Aerco Benchmark Platinum Series Pre-Installation Application Manual

Venting & combustion air guide natural gas, propane and dual fuel modulating and condensing boilers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Benchmark Series Pre-Installation Venting & Combustion Air
VENTING & COMBUSTION AIR GUIDE
Natural Gas, Propane and Dual Fuel Modulating and Condensing Boilers
EXHAUST MANIFOLD
Latest Update: 9/14/2018
TAG-0022_0Z
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913
GF-2050
PRE-INSTALLATION APPLICATION GUIDE
VENT
STARTER
SECTION
Phone: 800-526-0288
APPLIES TO MODELS:
•
BMK 750
•
BMK 1000
•
BMK 1500
•
BMK 2000
•
BMK 2500
•
BMK 3000
•
BMK 5000
•
BMK 6000
Page 1 of 51
9/14/2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Benchmark Platinum Series and is the answer not in the manual?

Questions and answers

Related Manuals for Aerco Benchmark Platinum Series

Summary of Contents for Aerco Benchmark Platinum Series

  • Page 1 BMK 2000 • BMK 2500 • BMK 3000 • BMK 5000 • BMK 6000 EXHAUST MANIFOLD Latest Update: 9/14/2018 TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 1 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...

  • Page 2: Table Of Contents

    24.2 Ducted Combustion Air Duct Pressure Drop ............... 29 24.3 Gross Natural Draft ..................... 43 24.4 Altitude Correction ...................... 49 24.4 Round vs Square Duct ....................50 Page 2 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018 Phone: 800-526-0288 GF-2050...

  • Page 3: General

    Benchmark Series Pre-Installation Venting & Combustion Air 1. General The AERCO Benchmark gas-fired boiler is a high efficiency, forced draft, hydronic-heating unit with unique venting capabilities. All Benchmark venting options (which include horizontal and vertical discharges, direct vent, and manifolded vent breeching), typically exceed the capabilities of competing combustion equipment.

  • Page 4: Code Required Vent Terminations

    All Canada installations must comply with CSA B149.1 installation code. 3. Code Required Vent Terminations The guidelines provided in this bulletin should be followed to comply with AERCO, UL, NFPA 54 (National Fuel Gas Code, ANSI Z223.1) and in Canada: CSA B149.1-10 recommendations and regulations.
  • Page 5 AIR INLET EXHAUST VENT EXHAUST VENT CONNECTION CONNECTION CONDENSATE CONDENSATE TRAP TRAP Figure 1c: BMK 2500/3000 Figure 1d: BMK 5000/6000 TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 5 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...

  • Page 6: Combustion Air Supply

    Accumulate over the burner surface and restrict flow of air/fuel mixture In these situations, AERCO requires that a disposable air intake filter be installed, temporarily, above the boiler combustion air inlet. Air filters may be required year-round in instances in which dust or debris can enter the combustion air tube.

  • Page 7: Combustion Air From Within The Building

    For additional details, consult NFPA 54, or in Canada, CSA B149.1-10, paragraphs 8.4.1 and 8.4.3. TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 7 of 51 GF-2050 Phone: 800-526-0288...

  • Page 8: Two-Permanent-Openings Method (Usa Only)

    Figure 3: All Combustion Air From Outdoors - Inlet Air From Ventilated Crawl Space and Outlet Air to Ventilated Attic Page 8 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018 Phone: 800-526-0288...
  • Page 9 2,000 BTU/hr. (1100 mm /kW) of total input rating of all appliances in the space (see Figure 5). TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 9 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...
  • Page 10 Benchmark Series Pre-Installation Venting & Combustion Air Figure 5: All Combustion Air from Outdoors Through Horizontal Ducts Page 10 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018 Phone: 800-526-0288 GF-2050...

  • Page 11: One Permanent Opening Method

    /kW) of the total input rating of all appliances located in the space. Figure 6: All Combustion Air from Outdoors Through Single Combustion Air Opening TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 11 of 51 GF-2050 Phone: 800-526-0288...

  • Page 12: Opening A Louver Through The Benchmark Boiler

    Aux Start On Delay parameter, refer to the Benchmark boiler’s Operations and Maintenance manual. If an AERCO Control System (ACS) is being used to manage a multiple boiler installation, the louver must be opened using the System Start Relay of the ACS. Refer to the ACS Operations and Maintenance Manual, GF-131, for wiring connections and further details.

  • Page 13: Exhaust Vent And Combustion Air Systems

    Contact your AERCO sales representative or AERCO International for design assistance and approval when designing manifolded exhaust vent systems. CAUTION! Do NOT install a non-sealed draft control damper. TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 13 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...

  • Page 14: Acceptable Pressure Ranges

    The minimum distance required between two elbows is 5 feet (1.5 m). Page 14 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018 Phone: 800-526-0288...

