:VOR:COMid:DOT 0.11 SOURce1:VOR:COMid:DASH 0.29 SOURce1:VOR:COMid:SYMBol 0.11 SOURce1:VOR:COMid:LETTer 0.29 SOURce1:VOR:COMid:STATe 1 SOURce1:VOR:STATe 1 13.16.2.2...
  • Page 548 ® Remote Control Commands R&S SMA100B SOURce Subsystem <subsystem>:PRESet [:SOURce<hw>]:ADF:PRESet [:SOURce<hw>]:ILS:PRESet [:SOURce<hw>]:VOR:PRESet Sets the parameters of the digital standard to their default values (*RST values speci- fied for the commands). Not affected is the state set with the command SOURce<hw>:VOR:STATe.
  • Page 549 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Filename> "<filename>" Filename or complete file path; file extension can be omitted Example: Example "Save/Recall a configuration" on page 541. Usage: Setting only <subsystem>:SETTing:STATe [:SOURce<hw>]:ADF:STATe <State> [:SOURce<hw>]:ILS:STATe <State> [:SOURce<hw>]:VOR:STATe <State> Activates/deactivates the VOR modulation.

  • Page 550: Source:adf Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem EXT|INT,EXT An external modulation source is used, additional to the internal modulation source. The external signal is input at the Ext connector. Example: Example "Configure and generate a VOR signal" on page 544.
  • Page 551 ® Remote Control Commands R&S SMA100B SOURce Subsystem The COM/ID tone is sent according to the selected code, see Chapter D, "Morse Code Settings", on page 740. If no coding is set, the COM/ID tone is sent uncoded (key down).
  • Page 552 ® Remote Control Commands R&S SMA100B SOURce Subsystem Example: Example "Configure and generate a ADF signal" on page 542. Manual operation: "Dot Length" on page 152 [:SOURce<hw>]:ADF:COMid:FREQuency <Frequency> Sets the frequency of the COM/ID signal. Parameters: <Frequency> float Range: 0.1 to 20E3 Increment: 0.01...

  • Page 553: Source:ils Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:ADF:COMid:SYMBol <Symbol> Sets the length of the Morse code symbol space. Parameters: <Symbol> float Range: 50E-3 to 1 Increment: 1E-4 *RST: 100E-3 Example: Example "Configure and generate a ADF signal" on page 542.
  • Page 554 ® Remote Control Commands R&S SMA100B SOURce Subsystem Commands ....................553 [:SOURce<hw>]:ILS:TYPE ............553 [:SOURce<hw>]:ILS[:GS|GSLope]:DDM:COUPling ............553 [:SOURce<hw>]:ILS[:GS|GSLope]:DDM:CURRent ............554 [:SOURce<hw>]:ILS[:GS|GSLope]:DDM:DIRection ............554 [:SOURce<hw>]:ILS[:GS|GSLope]:DDM:LOGarithmic ..............555 [:SOURce<hw>]:ILS[:GS|GSLope]:DDM:PCT ............. 555 [:SOURce<hw>]:ILS[:GS|GSLope]:DDM:POLarity ..............555 [:SOURce<hw>]:ILS[:GS|GSLope]:DDM:STEP ..............556 [:SOURce<hw>]:ILS[:GS|GSLope]:DDM[:DEPTh] ..............556 [:SOURce<hw>]:ILS[:GS|GSLope]:FREQuency ............556 [:SOURce<hw>]:ILS[:GS|GSLope]:FREQuency:MODE ........ 557 [:SOURce<hw>]:ILS[:GS|GSLope]:FREQuency:SYNChronize[:STATe] ............557...
  • Page 555 ® Remote Control Commands R&S SMA100B SOURce Subsystem ................569 [:SOURce<hw>]:ILS:LOCalizer:SOURce ..............569 [:SOURce<hw>][:ILS]:MBEacon:COMid:CODE ..............569 [:SOURce<hw>][:ILS]:MBEacon:COMid:DASH ..............570 [:SOURce<hw>][:ILS]:MBEacon:COMid:DEPTh ..............570 [:SOURce<hw>][:ILS]:MBEacon:COMid:DOT ............570 [:SOURce<hw>][:ILS]:MBEacon:COMid:FREQuency ..............571 [:SOURce<hw>][:ILS]:MBEacon:COMid:LETTer ............... 571 [:SOURce<hw>][:ILS]:MBEacon:COMid:PERiod ...............571 [:SOURce<hw>][:ILS]:MBEacon:COMid:SYMBol ............572 [:SOURce<hw>][:ILS]:MBEacon:COMid:TSCHema ............... 572 [:SOURce<hw>][:ILS]:MBEacon:COMid[:STATe] ..............572 [:SOURce<hw>][:ILS]:MBEacon:FREQuency ............
  • Page 556 ® Remote Control Commands R&S SMA100B SOURce Subsystem A variation of the instrument current automatically leads to a variation of the DDM value and the DDM value in dB. Parameters: <Current> float Range: -8.57125E-4 to 8.57125E-4 Increment: 1E-7 *RST: Example: Example "Configure and generate an ILS glide slope signal"...
  • Page 557 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:ILS[:GS|GSLope]:DDM:PCT <Pct> Sets the difference in depth of modulation between the signal of the upper lobe (90 Hz) and the lower lobe (150 Hz). The maximum value equals the sum of the modulation depths of the 90 Hz and the 150 Hz tone.
  • Page 558 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:ILS[:GS|GSLope]:DDM[:DEPTh] <Depth> Sets the difference in depth of modulation between the signal of the upper/left lobe (90 Hz) and the lower/right lobe (150 Hz). The maximum value equals the sum of the mod- ulation depths of the 90 Hz and the 150 Hz tone.
  • Page 559 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:ILS[:GS|GSLope]:FREQuency:SYNChronize[:STATe] <Mode> Activates synchronization of the ILS glide slope ICAO channel with the ILS localizer ICAO channel. The ILS glide slope/localizer frequency of the ICAO channel (Table 5-2) is set automat- ically.
  • Page 560 ® Remote Control Commands R&S SMA100B SOURce Subsystem Manual operation: "Down Frequency" on page 131 [:SOURce<hw>]:ILS[:GS|GSLope]:MODE <Mode> Sets the operating mode for the ILS glide slope modulation signal. Parameters: <Mode> NORM | ULOBe | LLOBe NORM ILS glide slope modulation is active.
  • Page 561 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:ILS[:GS|GSLope]:SDM <Sdm> Sets the arithmetic sum of the modulation depths of the upper lobe (90 Hz) and lower lobe (150 Hz) for the ILS glide slope signal contents. The RMS modulation depth of the sum signal depends on the phase setting of both modulation tones.
  • Page 562 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:ILS:LOCalizer:COMid:CODE <Code> Sets the coding of the COM/ID signal by the international short name of the airport (e.g. MUC for the Munich airport). The COM/ID tone is sent according to the selected code, see Chapter D, "Morse Code...
  • Page 563 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Dot> float Range: 0.05 to 1 Increment: 1E-4 *RST: Example: Example "Configure and generate an ILS localizer signal" on page 543. Manual operation: "Dot Length" on page 143 [:SOURce<hw>]:ILS:LOCalizer:COMid:FREQuency <Frequency> Sets the frequency of the COM/ID signal.
  • Page 564 ® Remote Control Commands R&S SMA100B SOURce Subsystem Example: Example "Configure and generate an ILS localizer signal" on page 543. Manual operation: "Period" on page 142 [:SOURce<hw>]:ILS:LOCalizer:COMid:SYMBol <Symbol> Sets the length of the Morse code symbol space. Parameters: <Symbol> float Range: 0.05 to 1...
  • Page 565 ® Remote Control Commands R&S SMA100B SOURce Subsystem Manual operation: "COM/ID State" on page 142 [:SOURce<hw>]:ILS:LOCalizer:DDM:COUPling <Coupling> Selects if the DDM value is fixed or is changed with a change of sum of modulation depths (SDM, see on page 568).
  • Page 566 ® Remote Control Commands R&S SMA100B SOURce Subsystem *RST: LEFT Example: Example "Configure and generate an ILS localizer signal" on page 543. Manual operation: "FlyMode" on page 139 [:SOURce<hw>]:ILS:LOCalizer:DDM:LOGarithmic <Logarithmic> Sets the modulation depth in dB for ILS localizer modulation.
  • Page 567 ® Remote Control Commands R&S SMA100B SOURce Subsystem DDM = [ AM (150 Hz) - AM (90 Hz) ] / 100% Parameters: <Polarity> P90_150 | P150_90 *RST: P90_150 Example: Example "Configure and generate an ILS localizer signal" on page 543.
  • Page 568 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <CarrierFreq> float Range: 100E3 to 6E9 Increment: 0.01 *RST: 108.1E6 Example: Example "Configure and generate an ILS localizer signal" on page 543. Manual operation: "Carrier Frequency" on page 135 [:SOURce<hw>]:ILS:LOCalizer:FREQuency:MODE <IlsLocFreqMode>...
  • Page 569 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <SelIcaoChan> CH18X | CH18Y | CH20X | CH20Y | CH22X | CH22Y | CH24X | CH24Y | CH26X | CH26Y | CH28X | CH28Y | CH30X | CH30Y | CH32X | CH32Y | CH34X | CH34Y | CH36X | CH36Y | CH38X |...
  • Page 570 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:ILS:LOCalizer:PHASe <Phase> Sets the phase between the modulation signals of the left and right antenna lobe of the ILS localizer signal. The zero crossing of the right lobe (150Hz) signal serves as a reference. The angle refers to the period of the signal of the right antenna lobe.
  • Page 571 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Sdm> float Range: 0 to 100 Increment: 0.1 *RST: Example: Example "Configure and generate an ILS localizer signal" on page 543. Manual operation: "Sum of Depth" on page 139 [:SOURce<hw>]:ILS:LOCalizer:SOURce <IlsLocSource>...
  • Page 572 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Dash> float Range: 0.05 to 1 Increment: 1E-4 *RST: Example: Example "Configure and generate an ILS marker beacons signal" on page 544. Manual operation: "Dash Length" on page 148 [:SOURce<hw>][:ILS]:MBEacon:COMid:DEPTh <Depth>...
  • Page 573 ® Remote Control Commands R&S SMA100B SOURce Subsystem Example: Example "Configure and generate an ILS marker beacons signal" on page 544. Manual operation: "Frequency" on page 147 [:SOURce<hw>][:ILS]:MBEacon:COMid:LETTer <Letter> Sets the length of a Morse code letter space. Parameters: <Letter>...
  • Page 574 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>][:ILS]:MBEacon:COMid:TSCHema <Tschema> Sets the time schema of the Morse code for the COM/ID signal. Parameters: <Tschema> STD | USER Activates the standard time schema of the Morse code. The set determines the...
  • Page 575 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Mode> USER | PREDefined *RST: USER Example: Example "Configure and generate an ILS marker beacons signal" on page 544. Manual operation: "Carrier Frequency Mode" on page 144 [:SOURce<hw>][:ILS]:MBEacon:MARKer:FREQuency <Frequency> Sets the modulation frequency of the marker signal for the ILS marker beacon modula- tion signal.

  • Page 576: Source:vor Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Pulsed> 0 | 1 | OFF | ON *RST: Example: Example "Configure and generate an ILS marker beacons signal" on page 544. Manual operation: "Pulsed Marker" on page 145 13.16.2.5 SOURce:VOR Subsystem Option: R&S SMAB-K25...
  • Page 577 ® Remote Control Commands R&S SMA100B SOURce Subsystem Internal modulation source is used. EXT|INT,EXT An external modulation source is used, additional to the internal modulation source. The external signal is input at the Ext connector. Example: Example "Configure and generate a VOR signal"...
  • Page 578 ® Remote Control Commands R&S SMA100B SOURce Subsystem The COM/ID tone is sent according to the selected code, see Chapter D, "Morse Code Settings", on page 740. If no coding is set, the COM/ID tone is sent uncoded (key down).
  • Page 579 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Dot> float Range: 0.05 to 1 Increment: 1E-4 *RST: Example: Example "Configure and generate a VOR signal" on page 544. Manual operation: "Dot Length" on page 123 [:SOURce<hw>]:VOR:COMid:FREQuency <Frequency> Sets the frequency of the COM/ID signal.
  • Page 580 ® Remote Control Commands R&S SMA100B SOURce Subsystem Example: Example "Configure and generate a VOR signal" on page 544. Manual operation: "Period" on page 123 [:SOURce<hw>]:VOR:COMid:SYMBol <Symbol> Sets the length of the Morse code symbol space. Parameters: <Symbol> float Range: 0.05 to 1...
  • Page 581 ® Remote Control Commands R&S SMA100B SOURce Subsystem Manual operation: "COM/ID State" on page 122 [:SOURce<hw>]:VOR:FREQuency <CarrierFreq> Sets the carrier frequency of the signal. Parameters: <CarrierFreq> float Range: 100E3 to 6E9 Increment: 0.01 *RST: 108E6 Example: Example "Configure and generate a VOR signal"...
  • Page 582 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Channel> CH17X | CH17Y | CH19X | CH19Y | CH21X | CH21Y | CH23X | CH23Y | CH25X | CH25Y | CH27X | CH27Y | CH29X | CH29Y | CH31X | CH31Y | CH33X | CH33Y | CH35X | CH35Y | CH37X |...
  • Page 583 ® Remote Control Commands R&S SMA100B SOURce Subsystem SUBCarrier Amplitude modulation of the output signal with the unmodulated FM carrier (9960Hz) of the VOR signal. The modulation depth of the 30 Hz signal can be set with SOURce<hw>]:VOR:SUBCarrier:DEPTh. FMSubcarrier Amplitude modulation of the output signal with the frequency modulated FM carrier (9960Hz) of the VOR signal.

