SSANGYONG REXTON 2004.04 Manual page 413

07-10
8610-11
1) Washer coupled mode
2) Limit switch ON/OFF mode operation
RAIN SENSOR
undefined
1. When wiper switch is turned on for over 0.6
sec. under ignition switch on condition,
washer coupled wiper output comes on.
2. When washer switch is turned off, wiper
mode operation will be performed 2 times
and then return to parking position.
3. Wiper motor output works same as the
wiper operation mode.
1. If turn on limit switch while wiper motor is
operating under ignition switch on
condition, returns to parking position
without delay to stop the motor.
2. Under limit switch on condition, wiper motor
output control will be stopped.
(It is to control the wiper blade not to be
blocked by rear glass when opened.)
