schmersal BN 20 Operating Instructions

Operating instructions

Magnetic reed switches
Operating instructions. . . . . . . . . . . . .pages 1 to 2
EN
Original
1. About this document
1.1 Function
This operating instructions manual provides all the information required
for the mounting, set-up and commissioning to ensure the safe opera-
tion and disassembly of the safety switchgear. The operating instruc-
tions must be available in a legible condition and a complete version in
the vicinity of the device.
1.2 Target group: authorised qualified personnel
All operations described in this operating instructions manual must
be carried out by trained specialist personnel, authorised by the plant
operator only.
1.3 Exclusion of liability
For safety reasons, invasive work on the device as well as arbitrary
repairs, conversions and modifications to the device are strictly
forbidden; the manufacturer shall accept no liability for damages
resulting from such invasive work, arbitrary repairs, conversions and/or
modifications to the device.
1.4 General safety instructions
The user must observe the safety instructions in this operating
instructions manual, the country specific installation standards as well
as all prevailing safety regulations and accident prevention rules.
2. Product description
2.1 Ordering code
This operating instructions manual applies to the following types:
BNS 20- Z
➀
No. Option Description
01 1 NC
➀
02 2 NC
10 1 NO
20 2 NO
11 1 NC contact / 1 NO contact
R 1 bistable contact
2R 2 bistable contact
11R 2 bistable contact NC / NO
2.2 Special versions
For special versions, which are not listed in the order code below 2.1,
these specifications apply accordingly, provided that they correspond to
the standard version.
2.3 Purpose
The magnetic reed switches BN 20 with two contacts are designed to
monitor the position of movable safety guards according to ISO 14119.
The magnetic reed switch is classified as uncoded switchgear
type 3 in accordance with ISO 14119.
Only the listed magnets may be used for actuation of the magnetic reed
switch. Only these magnets can guarantee flawless function and repeat
accuracy. With suitable evaluation and concealed installation, the
requirements for safety applications up to PL e in accordance with
ISO 13849-1 can be satisfied.
2.4 Technical data
Standards:
Enclosure:
Protection class:
Operating principle:
Cable entry:
Connection:
Switching voltage:
Switching current:
Switching capacity:
Dielectric strength:
Actuating speed:
Switching frequency:
Switching time "Close":
Switching time "Open":
Bounce duration:
Ambient temperature:
Mechanical life:
Electrical life:
Resistance to vibration:
Switching point accuracy:
Resistance to shock:
Tightening force:
- Cover screws:
- Cable gland:
- Blocking screws:
B to ISO 13849-1:
10D
- NC contacts (at 20 % contact load):
- NO contacts (at 20 % contact load):
Further technical information can be found in the Schmersal
catalogues or in the online catalogue on the Internet:
www.schmersal.net.
The information contained in this operating instructions manual is
provided without liability and is subject to technical modifications.
3. Mounting
3.1 General mounting instructions
When mounting to protective equipment, the requirements of
standard ISO 14119 must be taken into account.
Two elongated holes are available for fastening the enclosure.
Any mounting position, provided that the active surfaces are opposite
Magnetic reed switches and actuators
• Do not use as limit stops.
• Do not install in strong magnetic fields.
• Do not install on ferromagnetic material.
• Do not expose to strong vibrations or shocks.
• Inseparably fix to the safety guard.
The use of a protective ground wire is imperative.
Keep away from metal chips
EN
BN 20
IEC 60947-5-1
AlSi 12 die-casting, painted
IP67 to IEC 60529
screw terminals
max. 250 VAC/DC
max. 120 VA/W
> 600 VAC (50 Hz)
max. 18 m/s
max. 300/s
0.3 ms ... 1.5 ms
max. 0.5 ms
0.3 ms ... 0.6 ms
– 25 °C ... + 90 ºC
10 9 operations
10 6 ... 10 9 operations, depending on load
50 g on sine wave oscillation
± 0.25 mm, T = constant
30 g / 11 ms
min. 0.6 Nm
min. 1.2 Nm
min. 1.2 Nm
20,000,000
20,000,000
magnetic
2x M16
max. 3 A
1
