Distributed by Ergonomic Partners, Inc. | sales@ergonomicpartners.com | 314-884-8884 | www.ergonomicpartners.com
Serial # ______________________________________________
Placed in Service ______________________________________
Owner's Manual
PalletPal
Level Loader
Southworth Products Corp
P.O. Box 1380 • Portland, Maine 04104-1380
Distributed by Ergonomic Partners, Inc.
Email: sales@ergonomicpartners.com
Web: www.ergonomicpartners.com
PH: 314-884-8884 | FAX: 800-570-5584
360 Air
TM
December 2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PalletPal 360Air and is the answer not in the manual?

Questions and answers

Related Manuals for Southworth PalletPal 360Air

Summary of Contents for Southworth PalletPal 360Air

  • Page 1 Owner’s Manual PalletPal 360 Air Level Loader Serial # ______________________________________________ Placed in Service ______________________________________ Southworth Products Corp P.O. Box 1380 • Portland, Maine 04104-1380 Distributed by Ergonomic Partners, Inc. Email: sales@ergonomicpartners.com Web: www.ergonomicpartners.com PH: 314-884-8884 | FAX: 800-570-5584 December 2012...
  • Page 2 OWNER’S MANUAL This manual was current at the time of printing. To obtain the latest, most updated version, please contact Southworth's Customer Service Department. PALLETPAL 360 AIR...

  • Page 3: Table Of Contents

    SOUTHWORTH CONTENTS INTRODUCTION ..................Page 4 RESPONSIBILITY OF OWNERS AND USERS ..........5 SAFETY ......................6 INSTALLATION INSTRUCTIONS ..............7 Unpacking the Unit ................ 7 Setup and Instructions ..............7 Operation notes ................8 Specifications................... 9 OPERATING INSTRUCTIONS ................. 10 Labels and Precautionary Markings ..........10 Loading Manually ................

  • Page 4: Introduction

    Southworth shall not be liable for any loss, injury, or damage to persons or property, nor for any direct, indirect, or consequential damage of any kind resulting from the PalletPal 360 Air unit.

  • Page 5: Responsibility Of Owners And Users

    Inspected the device for proper operation and condition. Any suspect item shall be carefully examined and a determination made by a qualified per- son as to whether it constitutes a hazard. All items not in conformance with Southworth’s specification shall be corrected before further use of the equipment. During Operation The device shall only be used in accordance with this owner’s manual.

  • Page 6: Safety

    PalletPal 360 Air unit, and provided appropriate instructions or precautions which should be taken to avoid these hazards. In some cases, Southworth has also pointed out the consequences which may occur if Southworth’s instructions or precautions are not followed. Southworth...

  • Page 7: Installation Instructions

    If you have any questions about the steps in Choose the place where you want to set the the installation process, please call Southworth unit. It is very important that the PalletPal 360 Air Customer Service at 1-800-743-1000.

  • Page 8: Operation Notes

    OWNER’S MANUAL OPERATION NOTES WARNING! Do not try to use this unit with damaged or broken pallets. Broken pallets may have WARNING! boards or nails which hang down below the Never sit or ride on the turntable or operate the main part of the pallet.

  • Page 9: Specifications

    SOUTHWORTH Specifications Load capacity 400 to 4500 lbs. Load size 50" wide x 50" long x 72" high (max.) Base frame 36" x 36" Compressed height 9 1/2 inches Extended height 27 3/4 inches Air source 80 PSI Maximum system air pressure...

  • Page 10: Operating Instructions

    OWNER’S MANUAL OPERATING INSTRUCTIONS Labels and Precautinary Markings Item 2990413 Item 2990414 Decal 5900191 Figure 1. PALLETPAL 360 AIR...

  • Page 11: Loading Manually

    SOUTHWORTH OPERATING INSTRUCTIONS (continued) Figure 2. Loading Manually Figure 4. Warning - Load in Layers Loading Manually Operating Safely -- Manual Use Add boxes or parts until the pallet is full. The unit 1. Never push the load off of the side of the unit. If will gradually lower the pallet until it reaches the you do this, the frame of the unit may jump upward.

  • Page 12: Loading With A Fork Lift

    OWNER’S MANUAL Loading with a Fork Lift WARNING! 1. Place the load on the lift, then lower the fork If you skip these steps, the unit may lift. Before removing the load, be sure the unit is jump up suddenly when you remove carrying the weight, not the fork lift.

  • Page 13: Troubleshooting

    SOUTHWORTH Troubleshooting Troubleshooting Check List Problem Possible Cause Check This The unit lowers too easily Not enough air pressure See set-up procedure pg 7 (too early) The unit does not lower enough (too late) Too much air pressure See set-up procedure pg 7...

  • Page 14: Ordering Replacement Parts

    OWNER’S MANUAL Ordering Replacement Parts Southworth has carefully chosen the components in your unit to be the best available for the purpose. Replacement parts should be identical to the original equipment. Southworth will not be responsible for equipment failures resulting from the use of incorrect replacement parts or from unauthorized modifications to the unit.

  • Page 15: Warranty

    Southworth Products Corp’s discretion. This is buyer’s sole remedy. Except as stated herein, Southworth Products Corp will not be liable for any loss, injury or damage to persons or property, nor for direct, indirect, or con- sequential damage of any kind, resulting from failure or defective operation of said product.
  • Page 16 Southworth is the world class supplier of products designed to improve productivity and enhance safety. Our staff has over 400 years of engineering experience. If one of our standard products does not meet your needs, our engineers can custom design equipment specifically suited to your material handling application.