  • Page 584: Source:correction Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Frequency> float Range: 5E3 to 15E3 Increment: 0.01 *RST: 9.96E3 Example: Example "Configure and generate a VOR signal" on page 544. Manual operation: "Subcarrier Frequency" on page 120 [:SOURce<hw>]:VOR:VAR:FREQuency <Frequency> Sets the frequency of the variable and the reference signal. As the two signals must have the same frequency, the setting is valid for both signals.
  • Page 585 ® Remote Control Commands R&S SMA100B SOURce Subsystem Determine the correction values in one of the following ways: ● Measure the RF output level at several frequency points and enter the value pairs manually in a table ● Connect an R&S NRP to the generator output signal and send the command SOURce<hw>]:CORRection:CSET:DATA[:SENSor<ch>][:POWer]:SONCe...
  • Page 586 ® Remote Control Commands R&S SMA100B SOURce Subsystem // Query the currently used correction value SOURce1:CORRection:VALue? // -2.5 // Delete a user correction file SOURce1:CORRection:CSET:DELEte "/var/user/ucor1.uco" Example: Fill user correction data with sensor The following example shows a command sequence to fill a user correction list auto- matically supported by a connected R&S NRP.

  • Page 587: Correction Settings

    ® Remote Control Commands R&S SMA100B SOURce Subsystem // Select source and destination SOURce1:CORRection:DEXChange:AFILe:SELect "/var/user/ucor2ASCII" // Export the user correction data into the ASCII file SOURce1:CORRection:DEXChange:MODE EXPort SOURce1:CORRection:DEXChange:EXECute // Query the available ASCII files with extension .csv SOURce1:CORRection:DEXChange:AFILe:CATalog? // ucor2ASCII,my_ucor...
  • Page 588 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:CORRection:CSET:DATA:FREQuency:POINts? [:SOURce<hw>]:CORRection:CSET:DATA:POWer:POINts? Queries the number of frequency/level values in the selected table. Return values: <Points> integer Range: 0 to 10000 *RST: Example: Example "Create a table with user-defined correction values for the RF level"...
  • Page 589 ® Remote Control Commands R&S SMA100B SOURce Subsystem Example: Example "Create a table with user-defined correction values for the RF level" on page 583 . Usage: Query only Manual operation: "User Correction" on page 202 [:SOURce<hw>]:CORRection:ZERoing:STATe <State> Activates the zeroing procedure before filling the user correction data acquired by a sensor.

  • Page 590: Correction Data Exchange

    ® Remote Control Commands R&S SMA100B SOURce Subsystem Return values: <Catalog> string List of list filenames, separated by commas Example: Example "Create a table with user-defined correction values for the RF level" on page 583 . Usage: Query only Manual operation: "UCOR Data"...
  • Page 591 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Extension> TXT | CSV *RST: Example: Example "User correction data exchange" on page 584 . Manual operation: "ASCII File Settings" on page 94 [:SOURce<hw>]:CORRection:DEXChange:AFILe:SELect <Filename> Selects the ASCII file to be imported or exported.

  • Page 592: Source:frequency Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem Usage: Event Manual operation: "Import / Export" on page 95 [:SOURce<hw>]:CORRection:DEXChange:MODE <Mode> Determines import or export of a user correction list. Specify the source or destination file with the command [:SOURce<hw>]: CORRection:DEXChange:SELect.
  • Page 593 ® Remote Control Commands R&S SMA100B SOURce Subsystem Example: Setting a phase continuous frequency range SOURce1:FREQuency:CW 502000000 SOURce1:FREQuency:PHASE:MODE NARR SOURce1:FREQuency:PHASe:CONTinuous:STATe 1 ****************************************** // Query the frequency range SOURce1:FREQuency:PHASe:CONTinuous:LOW? // Response: 494062500 SOURce1:FREQuency:PHASe:CONTinuous:HIGh? // Response: 503750000 ****************************************** // Vary the frequency. Within the specified range the signal is phase continuous.
  • Page 594 ® Remote Control Commands R&S SMA100B SOURce Subsystem SWEep Sets sweep mode. The instrument processes frequency (and level) settings in defined sweep steps. Set the range and current frequency with the commands: on page 595 and [:SOURce<hw>]:FREQuency:STARt on page 595, SOURce<hw>]:FREQuency:STOP...
  • Page 595 ® Remote Control Commands R&S SMA100B SOURce Subsystem Range: (RFmin + OFFSet) to (RFmax + OFFSet) *RST: 100 MHz Example: Example "Frequency configuration" on page 590 Example: Example "Setup an RF frequency or power sweep" on page 643 Options: RFmax depends on the installed options, for example 3 GHz with R&S SMAB-B103...
  • Page 596 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:FREQuency:MULTiplier <Multiplier> Sets the multiplication factor N of a subsequent downstream instrument. FREQ:MULT The parameters offset f and multiplier N affect the frequency value FREQ:OFFSer FREQ:MULT set with the command FREQ. The query...
  • Page 597 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Center> float Range: 300 kHz to RFmax Increment: 0.01 Hz *RST: 300E6 Default unit: Hz Example: Example "Setup an RF frequency or power sweep" on page 643 Manual operation: " Center Frequency "...
  • Page 598 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Stop> float Range: 300kHz to RFmax Increment: 0.01Hz *RST: 500 MHz Default unit: Hz Example: Example "Setup an RF frequency or power sweep" on page 643 Manual operation: " Start Frequency/Stop Frequency "...
  • Page 599 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:FREQuency:PLL:MODE <Mode> Selects the PLL (Phase Locked Loop) bandwidth of the main synthesizer. Parameters: <Mode> NORMal | NARRow NORMal Maximum modulation bandwidth and FM/PhiM deviation. NARRow Narrow PLL bandwidth *RST: NORMal Example:...

  • Page 600: Source:input Subsystem

    [:SOURce<hw>]:FREQuency:PHASe: on page 597. CONTinuous:LOW? Note: Restricted structure of command line. In phase continuous mode, the R&S SMA100B only processes the first command of a command line and ignores further commands if they are on the same line. Parameters: <State>...

  • Page 601: Source:lfoutput Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem *RST: INP:MOD:COUP AC Example: Selects the coupling mode AC for an externally applied modula- tion signal. Manual operation: "Coupling (AC/DC)" on page 102 [:SOURce<hw>]:INPut:MODext:IMPedance<ch> <Impedance> Sets the impedance for the externally supplied modulation signal.
  • Page 602 ® Remote Control Commands R&S SMA100B SOURce Subsystem SOURce1:LFOutput1:SWEep:FREQuency:MODE AUTO SOURce1:LFOutput1:FREQuency:STARt 1 kHz SOURce1:LFOutput1:FREQuency:STOP 7 kHz // Select linear spacing // Select the waveform shape for the frequency sweep cycle // Set the step width and the dwell time. SOURce1:LFOutput1:SWEep:FREQuency:SPACing LINear...

  • Page 603: Lf Generator Settings

    ® Remote Control Commands R&S SMA100B SOURce Subsystem SOURce1:LFOutput1:SHAPe:PULSe:WIDTh 0.0005 SOURce1:LFOutput1:SHAPe:PULSe:DCYCle 0.5 // configure the signal of the LF1 generator SOURce1:LFOutput2:SHAPe SINE SOURce1:LFOutput2:FREQuency 1000000 SOURce1:LFOutput2:PERiod? // 0.000001 // changing the LF signal shape // SOURce1:LFOutput2:SHAPe TRAP // SOURce1:LFOutput2:SHAPe:PULSe:PERiod 0.2 // SOURce1:LFOutput2:SHAPe:TRAPeze:RISE 0.0001 // SOURce1:LFOutput2:SHAPe:TRAPeze:FALL 0.001...
  • Page 604 ® Remote Control Commands R&S SMA100B SOURce Subsystem ............607 [:SOURce<hw>]:LFOutput<ch>:SHAPe:PULSe:WIDTh ............ 607 [:SOURce<hw>]:LFOutput<ch>:SHAPe:TRAPeze:FALL ............ 607 [:SOURce<hw>]:LFOutput<ch>:SHAPe:TRAPeze:HIGH ..........607 [:SOURce<hw>]:LFOutput<ch>:SHAPe:TRAPeze:PERiod ............ 608 [:SOURce<hw>]:LFOutput<ch>:SHAPe:TRAPeze:RISE ..........608 [:SOURce<hw>]:LFOutput<ch>:SHAPe:TRIangle:PERiod ............. 608 [:SOURce<hw>]:LFOutput<ch>:SHAPe:TRIangle:RISE [:SOURce]:LFOutput<ch>:BANDwidth? Queries the bandwidth of the external LF signal. Return values: <Bandwidth> BW0M2 | BW10m...
  • Page 605 ® Remote Control Commands R&S SMA100B SOURce Subsystem Return values: <LfSinePeriod> float Range: 1E-6 to 100 Increment: 10E-9 *RST: 0.001 Default unit: s Example: Example "Configuring the LF generator" on page 600. Usage: Query only [:SOURce<hw>]:LFOutput:FREQuency:MANual <Manual> Sets the frequency of the subsequent sweep step if LFO:SWE:MODE MAN.
  • Page 606 ® Remote Control Commands R&S SMA100B SOURce Subsystem Example: Example "Setup an LF sweep" on page 599. Manual operation: "State (LF frequency sweep)" on page 99 [:SOURce<hw>]:LFOutput:FREQuency:STOP <Stop> [:SOURce<hw>]:LFOutput:FREQuency:STARt <Start> Sets the start/stop frequency for [:SOURce<hw>]:LFOutput:FREQuency:MODE SWEep. Parameters: <Start> float Range: 0.1 Hz to 1 MHz...
  • Page 607 ® Remote Control Commands R&S SMA100B SOURce Subsystem Example: Example "Configuring the LF generator" on page 600. Manual operation: "Output Voltage" on page 105 [:SOURce]:LFOutput:OFFSet <Offset> Sets a DC offset at the LF Output. Parameters: <Offset> float Range: depends on lfo voltage Increment: 0.001...
  • Page 608 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce]:LFOutput:VOLTage <Voltage> Sets the voltage of the LF output. Parameters: <Voltage> float Range: dynamic (see data sheet) Increment: 0.001 *RST: Example: SOURce:LFOutput:VOLTage 1.5 [:SOURce<hw>]:LFOutput<ch>:SHAPe <Shape> Selects the waveform shape of the LF signal.
  • Page 609 ® Remote Control Commands R&S SMA100B SOURce Subsystem Manual operation: "Period" on page 101 [:SOURce<hw>]:LFOutput<ch>:SHAPe:PULSe:WIDTh <Width> Sets the pulse width of the generated pulse. Parameters: <Width> float Range: 1E-6 to 100 Increment: 1E-8 *RST: 5E-4 Example: Example "Configuring the LF generator"...
  • Page 610 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Period> float Range: 1E-6 to 100 Increment: 1E-8 *RST: 1E-3 Example: Example "Configuring the LF generator" on page 600. Manual operation: "Period" on page 101 [:SOURce<hw>]:LFOutput<ch>:SHAPe:TRAPeze:RISE <Rise> Selects the rise time for the trapezoid shape of the LF generator.

  • Page 611: Lf Sweep Settings

    ® Remote Control Commands R&S SMA100B SOURce Subsystem 13.16.6.2 LF Sweep Settings With the commands described in this section, you can configure the sweep of the LF signal............ 609 [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:DWELl ..........609 [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:EXECute ............609 [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:MODE ...........610 [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:POINts ..........610 [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:RETRace...
  • Page 612 ® Remote Control Commands R&S SMA100B SOURce Subsystem AUTO Performs a complete sweep cycle from the start to the end value when a trigger event occurs. The dwell time determines the time period until the signal switches to the next step.
  • Page 613 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:RUNNing? Queries the current status of the LF frequency sweep mode. Return values: <State> 0 | 1 | OFF | ON Example: Example "Setup an LF sweep" on page 599. Usage: Query only [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:SHAPe <Shape>...