  • Page 15: Exhaust Muffler Guidelines

    (2.4 m) vertical connector, the total section linear length considered is 23 feet (4.0 m). Because this is less than 25 linear feet (7.6 m), an attenuator is required. Contact your local AERCO sales representative for more information on the AERCO exhaust muffler.

  • Page 16: Vent & Combustion Air System Design Requirements

    Optional 12 inch (30.5 cm) diameter exhaust venting requires a 12” (30.5 cm) vent adapter. Consult your local AERCO sales representative or vent manufacturer or AERCO International for more information on the 12” (30.5 cm) adapter. A 1/4-inch (6.35 mm) NPT combustion test hole is provided on each unit’s exhaust manifold connection (See Figures 8a, 8b, 8c and 8d).
  • Page 17 • BMK 1500 = 6” (15.2 cm) Figure 8b: Ducted Combustion Connection for BMK 1500 & BMK 2000 Boilers TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 17 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...
  • Page 18 BMK 2500 & BMK 3000 Boilers AIR INLET 14” (35.6 cm) MINIMUM DIAMETER Figure 8d: Ducted Combustion Connection for BMK 5000 & 6000 Boilers Page 18 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018 Phone: 800-526-0288 GF-2050...
  • Page 19 EXHAUST MANIFOLD Figure 9b: Vent Starter Section – Left Side View BMK 2500 & BMK 3000 (Left) & BMK 5000/6000 (Right) TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 19 of 51 GF-2050 Phone: 800-526-0288...

  • Page 20: Condensate Removal

    The installation must be designed in accordance with local codes that specify acceptable pH limits. If required, any type of commercially available neutralizer may be used. Page 20 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018...

  • Page 21: Individually Vented Systems

    6) Add the total vent pressure drop to the altitude corrected combustion air duct pressure drop. The total system pressure drop must not exceed 140 equivalent feet (42.7 m). TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 21 of 51 GF-2050 Phone: 800-526-0288...

  • Page 22: Bmk 1500 Example

    = 137.19 ft. (41.82 m) Conclusion: Pressure drop is less than 140 equivalent feet (42.7 m) – System OK. Page 22 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018 Phone: 800-526-0288 GF-2050...

  • Page 23: Manifolded Ducted Combustion Air

    3 Ft. (1 m) minimum 10 Ft. (3 m) minimum Figure 10a: Individual Vents – Preferred Installations TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 23 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...
  • Page 24 Benchmark Series Pre-Installation Venting & Combustion Air Figure 10b: Individual Vents – Acceptable Installations Page 24 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018 Phone: 800-526-0288 GF-2050...

  • Page 25: Common Vent Breeching (Manifolded)

    Benchmark Series Pre-Installation Venting & Combustion Air 23. Common Vent Breeching (Manifolded) IMPORTANT NOTES: 1. AERCO forced draft boilers are designed for application in common vent systems. 2. Please consult the AERCO factory for all applications utilizing common ducted combustion air with common breeching of exhausts.
  • Page 26 Benchmark vents must never be interconnected to those connected to other manufacturers’ equipment. Figure 13: Connection of Unit at End of Vent Main Page 26 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018 Phone: 800-526-0288...

  • Page 27: Pressure Drop And Draft Data Tables

    0.52 (0.16) 0.96 (0.29) 14 (35.6) 16 (40.6) 4.85 (1.48) 0.01 (0.01) 0.14 (0.04) 0.11 (0.03) 0.3 (0.09) 0.56 (0.17) TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 27 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...
  • Page 28 0.79 (0.24) 2.40 (0.73) 4.45 (1.36) 20 (6.1) 11.01 (3.36) 0.05 (0.05) 0.64 (0.2) 0.50 (0.15) 1.57 (0.48) 2.92 (0.89) Page 28 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018 Phone: 800-526-0288 GF-2050...

