xComfort Room Controller Touch
CRCA-00/08, CRCA-00/09, CRCA-00/10, CRCA-00/11
Danger
Lebensgefahr
Danger de mort
Nebezpečí
Nebezpečenstvo
Fare
Peligro
Életveszély
Pericolo di morte
Fare
Levensgevaar
Optional: External
Power Supply 24V
AC/DC
Technical Data / Technische gegevens / Tekniske data /
Technische Daten / Technická data
Power Supply
Batteries
External power supply
Internal Temperature sensor
Range
Accuracy
External Temperature sensor
Humidity sensor
Relative humidity range
Accuracy
Connections
Stripping length
Cross section
Solid core
Stranded core
Dimensions (H x W x D)
Eaton Industries (Austria) GmbH, Eugenia 1, 3943 Schrems, Austria
www.eaton.eu/documentation
Perigo
Niebezpieczenstwo
Varning
Vaara
Hayati Tehlike
Pericol
Temperature
Humidity
2x
LR03 AAA
External (Floor)
Temperature Sensor
3V via 2x LR03 (AAA)
12-24 VDC/AC
0 - 40 o C
+ 0.5 o C
PT-1000
5 - 95%
+ 5% rH
6 mm
0.14 - 0.5 mm²
0.2 - 0.5 mm²
55 x 55 x 21 mm
Installation by electricians only
Montage nur durch Elektrofachkräfte
Montage uniquement par un électricien
Montáž pouze osobami s elektrotechnickou kvalifikaci
Montáž iba osobami s elektrotechnickou kvalifikáciou
Må kun installeres af en aut. el-installatør
Debe ser instalado por un profesional eléctrico
Csak szakképzett személy szerelheti
Montaggio esclusivamente ad opera di personale specializzato
Må monteres av autorisert installatør Gr.L
Montage alleen door elektromonteurs
Deve ser instalado por um profissional
Montaz tylko przez uprawnionych instalatorów
Får endast utföras av behörig elektriker
Asennus vain sähköasentajan toimesta
Sadece uzman kisiler monte edebilir
Instalare numai de catre electricieni
+
Compatible
with
55x55mm
Controller
CRCA-00/08 Temperature, Humidity
CRCA-00/09 Temperature, Humidity
CRCA-00/10 Temperature, Humidity
CRCA-00/11 Temperature, Humidity
0
o
C
MRF
RM
SHC-RF Version 2.20
ECI-RF Version 2.10
USB-RF Version 2.10
868.3 MHz
Type
Color
Pure white
Anthracite
Traffic white
Alpine white
+70 C
+
40
o
C*
-25 C
o
Version 2.53
Version V41c
MA-crca-00-08/09.qxp/03.2017b
IL019122ZU / 136211189
IP20
IP20
o
Advertisement
Table of Contents
Related Manuals for Eaton xComfort CRCA-00/10
Summary of Contents for Eaton xComfort CRCA-00/10
- Page 1 Cross section Solid core 0.14 - 0.5 mm² Stranded core 0.2 - 0.5 mm² Dimensions (H x W x D) 55 x 55 x 21 mm Eaton Industries (Austria) GmbH, Eugenia 1, 3943 Schrems, Austria MA-crca-00-08/09.qxp/03.2017b www.eaton.eu/documentation IL019122ZU / 136211189...
- Page 2 Merten Gira Busch Jaeger Jung Berker Siemens Elko Kopp Standard 55 Carat* Delta line RS16 Alaska Atelier M Pur Edelstahl* A 500 Delta vita Plus M-Smart Event Solo* A plus Delta miro M-Arc Esprit Future* A creation B.7 Glas Delta profil** M-Star Profil 55 Future linear*...
- Page 3 Offset / Offset / Offset / Abgleich / Offset: Reference 21 C Reference - RC = Offset Positioning / Positionering / Plassering / Positionierung / Umístění:...
- Page 4 Cleaning / Reinigen / Rengjøring / Reinigung / Čištění: 60-59-58... 60 Sec. >5 Sec. Basic Mode: Start basic mode / Start basic mode / Start Basic Mode / Starte Basic Mode / Spustit základní režim Back to factory default / Terug naar fabrieksinstellingen / Tilbake til fabrikkinstillinger / In Auslieferungszustand zurücksetzen /...
- Page 5 Assign or remove device / Apparaat toewijzen of verwijderen / Tildele eller fjerne enheten / Zuweisen oder Entfernen von Geräten / Přiřazení nebo odebrání zařízení Actor in Program mode Select Selected device is blinking / Device Geselecteerde apparaat knippert / Valgt enhet blinker / Ausgewähltes Gerätsymbol blinkt / Vybrané...
- Page 6 Quick User Guide / Quick User Guide / Hurtigveiledning / Schnellanleitung / Stručný návod k obsluze Main menu Active operation mode Select view Hoofdmenu / Hovedmeny / Frost protection Temperature Hauptmenü / Hlavní menu Night / Standby Humidity Economy Clock Outdoor temperature Day / Comfort Enter operation mode - menu...
- Page 7 QR-code DE: Für das erweiterte Benutzerhandbuch und detaillierte Informationen zum xComfort System besuchen Sie www.eaton.eu/xcomfort oder www.xcomfort.de oder verwenden Sie den QR-code AT: Für das erweiterte Benutzerhandbuch und detaillierte Informationen zum xComfort System besuchen Sie www.eaton.eu/xcomfort oder www.xcomfort.at oder verwenden Sie den QR-code NO: For en mer omfattende brukerveiledning og mer informasjon om xComfort, besøk...
- Page 8 Declaration of Conformity We, EATON Industries (Austria) GmbH 3943 Schrems, Eugenia 1 Austria declare under our sole responsibility that the product (family) Eaton - Room Controller Touch CRCA-00/08; CRCA-00/09; CRCA-00/10; CRCA-00/11 (contains RF-Modul CSCZ-01/xx) (the declaration of conformity applies to all...
