to display the current VSWR.
Tips: In the tuning process of the tuner, the larger wall SWR can be detected by the transmitter.
There are very few transmitters that stop transmitting when SWR is large and cause tuning failure.
The mAT-10 tuner may not work properly with these transmitters. This has happened when we
applied mAT-10 to YAESU FT-857D with low transmit power.
Batteries and Charging Two 10440 lithium batteries installed inside mAT-10 to provide power
for the tuner. Tuner is charged, can only be used with
prescribed
charger, the charger has the
highest output voltage of 8.4VDC. mAT-10 uses little power while tuning, and essentially zero
power when in standby, when the equipment is full of electricity, it can work for a long time.
These 10440 lithium batteries do not have a protective circuit, and the protection function is
completed by tuner. When batteries need to be replaced, please choose the same type of batteries.
The indicator on the charger shows the charging process. The yellow indicator indicates that the
charging is in progress, and the green indicator indicates that the charging is completed.
Before the first use or after the battery is replaced, the tuner must be charged by the charger to
activate the internal protection circuit before it can be used normally.
TRANSPORT
Because there are two lithium batteries installed inside the tuner, Please comply with local laws
when transporting. It could be banned from air transportation.
TECHNICAL SUPPORT
Visit the Support Center at: http://www.mat-tuner.com/en/
The website provides links to product manuals, just in case you lose this one! When you are
thinking about the purchase of other
products our website also has complete
product specifications and photographs you can use to help make your purchase decision. Don't
forget the links to all of the quality
Dealers also ready to help you make that
purchase decision.
PRODUCT FEEDBACK
We encourage product feedback! Tell us what you really think of your
product. In
an email tell us how you used the product and how well it worked in your application.
We like to share your comments with our staff, our dealers, and even other customers at the
website.
Welcome to http://www.mat-tuner.com/en/ for more information
BG3MZU 2019.05.12
5 / 5
