E LEC T R O NI C C ONT R O L S
Control Panel
FUN C T IO N
LIGHTS Turns the interior accent lighting on or off for glass
door models.
ICE MAKER Turns power to the ice maker on or off. Use to dis-
able the ice maker during extended vacations.
MAX ICE Activates or deactivates the max ice feature which
increases ice production 30% for a 24-hour period.
COLDER Adjusts the tem per ature in one-degree increments.
WARMER Combination units have separate temperature con-
trols for the refrigerator and freezer. Temper atures
are preset at 38°F
PURE AIR Activates or deactivates the air purification system.
ALARM Activates or deactivates the door alarm. A chime
indicates the door has been left ajar for more than
60 seconds.
POWER Turns the unit on or off. When the power is off,
"OFF" appears in the control panel display. Turning
the power off at the control panel eliminates the
need to unplug or turn the power off at the circuit
breaker during service or extended vacations.
Control panel and display (model BI-30UG shown)
4 | Sub-Zero Customer Care 800.222.7820
and 0°F .
(3°C) (-18°C)
Display
I N D I C ATO R
Illuminates or flashes when the electronic control system
detects a temperature or ice maker problem, or if the
condenser needs to be cleaned.
Illuminates when the air purification system is activated,
and flashes when the cartridge needs to be replaced.
After the cartridge has been replaced, touch and hold
PURE AIR on the control panel for 5 seconds to reset.
Illuminates when the water filter needs to be replaced.
Illuminates when the ice maker system is activated.
Illuminates when the max ice feature is activated.
Illuminates when the door alarm is activated.
Illuminates when the accent lighting is activated for glass
door models.
