Recessed Concrete, Wood, or UPB Box—Autosave
OPTION 2: Conduit comes from side of box.
conduit must be as close to
rear wall as possible for
mechanism clearance.
conduit should not
protrude more
than 4" into box
drain centerline 4"
max from end wall
bond wire to bonding grid (route so that cover will not rub or catch or interfere with mechanism)
Consult a certified electrician and the pre-wiring diagrams for conduit and bonding requirements.
Underside Track
Box Dimensions For Autosave™
Up to 13' or
200 square feet
Motor Behind
w/ Auto-Shutoff
Motor Below
w/ Auto-Shutoff
Side View
8-1/2"
9
M
3" drain can be on either end
Motor Opposite
M
9" min
14-1/2" min
12-1/2" min
12-1/2" min
MTR
12"
Conduit
Motor Behind
All diagrams are for general information. Consult installation instructions for details.
12"
POOL
B
pool beam wall
D
recessed box wall
cut away for clarity
8-1/2" MTR
Beam
12"
O B
9" min 10" min 1" to Finished Beam
9" min 10" min 1" to Finished Beam
9" min 10" min 1" to Finished Beam
9" min 10" min 1" to Finished Beam
MTR
8-1/2"
Motor Below
O
T
W
Throat Depth
T D
Conduit
9"min
9"min
9"min
9"min
12"
Conduit
Width
W
12-1/2" min
12-1/2" min
12-1/2" min
14-1/2" min