  • Page 614: Source:list Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem Manual operation: " Step Linear/Step Logarithmic " on page 177 [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:STEP[:LINear] <Linear> Sets the step width for the linear sweep. For information on how the value is calculated and the interdependency with other parameters, see Chapter 6.2.1, "Correlating Parameters in Sweep...
  • Page 615 ® Remote Control Commands R&S SMA100B SOURce Subsystem // Query the amount of free memory (in bytes) for list mode lists SOUR1:LIST:FREQ 58 MHz, 61 MHz, 73 MHz, 86 MHz, 91 MHz, 92 MHz, 98 MHz SOUR1:LIST:POW 13 dBm, 12 dBm, 5 dBm, 3 dBm, 0 dBm, 4 dBm, 6 dBm...
  • Page 616 ® Remote Control Commands R&S SMA100B SOURce Subsystem // Activate the list mode SOUR1:FREQ:MODE LIST // For each step: select frequency/powerlevel pair as index from the list SOUR1:LIST:IND 2 SOUR1:LIST:IND 3 SOUR1:LIST:IND 4 // Use the selected list for path B (with List Mode B default settings) SOUR2:LIST:SEL "/var/user/list1.lsw"...

  • Page 617: List Mode Settings

    ® Remote Control Commands R&S SMA100B SOURce Subsystem ● List Mode Settings....................615 ● List Mode File Operation..................620 ● List Mode Data Exchange..................622 13.16.7.1 List Mode Settings With the following commands, you can create list mode data, select the trigger mode and determine the dwell time.
  • Page 618 ® Remote Control Commands R&S SMA100B SOURce Subsystem LIST Uses the dwell time, specified in the data table for each value pair individually. GLOBal Uses a constant dwell time, set with command SOURce<hw>]:LIST:DWELl. *RST: GLOBal Example: Example "Create an RF list and activate the list mode"...
  • Page 619 ® Remote Control Commands R&S SMA100B SOURce Subsystem You can either enter the data as a list of numbers, or as binary block data. The list of numbers can be of any length, with the list entries separated by commas.
  • Page 620 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Start>/<Stop> integer Index range Only values inside this range are processed in list mode Range: 0 to list length *RST: Example: Example "Create an RF list and activate the list mode"...
  • Page 621 ® Remote Control Commands R&S SMA100B SOURce Subsystem Default unit: dBm Example: Example "Create an RF list and activate the list mode" on page 612. Manual operation: "Edit List Mode Data" on page 190 [:SOURce<hw>]:LIST:POWer:POINts? Queries the number (points) of level entries in the selected list.

  • Page 622: List Mode File Operation

    ® Remote Control Commands R&S SMA100B SOURce Subsystem AUTO|IMMediate The trigger is free-running, i.e. the trigger condition is fulfilled continuously. The selected list is restarted as soon as it is fin- ished. SINGle|BUS The list is triggered by the command [:SOURce<hw>]:LIST:...
  • Page 623 ® Remote Control Commands R&S SMA100B SOURce Subsystem Usage: Query only Manual operation: " List Mode Data " on page 185 [:SOURce<hw>]:LIST:DELete <Filename> Deletes the specified list. Setting parameters: <Filename> string Filename or complete file path; file extension is optional.

  • Page 624: List Mode Data Exchange

    ® Remote Control Commands R&S SMA100B SOURce Subsystem Return values: <Free> integer Range: 0 to INT_MAX *RST: Example: Example "Create an RF list and activate the list mode" on page 612. Usage: Query only [:SOURce<hw>]:LIST:RESet Jumps to the beginning of the list.
  • Page 625 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:LIST:DEXChange:AFILe:CATalog? Queries the available ASCII files for export or import of list mode data in the current or specified directory. Return values: <Catalog> string List of ASCII files *.txt or *.csv, separated by commas.
  • Page 626 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:LIST:DEXChange:AFILe:SEParator:COLumn <Column> Selects the separator between the frequency and level column of the ASCII table. Parameters: <Column> TABulator | SEMicolon | COMMa | SPACe *RST: COMMa Example: Example "List mode data exchange"...

  • Page 627: Source:noise Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem 13.16.8 SOURce:NOISe Subsystem The SOURce:NOISe subsystem contains the commands for setting the noise modula- tion signal. The noise generator is optional. Example: Configuring the noise generator SOURce1:NOISe:DISTribution GAUSs SOURce1:NOISe:BANDwidth 10000000 SOURce1:NOISe:BANDwidth:STATe 1...

  • Page 628: Source:pgen Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:NOISe:DISTribution <Distribution> Sets the distribution of the noise power density. Parameters: <Distribution> GAUSs | EQUal *RST: GAUSs Example: Example "Configuring the noise generator" on page 625. Manual operation: "Distribution" on page 103 [:SOURce<hw>]:NOISe:LEVel:RELative?
  • Page 629 ® Remote Control Commands R&S SMA100B SOURce Subsystem Example: Using pulse generator as source for pulse modulation // select pulse generator as source for pulse modulation // enable pulse modulation SOURce1:PULM:SOURce INT SOURce1:PULM:STATe 1 // pulse generator and signal output are also activated...

  • Page 630: Source:phase Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem Manual operation: "Pulse Output State" on page 89 [:SOURce<hw>]:PGENerator:STATe <State> Enables the output of the video/sync signal. If the pulse generator is the current modulation source, activating the pulse modulation automatically activates the signal output and the pulse generator.

  • Page 631: Source:power Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem Example: Example "Programming Example" on page 628. Usage: Event Manual operation: "Reset Delta Phase Display" on page 72 13.16.11 SOURce:POWer Subsystem The SOURce:POWer subsystem contains the commands for setting the output level, level control and level correction of the RF signal.
  • Page 632 SOURce Subsystem 0|OFF Provided only for backward compatibility with other Rohde & Schwarz signal generators. The R&S SMA100B accepts these values and maps them auto- matically as follows: 0|OFF = OFFTable ONTable Starts with the attenuation setting from the table and continues with automatic level control.
  • Page 633 ® Remote Control Commands R&S SMA100B SOURce Subsystem FATTenuation The step attenuator switches to maximum attenuation UNCHanged Retains the current setting and keeps the output impedance constant during RF off. *RST: n.a. (factory preset: FATTenuation) Example: SOURce1:POWer:ATTenuation:RFOFf:MODE FATTenuation uses maximum attenuation when the RF output is turned off.
  • Page 634 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Amplitude> float Range: depends on the installed options Increment: 0.01 *RST: n.a. (factory preset: 30) Example: SOURce1:POWer:LIMit:AMPLitude 10 Manual operation: " Limit " on page 69 [:SOURce<hw>]:POWer:LMODe <LevMode> Sets the RF level mode.
  • Page 635 ® Remote Control Commands R&S SMA100B SOURce Subsystem Manual operation: " Current Level" on page 172 [:SOURce<hw>]:POWer:MODE <Mode> Selects the operating mode of the instrument to set the output level. Parameters: <Mode> CW | FIXed | SWEep CW|FIXed Operates at a constant level.
  • Page 636 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:POWer:STARt <Start> [:SOURce<hw>]:POWer:STOP <Stop> Sets the RF start/stop level in sweep mode. Parameters: <Stop> float Sets the setting range calculated as follows: (Level_min + OFFSet) to (Level_max + OFFSet) Where the values are set with the commands: [:SOURce<hw>]:POWer[:LEVel][:IMMediate]:OFFSet...
  • Page 637 ® Remote Control Commands R&S SMA100B SOURce Subsystem Note: The command also sets "Variation Step" in the manual control, that means the user-defined step width for setting the level with the rotary knob or the [Up/Down] arrow keys. Parameters: <Increment>...
  • Page 638 ® Remote Control Commands R&S SMA100B SOURce Subsystem EXCLude Retains the current level when an instrument configuration is loaded. *RST: INCLude Example: POW:RCL INCL Takes the level value from an instrument configuration loaded with command *RCL. Manual operation: "Exclude Level"...

  • Page 639: Source:roscillator Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem Return values: <Upper> float Increment: 0.01 Default unit: dBm Example: SOURce1:POWer:RANGe:UPPer? // -15 SOURce1:POWer:RANGe:LOW? // -50 Usage: Query only Manual operation: " Level Range " on page 70 [:SOURce]:POWer:WIGNore <State> Ignores level range warnings.
  • Page 640 ® Remote Control Commands R&S SMA100B SOURce Subsystem Example: Configuring the reference oscillator // Using 100 MHz external reference source SOURce:ROSCillator:PRESet SOURce:ROSCillator:SOURce EXT SOURce:ROSCillator:EXTernal:RFOFf:STATe 1 SOURce:ROSCillator:EXTernal:FREQuency 100MHZ SOURce:ROSCillator:EXTernal:SBANdwidth WIDE // 100 MHz (loop thought) and 1 GHz output SOURce:ROSCillator:OUTPut:FREQuency:MODE LOOP...
  • Page 641 ® Remote Control Commands R&S SMA100B SOURce Subsystem ..........642 [:SOURce]:ROSCillator:OUTPut:ALTernate:FREQuency:MODE .............. 642 [:SOURce]:ROSCillator[:INTernal]:ADJust:VALue .............643 [:SOURce]:ROSCillator[:INTernal]:ADJust[:STATe] [:SOURce]:ROSCillator:PRESet Resets the reference oscillator settings. Example: Example "Configuring the reference oscillator" on page 638. Usage: Event Manual operation: "Set to Default" on page 273 [:SOURce]:ROSCillator:SOURce <Source>...
  • Page 642 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce]:ROSCillator:EXTernal:RFOFf[:STATe] <State> Determines that the RF output is turned off when the external reference signal is selected, but missing. Parameters: <State> 0 | 1 | OFF | ON *RST: n.a. (factory preset: 0) Example: Example "Configuring the reference oscillator"...
  • Page 643 SMA100B SOURce Subsystem NARRow The synchronization bandwidth is a few Hz. Suitable for external reference sources with phase noise worse than the R&S SMA100B. WIDE Uses the widest possible synchronization bandwidth. For more information, see data sheet. *RST: n.a. (factory preset) Example: Example "Configuring the reference oscillator"...
  • Page 644 ® Remote Control Commands R&S SMA100B SOURce Subsystem LOOPthrough This option is unavailable for ROSCillator:EXTernal:FREQuency 1GHZ. Forwards the input reference frequency to the reference frequency output. *RST: n.a. (factory preset: DER10M) Example: Example "Configuring the reference oscillator" on page 638.

  • Page 645: Source:sweep Subsystem

    ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce]:ROSCillator[:INTernal]:ADJust[:STATe] <State> Determines whether the calibrated (off) or a user-defined (on) adjustment value is used for fine adjustment of the frequency. Parameters: <State> 0 | 1 | OFF | ON Fine adjustment with the calibrated frequency value User-defined adjustment value.
  • Page 646 ® Remote Control Commands R&S SMA100B SOURce Subsystem // (especially with short dwell times) // Set the sweep mode (first two commands) and the sweep range // Select linear spacing // Select the waveform shape for the frequency sweep *RST; *CLS...
  • Page 647 ® Remote Control Commands R&S SMA100B SOURce Subsystem // Input the frequency manually for each step SOURce1:FREQuency:MANual 200 MHz SOURce1:FREQuency:MANual 201 MHz // Alternatively use the UP or DOWN commands with the set step width. SOURce1:SWEep:FREQuency:STEP:LINear 1 MHz SOURce1:FREQuency:MANual UP .......................
  • Page 648 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Dwell> float Range: 3E-3 to 100 Increment: 100E-6 *RST: 10E-3 Default unit: s Example: Example "Setup an RF frequency or power sweep" on page 643. Manual operation: " Dwell Time "...
  • Page 649 ® Remote Control Commands R&S SMA100B SOURce Subsystem Example: Example "Setup an RF frequency or power sweep" on page 643. Manual operation: "Mode" on page 172 [:SOURce<hw>]:SWEep:POWer:POINts <Points> Sets the number of steps within the RF level sweep range. Chapter 6.2.1, "Correlating Parameters in Sweep Mode",...
  • Page 650 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:SWEep[:FREQuency]:DWELl <Dwell> Sets the dwell time for a frequency sweep step. Parameters: float Range: 3E-3 (R&S SMAB-B709/-B710/-B710N), 5E-3 (R&S SMAB-B711/-B711N) to 100 Increment: 100E-6 *RST: 10E-3 Default unit: s Note: The minimum dwell time varies, depending on the phase noise options the instrument is equipped with (see the data sheet for the specifications).
  • Page 651 ® Remote Control Commands R&S SMA100B SOURce Subsystem Two separate POINts values are used for linear or logarithmic sweep spacing LOG). The command SOURce<hw>]:SWEep[:FREQuency]:SPACing LIN | always affects the currently set sweep spacing. Parameters: <Points> integer Range: 2 to Max Example: Example "Setup an RF frequency or power sweep"...
  • Page 652 ® Remote Control Commands R&S SMA100B SOURce Subsystem [:SOURce<hw>]:SWEep:POWer:EXECute [:SOURce<hw>]:SWEep[:FREQuency]:EXECute Executes an RF frequency sweep. The command performs a single sweep and is therefore only effective in manual sweep mode. Example: Example "Setup an RF frequency or power sweep" on page 643.
  • Page 653 ® Remote Control Commands R&S SMA100B SOURce Subsystem Parameters: <Logarithmic> float The unit is mandatory. Range: 0.01 to 100 Increment: 1E-3 *RST: Default unit: PCT Example: Example "Setup an RF frequency or power sweep" on page 643. Manual operation: " Step Linear/Step Logarithmic "...
  • Page 654 ® Remote Control Commands R&S SMA100B SOURce Subsystem Options: R&S SMAB-B28 Manual operation: " Sweep Time " on page 174 [:SOURce<hw>]:SWEep:MARKer:OUTPut:POLarity <Polarity> Selects the polarity of the marker signal. Parameters: <Polarity> NORMal | INVerted NORMal Marker level is high when after reaching the mark.

