Operating and installation instructions
Ceramic hobs with induction
To avoid the risk of accidents or damage to the appliance it is essential
to read these instructions before it is installed and used for the first time.
en-GB
M.-Nr. 11 123 010

Advertisement

Table of Contents
loading

Summary of Contents for Miele KMDA 7774-1

  • Page 1 Operating and installation instructions Ceramic hobs with induction To avoid the risk of accidents or damage to the appliance it is essential to read these instructions before it is installed and used for the first time. en-GB M.-Nr. 11 123 010...
  • Page 2: Table Of Contents

    Before using for the first time ................ 22 Cleaning the hob for the first time................. 22 Switching on the hob for the first time ..............22 Setting up Miele@home ..................23 Induction ...................... 26 How it works......................26 Pans........................26 Noises........................
  • Page 3 Contents Demonstration mode..................... 43 Displaying hob data....................43 Safety features.....................  44 System lock / Safety lock..................44 Safety switch-off ....................46 Overheating protection..................47 Programming .......................  48 Cleaning and care .................... 51 Grease filter/Extraction grille ................. 53 Cooker hood drip tray ................... 54 Resetting the grease filter operating hours counter ..........
  • Page 4 Contents Onset installation....................84 Flush-fit installation ....................85 Exhaust ducting.................... 86 Electrical connection .................. 87 After sales service.................... 90 Contact in case of malfunction ................90 Data plate ......................90 Warranty ........................ 90 Product data sheets ...................  91 Conformity declaration .................. 93...
  • Page 5: Warning And Safety Instructions

    They contain important notes on installation, safety, use and maintenance. Miele cannot be held liable for damage caused by non-compliance with these instructions. Keep these instructions in a safe place and ensure that new users...
  • Page 6 Warning and Safety instructions Correct application  This hob is intended for domestic use and use in other similar en- vironments.  This hob is not intended for outdoor use.  It is intended for domestic use only to cook food and keep it warm.
  • Page 7 Warning and Safety instructions Safety with children  Children under 8 years of age must be kept away from the hob unless they are constantly supervised.  Children over 8 years of age may use the hob without supervision if its operation has been clearly explained to them and they are able to use it safely.
  • Page 8  Unauthorised installation, maintenance and repairs can cause considerable danger for the user. Installation, maintenance and re- pairs must only be carried out by a Miele authorised technician.  Damage to the hob can compromise your safety. Check the hob for visible signs of damage.
  • Page 9 Miele authorised service technician. Otherwise the war- ranty is invalidated.  Miele can only guarantee the safety of the appliance when genu- ine original Miele replacement parts are used. Faulty components must only be replaced by Miele spare parts.
  • Page 10 Warning and Safety instructions Using at the same time as other heating appliances that depend on the air from the room  Danger of toxic fumes! Great care should be taken when using the cooker hood in the same room or the same area of the house as another heating ap- pliance that depends on the air from the room.
  • Page 11 Warning and Safety instructions In order to ensure safe operation and to prevent gases given off by the heating appliance from being drawn back into the room, when the cooker hood and the heater are both operated simultaneously, an underpressure in the room of 0.04 mbar (4 Pa) is the maximum permissible.
  • Page 12 Warning and Safety instructions Correct use  The hob gets hot when in use and remains hot for a while after be- ing switched off. There is a danger of burning until the residual heat indicators go out.  Oil and fat can overheat and catch fire. Do not leave the hob unat- tended when cooking with oil and fat.
  • Page 13 Warning and Safety instructions  You could burn yourself on the hot hob. Protect your hands with heat-resistant pot holders or gloves when handling hot pots and pans. Do not let them get wet or damp, as this causes heat to trans- fer through the material more quickly with the risk of scalding or burning yourself.
  • Page 14 Warning and Safety instructions  Only use pots and pans with smooth bases. Rough bases will scratch the ceramic glass.  Lift pans into position on the hob. Sliding them into place can cause scuffs and scratches.  Because induction heating works so quickly, the base of the pan could, under certain circumstances, heat up to the temperature at which oil or fat self-ignites within a very short time.
  • Page 15 Warning and Safety instructions  If the cookware only partially covers a cooking or extended zone, the handle could become very hot. Always place cookware in the middle of a cooking or extended zone!  Deposits of grease and dirt will prevent the cooker hood from working properly.
  • Page 16 (see relev- ant section). Accessories  Only use genuine original Miele accessories and spare parts with this appliance. Using accessories or spare parts from other manu- facturers will invalidate the warranty and Miele cannot accept liabil- ity.
  • Page 17: Caring For The Environment

