TABLE OF CONTENTS Quick setup using the bindisc display/adjustment module ________________ 3 Additional adjustments - False s ignal suppression ____________________ 5 925-0371 1218...
Page 3
QUICK SETUP USING THE BINDISC DISPLAY/ADJUSTMENT MODULE Unscrew the housing cover. 2. Place the BinDisc display and adjustment module on the top of the unit and turn to the right until it snaps in place. Disassembly is carried out in reverse order 1.
Page 4
4. Vessel height/Meas. Range, press [OK] Use [>] and [+] keys to set overall height of vessel Press [OK] then [>] key. 5. Max adjustment, press [OK] Use [>] and [+] keys to set the headspace of the vessel (min 2ft.) Press [OK] then [>] key.
Page 5
ADDITIONAL ADJUSTMENTS - FALSE SIGNAL SUPPRESSION The following circumstances cause interfering reflections and can influence the measurement: - High standpipes - Vessel installations such as structures, cages or ladders - Agitators - Buildup or welded joints on vessel walls Note: A false signal suppression detects, marks, and saves these false signals so they are no longer considered in the level measurement.
Page 6
4. Screen shows “Change now?” Press [OK] 5. False signal suppression, scroll to Create new Press [OK] 6. False signal suppression, use [>] and [+] keys to set the actual distance from the sensor to the product surface Press [OK] 7.
