Typical Applications - Altronix NetWay spectrum NetWay SP1P Installation Manual

Fig. 1
NetWaySP1P
Media Converter/Injector
Input: 24VDC–56VDC
Output: IEEE 802.3at (30W) and
IEEE 802.3af (15.4W)
compliant.
24-56VDC Pwr PoE+ PoE
-- Input + In Output Out
Fig. 2
DC
Power
Supply
115/230VAC
Input
Fig. 3
DC
Power
Supply
24-56VDC Input
115/230VAC
Input
CAT5e/6
PoE+ (30W) PTZ
- 2 -
All manuals and user guides at all-guides.com
Fig. 1a
Made in U.S.A.
Structured
www.altronix.com
Cable to
PoE Device
24VDC to
56VDC
Input
I.T.E. 43KC
Fiber
SFP Signal

Typical Applications:

I.T.E. 43KC
24-56VDC
Input
NetWaySP1P
Converts Ethernet
to Fiber & Provides PoE
I.T.E. 43KC
-- +
Power In PoE LED
LED Indicates
Indicates PoE
unit is present
powered
NetWaySP1P
Converts Ethernet
to Fiber & Provides PoE
PoE+ (30W) PTZ
CAT5e/6
Fiber
NetWay8E
or Midspan/Endspan
One (1) Gb
SFP port
for Fiber
SFP LED
Indicates
data connection
Fiber
Made in
NetWaySP1A
U.S.A.
Media
NetWaySP1A
Media Converter/Repeater Converter/
Input: PoE Class 1 or Higher
Data: 10/100/1000
Repeater
www.altronix.com
PoE / Fiber
PoE 10/100/1000 In SFP Signal
CAT5e/6
NetWaySP1P
