- Page 1 A200P E n g i n e e r i n g O p e r a t i o n & ™ Advanced Series PLASTIC Pumps M a i n t e n a n c e S i m p l i f y y o u r p r o c e s s WIL -11060-E-03 REPLACES WIL -11060-E-02...
-
Page 2: Table Of Contents
..........1 SECTION 2 WILDEN PUMP DESIGNATION SYSTEM ....... . .2 SECTION 3 HOW IT WORKS—PUMP &... -
Page 3: Cautions-Read First
CAUTION: Do not exceed 8.6 bar (125 psig) air supply on polypropylene and PVDF pumps. NOTE: When reinstalling the outer pistons, apply ® two (2) drops of Loctite 246 to the shaft internal threads before the diaphragm assembly. WILDEN PUMP & ENGINEERING, LLC WIL-11060-E-03... -
Page 4: Wilden Pump Designation System
0180 Accu-Flo™, 24V AC / 12V DC coil, PFA coated 0360 Accu-Flo™, 24V DC coil, DIN flange NOTE: MOST ELASTOMERIC MATERIALS USE COLORED DOTS FOR IDENTIFICATION. ® Viton is a registered trademark of DuPont Dow Elastomers. WILDEN PUMP & ENGINEERING, LLC WIL-11060-E-03... - Page 5 H O W I T W O R K S — P U M P The Wilden diaphragm pump is an air-operated, positive displacement, self-priming pump. These drawings show fl ow pattern through the pump upon its initial stroke. It is assumed the pump has no fl uid in it prior to its initial stroke.
-
Page 6: Dimensional Drawings
DIMENSIONS ITEM METRIC (mm) STANDARD (inch) 13 mm (1/2") 18.0 FNPT AIR INLET 15.0 10.6 17.1 13.9 12.2 DIN (mm) ANSI (inch) 85 DIA. 3.1 DIA. 115 DIA. 4.3 DIA. 14 DIA. 0.6 DIA. WILDEN PUMP & ENGINEERING, LLC WIL-11060-E-03... -
Page 7: Rubber-Fitted
(60 psig) requires 5.5 bar (80 psig) and For optimum life and performance, pumps should be specifi ed so that daily operation 20.4 Nm /h (12 scfm) air consumption. parameters will fall in the center of the pump performance curve. WILDEN PUMP & ENGINEERING, LLC WIL-11060-E-03... -
Page 8: Suction Lift Curves
These curves demonstrate the fl ow created when the stroke rate is modifi ed under static air and fl uid pressure condition. This curve can be applied to different pressure conditions to estimate the change in fl ow due to stroke rate. WILDEN PUMP & ENGINEERING, LLC WIL-11060-E-03... - Page 9 S U G G E S T E D I N S T A L L A T I O N All Wilden pumps are manufactured with a variety of materials used, thus allowing trapped air to bleed off and improving for the air distribution system, liquid path and elastomers.
- Page 10 AIR OPERATED PUMPS: To stop the pump from pumping equipment such that it can be reached safely operating in an emergency situation, simply close the in an emergency situation. WILDEN PUMP & ENGINEERING, LLC WIL-11060-E-03...
- Page 11 fl uid buna-n compatible white bearing grease every 50 mil- all effect the parts life of a Wilden pump. Periodic lion cycles. Continuous lubrication with a compatible inspections have been found to offer the best means...
- Page 12 1. Broken spring, mechanical binding. 5. Check to make sure that all suction connections are air tight, and that the clamp bands are properly Excessive leaking from air valve vent. tightened. 1. Worn seals in air valve. WILDEN PUMP & ENGINEERING, LLC WIL-11060-E-03...
- Page 13 Power Requirement: 110-120V AC @ 50/60 Hz., 220-240V AC @ 50 Hz. Pump Output Voltage & Amps: 12V DC at no greater than 0.4 amps. External Input Activation: Dry contact less than 1 mA WILDEN PUMP & ENGINEERING, LLC WIL-11060-E-03...
-
Page 14: Exploded View And Parts Listing
R u b b e r / T P E - F i t t e d E X P L O D E D V I E W —30 —29 —24 —25 3— —26 4— 2— —27 1— —28 —23 WILDEN PUMP & ENGINEERING, LLC WIL-11060-E-03... - Page 15 DIN Flange: Polypropylene = 02-5091-02, PVDF = 02-5091-21 All boldface items are primary wear parts. ADAPTER BLOCK OPTION FOR A200B Part Desription Qty. A200P/PPPP Adapter Block 00-2155-20 Fitting, Air Inlet 00-2170-20 Screw, HHC 04-6000-03 WILDEN PUMP & ENGINEERING, LLC WIL-11060-E-03...
-
Page 16: Ptfe-Fitted
P T F E - F i t t e d E X P L O D E D V I E W —31 —30 —25 —26 —27 3— 2— —28 4— 1— —29 —24 WILDEN PUMP & ENGINEERING, LLC WIL-11060-E-03... - Page 17 DIN Flange: Polypropylene = 02-5091-02, PVDF = 02-5091-21 All boldface items are primary wear parts. ADAPTER BLOCK OPTION FOR A200B Part Desription Qty. A200P/PPPP Adapter Block 00-2155-20 Fitting, Air Inlet 00-2170-20 Screw, HHC 04-6000-03 WILDEN PUMP & ENGINEERING, LLC WIL-11060-E-03...
-
Page 18: Elastomer Options
24V AC, Nema 7 Coil 00-2110-99-154 24V DC, Nema 7 Coil 00-2110-99-155 110V AC Coil 00-2110-99-156 110V AC Nema 7 Coil 00-2110-99-157 International 24V DC Coil Meets European standards and regulations; CENELEC/PTB File #EX-91.C.2027. WILDEN PUMP & ENGINEERING, LLC WIL-11060-E-03... - Page 19 Since the use of Wilden pumps and parts is beyond our control, we cannot guarantee the suitability of any pump or part for a particular application and Wilden Pump and Engineering, LLC shall not be liable for any consequential damage or expense arising from the use or misuse of its products on any application.
- Page 20 Pulsation dampening Fewest parts in industry Drum unloading systems Solutions since 1955 Complete system solutions The result of innovative thought The result of original thought Your Local Authorized Distributor: Printed in the U.S.A. Copyright 2005, Wilden Pump & Engineering, LLC...
