5 Motor Assembly

Figure 3 - Cutter Motor Assembly
KIT REF
1
1.1
1.2
1.3
1.4
1.5
1.6
2
(1.6)
2.2
2.3
3
3.1
3.2
3.3
3.4
3.5
3.6
3.7
3.8
4 4
PART DESCRIPTION
Vortex Motor Kit
Electric Motor 230V/400V 3PH 50Hz
Motor Gasket
Barbed Fitting
Vortex Motor Cable
Cutter Motor Adaptor (x1)
Mechanical Seal (x1)
Vortex Mechanical Seal Kit
Mechanical Seal
V Seal
M8 x 50 H.H.S.S
Vortex Blade Kit
Top Cutter Blade
Bottom Cutter Blade
Cutting Blade Locking Plate (Tab Washer)
M8 x 20 Hex HD Screw x2
M8 x 50 Hex HD Screw x1
M8 x 35 Button HD Screw x2
Fibre Gasket
D8 Spring Washer
Cutter Motor Assembly Kit
KIT NUMBER ITEM NUMBER*
9207004
9200424
9752027
9750100
9200693
9200402
9753005
9207006
9753005
9753000
9750006
9207015
9200418
9200417
9753011
9750077
9750006
9750075
(also in kit 9207004) 9753010
9750033
9207005
