Description Of Elements - Nacon Asymmetric Wireless Controller User Manual

I

Description of elements

3
7
5
9
12
13
17
1/ Micro USB connector
2/ Touch pad
3/ "SHARE" button
4/ "OPTIONS" button
5/ "PS" button
6/ Action buttons
7/ Left stick with L3 button
8/ Right stick with R3 button
9/ Directional pad
10/ LED for Sync / Battery level indication
20
1 2
11
10
19
11/ Headset connector (3.5mm jack)
12/ R1 Shoulder button
13/ R2 Analogue trigger
14/ L1 Shoulder button
15/ L2 Analogue trigger
16/ Battery indicator button
17/ Reset button
18/ USB Bluetooth
19/ "SYNC" button
20/ LED for Sync indication
4
6
8
14
15
16
18
receiver
®
