Speaker Settings

In the upper area, you can select the
speaker you want to configure with the
controls below.
Use the upper slider to adjust the
distance of the speaker to the seating
position.
And here you determine the volume of
the selected speaker compared to the
others. You can raise or lower the
level by up to 12 dB each.
Here you indicate
selected one is a "large speaker", thus
suitable for playing deep frequencies
(bass). If you have selected "LFE" at
the top, specify here if a subwoofer is
connected.
With this switch you can play a test
tone. This will allow you to identify the
speaker selected above and verify
that it is connected to the correct
output of the decoder. In addition, the
test tone is helpful to optimally adjust
the volume ratios
individual speakers.
whether the
between the