  • Page 29: Ducted Combustion Air Duct Pressure Drop

    2.24 2.35 2.51 2.68 2.86 3.05 3.25 3.47 Ent. Loss (0.652) (0.683) (0.716) (0.765) (0.817) (0.872) (0.93) (0.991) (1.058) TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 29 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...
  • Page 30 2) Units for "Straight Run" pressure drop values are equivalent feet per foot (eq. m / m) 3) Units for "Elbows" and "Ent. Loss" are equivalent feet per item (eq. m / item) Page 30 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018...
  • Page 31 3.98 4.18 4.46 4.76 5.08 5.42 5.78 6.16 Ent. Loss (1.158) (1.213) (1.274) (1.359) (1.451) (1.548) (1.652) (1.762) (1.878) TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 31 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...
  • Page 32 2) Units for "Straight Run" pressure drop values are equivalent feet per foot (eq. m / m) 3) Units for "Elbows" and "Ent. Loss" are equivalent feet per item (eq. m / item) Page 32 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018...
  • Page 33 4.32 4.54 4.84 5.16 5.51 5.88 6.27 6.69 Ent. Loss (1.256) (1.317) (1.384) (1.475) (1.573) (1.679) (1.792) (1.911) (2.039) TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 33 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...
  • Page 34 2) Units for "Straight Run" pressure drop values are equivalent feet per foot (eq. m / m) 3) Units for "Elbows" and "Ent. Loss" are equivalent feet per item (eq. m / item) Page 34 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018...
  • Page 35 2.43 2.55 2.72 2.90 3.10 3.31 3.53 3.76 Ent. Loss (0.707) (0.741) (0.777) (0.829) (0.884) (0.945) (1.009) (1.076) (1.146) TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 35 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...
  • Page 36 2) Units for "Straight Run" pressure drop values are equivalent feet per foot (eq. m / m) 3) Units for "Elbows" and "Ent. Loss" are equivalent feet per item (eq. m / item) Page 36 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018...
  • Page 37 4.56 4.78 5.10 5.44 5.81 6.20 6.62 7.06 Ent. Loss (1.32) (1.39) (1.46) (1.55) (1.66) (1.77) (1.89) (2.02) (2.15) TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 37 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...
  • Page 38 2) Units for "Straight Run" pressure drop values are equivalent feet per foot (eq. m / m) 3) Units for "Elbows" and "Ent. Loss" are equivalent feet per item (eq. m / item) Page 38 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018...
  • Page 39 5.47 5.74 6.12 6.53 6.97 7.44 7.94 8.47 Ent. Loss (1.588) (1.667) (1.75) (1.865) (1.99) (2.124) (2.268) (2.42) (2.582) TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 39 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...
  • Page 40 2) Units for "Straight Run" pressure drop values are equivalent feet per foot (eq. m / m) 3) Units for "Elbows" and "Ent. Loss" are equivalent feet per item (eq. m / item) Page 40 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018...
  • Page 41 5.84 6.12 6.43 6.85 7.31 8.32 8.88 9.47 Ent. Loss (1.78) (1.865) (1.96) (2.088) (2.228) (2.377) (2.536) (2.707) (2.886) TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 41 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...
  • Page 42 2) Units for "Straight Run" pressure drop values are equivalent feet per foot (eq. m / m) 3) Units for "Elbows" and "Ent. Loss" are equivalent feet per item (eq. m / item) Page 42 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018...

  • Page 43: Gross Natural Draft

    209.7 194.8 179.8 159.9 140.0 119.8 99.9 80.0 60.0 60.96 239.9 222.7 205.5 182.8 159.9 137.0 114.1 91.4 68.5 TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 43 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...
  • Page 44 50.5 46.9 43.3 38.5 33.6 28.8 24.0 19.2 14.4 Note: Based on 71 °C to 82 °C Boiler Water Page 44 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018 Phone: 800-526-0288 GF-2050...
  • Page 45 209.7 194.8 179.8 159.9 140.0 119.8 99.9 80.0 60.0 60.96 239.9 222.7 205.5 182.8 159.9 137.0 114.1 91.4 68.5 TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 45 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...
  • Page 46 50.5 46.9 43.3 38.5 33.6 28.8 24.0 19.2 14.4 Note: Based on 71 °C to 82 °C Boiler Water Page 46 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018 Phone: 800-526-0288 GF-2050...
  • Page 47 209.7 194.8 179.8 159.9 140.0 119.8 99.9 80.0 60.0 60.96 239.9 222.7 205.5 182.8 159.9 137.0 114.1 91.4 68.5 TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 47 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...
  • Page 48 50.5 46.9 43.3 38.5 33.6 28.8 24.0 19.2 14.4 Note: Based on 71 °C to 82 °C Boiler Water Page 48 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018 Phone: 800-526-0288 GF-2050...

  • Page 49: Altitude Correction

    0.772 2286.0 7500 0.758 2438.4 8000 0.743 2590.8 8500 0.729 2743.2 9000 0.715 2895.6 9500 0.701 3048.0 10000 0.688 TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 49 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...

  • Page 50: Round Vs Square Duct

    1. National Fuel Gas Code, 2006 edition, American National Standards Institute, Inc (ANSI Z223.1-2006) and National Fire Protection Association (NFPA54-2006) 2. CSA B149.1 (For Canada installations) Page 50 of 51 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 TAG-0022_0Z 9/14/2018 Phone: 800-526-0288...
  • Page 51 9/14/2018 Chris Blair DIR 18-32: Modified “approved Vent Material” in Section 2, added Disclaimer. © AERCO International, Inc., 2018 TAG-0022_0Z AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 51 of 51 GF-2050 Phone: 800-526-0288 9/14/2018...