    / recycling centre for electrical and electronic ap- pliances, or contact your dealer or Miele for advice. You are also respons- ible (by law, depending on country) for deleting any personal data that may be stored on the appliance being disposed of.
  • Page 18: Guide To The Appliance

    Guide to the appliance a PowerFlex cooking zone cd can be combined to form a Power- Flex cooking area b PowerFlex cooking zone e Controls / Indicators ab can be combined to form a Power- f Grille Flex cooking area c PowerFlex cooking zone g Grease filter d PowerFlex cooking zone...
  • Page 19: Controls / Indicators

    Guide to the appliance Controls / Indicators Cooking zones/Timer Sensor controls a For switching the hob on and off b Stop & Go c Wipe protection d For switching PowerFlex cooking zones on together/separately. e For activating/deactivating the keeping warm function f Numerical keybank For setting power levels/minute minder and switch-off times g Automatic switch-off selector for cooking zones...
  • Page 20 Guide to the appliance Cooker hood a Numerical keybank for setting the power level b Touch control for the 5 minute run-on option c Touch control for the 15 minute run-on option d Clean grease filter indicator e Reactivate charcoal filter indicator...
  • Page 21: Cooking Zones

    Guide to the appliance Cooking zones Ø in cm* Cooking zone Rating in watts for 230 V**  15–23 Normal 2100 TwinBooster, level 1 3000 TwinBooster, level 2 3650  15–23 Normal 2100 TwinBooster, level 1 3000 TwinBooster, level 2 3650  +  22–23 / Normal 3400...
  • Page 22: Before Using For The First Time

    Before using for the first time  Please stick the extra data plate for Switching on the hob for the the appliance supplied with this doc- first time umentation in the space provided in The metal components have a protect- the “After sales service”...
  • Page 23: Setting Up Miele@Home

    Store™. WiFi module. The hob can be connec- ted to the household WiFi network. If your Miele cooker hood is also con- nected to the home WiFi network, you can control the cooker hood automatic- ally with the Con@ctivity function. Fur-...
  • Page 24 Before using for the first time Connecting via the app Connecting via WPS The Miele@mobile app can be used to Pre-requisite: You must have a WPS connect to your network. (WiFi protected setup) compatible router.  Install the Miele@mobile app on your mobile device.
  • Page 25 Before using for the first time Cancelling the process  Touch any sensor. Resetting settings It is not necessary to reset the router when replacing it.  Switch the hob on.  Touch the 0 sensor control on any of the numerical displays. ...
  • Page 26: Induction

    Induction How it works Pans An induction coil is located under each Suitable pans induction cooking zone. The coil cre- – stainless steel pans with a magnetic ates a magnetic field that reacts directly base with the base of the pan and heats it up.
  • Page 27 Induction No pan/unsuitable pan display Tips The set power level flashes in the nu- – To make optimum use of the cooking merical display for the cooking zone zones, choose pans with a suitable base diameter (see chapter “Cooking – if the zone has been switched on zones”).
  • Page 28: Noises

    Induction Noises When using an induction hob, the fol- lowing noises can occur in the pan, de- pending on what it is made of and how it has been constructed. Buzzing on the higher power settings. This will decrease or cease altogether when the power setting is reduced.
  • Page 29: How The Cooker Hood Works

    How the cooker hood works The cooker hood can be operated in Operating hours counter one of the following ways: The number of hours that the cooker hood has been used for is stored in Extraction mode memory. The air is drawn in and cleaned by the When the grease filter symbol ...
  • Page 30: Tips On Saving Energy

    Tips on saving energy – Use a lid whenever possible to min- – Clean or replace the filters at regular imise heat loss. intervals. Heavily soiled filters reduce performance, increase the risk of fire – Select a smaller pan when cooking and are unhygienic.
  • Page 31: Cooking Zone Power Levels

    Cooking zone power levels The cooking zones are set as standard with 9 power levels. If you wish to fine-tune a setting, you can extend the power level range to 17 power levels (see “Program- ming”). Setting range Default Extended setting settings (9 power (17 power...
  • Page 32: Operation