  • Page 655: System Subsystem

    ® Remote Control Commands R&S SMA100B SYSTem Subsystem Example: SOURce1:SWEep:MARKer:OUTPut:POLarity NORMal three markers at 1 GHz, 2 GHz and 3 GHz SOURce1:SWEep:FREQuency:MARKer1:FREQuency 1000000000 SOURce1:SWEep:FREQuency:MARKer2:FREQuency 2000000000 SOURce1:SWEep:FREQuency:MARKer3:FREQuency 3000000000 SOURce1:SWEep:FREQuency:MARKer1:FSTate 1 SOURce1:SWEep:FREQuency:MARKer2:FSTate 1 SOURce1:SWEep:FREQuency:MARKer3:FSTate 1 SOURce1:SWEep:FREQuency:MARKer:ACTive M03 Options: R&S SMAB-B28 Manual operation: "...
  • Page 656 Example: Retrieving information on network-related settings SYSTem:COMMunicate:NETWork:STATus? // 1 SYSTem:PROTection1:STATe 0,123456 SYSTem:COMMunicate:NETWork:IPADdress:MODE STAT SYSTem:COMMunicate:NETWork:IPADdress "10.113.0.104" SYSTem:COMMunicate:NETWork:IPADdress:DNS "10.0.2.166" SYSTem:COMMunicate:NETWork:COMMon:HOSTname? // "SMA100B-102030" SYSTem:COMMunicate:NETWork:COMMon:WORKgroup "instrument" SYSTem:COMMunicate:NETWork:COMMon:DOMain "rsint.net" SYSTem:COMMunicate:NETWork:IPADdress:GATeway "10.113.0.1" SYSTem:COMMunicate:NETWork:IPADdress:SUBNet:MASK "255.255.252.0" SYSTem:COMMunicate:NETWork:MACaddress "08 00 27 a3 a1 70" SYSTem:PROTection1:STATe 1 Example: Finding out the used VISA ressource strings SYSTem:COMMunicate:NETWork:RESource? // "TCPIP::10.113.0.104::inst0::INSTR"...
  • Page 657 ® Remote Control Commands R&S SMA100B SYSTem Subsystem Example: Querying the error queue SYSTem:ERRor:STATic? // -221,"Settings conflict", 153,"Input voltage out of range", ... // returns all static errors that are collected in the error queue SYSTem:ERRor:HISTory:ClEar // deletes the history entries ....................656...
  • Page 658 ® Remote Control Commands R&S SMA100B SYSTem Subsystem ......................669 :SYSTem:LANGuage ....................669 :SYSTem:INFormation:SCPI ................670 :SYSTem:SECurity:SANitize[:STATe] ................... 670 :SYSTem:SECurity:SUPolicy ....................670 :SYSTem:SPECification? ..................671 :SYSTem:SPECification:VERSion ...............671 :SYSTem:SPECification:IDENtification:CATalog? ................672 :SYSTem:SPECification:PARameter? ..............672 :SYSTem:SPECification:VERSion:CATalog? ..............672 :SYSTem:SPECification:VERSion:FACTory? ......................673 :SYSTem:SRData? ..................673 :SYSTem:STARtup:COMPlete? ......................673 :SYSTem:DATE .....................
  • Page 659 ® Remote Control Commands R&S SMA100B SYSTem Subsystem Example: SYST:ERR:ALL? Queries all entries in the error queue. Response: 0, 'no error' No errors have occurred since the error queue was last read out. Usage: Query only Manual operation: "Clear History"...
  • Page 660 ® Remote Control Commands R&S SMA100B SYSTem Subsystem Example: SYST:ERR:CODE Queries the oldest entry in the error queue. Response: 0 No errors have occurred since the error queue was last read out. Usage: Query only :SYSTem:ERRor:COUNt? Queries the number of entries in the error queue.
  • Page 661 ® Remote Control Commands R&S SMA100B SYSTem Subsystem :SYSTem:ERRor:GNEXt? Similar to :SYSTem:ERRor[:NEXT]?, but queries the next entry from the global per- sistant error/event queue. Return values: <NextGlobalError> string Error/event number, "Error/event description> [;Device depend- ent info]" An error number and a short description of the error.
  • Page 662 ® Remote Control Commands R&S SMA100B SYSTem Subsystem DONLy Locks the touchscreen and controls for the manual operation of the instrument. The display shows the current settings. VNConly Locks the touchscreen and controls for the manual operation, and enables remote operation over VNC. The display shows the current settings.
  • Page 663 ® Remote Control Commands R&S SMA100B SYSTem Subsystem :SYSTem:SAV <Pathname> Saves the current instrument settings to a file with defined filename. Setting parameters: <Pathname> string Example: SYSTem:SAV "/var/user/Instrument_settings.svrcltxt" Usage: Setting only :SYSTem:RCL <Pathname> Loads a file with previously saved instrument settings.
  • Page 664 ® Remote Control Commands R&S SMA100B SYSTem Subsystem :SYSTem:SECurity:VOLMode[:STATe] <SecPassWord>, <MmemProtState> Activates volatile mode, so that no user data can be written to the internal memory per- manently. To enable volatile mode, reboot the instrument. Otherwise the change has no effect.
  • Page 665 ® Remote Control Commands R&S SMA100B SYSTem Subsystem Usage: Query only :SYSTem:COMMunicate:GPIB[:SELF]:ADDRess <Address> Sets the GPIB address. Parameters: <Address> integer Range: 0 to 30 *RST: Example: Example "Finding out the used VISA ressource strings" on page 654. :SYSTem:COMMunicate:HISLip:RESource? Queries the VISA resource string . This string is used for remote control of the instru- ment with HiSLIP protocol.
  • Page 666 ® Remote Control Commands R&S SMA100B SYSTem Subsystem Example: SYSTem:COMMunicate:NETWork:IPADdress:MODE STATic SYSTem:COMMunicate:NETWork:IPADdress "10.113.0.105" Manual operation: "Address Mode" on page 359 :SYSTem:COMMunicate:NETWork:MACaddress <MacAddress> Queries the MAC address of the network adapter. This is a password-protected function. Unlock the protection level 1 to access it, see SYSTem:PROTect<ch>[:STATe].
  • Page 667 ® Remote Control Commands R&S SMA100B SYSTem Subsystem Usage: Query only Manual operation: "Network Status" on page 358 :SYSTem:COMMunicate:NETWork[:COMMon]:DOMain <Domain> Determines the primary suffix of the network domain. Parameters: <Domain> string Example: Example "Retrieving information on network-related set- tings" on page 654.
  • Page 668 ® Remote Control Commands R&S SMA100B SYSTem Subsystem Manual operation: "DNS Server" on page 360 :SYSTem:COMMunicate:NETWork[:IPADdress]:GATeway <Gateway> Sets the IP address of the default gateway. Parameters: <Gateway> string Range: 0.0.0.0 to ff.ff.ff.ff Example: Example "Retrieving information on network-related set- tings"...
  • Page 669 ® Remote Control Commands R&S SMA100B SYSTem Subsystem :SYSTem:COMMunicate:SERial:RESource? Queries the visa resource string for the serial remote control interface. This string is used for remote control of the instrument. Return values: <Resource> string Example: Example "Finding out the used VISA ressource strings"...
  • Page 670 Selects the mode to determine the "IDN String" and the "OPT String" for the instru- ment, selected with command :SYSTem:LANGuage. Note: While working in an emulation mode, the R&S SMA100B specific command set is disabled, that is, the SCPI command SYST:IDEN is discarded.
  • Page 671 ® Remote Control Commands R&S SMA100B SYSTem Subsystem Example: SYST:IDEN USER // Selects a user-defined identification SYST:IRES "Test Device" // Defines identification string 'test device' *IDN? // Response: 'test device' Manual operation: "IDN String" on page 364 :SYSTem:ORESponse <OResponse> Defines the user defined response string for *OPT.
  • Page 672 ® Remote Control Commands R&S SMA100B SYSTem Subsystem :SYSTem:SECurity:SANitize[:STATe] <SecPassWord>, <MmemProtState> Sanitizes the internal memory. Parameters: <MmemProtState> 0 | 1 | OFF | ON *RST: Setting parameters: <SecPassWord> string Example: SYSTem:SECurity:SANitize[:STATe] 1 Manual operation: "Sanitize" on page 336 :SYSTem:SECurity:SUPolicy <SecPassWord>, <Update Policy>...
  • Page 673 ® Remote Control Commands R&S SMA100B SYSTem Subsystem Example: Retrieving instruments specification Note: The following values are merely an example. Query the data sheet versions stored in the instrument: :SYSTem:SPECification:VERSion:CATalog? "04.03,04.02,04.01,04.00,03.04,03.03,03.02, 03.01,03.00,02.96,02.95,02.94,02.02,02.01, 02.00,01.03,01.02,01.01,01.00" Query the data sheet version with that the instrument was deliv-...
  • Page 674 ® Remote Control Commands R&S SMA100B SYSTem Subsystem Return values: <IdList> string Comma-separated string of the parameter identifiers (<Id>) Example: on page 670. :SYSTem:SPECification? Usage: Query only :SYSTem:SPECification:PARameter? <Id>[, <Parameter>] Retrieves data sheet information for a specific parameter. Setting parameters: <Id>...
  • Page 675 ® Remote Control Commands R&S SMA100B SYSTem Subsystem Usage: Query only Manual operation: "Versions" on page 701 :SYSTem:SRData? Queris the SCPI recording data from the internal file. This feature enables you to transfer an instrument configuration to other test environ- ments, as e.g.
  • Page 676 ® Remote Control Commands R&S SMA100B SYSTem Subsystem Example: :SYSTem:DATE? // 2016,05,01 Manual operation: "Date" on page 690 :SYSTem:NTP:HOSTname <NTPName> Sets the address of the NTP server. You can enter the IP address, or the hostname of the time server, or even set up an own vendor zone. See the Internet for more informa- tion on NTP.
  • Page 677 ® Remote Control Commands R&S SMA100B SYSTem Subsystem :SYSTem:TIME:ZONE <TimeZone> Sets the timezone. You can query the list of the available timezones with :SYSTem: TIME:ZONE:CATalog?. Parameters: <TimeZone> string Manual operation: "Timezone" on page 691 :SYSTem:TIME:ZONE:CATalog? Querys the list of available timezones.
  • Page 678 Queries the operating system of the instrument. Return values: <OperSystem> string Example: SYSTem:OSYStem? Response: "Linux" Usage: Query only :SYSTem:MMEMory:PATH:USER? Queries the user directory, that means the directory the R&S SMA100B stores user files on. Return values: <PathUser> string Example: SYSTem:MMEMory:PATH:USER? Response: "'/var/user/" Usage: Query only :SYSTem:DFPR? Queries the device footprint of the instrument.

  • Page 679: Status Subsystem

    ® Remote Control Commands R&S SMA100B STATus Subsystem :SYSTem:RESTart Restarts the instrument without restarting the operating system. Usage: Event :SYSTem:SHUTdown Shuts down the instrument. Usage: Event Manual operation: "Shut down" on page 697 :SYSTem:WAIT <TimeMs> Delays the execution of the subsequent remote command by the specified time.
  • Page 680 Return values: A decimal value in the range 0 to 32767 (=2 ● The configuration commands set the respective register thus determining which status changes of the R&S SMA100B cause the status registers to be changed. Setting values: A decimal value in the range 0 to 32767 (=2 ..................678 :STATus:OPERation:CONDition? ...................678...
  • Page 681 ® Remote Control Commands R&S SMA100B STATus Subsystem :STATus:OPERation[:EVENt] <Event> Queries the content of the EVENt part of the STATus:OPERation register. This part contains information on the actions performed in the instrument since the last readout. The content of the EVENt part is deleted after being read out.
  • Page 682 ® Remote Control Commands R&S SMA100B STATus Subsystem Example: STAT:PRES resets the status registers. :STATus:QUEStionable:CONDition <Condition> Queries the content of the CONDition part of the STATus:QUEStionable register. This part contains information on the action currently being performed in the instrument.

