Beyerdynamic MCS 523 Product Manual

MCS 523
C
HAIRMAN
M
ICROPHONE
U
NIT WITH
L
OUDSPEAKER
Order # 459.313
F
EATURES
• Modern design plastic housing with non-glare, scratch-resistant Nextel
• High-quality gooseneck microphone (including pop screen)
• Ring of the gooseneck illuminates to indicate the Ready-to-Talk status
• 3 buttons (priority, microphone, clear)
• LED to indicate microphone is switched on or off
• Integrated loudspeaker
• Volume control to adjust the loudspeaker's volume
• DIP switches for addressing and programming the microphone unit
• 15-pin Sub-D socket for the system connecting cable
• Fixed connecting cable (3 m long) with 15-pin Sub-D plug
• Mono mini-jack output for the connection of recorders, dictating machines etc.
D
ESCRIPTION
The MCS 523 chairman's microphone unit consists of one microphone button, one priority button and one clear button in the housing.
The microphone button operates normal switching on and off of the microphone. The chairman does not depend upon the limited
number of open microphones (NOM). Using the priority button the chairman can intervene into the discussion and mute or clear the
activated delegate microphone units depending on the system configuration. Using the clear button all activated delegate micro-
phone units are switched off.
The Ready-to-Talk status of the microphone is indicated by the illuminated red ring and the green LED in the housing.
The integrated loudspeaker has been optimised for excellent speech intelligibility. If the participant switches on the microphone, the
loudspeaker is switched off automatically. Depending on the system configuration it is possible that the loudspeakers of other, pre-
defined microphone units, e.g. neighbouring microphone units, are also switched off.
The metal base plate of the housing gives good physical isolation of the microphone unit against mechanical coupling.
A ' S
RCHITECT S
Digitally controlled chairman microphone unit with three buttons for switching on/off, priority and clearing. Programmable priority
function like switching on only or switching on and clearing or muting of the switched on delegate microphone units. LED: green
indication for microphone on. Fixed condenser gooseneck microphone (back electret) with cardioid polar pattern. Total length 400 mm
and diameter 8 mm. Illuminated ring below the mic capsule to indicate the ready-to-talk status. 15-pin Sub-D socket to connect the
system connecting cable. 3 m long connecting cable with 15-pin Sub-D plug. Mini jack for the connection of recorders. Integral loud-
speaker with volume control. DIP-switches for microphone address. Plastic housing with charcoal-grey, non-glare and scratch-resistant
Nextel ® finish. Dimensions (LxWxH) 190x155x52 mm.
Manufacturer: beyerdynamic GmbH, Germany
Type: MCS 523
Germany
Theresienstr. 8
D-74072 Heilbronn
Tel. +49 (0 )71 31 / 6 17-0
Fax +49 (0 )71 31 / 617-224
E-mail: info@beyerdynamic.de
Internet: www.beyerdynamic.de
