Viking PA-15 Overhead Paging System Configuration
To configure a Viking PA-15 Overhead Paging System for 8x8 services, move the FXS/FXO Switch to FXS and leave
DIP switches 1-10 in default settings. Learn more.
Objective
Configuring a Viking PA-15 overhead paging system for 8x8 services.
Applies To
Viking PA-15 overhead paging system
Procedure
1. Move the FXS/FXO Switch to FXS.
2. Leave DIP switches 1-10 in their default settings (Switch 4 and 8 are ON by default; all others are OFF by default).
Note: If you do not want to hear a beep sound when paging, turn DIP Switch 8 OFF.
3. Connect the phone line or RJ11 cable to your 8x8 adapter.
4. Use a wire cutter to strip the other end of the cable and attach the wires to the corresponding pins on the PA-15:
◦ Red Wire (Ring): Pin 5
◦ Green Wire (Tip): Pin 6
Note: The black and yellow wires of the cable are not used.
5. Connect the speakers to Pin 1 and Pin 2 on the PA-15.
https://support.8x8.com/equipment-devices/overhead-paging/viking-pa-15-overhead-paging-system-configuration-for-8x8-serv...
Updated: Thu, 30 Jul 2020 16:00:11 GMT
Powered by
1
Advertisement
Table of Contents
Related Manuals for Viking PA-15
Summary of Contents for Viking PA-15
- Page 1 3. Connect the phone line or RJ11 cable to your 8x8 adapter. 4. Use a wire cutter to strip the other end of the cable and attach the wires to the corresponding pins on the PA-15: ◦ Red Wire (Ring): Pin 5 ◦...
- Page 2 Additional Information The Viking PA-15 device: • Has 15 watts of output power. • Can support up to 15 8-ohm speakers. If you are seeking a higher output, you may be interested in the Viking PA-30 instead (30W output; supports up to 30 8-ohm speakers).