  • Page 683: Test Subsystem

    ® Remote Control Commands R&S SMA100B TEST Subsystem Example: STAT:QUES:NTR 0 a transition from 1 to 0 in the condition part of the STA- Tus:QUEStionable register does not cause an entry to be made in the EVENt part :STATus:QUEStionable:PTRansition <PTransition>...

  • Page 684: Trigger Subsystem

    You can work with an internal or with an externally applied trigger signal. In this case, use the commands in the SOURce:INPut subsystem to configure the signal. The trigger system of the R&S SMA100B is a simplified implementation of the SCPI trigger system. The TRIGger system differs from the SCPI system as follows: ●...
  • Page 685 ® Remote Control Commands R&S SMA100B TRIGger Subsystem ................684 :TRIGger<hw>:FSWeep[:IMMediate] ................684 :TRIGger<hw>:PSWeep[:IMMediate] ................684 :TRIGger<hw>:LFFSweep:IMMediate ................684 :TRIGger<hw>[:SWEep][:IMMediate] ....................684 :TRIGger<hw>:LFFSweep :TRIGger<hw>:FSWeep:SOURce <Source> :TRIGger<hw>:LFFSweep:SOURce <Source> :TRIGger<hw>:PSWeep:SOURce <Source> :TRIGger<hw>[:SWEep]:SOURce <Source> Selects the trigger source for the corresponding sweeps: ● FSWeep - RF frequency ●...
  • Page 686 ® Remote Control Commands R&S SMA100B TRIGger Subsystem EAUTo An external signal triggers the sweep. When one sweep is fin- ished, the next sweep starts. A second trigger event stops the sweep at the current frequency, a third trigger event starts the trigger at the start frequency, and so on.

  • Page 687: Unit Subsystem

    ® Remote Control Commands R&S SMA100B UNIT Subsystem 13.21 UNIT Subsystem The UNIT subsystem is used to set default units for parameters if no unit is indicated in a command. These settings are valid for the entire instrument. Example: Setting default units for remote control...

  • Page 688: Maintenance

    ® Maintenance R&S SMA100B Cleaning 14 Maintenance The instrument does not need periodic maintenance. Only the cleaning of the instru- ment is essential. Follow the instructions in the service manual and the safety instructions when exchanging modules or ordering spares. The order no. for spare parts is included in the service manual.

  • Page 689: Storing And Packing

    ® Maintenance R&S SMA100B Storing and Packing Instrument damage caused by cleaning agents Cleaning agents contain substances such as solvents (thinners, acetone, etc.), acids, bases, or other substances. Solvents can damage the front panel labeling, plastic parts, or screens, for example.

  • Page 690: Performing Maintenance Tasks

    R&S SMA100B Performing Maintenance Tasks 14.3 Performing Maintenance Tasks The R&S SMA100B is accurate due to integrated adjustment procedures, which you can execute directly on the instrument. Internal Adjustments Risk of DUT damage During internal adjustments, the instrument temporarily applies high power at the RF output.

  • Page 691: Date And Time Settings

    The extent of the adjustments depends on the installed options. 14.3.1 Date and Time Settings The R&S SMA100B uses an internal real-time clock to determine the date and time. It adjusts the time and date to the timezone of your location automatically, by providing a selection list of continents and cities.
  • Page 692 ® Maintenance R&S SMA100B Performing Maintenance Tasks The "Date / Time" dialog contains the time and data settings of the operating sys- tem. This function is password-protected. Unlock the protection level 1 to access it. The required remote commands are described in Chapter 13.17, "SYSTem Subsys-...

  • Page 693: Check Front Panel

    ® Maintenance R&S SMA100B Performing Maintenance Tasks Remote command: on page 674 :SYSTem:TIME Timezone Selects the timezone. You can select the timezone according to the major cities on the respective continents. Note: By typing the first letter, you can quickly navigate through the lists to find the desired destination.

  • Page 694: Check Front Panel Settings

    ® Maintenance R&S SMA100B Performing Maintenance Tasks 14.3.2.1 Check Front Panel Settings Access: ► Select "System Config > Setup > Maintenance > Check Front Panel". Reflecting the front panel, the "Check Front Panel" dialog contains all functions to test the operating elements of the instrument.
  • Page 695 ® Maintenance R&S SMA100B Performing Maintenance Tasks Note: Pressing the same key again has no further effect, except for the [Esc] key, Press the ESC key a third time. 5. Continue with the next key on the front panel and repeat...

  • Page 696: Internal Adjustment Settings

    ® Maintenance R&S SMA100B Performing Maintenance Tasks ● If there are any gaps, the touch-sensitive functionality is damaged. ● To return to the "Check Front Panel" dialog, press [Esc]. If there are malfunctions: Contact the Rohde & Schwarz customer support, see Chapter 15.6, "Collecting...
  • Page 697 These functions are password-protected and require higher-level protection pass- word, see "Protection levels" on page 332 For more information, see R&S SMA100B Service Manual. Adjust All Performs all available internal calibration routines of the instrument. NOTICE! Risk of DUT damage. During internal adjustments, the instrument temporarily applies high power at the RF output.
  • Page 698 ® Maintenance R&S SMA100B Performing Maintenance Tasks If the termination resistor is missing, a second warning message appears. Remote command: on page 423 :CALibration:ALL[:MEASure]? Last Full Adjustment Displays the date of the last fully performed adjustment. Remote command: on page 423 :CALibration<hw>:ALL:DATE?

  • Page 699: Fpga/Uc Update Settings

    ® Maintenance R&S SMA100B Performing Maintenance Tasks 14.3.4 FPGA/uC Update Settings Access: ► Select "System Config > Setup > Maintenance > FPGA/µC Update". This dialog enables you to check for and install internal assembly updates. Settings: Check For Updates..................... 697 Assembly........................697...

  • Page 700: Requesting Instrument Configuration And Specifications

    :SYSTem:SHUTdown 14.3.5 Requesting Instrument Configuration and Specifications The R&S SMA100B is equipped with various hardware and software components. To get an overview of what your instrument is equipped with, you can request the assem- blies, hardware and software options, and the firmware version. The components are structured according to the hardware configuration, software options, including the license management, and externally used Rohde &...

  • Page 701: Versions/Options Settings

    Indicates whether the assembly is connected to the serial bus or PCI bus. Remote command: on page 431 :DIAGnostic<hw>:BGINfo? Counter Displays information on the operation times of the R&S SMA100B. Operation Time / h ← Counter Displays the operation time in hours. Remote command: n.a. Power On Count ← Counter Displays the number of power-on.
  • Page 702 ® Maintenance R&S SMA100B Performing Maintenance Tasks The "Versions/Options" dialog shows the version of the installed instrument firm- ware, the hardware and software options, the data sheet and the software compo- nents of the firmware. The BIOS version is also listed; firmware updates do not update the BIOS version.

  • Page 703: Requesting The Data Sheet

    *OPT? on page 407 *IDN? Versions The "Versions" tab shows the versions of the technical specification of the R&S SMA100B and of the software components that comprise the firmware. "Package" Name of the component. "Version" Current issue of the component.

  • Page 704: Troubleshooting And Error Messages

    Error Messages 15 Troubleshooting and Error Messages The R&S SMA100B distinguishes between various messages such as status mes- sages, error messages, warnings, or information that are displayed in the "Info" line on the screen, and also entered in the error/event queue of the status reporting system.

  • Page 705: Scpi-Error Messages

    ® Troubleshooting and Error Messages R&S SMA100B Device-Specific Error Messages The message is displayed until the error is eliminated. It covers the status display in the info line. After error elimination, the message automatically disappears and is also recorded in the history.

  • Page 706: Querying Error Messages

    15.4 Querying Error Messages The R&S SMA100B monitors the functions performed and automatically detects errors and irregularities. The instrument displays the messages in the "Info" line and records them in the background with a detailed description.
  • Page 707 ® Troubleshooting and Error Messages R&S SMA100B Querying Error Messages To display information on static errors and error history 1. In the taskbar, select the "Info" icon. 2. For some messages, the information line appears briefly on the home screen.

  • Page 708: Resolving Network Connection Failures

    SMA100B Resolving Network Connection Failures Indication and handling of permanent messages If any critical error occurs, the R&S SMA100B automatically shows the icon in the taskbar. Select the icon to obtain information on the error and the number of occurren- ces.

  • Page 709: Collecting Information For Technical Support

    ● Observe the link status LED on the R&S SMA100B or the connected network device. The link status LED is located next to the LAN connector. If a link failure is detected, connect the instrument to a different device port or to a different network device.
  • Page 710 702. To collect error information in a support file 1. Connect a USB device to the R&S SMA100B. 2. Select "System Config > Setup > Maintenance > Create R&S Support Information". 3. In the "Create R&S Support Information" dialog, navigate to the /usb directory.
  • Page 711 ► For information on how to handle or remove the sensitive data from your instru- ment, refer to the description "Resolving Security Issues when working with R&S SMA100B". Packing and transporting the instrument ► If the instrument has to be transported or shipped, observe the notes described in Chapter 2.1.1.2, "Unpacking and Checking the...

  • Page 712: Annex

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control Annex A Reference Information for Remote Control A.1 Additional Basics on Remote Control This section provides basic information using the remote control. A.1.1 Messages The messages transferred on the data lines are divided into the following categories: ●...

  • Page 713: A.1.2 Lan Interface Messages

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control – Instrument control commands refer to functions depending on the features of the instrument such as frequency settings. Many of these commands have also been standardized by the SCPI committee. These commands are marked as "SCPI confirmed"...

  • Page 714: A.1.3.1 Syntax For Common Commands

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control The commands can be either device-specific or device-independent (common com- mands). Common and device-specific commands differ in their syntax. A.1.3.1 Syntax for Common Commands Common (= device-independent) commands consist of a header preceded by an aster- isk (*), and possibly one or more parameters.

  • Page 715: Long And Short Form

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control Long and short form The mnemonics feature a long form and a short form. The short form is marked by upper case letters, the long form corresponds to the complete word. Either the short form or the long form can be entered;...

  • Page 716: A.1.3.3 Scpi Parameters

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control Optional mnemonics with numeric suffixes Do not omit an optional mnemonic if it includes a numeric suffix that is relevant for the effect of the command. Example: Definition:DISPlay[:WINDow<1...4>]:MAXimize <Boolean>...

  • Page 717: Special Numeric Values

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control ● N (nano) Example: SENSe:FREQ:STOP 1.5GHz = SENSe:FREQ:STOP 1.5E9 Some settings allow relative values to be stated in percent. According to SCPI, this unit is represented by the PCT string.

  • Page 718: Text Parameters

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control Example: Setting command: HCOPy:DEV:COL ON Query: HCOPy:DEV:COL? Response: 1 Text Parameters Text parameters observe the syntactic rules for mnemonics, i.e. they can be entered using a short or long form. Like any parameter, they have to be separated from the header by a white space.
  • Page 719 ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control Table A-2: Syntax elements The colon separates the mnemonics of a command. The semicolon separates two commands of a command line. It does not alter the path.

  • Page 720: A.1.3.5 Structure Of A Command Line

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control A.1.3.5 Structure of a Command Line A command line may consist of one or several commands. It is terminated by one of the following: ● <New Line>...

  • Page 721: A.1.4 Command Sequence And Synchronization

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control ● Truth values (Boolean values) are returned as 0 (for OFF) and 1 (for ON). Example: Setting command: HCOPy:DEV:COL ON Query: HCOPy:DEV:COL? Response: 1 ● Text (character data) is returned in a short form.
  • Page 722 ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control Table A-4: Synchronization using *OPC, *OPC? and *WAI Com- Action Programming the controller mand ● *OPC Sets the Operation Complete bit in the ESR Setting bit 0 in the ESE ●...

  • Page 723: A.1.4.2 Examples To Command Sequence And Synchronization

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control 3. Poll the operation complete state periodically (with a timer) using the sequence: *OPC; *ESR? A return value (LSB) of 1 indicates that the overlapped command has finished.

  • Page 724: A.1.5 Status Reporting System

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control Example: Overlapped command followed by conflicting commands Suppose that the generator is switched on to provide a real time test signal that requires some calculation time. This signal is to be added to a waveform from the sec- ond baseband generator.

