Removing The Battery - Ferrari 458 Italia Technical Documentation Manual

Battery, disconnecting / reconnecting

Removing the battery

Each time the battery is disconnected from the electrical system of the vehicle, all the self-acquisition
parameters are cancelled from the injection ECU.
These parameters must be reacquired before reusing the vehicle.
The battery is located in the passenger compartment, behind the passenger side footrest.
Disconnect the battery (
Remove the mats (
Remove the underdashboard mat on passenger's side.
F2.01).
E4.05).
UP TO Ass.ly No. 90266
Release connector (1) from bodyshell.
Position connector aside so that it does not hinder
the following operations.
UP TO Ass.ly No. 90266
Undo the screws indicated.
Lift crosspiece (B).
Page 2 of 13
