QuickSTART
This document provides a brief introduction on how to install and run the demos based on
the ECP5-5G Versa Development Kit.
User
Switches
Status LEDs
USB
Programming
JTAG Interface
Dual RJ45
Ethernet ports

Check Kit Contents

1
The ECP5-5G Versa Development Kit contains the following items:
ECP5-5G Versa Evaluation Board
12V AC/DC Adapter & International Plug Adapters
USB Cable for Programming via PC (USB-A to Mini-B)
Quick Start Guide
2

Using the ECP5-5G Versa Development Kit

The ECP5-5G Versa Board as shipped supports Master-SPI based configuration. The
external SPI Flash Configuration Memory is pre-loaded with a demonstration program
described below.
SERDES test
SMA Connectors
Push Buttons
LED
Display
Configuration
Mode Switches
ECP5-5G
Device
PCI Express x1
ECP5-5G Versa
Development Kit
DDR3
Memory
Expansion Connectors
On-board
Clock
Management
SPI Flash
Configuration
Memory
12V DC
Power Input
