MECHANISM HOUSING

4
Choose a recessed mechanism (concrete or wood box) or deck-mounted mechanism. Systems
include a lid assembly, bench frame assembly or fiberglass ends.
Recessed Concrete, Wood, or UPB Box—Underside™ Track
conduit must be on the
motor end
conduit should not
protrude more
than 4" into box
conduit 6" max
from top
of box
bond wire
Consult a certified electrician and the pre-wiring diagrams for conduit and bonding requirements.
Underside Track
Box Dimensions for Save-T
Pools under
55 ft. long x 24 ft. wide
UPB BOX Pools up to
55 ft. long
Pools over
55 ft. long x 24 ft. wide
Pools over 65 ft. long or 25 ft. wide and vanishing-edge pools — Call Cover-Pools 1-800-447-2838
Box Side View—Underside Track
7
M
drain centerline 4"
max from end wall
3" drain - floor or wall
can be on either end
MOTOR
M
3
®
32"
32"
32"
minimum 2" clearance
for tracks
All diagrams are for general information. Consult installation instructions for details.
POOL
B
pool beam wall
D
OPPOSITE BEAM
O B
10" 8-12"
finished beam
10" 8-12"
finished beam
10" 8-12"
finished beam
lid
Optional coping or condrete build up.
T
[
O
W
wall cut away for clarity
THROAT DEPTH
T D
2" min to 12-1/2"
min
2" min to 13"
2" min to 14½"
bond wire
WIDTH
W
12-1/2"
min
13"
14½"
