Viking PI-1A Product Manual

Designed, Manufactured and Supported in the USA
VIKING
S E C U R I T Y & C O M M U N I C A T I O N S O L U T I O N S
Interface Your Paging System with
Viking's Telecom Paging Interface allows you to
provide paging from nearly any phone system
instead of from a microphone. You can also
provide background music and electronic night bell
over the audio system.
The PI-1A features a built-in voice activated (VOX)
relay which provides DPDT contacts for muting
background music during paging. The relay is also
activated by AC ring for providing electronic night
bell. These contacts are necessary when
interfacing with systems such as Panasonic, South
Western Bell, Intertel, etc., which do not provide a
paging contact closure.
In the event a paging port is not available, the
PI-1A can provide talk battery to allow connection
of the public address system to an unused
line/trunk input on the phone system.
Features
• Floating 600 ohm output
• Selectable 22V DC talk battery for
interfacing with unused phone system line
input / trunk ports
• Paging port interface
• Ringing analog line input for night bell
• Contact closure input for night bell
• DPDT normally open and normally closed VOX
activated contacts for cutting out background
music
• Adjustable VOX contact time-out
• Adjustable VOX trigger sensitivity
• Adjustable ring volume
• Adjustable ring pitch
• Wall mount housing, (2) #6 x ¾ panhead
screws included
www.VikingElectronics.com
Information: 715-386-8861
PRODUCT MANUAL
Nearly Any Phone System!
The electronic night bell feature is activated by a
standard ringing analog PABX/KSU station circuit
or by a common audible contact closure provided
by an electronic key system. The ring pitch and
volume are adjustable allowing you to differentiate
between multiple ringing lines.
Applications
• Integrate your public address system with
nearly any phone system
• Cut out background music during paging
• Electronic night bell from ringing line or contact
closure
Note: The PI-1A is not compatible with ring trip paging
applications. See Viking models FXI-1 (DOD 494),
PA-15 (DOD 486), or RAD-1A (DOD 410).
Specifications
Power: 120V AC/12V DC 500mA, UL listed adapter
provided
Dimensions: 4.38" x 2.97" x 1.38" (111mm x 76mm x 36mm)
Shipping Weight: 1.06 lbs (0.48 kg)
Environmental: 32°F to 90°F (0°C to 32°C) with 5% to
95% non-condensing humidity
Relay Contacts: 30V DC@1A, 110V DC@0.3A, 125V
AC @ 0.5A
Maximum Ring Output: 0.5V AC RMS no load, 0.4V AC
RMS @ 600 ohms
VOX Minimum Audio Signal to Activate Relay: At
1KHz with VOX sensitivity POT set to minimum: -17dbm,
with POT set to maximum: -37dbm
VOX Time Out Delay: 0.9 second minimum and 4.3
second maximum
Talk Battery: 22V DC
PI-1A
Telecom Paging
Interface
September 8, 2017
