SERVICE PARTS AND ACCESSORIES

Item
39-020 115V 6˝ Fan
39-021 230V 6˝ Fan
54-100 Spare oil bottle
Item
AR2788SX3 Scale module
AR2788SX11 AR2788S / FA1000 tank liquid to filter IN hose
AR2788SX17 Black scale patch cord
AR2788SX18 Red relay PCB patch cord
AR2788SX19 Yellow Low side block PCB patch cord
AR2788SX20 Green High side block PCB patch cord
AR2788SX21 Low side block PCB
AR2788SX22 High side block PCB
AR2788SX23 Main PCB
AR2788SX24 LCD
Oil injection assembly (all models except FA1000/
AR2788SX28
FA1000B)
AR2788SX29 Tank filter bracket / straps
Item
AR2788X14a 1/2˝ ACME tank refill adaptor
AR2788X14b 1/4˝ SAE tank refill adaptor
AR2788X16 Low side gauge kit
AR2788X17 High side gauge kit
AR2788X25 Scale PCB
AR2788X28 Power supply
AR2788X30 1lb. check weight
AR2788X32 15 AMP breaker 115 VAC
AR2788X33 10 AMP breaker 240 VAC
AR2788X34 ON / OFF monentary switch
AR2788X40 6 ft. power cord 115 VAC
AR2788X41 6 ft. power cord 240 VAC (Europe)
AR2788X45 High pressure switch 450 PSI
AR2788X46 Pressure transducer
AR2788X53 IEC heater blanket / vacuum pump outlet
AR2788X57 Gauge line repair kit
AR2788X64 Castor with brake
AR2788X65 10˝ wheel
AR2788X67 Charging orifice
Description
Description
Description
AR27XHB15 115 volt 300 watt heater blanket
AR27XHB230 230 volt 300 watt heater blanket
ARXF5 Coded 41 cu in filter
Item
FA1234X2 FA1000 compressor assembly 115V
FA1234X3 FA1000 compressor assembly 230V 50 Hz.
FA1234X4 FA1000 compressor assembly 100V
FA1234X5 AR2788 II / FA1000 oil drain bottle assembly
FA1234X6 AR2788 II / FA1000 Low side block complete
FA1234X7 FA1000 High side block complete
FA1234X8 FA1000 DOA chamber
FA1234X9 FA1000 R-134A High side service hose
FA1234X10 FA1000 R-134A Low side service hose
FA1234X13 AR2788S II / FA1000 discharge tank hose
FA1234X14 Hybrid hose assembly for R134A
FA1234X16 AR2788S II / FA1000 vacuum pump hose
FA1000X2 DOA out comp suction hose
FA1000X3 Comp discharge DOA HX IN hose
FA1000X4 DOA HX OUT-HV1 tee hose
FA1000X5 DOA oil drain HV3 hose
FA1234X21 FA1000 DOA IN tee (AUX) HS1 purge hose
AR2788SX38 HV1 tank vapor bulk head hose
AR2788SX37 LS1 tank liquid bulk head hose
FA1000X6 HV1 tee HV2 hose
AR2788SX35 HV3 oil drain bulk head hose
FA1000X7 LV3-HV2 tee VAC hose
FA1000X8 LV4 (Regulator) DOA IN tee hose
FA1234X28 AR2788 II / FA1000 four relay PCB
FA1234X29 FA1000 temp. sensor internal tank vapor line
FA1234X30 AR2788 II / FA1000 temp. sensor ambient
FA1234X33 FA1000 key pad
FA1234X34 FA1000 R-134A coupler storage fittings set
FA1234X37 Regulator - 80 PSIG
FA1000X1 Main PCB
FA1234X39 IEC main power inlet
QCH134 R-134A High side coupler
QCL134 R-134A Low side coupler
22
Description
