Summary of Contents for Solid State Logic XLOGIC 82S6XL010D

  • Page 1 Multichannel Compressor Owner’s Manual...
  • Page 3 Solid State Logic S U P E R A N A L O G U E M U L T I C H A N N E L C O M P R E S S O R Super-Analogue™ Outboard Owner’s Manual...
  • Page 4 Revision 0C, June 2004 Revision 0D, July 2004 Minor changes, November 2004 Minor changes, June 2005 As research and development is a continual process, Solid State Logic reserves the right to change the features and specifications described herein without notice or obligation E&OE...
  • Page 5: Table Of Contents

    Contents 1.0 Introduction 2.0 Safety Considerations Safety Warnings 3.0 Installation Setting the mains voltage selector Mounting Connections 4.0 Operation Compressor Controls Side Chain Adjust Section Mode Section Fader Section Appendices: Internal Links and Fuses Connector Details Electronic Specification Calibration Instructions Physical Specification Environmental Specification Page 1...
  • Page 6 XLogic Multichannel Compressor Owner’s Manual Page 2...
  • Page 7: Introduction

    In the event of a fault during the warranty period the unit must be returned to your local distributor who will arrange for it to be shipped to Solid State Logic for repair. All units should be shipped to Solid State Logic in their original packaging.
  • Page 8: Safety Considerations

    Safety Earth Connection Any mains powered item of Solid State Logic equipment that is supplied with a 3-core mains lead (whether connectorised or not) should always have the earth wire connected to the mains supply ground. This is the safety earth and grounds the exposed metal parts of the racks and cases and should not be removed for any reason.
  • Page 9 Mains Supply and Phases Solid State Logic equipment is designed for connection to single phase supplies with the Neutral conductor at earth potential – category TN – and is fitted with a protective fuse in the Live conductor only. It is not designed for use with Phase (Live) and Neutral connections reversed or where the Neutral conductor is not at earth potential (TT or IT supplies).
  • Page 10: Installation

    XLogic Multichannel Compressor Owner’s Manual 3.0 Installation Voltage Selection Before connecting the mains supply ensure that the voltage range selector next to the IEC socket on the rear of the unit is correctly set. The input setting must be confirmed before applying power. The input module can be configured to be one of 4 voltage settings.
  • Page 11: Operation

    4.0 Operation The XLogic Multichannel Compressor unit is a 2U rack-mounting six-channel compressor designed to provide extremely flexible control over a 5.1 channel mix, or to be used as two separate compressors when working on stereo material. The compressor design is very similar to that found in the XL 9000 console centre section, but with additional controls to provide the flexibility that modern 5.1 productions require.
  • Page 12: Mode Section

    XLogic Multichannel Compressor Owner’s Manual The ISO switches isolate their respective channels from the compressor. When pressed that channel will not contribute to the side chain and will not be affected by the compressor. It is still controlled by the Master Fader and AutoFade controls.
  • Page 13: Appendix A - Internal Links And Fuses

    Appendix A – Internal links and fuses Fuses (Mains Inlet) The mains inlet contains a single 1 amp 1.25" time delay fuse (SSL Part No. 35FJJ310). To change it disconnect the mains inlet, then using a small screwdriver prise open the mains selector cover. This contains the fuse. Test and replace with the same type and value if necessary.
  • Page 14: Appendix C - Performance Specification

    XLogic Multichannel Compressor Owner’s Manual Appendix C – Performance Specification Conditions Source impedance 50Ω unless otherwise stated. All measurements are RMS and are made using a 22Hz to 22kHz filter unless otherwise stated. Noise Input terminated with 50Ω. Compressor switched in and set for 0dB gain. Noise Headroom Headroom is defined at the output level at which THD exceeds 1%.
  • Page 15: Appendix D - Calibration Information

    Appendix D - Calibration Information The XLogic Multi Channel compressor is factory calibrated and should only need calibration if a potentiometer or other component has been replaced or if it is suspected that there is a problem with calibration. In all of the following instructions it is assumed that the lid has been removed and that power has been applied. It is also assumed that unless otherwise specified, all switches are released and all potentiometers are at unity, minimum or indent position as appropriate.
  • Page 16 XLogic Multichannel Compressor Owner’s Manual Distortion Null Equipment Required: Test Signal: Input and Output: Adjustment: 1. Connect the +ve input of the analyser to the test point as shown below and 2. Finally, re-connect the analyser to each output in turn and adjust the +ve VCA Gain Adjust Equipment Required: Test Signal:...
  • Page 17: Appendix E - Physical Specification

    Appendix E – Physical specification * Depth: Height: Width: Weight: Power: Boxed size: Boxed weight: * All weights and dimensions are approximate Appendix F – Environmental Specification Temperature Operating: Non-operating: Max. Gradient: Relative Humidity Operating: Non-operating: Max. wet bulb: Vibration Operating: Non-operating, power off: Shock...
  • Page 18 XLogic Multichannel Compressor Owner’s Manual Notes Page 14...