    Operation Using the appliance  Malfunction due to dirty and/or covered sensor controls. This ceramic hob is equipped with elec- tronic sensor controls which react to If the sensor controls are dirty or covered this could cause them to fail finger contact.
  • Page 33: Switching On The Hob

    Operation Switching off a cooking zone  Risk of fire with overheated food. Unattended food can overheat and  To switch off a cooking zone, touch catch alight. the  0 sensor for that cooking zone. Do not leave the hob unattended ...
  • Page 34: Power Level Setting - Extended Setting Range

    Operation Power level setting - Extended PowerFlex area setting range The PowerFlex cooking zones combine automatically to form a PowerFlex  Touch the numerical keybank in cooking area when you place a suffi- between two number sensors. ciently large pot or pan on them (see The numbers to the left and right of the “Guide to the appliance - Hob”).
  • Page 35: Auto Heat-Up

    Operation Auto heat-up Continued cook- Heat-up time ing setting* [min : sec] When Auto heat-up has been activated, the cooking zone switches on automat- Approx. 0:15 ically at the highest setting and then Approx. 0:15 switches to the continued cooking set- ting which you have previously selec- Approx.
  • Page 36: Booster

    Operation Activating TwinBooster Booster The cooking zones are equipped with a Level 1 TwinBooster.  Place the pan on the cooking zone When activated, the power is boosted you want to use. so that large quantities can be heated  Select a power level if necessary. up quickly, e.g.
  • Page 37: Keeping Warm

    Operation Activating/deactivating the keeping Keeping warm warm function This function is for keeping food warm  Touch the  sensor for the cooking which has just been cooked and is still zone you wish to use. hot. It is not for reheating food that has gone cold.
  • Page 38: Extractor

    Operation Power level setting / Switching off Extractor  To switch the fan on touch the appro- The extractor will switch itself on auto- priate sensor for the power level you matically if a there is a pan on a cook- want.
  • Page 39 Operation Run-on time It is advisable to run the fan for a few minutes after cooking has finished. This helps to neutralise any lingering va- pours and odours in the air. The follow- ing two options are available:  (5 minutes) and   (15 minutes). The run-on duration will be carried out using the power level set during activa- tion.
  • Page 40: Timer

    Timer The hob has to be switched on if you The functions can be used at the same wish to use the timer. time. The shortest time is always dis- A duration of between 1 minute (:) played and the  sensor control and 9 hours 59 minutes (:) can be (minute minder) or the indicator light of the cooking zone for automatic switch-...
  • Page 41: Switching Off A Cooking Zone Automatically

    Timer the  sensor repeatedly until the in- Switching off a cooking zone dicator light for the zone you require automatically flashes. You can set a time after which the Changing the switch-off time cooking zone will switch off automatic- ally.
  • Page 42: Additional Functions

    Additional functions Stop & Go Recall When Stop & Go is activated, the power If the hob is switched off in error during of all cooking zones in use is reduced to operation, this function can be used to power level 1. The power level of the reset all settings.
  • Page 43: Wipe Protection

    Additional functions Wipe protection Displaying hob data The model number and software ver- The hob sensors can be locked for sion of the hob can be displayed. There 20 s in order, for example, to remove must not be any pots or pans on the soiling.
  • Page 44: Safety Features

    Safety features The safety lock is activated when the System lock / Safety lock hob is switched on. When the safety The lock function is deactivated if lock is activated, the hob can be oper- there is a break in the mains supply. ated only under certain conditions: –...
  • Page 45 Safety features Activating the safety lock  Touch and hold the  and  sensors at the same time for 6 seconds. The seconds can be seen counting down in the timer display. When this time has elapsed  will appear in the timer display.
  • Page 46: Safety Switch-Off

    Safety features Safety switch-off Power level* Maximum operating time [h:min] Sensor controls are covered Safety setting Your hob will turn off automatically if one or several of the sensors remain 10:00 8:00 5:00 covered for longer than 10 seconds, for example, by finger contact, food boiling 10:00 7:00...
  • Page 47: Overheating Protection

    If, despite removing the cause, the overheating protection mechanism trig- – The cooking zone turns off automat- gers again, contact Miele Service. ically.  will flash alternately with  in the timer display. You can use the cooking zone again as usual when the fault code has gone out.
  • Page 48: Programming