  • Page 725: A.1.5.1 Hierarchy Of The Status Registers

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control A.1.5.1 Hierarchy of the Status Registers Figure A-1 shows the hierarchical structure of information in the status registers (ascending from left to right). Figure A-1: Graphical overview of the status registers hierarchy...

  • Page 726: A.1.5.2 Structure Of A Scpi Status Register

    Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control The R&S SMA100B uses the following status registers: ● Status Byte (STB) and Service Request Enable (SRE), see Chapter A.1.5.3, "Status Byte (STB) and Service Request Enable Register (SRE)",...
  • Page 727 ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control Figure A-2: The status-register model Description of the five status register parts The five parts of a SCPI register have different properties and functions: ● CONDition The CONDition part is written into directly by the hardware or the sum bit of the next lower register.

  • Page 728: A.1.5.3 Status Byte (Stb) And Service Request Enable Register (Sre)

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control read by the user. Reading the register clears it. This part is often equated with the entire register. ● ENABle The ENABle part determines whether the associated EVENt bit contributes to the sum bit (see below).

  • Page 729: A.1.5.4 Event Status Register (Esr) And Event Status Enable Register (Ese)

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control Bit No. Meaning MAV bit (message available) The bit is set if a message is available in the output queue which can be read. This bit can be used to enable data to be automatically read from the instrument to the controller.

  • Page 730: A.1.5.5 Questionable Status Register (Status:questionable)

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control Bit No. Meaning Command Error This bit is set if a command is received, which is undefined or syntactically incorrect. An error message with a number between -100 and -200, which denotes the error in greater detail, is entered into the error queue.

  • Page 731: Service Request

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control receive and evaluate the information of all devices. The following standard methods are used: ● Service request (SRQ) initiated by the instrument ● Serial poll of all devices in the bus system, initiated by the controller to find out who sent an SRQ and why ●...

  • Page 732: Error Queue

    ® Reference Information for Remote Control R&S SMA100B Additional Basics on Remote Control The returned value is always a decimal number that represents the bit pattern of the queried register. This number is evaluated by the controller program. Queries are usually used after an SRQ in order to obtain more detailed information on the cause of the SRQ.

  • Page 733: A.1.6 General Programming Recommendations

    The following program example shows a simple TcpClient class that is intended to explain on how to get started with programming of sockets. The example sets up a socket communication to R&S SMA100B and opens a simple user interface, very similar to the telnet, which allows input of commands. To enable real automation, further development of the program is required.
  • Page 734 ® Reference Information for Remote Control R&S SMA100B Telnet program examples class TcpClient public: TcpClient(); ~TcpClient(); void connectToServer( string &hostname, int port ); void disconnect( ); void transmit( string &txString ); void receive( string &rxString ); string getCurrentHostName( ) const;...
  • Page 735 ® Reference Information for Remote Control R&S SMA100B Telnet program examples #include <netdb.h> #include <netinet/in.h> #include <unistd.h> #include "TcpClient.h" TcpClient::TcpClient() : currentHostName( "" ) , currentPort( 0 ) , currentSocketDescr( 0 ) , serverAddress ( ) , currentHostInfo( NULL )
  • Page 736 ® Reference Information for Remote Control R&S SMA100B Telnet program examples clientIsConnected = true; void TcpClient::disconnect( ) if( clientIsConnected ) close( currentSocketDescr ); currentSocketDescr = 0; currentHostName = ""; currentPort = 0; currentHostInfo = NULL; clientIsConnected = false; void TcpClient::transmit( string &txString ) if( !clientIsConnected ) throw string("connection must be established before any data can be sent\n");...
  • Page 737 ® Reference Information for Remote Control R&S SMA100B Telnet program examples string TcpClient::getCurrentHostName( ) const return currentHostName; int TcpClient::getCurrentPort( ) const return currentPort; TelnetClient.cpp #include <iostream> #include "TcpClient.h" void printUsage() cout<<"usage: EthernetRawCommand <server-ip> [scpi-command]"<<endl; int main( int argc, char *argv[] ) int errorCode = 0;...
  • Page 738 ® Reference Information for Remote Control R&S SMA100B Telnet program examples else cin.getline( buffer, 1024 ); input = buffer; if( input == "end" ) terminate = true; if( !terminate) client.transmit( input ); //send string int qPos = input.find( "?", 0 );...

  • Page 739: B Hardware Interfaces

    ® Hardware Interfaces R&S SMA100B GPIB-Bus Interface B Hardware Interfaces This section covers hardware-related topics, like pin assignment of the IEC 625/IEEE 488 interface. The remote control interfaces are described in details in Chapter 12, "Network Opera- tion and Remote Control",...
  • Page 740 Interface functions Instruments which can be controlled via GPIB-bus interface can be equipped with dif- ferent interface functions. Table B-1 lists the interface functions for the R&S SMA100B. Table B-1: GPIB-bus interface functions Control character Interface function Handshake source function (source handshake), full capability Handshake sink function (acceptor handshake), full capability Listener function, full capability, de-addressed by MTA.

  • Page 741: C Extensions For User Files

    ® Extensions for User Files R&S SMA100B C Extensions for User Files Table C-1 lists all available file extensions for user files. The currently available files on the instrument depend on the installed options. Table C-1: List of the automatically assigned file extensions in the instrument...

  • Page 742: D Morse Code Settings

    ® Morse Code Settings R&S SMA100B D Morse Code Settings The COM/ID tone is sent according to the selected code (see Table D-1). The length of the Morse code can be varied. For selected standard time scheme, the selected dot length determines the setting of all other length parameters of the Morse code (dash length, symbol space and letter space) .

  • Page 743: Glossary: List Of The Often Used Terms And Abbreviations

    1MA193: 1MA193_0e Application Note, "Aeronautical radio navigation measurement solutions" Absolute file path: Complete file path Base unit: This term describes a R&S SMA100B equipped with the option R&S SMAB-B103. Clock: A mandatory internal or an external reference clock signal for generating the timing pulse in the instrument.
  • Page 744 Power: A term describing the signal level of the RF signal product page: A designation of the R&S SMA100B product page http://www.rohde- schwarz.com/product/SMA100B.html Remote access: Remote operation Remote control: The operation of the R&S SMA100B by remote control commands or programs to perform automated tests. User Manual 1178.3834.02 ─ 05...
  • Page 745 Remote operation. Synonyms: External controller, client device Remote operation: Allows you to operate the R&S SMA100B from a remote device via VNC. Both the R&S SMA100B and the remote device are connected in a LAN. Synonym: Remote access Removable memory: General term describing mass memory that can be unmounted from the instrument.
  • Page 746 ® Glossary: List of the Often Used Terms and Abbreviations R&S SMA100B UE: User equipment USBTMC: (USB test & measurement class) A protocol built on top of USB for communication with USB devices. Using VISA library, it supports service request, triggers, and other specific operations, similar to GPIB.

