Summary of Contents for Fire dept WD6
- Page 1 (Timber Cavity) Installation Guide Operating Instructions Warranty...
-
Page 2: Table Of Contents
Warranty Information in this installation guide may be subject to change without notice. Please ensure you have the current version before beginning installation. If you have any queries, please contact ‘The Fire Dept.’ on 0800 888 550 Version: March 2019... -
Page 3: Step 1: Ensure All Components Are Correct And Undamaged
Step 1: Unpack and ensure all components are correct and undamaged Steel firebox. Outer cavity box. Ashpan. AAC panels. AAC supporting brackets. Flue kit. WD6 technical specifications (to be read in conjunction with this installation guide). Version: March 2019... -
Page 4: Step 2: Pre-Installation Checklist
Step 2: Pre-installation checklist Ensure cavity dimensions are correct – refer to technical specifications. Ensure hearth dimensions are correct – refer to technical specifications. Plan flue path. The starting point: Timber frame. Note: Timber lintel to suit opening must be fitted after appliance has been fixed into position. Version: March 2019... -
Page 5: Step 3: Fit Steel Aac Supporting Brackets Into Cavity
Step 3: Fit steel AAC supporting brackets into cavity Fix the AAC supporting brackets into position in accordance with technical specifications (example shown). Rear brackets have 6 x fixing holes each and the front brackets have 4 x fixings holes each. 5mm screws/bolts. Version: March 2019... -
Page 6: Step 4: Fit Aac Panel To Steel Support Panels
Step 4: Fix AAC panel to steel support brackets Uncut AAC panels and cement supplied. Steel screws and wood screws supplied. All joints must be cemented. IMPORTANT! Refer to technical specifications for latest version of cutting list. 1. -
Page 7: Step 5: Fit Firebox And Outer Cavity Box Into Cavity
Step 5: Fit firebox and outer cavity box into cavity Outer cavity box Firebox Ash pan 1. Remove ash pan from firebox and outer cavity box. 3. Fix the fire box through the AAC panel and into the AAC 2. With a minimum of two people, slide the firebox supporting brackets. -
Page 8: Step 6: Fit Flue
Step 6: Fit flue 1. Run the flue transition. Note: The 1600mm wide model has 2 flues. The flue runs into the firebox. The inner casing runs into the outer cavity box. The outer casing finishes 25mm above the outer cavity box. -
Page 9: Step 7: Insert Ashpan Into Firebox
Step 7: Insert ashpan into fire box cavity Insert ashpan into firebox. Appliance is now ready for customer-specified outer finishes. Version: March 2019... -
Page 10: Step 8: Show Owner How To Operate Appliance
Step 8: Show owner how to operate appliance Following the Operating Instructions on the next page, show the owner how to operate the baffle. If the owner is not available, leave this manual by the appliance. Version: March 2019... -
Page 11: Operating Instructions
OPERATING INSTRUCTIONS The WD6 has an integrated flue damper which has two positions – open and closed. The flue damper MUST be in the open position when the fire is being used. To set the flue damper to the open position, simply push it to the rear of the fire. -
Page 12: Warranty
5 (five) years. Beyond normal heat-induced staining, tarnishing and mild warping , if a firebox, outer skin or support frame defect occurs, contact ‘The Fire Dept.’ and the defect will be repaired or replaced at our discretion with all costs covered.