    Programming You can adapt the programming of the To save the settings hob to your personal needs. Several  While the programme is showing in settings can be altered in succession. the display (e. g. :) touch the  sensor until the indicators go out. After accessing programming mode, the  symbol appears and ...
  • Page 49 Programming Settings Programme Code P:01 Demonstration mode C:00 Demonstration mode off C:01 Demonstration mode on P:02 C:00 Power management C:01 3680 W C:02 3000 W C:03 2000 W C:04 1000 W P:03 Factory default setting C:00 Factory default settings not re- stored C:01 Factory default settings restored P:04 Number of power levels C:00...
  • Page 50 Programming Settings Programme Code P:10 Signing WiFi on C:00 Not active/deactivated C:01 Active but not configured C:02 Active and configured C:03 Connection possible via WPS push button C:04 WiFi reset to default (C:00) C:05 Direct WiFi connection between hob and external hood without App (Con@ctivity 3.0) P:12 Sensor controls reaction...
  • Page 51: Cleaning And Care

    Cleaning and care  Clean the hob after every use.  Risk of burning due to hot cook- ing zones.  Dry the hob thoroughly after cleaning with water to avoid limescale residue. The cooking zones will be hot after use.
  • Page 52  Then clean the ceramic glass surface able for use on glass. with the Miele ceramic and stainless steel hob cleaner (see “optional ac-  Afterwards, clean the ceramic surface cessories”) or with a proprietary...
  • Page 53: Grease Filter/Extraction Grille

    Cleaning and care Cleaning the extraction grille and the Grease filter/Extraction grille grease filter by hand. The extraction grille and the reusable  Clean the extraction grille and the metal grease filter collect solid matter grease filter with a soft nylon brush in from kitchen vapours (grease, dust, a mild solution of hot water and a etc.) and therefore prevent soiling of the...
  • Page 54: Cooker Hood Drip Tray

    Cleaning and care Cooker hood drip tray Resetting the grease filter op- erating hours counter Clean the drip tray if liquid from food being spilled or boiling over has got into After cleaning the grease filter, the oper- the cooker hood. ating hours counter needs to be reset.
  • Page 55: Problem Solving Guide

    There is no power to the hob. zones will not switch  Check whether the mains fuse has tripped. Con- tact an electrician or Miele Service (for the min- imum fuse rating, see data plate). There may be a technical fault.
  • Page 56 Problem solving guide Problem Cause and remedy The hob has switched One or more of the sensor controls are covered, e.g. off automatically. When by finger contact, food boiling over or an object. the element is switched  Clean off any dirt and/or remove the object (see back on, ...
  • Page 57  Disconnect the hob from the mains electricity sup- play and a buzzer ply. sounds.  Call Miele Service. The hob must be connected to the mains according to the wiring diagram. 1 and a number, e.g. 1-0 Cooking zone fault flashes alternately with ...
  • Page 58  Interrupt the power supply to the hob for approx. 1 minute.  If the problem persists after power has been re- stored, please contact Miele Service. Liquid has got into the Due to boiling over or spillage, liquid has made its cooker hood.
  • Page 59 Problem solving guide Problem Cause and remedy The  sensor control is The charcoal filter needs to be reactivated. lit up.  If the cooker hood is being operated in Recircula- tion mode, reactivate the charcoal filter as de- scribed in the operating and installation instruc- tions supplied with the recirculation box.
  • Page 60: Optional Accessories

    Miele dealer. Microfibre cloth Pans Miele offer a wide range of pans which are perfect for Miele hobs. Please refer to the Miele website for more details on individual products. Removes finger marks and light soiling –...
  • Page 61: Safety Instructions For Installation

    (e.g. a drawer) or be subject to mechanical ob- struction which could damage it.  Observe carefully the safety clearances listed on the following pages.  Exhaust ducting must be of non-inflammable material. Suitable material is available from Miele specialist dealers or the Miele Spares Dept.
  • Page 62 Safety instructions for installation  The appliance must not be connected to a chimney or flue which is in use. Neither should it be connected to ducting which ventilates rooms with fireplaces.  If exhaust air is to be extracted into a chimney or ventilation duct no longer used for other purposes, seek professional advice.
  • Page 63: Safety Distances