  • Page 747: List Of Commands

    ® List of Commands R&S SMA100B List of Commands :CALCulate[:POWer]:SWEep:FREQuency:MATH<ch>:STATe..............449 :CALCulate[:POWer]:SWEep:FREQuency:MATH<ch>:SUBTract..............450 :CALCulate[:POWer]:SWEep:POWer:MATH<ch>:STATe................450 :CALCulate[:POWer]:SWEep:POWer:MATH<ch>:SUBTract................ 450 :CALCulate[:POWer]:SWEep:TIME:GATE<ch>:AVERage?................451 :CALCulate[:POWer]:SWEep:TIME:GATE<ch>:FEED..................451 :CALCulate[:POWer]:SWEep:TIME:GATE<ch>:MAXimum?.................451 :CALCulate[:POWer]:SWEep:TIME:GATE<ch>:STARt................. 452 :CALCulate[:POWer]:SWEep:TIME:GATE<ch>:STATe................. 452 :CALCulate[:POWer]:SWEep:TIME:GATE<ch>:STOP..................452 :CALCulate[:POWer]:SWEep:TIME:MATH<ch>:STATe.................453 :CALCulate[:POWer]:SWEep:TIME:MATH<ch>:SUBTract................453 :CALibration:ALL[:MEASure]?........................423 :CALibration:DATA:FACTory:DATE?......................424 :CALibration<hw>:ALL:DATE?........................423 :CALibration<hw>:ALL:INFormation?......................423 :CALibration<hw>:ALL:TEMP?........................424 :CALibration<hw>:ALL:TIME?........................424 :CALibration<hw>:CONTinueonerror......................425 :CSYNthesis:FREQuency..........................426 :CSYNthesis:FREQuency:STEP........................429 :CSYNthesis:FREQuency:STEP:MODE......................429 :CSYNthesis:OFFSet............................. 427 :CSYNthesis:OFFSet:STATe..........................427...
  • Page 748 ® List of Commands R&S SMA100B :DISPlay:PSAVe[:STATe]..........................433 :DISPlay:UPDate............................434 :DISPlay[:WINDow][:POWer]:SWEep:BACKground:COLor................453 :DISPlay[:WINDow][:POWer]:SWEep:GRID:STATe..................454 :FORMat:BORDer............................437 :FORMat:SREGister............................437 :FORMat[:DATA]............................438 :HCOPy:DATA?..............................440 :HCOPy:DEVice:LANGuage.......................... 440 :HCOPy:FILE[:NAME]............................440 :HCOPy:FILE[:NAME]:AUTO:DIRectory......................441 :HCOPy:FILE[:NAME]:AUTO:DIRectory:CLEar.....................442 :HCOPy:FILE[:NAME]:AUTO:FILE?......................442 :HCOPy:FILE[:NAME]:AUTO:STATe......................442 :HCOPy:FILE[:NAME]:AUTO?........................441 :HCOPy:FILE[:NAME]:AUTO[:FILE]:DAY:STATe................... 442 :HCOPy:FILE[:NAME]:AUTO[:FILE]:MONTh:STATe..................442 :HCOPy:FILE[:NAME]:AUTO[:FILE]:NUMBer?..................... 443 :HCOPy:FILE[:NAME]:AUTO[:FILE]:PREFix....................443 :HCOPy:FILE[:NAME]:AUTO[:FILE]:PREFix:STATe..................443 :HCOPy:FILE[:NAME]:AUTO[:FILE]:YEAR:STATe..................442 :HCOPy:IMAGe:FORMat..........................440 :HCOPy:REGion............................
  • Page 749 ® List of Commands R&S SMA100B :OUTPut<hw>:PROTection:CLEar.........................447 :OUTPut<hw>:PROTection:TRIPped?......................448 :OUTPut<hw>[:STATe]...........................445 :OUTPut<hw>[:STATe]:PON.......................... 445 :READ<ch>[:POWer]?........................... 454 :READ<ch>[:POWer]?........................... 502 :SENSe[:POWer]:SWEep:ABORt........................465 :SENSe[:POWer]:SWEep:FREQuency:REFerence:DATA:COPY..............465 :SENSe[:POWer]:SWEep:FREQuency:REFerence:DATA:POINts?..............466 :SENSe[:POWer]:SWEep:FREQuency:REFerence:DATA:XVALues.............466 :SENSe[:POWer]:SWEep:FREQuency:REFerence:DATA:YVALues.............466 :SENSe[:POWer]:SWEep:FREQuency:RMODe....................466 :SENSe[:POWer]:SWEep:FREQuency:SPACing[:MODE]................467 :SENSe[:POWer]:SWEep:FREQuency:STARt....................467 :SENSe[:POWer]:SWEep:FREQuency:STEPs..................... 467 :SENSe[:POWer]:SWEep:FREQuency:STOP....................468 :SENSe[:POWer]:SWEep:FREQuency:TIMing[:MODE]................468 :SENSe[:POWer]:SWEep:FREQuency:YSCale:AUTO................. 468 :SENSe[:POWer]:SWEep:FREQuency:YSCale:AUTO:RESet..............469 :SENSe[:POWer]:SWEep:FREQuency:YSCale:MAXimum................469 :SENSe[:POWer]:SWEep:FREQuency:YSCale:MINimum................469 :SENSe[:POWer]:SWEep:HCOPy:DATA?..................... 470 :SENSe[:POWer]:SWEep:HCOPy:DEVice....................
  • Page 750 ® List of Commands R&S SMA100B :SENSe[:POWer]:SWEep:POWer:RMODe....................479 :SENSe[:POWer]:SWEep:POWer:SPACing[:MODE]..................480 :SENSe[:POWer]:SWEep:POWer:STARt...................... 480 :SENSe[:POWer]:SWEep:POWer:STEPs..................... 480 :SENSe[:POWer]:SWEep:POWer:STOP.......................480 :SENSe[:POWer]:SWEep:POWer:TIMing[:MODE]..................481 :SENSe[:POWer]:SWEep:POWer:YSCale:AUTO..................481 :SENSe[:POWer]:SWEep:POWer:YSCale:AUTO:RESet................482 :SENSe[:POWer]:SWEep:POWer:YSCale:MAXimum...................482 :SENSe[:POWer]:SWEep:POWer:YSCale:MINimum..................482 :SENSe[:POWer]:SWEep:RMODe........................ 483 :SENSe[:POWer]:SWEep:TIME:AVERage[:COUNt]..................483 :SENSe[:POWer]:SWEep:TIME:REFerence:DATA:COPY................483 :SENSe[:POWer]:SWEep:TIME:REFerence:DATA:POINts?.................484 :SENSe[:POWer]:SWEep:TIME:REFerence:DATA:XVALues................484 :SENSe[:POWer]:SWEep:TIME:REFerence:DATA:YVALues................484 :SENSe[:POWer]:SWEep:TIME:RMODe.......................484 :SENSe[:POWer]:SWEep:TIME:SPACing[:MODE]..................485 :SENSe[:POWer]:SWEep:TIME:STARt......................485 :SENSe[:POWer]:SWEep:TIME:STEPs......................485 :SENSe[:POWer]:SWEep:TIME:STOP......................485 :SENSe[:POWer]:SWEep:TIME:TEVents...................... 486 :SENSe[:POWer]:SWEep:TIME:YSCale:AUTO....................
  • Page 751 ® List of Commands R&S SMA100B :SENSe<ch>[:POWer]:SWEep:FREQuency[:SENSor]:SRANge:STARt............458 :SENSe<ch>[:POWer]:SWEep:FREQuency[:SENSor]:SRANge:STOP............458 :SENSe<ch>[:POWer]:SWEep:FREQuency[:SENSor]:SRANge[:STATe]............. 458 :SENSe<ch>[:POWer]:SWEep:POWer[:SENSor]:OFFSet................459 :SENSe<ch>[:POWer]:SWEep:POWer[:SENSor]:OFFSet:STATe..............459 :SENSe<ch>[:POWer]:SWEep:POWer[:SENSor]:SFRequency..............460 :SENSe<ch>[:POWer]:SWEep:POWer[:SENSor]:SFRequency:STATe............460 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:OFFSet................460 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:OFFSet:STATe..............461 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:PULSe:STATe..............461 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:PULSe:THReshold:BASE...........461 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:PULSe:THReshold:POWer:HREFerence......462 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:PULSe:THReshold:POWer:LREFerence......462 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:PULSe:THReshold:POWer:REFerence......462 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:SFRequency...............463 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:SFRequency:STATe............463 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:TRIGger:AUTO..............463 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:TRIGger:DTIMe..............464 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:TRIGger:HYSTeresis............464 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:TRIGger:LEVel..............464 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:TRIGger:SLOPe..............464 :SENSe<ch>[:POWer]:SWEep:TIME[:SENSor]:TRIGger:SOURce...............465 :SENSe<ch>[:POWer]:TYPE?........................510 :SENSe<ch>[:POWer]:ZERO........................
  • Page 752 ® List of Commands R&S SMA100B :SYSTem:COMMunicate:NETWork:MACaddress..................664 :SYSTem:COMMunicate:NETWork:RESource?.................... 664 :SYSTem:COMMunicate:NETWork:RESTart....................664 :SYSTem:COMMunicate:NETWork:STATus?....................664 :SYSTem:COMMunicate:NETWork[:COMMon]:DOMain................665 :SYSTem:COMMunicate:NETWork[:COMMon]:HOSTname................. 665 :SYSTem:COMMunicate:NETWork[:COMMon]:WORKgroup................665 :SYSTem:COMMunicate:NETWork[:IPADdress]:DNS...................665 :SYSTem:COMMunicate:NETWork[:IPADdress]:GATeway................666 :SYSTem:COMMunicate:NETWork[:IPADdress]:SUBNet:MASK..............666 :SYSTem:COMMunicate:SERial:BAUD......................666 :SYSTem:COMMunicate:SERial:PARity......................666 :SYSTem:COMMunicate:SERial:RESource?....................667 :SYSTem:COMMunicate:SERial:SBITs......................667 :SYSTem:COMMunicate:SOCKet:RESource?....................667 :SYSTem:COMMunicate:USB:RESource?....................667 :SYSTem:DATE..............................673 :SYSTem:DFPR?............................676 :SYSTem:DLOCk............................660 :SYSTem:ERRor:ALL?...........................656 :SYSTem:ERRor:CODE:ALL?........................657 :SYSTem:ERRor:CODE[:NEXT]?........................
  • Page 753 ® List of Commands R&S SMA100B :SYSTem:SHUTdown.............................677 :SYSTem:SPECification:IDENtification:CATalog?..................671 :SYSTem:SPECification:PARameter?......................672 :SYSTem:SPECification:VERSion......................... 671 :SYSTem:SPECification:VERSion:CATalog?....................672 :SYSTem:SPECification:VERSion:FACTory?....................672 :SYSTem:SPECification?..........................670 :SYSTem:SRData?............................673 :SYSTem:STARtup:COMPlete?........................673 :SYSTem:TIME.............................. 674 :SYSTem:TIME:ZONE........................... 675 :SYSTem:TIME:ZONE:CATalog?........................675 :SYSTem:ULOCk............................659 :SYSTem:UPTime?............................675 :SYSTem:VERSion?............................675 :SYSTem:WAIT.............................. 677 :TEST<hw>:ALL:RESult?..........................682 :TEST<hw>:ALL:STARt..........................681 :TRACe[:POWer]:SWEep:MEASurement:FULLscreen:DISPlay:ANNotation[:STATe]........496 :TRACe[:POWer]:SWEep:MEASurement:GATE:DISPlay:ANNotation[:STATe]..........496 :TRACe[:POWer]:SWEep:MEASurement:MARKer:DISPlay:ANNotation[:STATe].........497 :TRACe[:POWer]:SWEep:MEASurement:PULSe:DISPlay:ANNotation[:STATe]...........497...
  • Page 754 ® List of Commands R&S SMA100B :TRACe<ch>[:POWer]:SWEep:MEASurement:PULSe:DURation?...............492 :TRACe<ch>[:POWer]:SWEep:MEASurement:PULSe:PERiod:DISPlay:ANNotation[:STATe]......493 :TRACe<ch>[:POWer]:SWEep:MEASurement:PULSe:PERiod?..............492 :TRACe<ch>[:POWer]:SWEep:MEASurement:PULSe:SEParation:DISPlay:ANNotation[:STATe]....493 :TRACe<ch>[:POWer]:SWEep:MEASurement:PULSe:SEParation?............492 :TRACe<ch>[:POWer]:SWEep:MEASurement:PULSe:STATe?..............492 :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:NEGative:DURation:DISPlay: ANNotation[:STATe]..........................493 :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:NEGative:DURation?........492 :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:NEGative:OCCurrence:DISPlay: ANNotation[:STATe]..........................493 :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:NEGative:OCCurrence?........492 :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:NEGative:OVERshoot:DISPlay: ANNotation[:STATe]..........................493 :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:NEGative:OVERshoot?........492 :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:POSitive:DURation:DISPlay: ANNotation[:STATe]..........................493 :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:POSitive:DURation?......... 492 :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:POSitive:OCCurrence:DISPlay: ANNotation[:STATe]..........................493 :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:POSitive:OCCurrence?........492 :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:POSitive:OVERshoot:DISPlay: ANNotation[:STATe]..........................493 :TRACe<ch>[:POWer]:SWEep:MEASurement:TRANsition:POSitive:OVERshoot?........492 :TRACe<ch>[:POWer]:SWEep:PULSe:THReshold:BASE?................494 :TRACe<ch>[:POWer]:SWEep:PULSe:THReshold:POWer:HREFerence............ 494 :TRACe<ch>[:POWer]:SWEep:PULSe:THReshold:POWer:LREFerence.............495...
  • Page 755 ® List of Commands R&S SMA100B [:SOURce]:LFOutput<ch>[:STATe]........................ 604 [:SOURce]:PM<ch>[:DEViation]........................528 [:SOURce]:POWer:WIGNore......................... 637 [:SOURce]:PULM[:INTernal][:TRAin]:TRIGger:IMMediate................531 [:SOURce]:ROSCillator:EXTernal:FREQuency....................640 [:SOURce]:ROSCillator:EXTernal:FREQuency:VARiable................640 [:SOURce]:ROSCillator:EXTernal:MLRange?....................641 [:SOURce]:ROSCillator:EXTernal:NSBandwidth?..................641 [:SOURce]:ROSCillator:EXTernal:RFOFf[:STATe]..................640 [:SOURce]:ROSCillator:EXTernal:SBANdwidth..................... 640 [:SOURce]:ROSCillator:INTernal:TUNing:SLOPe..................639 [:SOURce]:ROSCillator:INTernal:TUNing[:STATe]..................639 [:SOURce]:ROSCillator:OUTPut:ALTernate:FREQuency:MODE..............642 [:SOURce]:ROSCillator:OUTPut:FREQuency:MODE................... 641 [:SOURce]:ROSCillator:PRESet........................639 [:SOURce]:ROSCillator:SOURce........................639 [:SOURce]:ROSCillator[:INTernal]:ADJust:VALue..................642 [:SOURce]:ROSCillator[:INTernal]:ADJust[:STATe]..................643 [:SOURce<hw>]:ADF:COMid:CODE......................548 [:SOURce<hw>]:ADF:COMid:DASH......................549 [:SOURce<hw>]:ADF:COMid:DEPTh......................549 [:SOURce<hw>]:ADF:COMid:DOT........................
  • Page 756 ® List of Commands R&S SMA100B [:SOURce<hw>]:CORRection:CSET:DATA[:SENSor<ch>][:POWer]:SONCe..........586 [:SOURce<hw>]:CORRection:CSET:DATA[:SENSor<ch>][:POWer]:SONCe..........587 [:SOURce<hw>]:CORRection:CSET[:SELect]....................586 [:SOURce<hw>]:CORRection:DEXChange:AFILe:CATalog?................588 [:SOURce<hw>]:CORRection:DEXChange:AFILe:EXTension..............588 [:SOURce<hw>]:CORRection:DEXChange:AFILe:SELect................589 [:SOURce<hw>]:CORRection:DEXChange:AFILe:SEParator:COLumn............589 [:SOURce<hw>]:CORRection:DEXChange:AFILe:SEParator:DECimal............589 [:SOURce<hw>]:CORRection:DEXChange:EXECute................... 589 [:SOURce<hw>]:CORRection:DEXChange:MODE..................590 [:SOURce<hw>]:CORRection:DEXChange:SELect..................590 [:SOURce<hw>]:CORRection:VALue?......................586 [:SOURce<hw>]:CORRection:ZERoing:STATe..................... 587 [:SOURce<hw>]:CORRection[:STATe]......................587 [:SOURce<hw>]:FM:DEViation:MODE......................522 [:SOURce<hw>]:FM:DEViation:SUM......................523 [:SOURce<hw>]:FM:MODE........................... 523 [:SOURce<hw>]:FM:RATio..........................523 [:SOURce<hw>]:FM:SENSitivity?........................524 [:SOURce<hw>]:FM<ch>:SOURce........................522...
  • Page 757 ® List of Commands R&S SMA100B [:SOURce<hw>]:ILS:LOCalizer:DDM:COUPling................... 563 [:SOURce<hw>]:ILS:LOCalizer:DDM:CURRent.................... 563 [:SOURce<hw>]:ILS:LOCalizer:DDM:DIRection....................563 [:SOURce<hw>]:ILS:LOCalizer:DDM:LOGarithmic..................564 [:SOURce<hw>]:ILS:LOCalizer:DDM:PCT....................564 [:SOURce<hw>]:ILS:LOCalizer:DDM:POLarity..................... 564 [:SOURce<hw>]:ILS:LOCalizer:DDM:STEP....................565 [:SOURce<hw>]:ILS:LOCalizer:DDM[:DEPTh]....................565 [:SOURce<hw>]:ILS:LOCalizer:FREQuency....................565 [:SOURce<hw>]:ILS:LOCalizer:FREQuency:MODE..................566 [:SOURce<hw>]:ILS:LOCalizer:FREQuency:SYNChronize[:STATe].............548 [:SOURce<hw>]:ILS:LOCalizer:FREQuency:SYNChronize[:STATe].............566 [:SOURce<hw>]:ILS:LOCalizer:ICAO:CHANnel....................566 [:SOURce<hw>]:ILS:LOCalizer:LLOBe[:FREQuency]...................567 [:SOURce<hw>]:ILS:LOCalizer:MODE......................567 [:SOURce<hw>]:ILS:LOCalizer:PHASe......................568 [:SOURce<hw>]:ILS:LOCalizer:PRESet......................568 [:SOURce<hw>]:ILS:LOCalizer:RLOBe[:FREQuency].................. 568 [:SOURce<hw>]:ILS:LOCalizer:SDM......................568 [:SOURce<hw>]:ILS:LOCalizer:SOURce...................... 547 [:SOURce<hw>]:ILS:LOCalizer:SOURce...................... 569 [:SOURce<hw>]:ILS:PRESet.........................546 [:SOURce<hw>]:ILS:SETTing:CATalog?....................... 546 [:SOURce<hw>]:ILS:SETTing:DELete......................546...
  • Page 758 ® List of Commands R&S SMA100B [:SOURce<hw>]:LFOutput:FREQuency:MANual...................603 [:SOURce<hw>]:LFOutput:FREQuency:MODE.....................603 [:SOURce<hw>]:LFOutput:FREQuency:STARt..................... 604 [:SOURce<hw>]:LFOutput:FREQuency:STOP....................604 [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:DWELl................609 [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:EXECute................. 609 [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:MODE................609 [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:POINts................610 [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:RETRace.................610 [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:RUNNing?............... 611 [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:SHAPe................611 [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:SPACing................611 [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:STEP:LOGarithmic............611 [:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:STEP[:LINear]..............612 [:SOURce<hw>]:LFOutput<ch>:PERiod?......................602 [:SOURce<hw>]:LFOutput<ch>:SHAPe......................606 [:SOURce<hw>]:LFOutput<ch>:SHAPe:PULSe:DCYCle................606 [:SOURce<hw>]:LFOutput<ch>:SHAPe:PULSe:PERiod................606 [:SOURce<hw>]:LFOutput<ch>:SHAPe:PULSe:WIDTh................607 [:SOURce<hw>]:LFOutput<ch>:SHAPe:TRAPeze:FALL................607 [:SOURce<hw>]:LFOutput<ch>:SHAPe:TRAPeze:HIGH................607 [:SOURce<hw>]:LFOutput<ch>:SHAPe:TRAPeze:PERiod................607 [:SOURce<hw>]:LFOutput<ch>:SHAPe:TRAPeze:RISE................608 [:SOURce<hw>]:LFOutput<ch>:SHAPe:TRIangle:PERiod................608 [:SOURce<hw>]:LFOutput<ch>:SHAPe:TRIangle:RISE................
  • Page 759 ® List of Commands R&S SMA100B [:SOURce<hw>]:LIST:RUNNing?........................620 [:SOURce<hw>]:LIST:SELect........................622 [:SOURce<hw>]:LIST:TRIGger:EXECute...................... 619 [:SOURce<hw>]:LIST:TRIGger:SOURce.......................619 [:SOURce<hw>]:MODulation[:ALL][:STATe]....................512 [:SOURce<hw>]:NOISe:BANDwidth|BWIDth....................625 [:SOURce<hw>]:NOISe:BWIDth:STATe......................625 [:SOURce<hw>]:NOISe:DISTribution......................626 [:SOURce<hw>]:NOISe:LEVel:RELative?..................... 626 [:SOURce<hw>]:NOISe:LEVel[:ABSolute]?....................626 [:SOURce<hw>]:PGENerator:OUTPut:POLarity................... 627 [:SOURce<hw>]:PGENerator:OUTPut[:STATe]..................... 627 [:SOURce<hw>]:PGENerator:STATe......................628 [:SOURce<hw>]:PHASe..........................628 [:SOURce<hw>]:PHASe:REFerence......................628 [:SOURce<hw>]:PM:DEViation:MODE......................527 [:SOURce<hw>]:PM:DEViation:SUM......................527 [:SOURce<hw>]:PM:MODE...........................527 [:SOURce<hw>]:PM:RATio..........................528 [:SOURce<hw>]:PM:SENSitivity?........................528 [:SOURce<hw>]:PM<ch>:SOURce....................... 526 [:SOURce<hw>]:PM<ch>:STATe........................
  • Page 760 ® List of Commands R&S SMA100B [:SOURce<hw>]:PULM:POLarity........................534 [:SOURce<hw>]:PULM:SOURce........................533 [:SOURce<hw>]:PULM:STATe........................532 [:SOURce<hw>]:PULM:THReshold....................... 534 [:SOURce<hw>]:PULM:TRAin:CATalog?.......................536 [:SOURce<hw>]:PULM:TRAin:DELete......................536 [:SOURce<hw>]:PULM:TRAin:DEXChange:AFILe:CATalog?............... 539 [:SOURce<hw>]:PULM:TRAin:DEXChange:AFILe:EXTension..............538 [:SOURce<hw>]:PULM:TRAin:DEXChange:AFILe:SELect................539 [:SOURce<hw>]:PULM:TRAin:DEXChange:AFILe:SEParator:COLumn............539 [:SOURce<hw>]:PULM:TRAin:DEXChange:AFILe:SEParator:DECimal............539 [:SOURce<hw>]:PULM:TRAin:DEXChange:EXECute.................. 540 [:SOURce<hw>]:PULM:TRAin:DEXChange:MODE..................538 [:SOURce<hw>]:PULM:TRAin:DEXChange:SELect..................540 [:SOURce<hw>]:PULM:TRAin:OFFTime.......................536 [:SOURce<hw>]:PULM:TRAin:OFFTime:POINts?..................537 [:SOURce<hw>]:PULM:TRAin:ONTime......................536 [:SOURce<hw>]:PULM:TRAin:ONTime:POINts?..................537 [:SOURce<hw>]:PULM:TRAin:REPetition..................... 537 [:SOURce<hw>]:PULM:TRAin:REPetition:POINts?..................537 [:SOURce<hw>]:PULM:TRAin:SELect......................537 [:SOURce<hw>]:PULM:TRIGger:MODE.......................
  • Page 761 ® List of Commands R&S SMA100B [:SOURce<hw>]:VOR:COMid:CODE......................575 [:SOURce<hw>]:VOR:COMid:DASH......................576 [:SOURce<hw>]:VOR:COMid:DEPTh......................576 [:SOURce<hw>]:VOR:COMid:DOT....................... 576 [:SOURce<hw>]:VOR:COMid:FREQuency....................577 [:SOURce<hw>]:VOR:COMid:LETTer......................577 [:SOURce<hw>]:VOR:COMid:PERiod......................577 [:SOURce<hw>]:VOR:COMid:SYMBol......................578 [:SOURce<hw>]:VOR:COMid:TSCHema...................... 578 [:SOURce<hw>]:VOR:COMid[:STATe]......................578 [:SOURce<hw>]:VOR:FREQuency........................579 [:SOURce<hw>]:VOR:FREQuency:MODE....................579 [:SOURce<hw>]:VOR:ICAO:CHANnel......................579 [:SOURce<hw>]:VOR:MODE........................580 [:SOURce<hw>]:VOR:PRESet........................546 [:SOURce<hw>]:VOR:REFerence[:DEViation]....................581 [:SOURce<hw>]:VOR:SETTing:CATalog?..................... 546 [:SOURce<hw>]:VOR:SETTing:DELete......................546 [:SOURce<hw>]:VOR:SETTing:LOAD......................546 [:SOURce<hw>]:VOR:SETTing:STORe......................547 [:SOURce<hw>]:VOR:SOURce........................
  • Page 762 ® List of Commands R&S SMA100B *OPC................................408 *OPT?................................408 *PRE................................408 *PSC................................408 *RCL................................409 *RST................................409 *SAV................................409 *SRE................................410 *STB?................................410 *TRG................................410 *TST?................................410 *WAI................................410 <subsystem>:PRESet............................546 <subsystem>:SETTing:CATalog........................546 <subsystem>:SETTing:DELete........................546 <subsystem>:SETTing:FREQuency:SYNChronize:STATe................548 <subsystem>:SETTing:LOAD........................546 <subsystem>:SETTing:SOURce........................547 <subsystem>:SETTing:STATe........................547 <subsystem>:SETTing:STORe........................547 User Manual 1178.3834.02 ─ 05...

