BIPAC-7500G
802.11g ADSL VPN Firewall Router with
3DES Accelerator
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIPAC 7500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Billion BIPAC 7500

  • Page 1 BIPAC-7500G 802.11g ADSL VPN Firewall Router with 3DES Accelerator Quick Start Guide...
  • Page 3: Package Contents

    Billion BIPAC-7500G - 802.11g ADSL VPN Firewall Router with 3DES Accelerator For more detailed instructions on configuring and using the 802.11g ADSL VPN Firewall Router, please refer to the on-line manual. Package Contents BIPAC-7500G ADSL VPN Firewall Router CD-ROM containing the online manual RJ-11 ADSL/telephone Cable Ethernet (CAT-5 LAN) Cable Console (PS2-RS232) Cable...
  • Page 4: The Front Leds

    Quick Start Guide The Front LEDs LAN port 1 LAN port 2 LAN port 3 LAN port 4 WLAN MAIL ADSL Lit when power is ON. Lit when the system is ready. Lit when connected to an Ethernet device. Green for 100Mbps; Orange for 10Mbps Blinking when data is transmitted/received.
  • Page 5: The Rear Ports

    Billion BIPAC-7500G - 802.11g ADSL VPN Firewall Router with 3DES Accelerator The Rear Ports Port LINE CONSOLE — (RJ-45 connector) RESET Power Switch Connect the supplied RJ-11 (“telephone”) cable to this port when connecting to the ADSL/telephone network. Connect a PS2/RS-232 cable to this port when connecting to a PC’s RS-232 port (9-pin serial port).
  • Page 6: Connecting Your Adsl Router

    Quick Start Guide Connecting Your ADSL Router 1. Connect the Router to a LAN (Local Area Network) and the ADSL/telephone (LINE) network. 2. Power on the device. 3. Make sure the PWR, SYS and WLAN LEDs are lit steadily and that the relevant LAN LED is lit.
  • Page 7: Configuring Pc In Windows Xp

    Billion BIPAC-7500G - 802.11g ADSL VPN Firewall Router with 3DES Accelerator Configuring PC in Windows XP 1. Go to Start / Control Panel (in Classic View). In the Control Panel, double-click on Network Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties.
  • Page 8: Configuring Pc In Windows 2000

    Quick Start Guide Configuring PC in Windows 2000 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4.
  • Page 9: Configuring Pc In Windows 98/Me

    Billion BIPAC-7500G - 802.11g ADSL VPN Firewall Router with 3DES Accelerator Configuring PC in Windows 98/Me 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP/IP -> NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC.
  • Page 10 Quick Start Guide Configuring PC in Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK.
  • Page 11 Billion BIPAC-7500G - 802.11g ADSL VPN Firewall Router with 3DES Accelerator Configuring Your ADSL VPN Firewall Router To configure this device, you must have IE 5.0 / Netscape 4.5 or above installed Verifying Your Local Network Connection with the Device To see if this ADSL Router is visible on the local network, go to Start / Run.
  • Page 12: Product Support And Contact Information

    Quick Start Guide Connecting to the Router Open the web browser and type http://192.168.1.254 in the browser’s address box. This number is the default IP address for this router. Press Enter. A user name and password window will appear. The default User Name and Password are “admin”...