    Safety distances Safety distance above the hob The safety distance specified by the manufacturer of the cooker hood must be maintained between the hob and the cooker hood above it. If combustible objects are installed above the hob (e.g., cabinets, utensil rail, etc.), a minimum safety distance of 600 mm must be maintained.
  • Page 64 Safety distances Safety distances to the sides and back of the hob It is advisable to install the hob with plenty of space either side of it. The minimum distance  shown below must be maintained between the back of the hob and a tall unit or wall. The minimum distance , ...
  • Page 65 Safety distances Safety distance when installing the appliance near a wall with additional niche cladding A minimum safety distance must be maintained between the worktop cut-out and any niche cladding to protect it from heat damage. If the niche cladding is made from a combustible material (e.g. wood) a minimum safety distance ...
  • Page 66: Installation Notes

    Installation notes Tiled worktops All dimensions are given in mm. Onset installation Seal between the hob and the work- Grout lines  and the hatched area un- derneath the hob frame must be smooth and even. If they are not the hob will not sit flush with the worktop and the sealing strip underneath the hob will not provide a good seal...
  • Page 67: Flush-Fit Installation

    Installation notes Natural stone worktops Flush-fit installation The hob is set directly in the cut-out. Flush-fit installation is only possible in natural stone (granite, marble), solid Solid wood worktops, tiled worktops, wood and tiled worktops. Certain glass worktops models are suitable for building into The hob is set on a wooden frame in- glass worktops - please see relevant side the cut-out.
  • Page 68: Installation Examples

    Installation notes Installation examples Recirculation mode Extraction mode...
  • Page 69: Building-In Dimensions - Onset Hobs

    Building-in dimensions - Onset hobs a Front KMDA 7774 FR b Removable drip tray c Mains connection box with mains connection cable, L = 1440 mm d Air duct connection – at the back (ex-works) e Air duct connection - on the right (conversion required) f Air duct connection - on the left (conversion required)
  • Page 70 Building-in dimensions - Onset hobs a Front KMDA 7774 FL b Removable drip tray c Mains connection box with mains connection cable, L = 1440 mm d Air duct connection – at the back (ex-works) e Air duct connection - on the right (conversion required) f Air duct connection - on the left (conversion required)
  • Page 71: Worktop Depth 600 Mm

    Building-in dimensions - Onset hobs KMDA 7774 FL Worktop depth 600 mm KMDA 7774 FR a Housing unit back panel The housing unit back panel must be a Housing unit back panel removable for service work. The The housing unit back panel must be housing unit wall and an adjoining removable for service work.
  • Page 72 Building-in dimensions - Onset hobs Extraction to the rear (standard) Extraction to the right Extraction to the left...
  • Page 73: Worktop Depth Greater Than 600 Mm

    Building-in dimensions - Onset hobs KMDA 7774 FL Worktop depth greater than 600 mm KMDA 7774 FR a Housing unit back panel The housing unit back panel must be removable for service work. The a Housing unit back panel housing unit wall and an adjoining room wall or a piece of furniture The housing unit back panel must be must be at least 110 mm apart to...
  • Page 74 Building-in dimensions - Onset hobs Extraction to the rear (standard) Extraction to the right Extraction to the left...
  • Page 75: Building-In Dimensions - Flush-Fit Hobs

    Building-in dimensions - Flush-fit hobs a Front KMDA 7774 FL b Removable drip tray c Mains connection box with mains connection cable, L = 1440 mm d Stepped cut-out e Wooden frame (to be provided on site) f Air duct connection – at the back (ex-works) g Air duct connection - on the right (conversion required)
  • Page 76: Worktop Depth 600 Mm

    Building-in dimensions - Flush-fit hobs Worktop depth 600 mm KMDA 7774 FL a Housing unit back panel The housing unit back panel must be removable for service work. The housing unit wall and an adjoining room wall or a piece of furniture must be at least 110 mm apart to ensure sufficient room for the duct- ing.
  • Page 77 Building-in dimensions - Flush-fit hobs Extraction to the rear (standard) Extraction to the right Extraction to the left...
  • Page 78: Worktop Depth Greater Than 600 Mm

    Building-in dimensions - Flush-fit hobs Worktop depth greater than 600 mm KMDA 7774 FL a Housing unit back panel The housing unit back panel must be removable for service work. The housing unit wall and an adjoining room wall or a piece of furniture must be at least 110 mm apart to ensure sufficient room for the duct- ing.
  • Page 79 Building-in dimensions - Flush-fit hobs Extraction to the rear (standard) Extraction to the right Extraction to the left...
  • Page 80: Change Extraction Direction