  • Page 763: Index

    ® Index R&S SMA100B Index Symbols Detector sensitivity ............ 198 *OPC ................720 Settings ..............198 *OPC? ................720 State ................. 198 *RST ................731 All packages *WAI ................720 Secure update policy ..........335 /var/user directory ............412 Alphanumeric parameters ..........57 /var/volatile directory ............
  • Page 764 ® Index R&S SMA100B Average Clock Power analysis ............233 Amplitude ..............280 Average level DC offset ..............281 Power viewer ............218 Frequency ..............280 Avionics standards Phase, reset .............. 281 Overview ..............110 Phase, set ..............281 Shape ............... 279 Clock synthesis ...............
  • Page 765 ® Index R&S SMA100B ILS marker beacons ..........147 Ref In ................42 VOR ................123 Ref Out ............... 42 Comma ................716 RF ................. 38, 43 Command sequence Sensor ................ 37 recommendation ............731 Signal Valid ..............41 Remote ..............410 Stop ................
  • Page 766 ® Index R&S SMA100B DDM polarity Setup ................ 318 ILS localizer .............. 138 Status bar ..............52 DDM step Tab labels ..............54 ILS glide slope ............133 Taskbar ............... 53 ILS localizer .............. 140 Tile diagram ..............52 Deactivate RF output ............273 Wait time (screen saver) ..........
  • Page 767 ® Index R&S SMA100B Error messages ............... 704 Factory version Adjustment data invalid (183) ........704 Firmware ..............700 Adjustment data missing (182) ......... 703 Failure Adjustment failed (180) ..........703 Network connection ............ 29 Cannot access hardware (200) ......... 704 File Cannot access the EEPROM (202) ......
  • Page 768 ® Index R&S SMA100B Frequency Annotation disable ............ 337 Setting ............... 321 CW, fixed ..............65 GUI update LF generator ............. 100 Setup ................ 317 LF sweep ..............100 Multiplier ..............65 Offset ................65 Hard copy Power sensors ............219 Create, how to ............
  • Page 769 ® Index R&S SMA100B Pulse threshold ............97 Key panel test Trigger impedance ............97 Check front panel ............692 Input connector ............39, 42 Keyboard Input connectors On-screen ..............56 Stop ................41 Setting ............... 321 Installed assembly ............699 Settings ..............
  • Page 770 ® Index R&S SMA100B LF frequency sweep LAN configuration ............. 369 State ..............99, 171 LAN status ..............367 LF generator MAC address ............367 Shape ................. 99 Ping ................371 LF Out Remote trace (SCPI) ..........371 Overview ..............107 Reset (LCI) ...............
  • Page 771 ® Index R&S SMA100B Modulation Noise ratio AM ................75 Power sensors ............220 Analog ................. 73 NRFD ................737 Bandwidth, external input ......... 103 External coupling ............102 see Power analysis ........... 222 FM ................75 NRP power viewer Input impedance ............
  • Page 772 ® Index R&S SMA100B Stop ................41 Polarity V/GHz X-Axis .............. 41 Pulse generator output ..........89 Z-Axis ................41 Pulse modulation ............97 Output queue ..............724 Position Output, LF VOR ................121 Offset ................ 105 Power Voltage ..............105 UCOR ...............
  • Page 773 ® Index R&S SMA100B Protocol Queries ..............710, 718 VXI ................351 Status ................ 729 PTRansition ..............725 Question mark ............716, 718 PULM Questionable status register ........... 728 Delay ................89 Quotation mark ..............716 Double pulse delay ............. 89 Double pulse width .............
  • Page 774 ® Index R&S SMA100B HISLIP resource (Visa resource string) ....361 Setting characteristics ......... 69, 178 Identification .............. 363 Settings ............... 66 IDN string ..............364 RF level sweep Instrument emulations ..........363 State ................. 171 IP address mode ............359 RF OFF mode Language ..............
  • Page 775 ® Index R&S SMA100B SCPI Self-test Error messages ............703 Remote ..............410 Export ............... 297 Selftests Export settings ............388 About ................ 688 LAN services ............. 340 Sensitive information Output file ..............389 Protecting ............283, 290 Parameters ............... 714 Sequential commands .............
  • Page 776 ® Index R&S SMA100B Performing the front panel test ......... 692 Protection level ............333 LAN services ............. 340 Screen saver ............. 319 Standard settings ..........117, 126, 150 Secure update policy ..........335 Standby ............... 25, 34 Security password ............ 343 Start USB storage (security) ..........
  • Page 777 ® Index R&S SMA100B Storage location Temperature offset /usb/ ................282 Internal adjustments ..........696 /var/user ..............282 Temporary files ............283, 290 /var/volatile ..............282 Test Mass memory ............412 Check front panel ............692 Store Text entry ................56 Save ................
  • Page 778 ® Index R&S SMA100B State ................. 202 VISA ................349 Values, defining ..........190, 205 Libraries ..............354 Undo ................344 Resource string ............349 Clear history .............. 345 Visa resource string History ............... 345 Ethernet ..............361 Settings ..............344 GPIB ................. 361 State .................

This manual is also suitable for:

Smab-b28Smab-b34Smab-b1hSmab-b29Smab-b80Smab-b32 ... Show all

Table of Contents
