Hardware List
A
Hitch Pin
Qty.-2
E
M6x10 Phillips Flange Screw
Qty.-9
DO NOT RETURN TO RETAILER for assembly assistance, missing or damaged parts. Please
contact MASTERBUILT customer service at 1-800-489-1581 or support.masterbuilt.com. Please
STOP
have the model number and serial number available. These numbers are located on the silver
rating label on the smoker.
BEFORE ASSEMBLY READ ALL INSTRUCTIONS CAREFULLY.
•
• Assemble on a clean flat surface.
• Tools needed: Phillips head screwdriver
• Approximate assembly time: 20 minutes
• Actual product may differ from picture shown.
• It is possible that some assembly steps have been completed in the factory.
6
B
Flat Washer
Qty.-2
F
M6x15 Phillip Screw
Qty.-8
C
Hair Pin
Qty.-2
G
M8 Wing Nut
(Packed with temperature gauge)
Qty.-1
D
M5x10 Thumb Screw
Qty.-3
H
Cap Nut
(Assembled to warming rack)
Qty.-2