    Change extraction direction Rotating the fan  Place the hob on its ceramic surface on a soft underlay.  Rotate the fan by 90°.  Secure the fan by the 5 screws. Make sure that the plastic edge is on the ...
  • Page 81 Change extraction direction Extraction to the left  Undo the 4 screws on the frame.  Guide the cable under the fan.  Reattach the cable tie.  Refit the 4 screws in the frame.  Loosen the cable tie. ...
  • Page 82: Installation

    Installation Connection to window contact, if required  The window contact is connec- ted to the mains voltage! Danger of electric shock! Disconnect the hob from the mains electricity supply before connecting the switching mechanism. The connection cable of the switch- ing system must only be connected by a suitably qualified and compet- ent person.
  • Page 83 Installation  Exchange the jumper  with the con- nection cable of the switching sys- tem.  Close the casing.  Tighten the strain relief screw.  Reinsert the plug.
  • Page 84: Onset Installation

    Installation Onset installation  Prepare the worktop cut-out Remem- ber to maintain the minimum safety distances (see “Safety distances”).  Seal the cut surfaces on wooden worktops with a suitable heat-resist- ant sealant to avoid swelling caused by moisture. The sealant must be temperature-resistant.
  • Page 85: Flush-Fit Installation

    Installation Flush-fit installation  Create the worktop cut-out. Remem- ber to maintain the minimum safety distances (see “Safety distances”).  Solid wood, tiled and glass worktops: Fix a wooden frame 5,5 mm below the top edge of the worktop (see building-in diagram for “Flush-fit in- stallation”).
  • Page 86: Exhaust Ducting

    Exhaust ducting  If the cooker hood is used at the same time as a heating appliance that relies on oxygen from the same room, there is a risk of toxic fumes. It is essential that the “Warning and Safety” instructions are observed. Seek approval from the building in- spector where necessary in order to ...
  • Page 87: Electrical Connection

    The connection data is quoted on the Miele cannot be held liable for dam- data plate. Please ensure these match age or injury caused by unauthorised the household mains supply.
  • Page 88 H 05 VV-F with a suit- able cross section. A suitable connec- Residual current device (RCD) tion cable is available to order from  Switch the main switch from 1 (on) to Miele. 0 (off) or press the test button.
  • Page 89 Electrical connection Wiring diagram a b c d e 200-240 V~ 200-240 V~ 200-240 V~ (L3) 200-240 V~ 200-240 V~ b c d (L2) 200-240 V~...
  • Page 90: After Sales Service

    In the event of any faults which you cannot remedy yourself, please contact your Miele Dealer or Miele Service. Contact information for Miele Service can be found at the end of this document. Please note that telephone calls may be monitored and recorded for training pur- poses and that a call-out charge will be applied to service visits where the problem could have been resolved as described in this booklet.
  • Page 91: Product Data Sheets

    Information for domestic electric hobs In acc. with regulation (EU) No. 66/2014 MIELE Model name/identifier KMDA 7774-1 Number of cooking zones and/or areas For circular cooking zones: diameter of useful sur- 1. = 230x390 mm face area/cooking zone 2.
  • Page 92 Product data sheets Data sheet for household cooker hoods In acc. with delegated regulation (EU) No. 65/2014 and regulation (EU) No. 66/2014 MIELE Model name/identifier KMDA 7774-1 Annual Energy Consumption (AEC 25,1 kWh/year hood Energy efficiency class Energy efficiency index (EEI...
  • Page 93: Conformity Declaration

    Conformity declaration Miele hereby declares that this ceramic induction hob complies with Directive 2014/53/EU. The complete text of the EU declaration of conformity is available from one of the following internet addresses: – Products, Download from www.miele.co.uk – For service, information, operating in- structions etc: go to www.miele.co.uk/domestic/cus-...
  • Page 95 Tel: +65 6735 1191 Fax. +971 4 3418 852 Fax: 011-46 900 001 Fax: +65 6735 1161 800-MIELE (64353) E-mail: customercare@miele.in E-Mail: info@miele.com.sg E-Mail: info@miele.ae Internet: www.miele.in Internet: www.miele.sg Website: www.miele.ae Manufacturer: Miele & Cie. KG, Carl-Miele-Straße 29, 33332 Gütersloh, Germany...
  • Page 96 KMDA 7774-1 en-GB M.-Nr. 11 123 010 / 00...
