What is T&D Recorder for Windows ?
◆ An Overview
T&D Recorder for Windows is a software program that enables you to
easily make recording settings for our data loggers, download recorded
data from the loggers, and then process that data into graphs, tables and
/or save that data to files or print.Upon opening T&D Recorder for
Windows, a launcher program will appear with several icons lined up. By
clicking on an icon, a settings/communication display for the selected
type of device or a graph display will appear.
In order to use the software, the following operational environment is
necessary
OS Microsoft Windows 98/Me
PC/CPU IBM Compatible Pentium 90MHz or above
Memory 16MB or above
Hard Disk 4 MB or more of available space (more space necessary for data）
Monitor VGA (SVGA(800×600)or above)/256 or more colors possible is necessary
◆ Basic Functions
Recording Settings
●
Settings can be made for recording conditions such as channel name,
recording interval, and recording mode. By making a recording start (date
and time) setting in the main unit(s), the unit(s) will begin recording at
that time on that date.
Graph Display / Printing
●
Simultaneous Display of 8 Ch. of Data
●
It is possible to display up to 8 channels of downloaded data in 1 graph.
Zoom-in on Data by Mouse
●
By simple mouse operations, you can easily zoom in and out on data as
well as change the display.
View the High, Low, and Average Calculations for any Specified
●
Period
Make settings to specify the calculation range you desire and view the
high, low and average value for that range in each channel displayed in
the graph.
１
Microsoft WindowNT 4.0 (USB communication not possible）
Microsoft Windows 2000/Xp
USB Communication/Serial Communication(RS-232C D-Sub pin） possible
