9) Remove the rod from lever.
(A)
(C)
(A) Rod
(B) Lever
(C) Stay
10) Separate the rod and inner boot.
11) Remove the snap ring from the stay.
(A) Snap ring
12) Separate the gear shift lever and the stay.
MT Gear Shift Lever
(B)
CS-00233
(A)
CS-00234
CS-00235
13) Remove the boot and bushing from gear shift
lever.
(A) (B)
(A) O-ring
(B) Bushing
14) Remove the spring pin, the bushing and the
snap ring.
(A) Bushing
(B) Snap ring
15) Remove the bushing and spacer from boss.
(B)
(A) Bushing
(B) Spacer
CS-45
CONTROL SYSTEMS
(A)
(B)
(A)
(A)
(A)
CS-00236
CS-00237
CS-00238
