Recessed Concrete, Wood, or UPB Box—Autosave
OPTION 1: Conduit comes from back of box.
3" drain - floor or wall
can be on either end
bond wire to bonding grid (route so that cover will not rub or catch or interfere with mechanism)
Consult a certified electrician and the pre-wiring diagrams for conduit and bonding requirements.
Underside Track
Box Dimensions For Autosave™
Up to 13' or
200 square feet
Motor Behind
w/ Auto-Shutoff
Motor Below
w/ Auto-Shutoff
Side View
8-1/2"
Note: To avoid interference, run the conduit from the center of the box using flex conduit with 1/2" water tight connector.
M
drain centerline 4"
max from end wall
Motor Opposite
M
9" min 9" min
14-1/2" min 9" min
12-1/2" min 9" min
12-1/2" min 9" min
MTR
Conduit
12"
Motor Behind
All diagrams are for general information. Consult installation instructions for details.
POOL
B
pool beam wall
Conduit comes from
center of the housing
recessed box wall
cut away for clarity
8-1/2" MTR
Beam
O B
12"
10" min 1" to Finished Beam
10" min 1" to Finished Beam
10" min 1" to Finished Beam
10" min 1" to Finished Beam
MTR
8-1/2"
Motor Below
T
O
D
W
Conduit
Throat Depth
T D
9"min 12-1/2" min
9"min 12-1/2" min
9"min 12-1/2" min
9"min 14-1/2" min
12"
Conduit
Width
W
