Intesis IntesisBox FJ-AC-MBS-1 User Manual page 9

ModBus RTU – Fujitsu
®
IntesisBox
Register Address
(protocol address)
9
10
11
22
23
24
25
26
31
36
40
43
44
56
64
65
6
See section for possible error codes and their explanation
7 E
RROR CODES
© Intesis Software S.L.U. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SLU
Register Address
(PLC address)
10
11
12
23
24
25
26
27
32
37
41
44
45
57
65
66
R/W Description
AC unit Operation Time
R/W
▪ 0..65535 (hours). Counts the time the AC unit is in "On"
state.
AC unit Alarm Status
R
▪
0: No alarm condition
▪
1: Alarm condition
6
Error Code
▪
0: No error present
▪
65535(-1 if it is read as signed value): Error in the
R
communication of FJ-AC-MBS-1 or Remote Controller
with the AC unit.
▪
Any other value, see the table at the end of this
document.
Indoor unit´s ambient temperature from external
sensor (at Modbus side)
R/W
▪
-32768: (Initialization value). No temperature is being
provided from an external sensor.
▪
Any other: (ºC/x10ºC/ºF)
AC Real temperature setpoint
▪
When no external temperature is provided, this read-
only register will have the same value as register 5 (PLC
R
addressing). In all cases, it will show the current setpoint
in the indoor unit.
▪
16..31ºC (ºC/x10ºC)
▪
60..92ºF
Current AC max setpoint
R
▪
-32768 (Initialization value)
▪
Ranges are specific from Manufacturer
Current AC min setpoint
R
▪
-32768 (Initialization value)
▪
Ranges are specific from Manufacturer
AC unit Horizontal Vane Position
▪
0: Auto (Default)
▪
1: Position 1
R/W
▪ ...
▪
5: Position 5
▪
10: Swing
Window status (feedback)
R
▪
0: Not active (Default value)
▪
1: Active (Window is open)
External On/Off disablement:
R/W
▪
0: Not active (Default value)
▪
1: Active
Window contact ON/OFF disablement:
R
▪
0: Window contact is disabled (not working)
▪
1: Window contact is enabled (in use)
Filter reset:
W
▪
1: Reset
Filter status
R
▪
0: Off
▪
1: Lit
Antifreeze operation
▪
R/W
0: Disabled
▪
1: Enabled
Economy
R/W
▪
0: Disabled
▪
1: Enabled
R Input reference temperature
User Manual r1.0 EN
1,2,3,4
1,2,3,4
1,2,3
1,2,3
1
1,2,3
