1. Introduction

This document provides technical information and instructions for setting up and running the EVDK Based Vehicle
Classification Demo. This demo is designed to utilize the Lattice Machine Learning Engine (MLE) IP and is implemented
on the Lattice Embedded Vision Development Kit (EVDK). The EVDK based vehicle classification demo takes image data
from one of the cameras on the EVDK and feeds it through a CNN and outputs the input image with a bounding box
overlay through the HDMI Output. The color of the bounding box and a letter indicate the vehicle class.
Refer to the following documents for detailed information on Lattice development boards and kit:

Lattice Embedded Vision Development Kit User Guide (FPGA-UG-02015)

CrossLink VIP Input Bridge Board Evaluation Board User Guide (FPGA-EB-02002)

ECP5 VIP Processor Board Evaluation Board User Guide (FPGA-EB-02001)

HDMI VIP Output Bridge Board Evaluation Board User Guide (FPGA-EB-02003)
