Specifications
SUPPLY VOLTAGE
• 12 to 30 VDC
• Polarity Protected
Note: For use in Class 2 Circuits
CURRENT REQUIREMENTS
• 95mA @ 12 VDC, 45mA @ 30 VDC
DIGITAL OUTPUTS
• (1) NPN and (1) PNP open collector
output 150mA Max; <2V Residual
Voltage
(Note: On CLSC-1M8, NPN & PNP are
software selectable).
• All outputs are continuously short
circuit protected
REMOTE AUTOSET INPUT
• Momentary sinking or sourcing
input;
1.2mA max; Software Selectable
DIAGNOSTIC INDICATORS
• OLED Graphic Display - Includes
Contrast Indicator, Numerical
Display, Set Point and Trigger Point,
and all sensor options and modes.
• Red LED Output Indicator–
Illuminates when the sensor's
output transistors are "ON".
Note: If output LED flashes on power
up, a short circuit condition exists.
Connections and Dimensions
M8 & M8LE
MODELS
4.181"
[1 06 .2 0m m ]
CABLED
MODELS
4.332"
[1 10 .0 3m m ]
M12
MODELS
4.522"
[1 14 .8 6m m ]
0.767"
2.767"
[1 9.5m m ]
[7 0.3m m ]
3.113"
[7 9.1m m ]
3.893"
[9 8.9m m ]
2-112
PUSHBUTTON CONTROL
• Three (3) push button controls
• Gap (for Gap AUTOSET)
• Label (for multi-layered labels)
• Menu (for accessing Options)
HYSTERESIS
• Dynamic – adjusted by AUTOSET
RESPONSE TIME
• 200µs
REPEATABILITY
• 125µs
AMBIENT TEMPERATURE
• 4°C to 50°C (39°F to 122°F)
RUGGED CONSTRUCTION
• Chemical resistant, high impact
Aluminum housing
• Waterproof ratings: NEMA 4X, 6P
and IP65
• Conforms to heavy industry grade
CE requirements
THRESHOLD SET
• 1-Point, 2-Point, or Dynamic
AUTOSET; manually or remotely.
THRESHOLD ADJUST
• Manual or AUTO Adjust
M12 and Cable Wiring
R e d
P os
B ro w n * (1)
L O A D
W hite
N P N
W h ite * (2)
(S ink)
1 2 T o
3 0 V D C
G re en
P N P
B la c k * (4)
(S o u rce)
L O A D
B lack
N e g
B lu e * (3)
B lue
R e m o te
(1 ) - N P N (S IN K IN G ) O U T P U T LO A D T E R M IN A T E D T O P O S IT IV E
(2 )
G ra y * (5)
A uto set
(2 ) -
M 1 2 M a le
C o n n e ctor
2
1
1 - P os itive
2 - N P N
5
3 - N e gative
4 - P N P
3
4
5 - R e m o te AUTOSET
* - S en so rs w ith co nn ec to rs
0.360"
0 .3 6 0 "
2 X Ø 0.205"
[9 .1m m ]
[9 .1 m m ]
[2X 5.20m m ]
0 .4 7 2 "
2 X 6 -3 2 M ou n tin g
[1 2 .0m m ]
H o le s, 0.150"
[3 .8 m m ] D eep
www.ttco.com • 800-237-0946
OUTPUT TIMERS
• On Delay, Off Delay, One Shot, or
Debounce (Advanced Option,
software selectable).
CONNECTOR
• M12 5-Pin, M8 4-Pin, or 6' (1.8m)
Shielded Cable
Product subject to change without notice
Ultrasonic Clear Label Sensor
M8 Wiring
B ro w n (1)
P os
W h ite (2)
R e m o te
(2 )
A uto set
1 2 T o
3 0 V D C
B la ck (4)
O u tput
(1 )
L O A D
B lu e (3)
N e g
P N P (S O U R C IN G ) O U T P U T L O A D T E R M IN A T E D T O N E G A T IV E
N P N (S IN K IN G ) IN P U T A C T IV A T E D B Y C O N N E C T IN G T O N E G A T IV E
P N P (S O U R C IN G ) IN P U T A C T IV A T E D B Y C O N N E C T IN G T O P O S IT IV E
M 8 M a le
C o n n e ctor
2
4
1 - P os itive
2 - Remote AUTOSET
3 - N e gative
4 - Output
1
3
M12 MODELS
M8 & M8LE
MODELS
NOTE: Side and bottom mounting holes
are compatible with LER models.
RoHS Compliant
CLSC-1M8LE Wiring
B row n (1)
P os
L O A D
W hite (2)
N P N
(S ink)
12 T o
30 V D C
B lack (4)
P N P
(S o urce)
L O A D
B lue (3)
N eg
M 8 LE M a le
C o n n e ctor
2
4
1 - P os itive
2 - NPN
3 - N e gative
4 - PNP
1
3
0.850"
[2 1.6m m ]
