ENGLISH
The battery pack is designed for supplying power to the Pana-
sonic computer series. The battery pack is not charged when it
is first purchased.
Be sure to charge it before using it for the first time.
● Before using the battery pack, read this Operating Instruc-
tions and the relevant portions of the computer's Operating
Instructions and Reference Manual carefully.
Precautions
● Be Absolutely Sure to Use the Battery Pack With the
Specified Product
If it is used with a product other than the one for which it was
designed, electrolyte leakage, generation of heat, ignition or
rupture may result.
● Do Not Charge the Battery Using Methods Other Than
Those Specified
If the battery pack is not charged using one of the specified
*1
methods
, electrolyte leakage, generation of heat, ignition or
rupture may result.
*1 Refer to the manual of your product (or battery charger).
● Do Not Throw the Battery Pack Into a Fire or Expose It
to Excessive Heat
Generation of heat, ignition or rupture may result.
● Avoid Extreme Heat (Near the Fire, In Direct Sunlight,
for Example)
Electrolyte leakage, generation of heat, ignition or rupture
may result.
● Do Not Insert Sharp Objects Into the Battery Pack, Dis-
assemble, or Modify It
Electrolyte leakage, generation of heat, ignition or rupture
may result.
● Do Not Apply Shocks to the Product by Dropping It, Ap-
plying Strong Pressure to It, etc
Electrolyte leakage, generation of heat, ignition or rupture
may result.
• If this product is subjected to a strong impact, stop using it
immediately.
● Do Not Short the Positive (+) and Negative (-) Contacts
Generation of heat, ignition or rupture may result.
• Do not place the battery pack together with articles such
as necklaces or hairpins when carrying or storing.
● Do not use battery pack if wet
Generation of heat, ignition or rupture may result.
● When the Battery Pack Has Deteriorated, Replace It
with a New One
Continued use of a damaged battery pack may result in heat
generation, ignition or battery rupture.
● Using this product continuously in a hot environment
will shorten the product life. Avoid use in these types of
environments.
● When using in low temperature environment, battery
operation time may become short.
l Do not touch the terminals on the battery pack and the com-
puter. The battery pack may no longer function properly if the
contacts are dirty or damaged.
l Do not expose the battery pack to water, or allow it to be-
come wet.
l Should the battery leak and the fluid get into your eyes, do
not rub your eyes. Immediately flush your eyes with clear
water and see a doctor for medical treatment as soon as pos-
sible.
l Store the battery pack in a place with a temperature of be-
tween 10 °C to 30 °C (50 °F to 86 °F).
l When the battery pack is left installed in a computer, it
discharges electricity gradually in small amounts even if
the computer's power is off. If left for a long period (several
months or more), the battery pack will over discharge and its
performance may deteriorate.
If the battery pack will not be used for a long period of time (a
month or more), charge or discharge (use) the battery pack
until the remaining battery level becomes 30% to 40% and
store it in a cool, dry place.
l Read the computer's Reference Manual or the Operating
Instructions before use. For how to start up the Reference
Manual, please refer to the computer's Operating Instruc-
tions.
How to Replace and Charge the Battery Pack
The battery pack is not charged when it is first purchased. Be
sure to charge it before using for the first time. Refer to the com-
puter's Reference Manual or the Operating Instructions.
Main Unit
<To open the back cover>
1. Turn over the computer.
Make sure no foreign objects are under the computer.
Depending on the models, the shape of cover may differ.
2. Open the cover.
1 Slide both latches to the arrow
direction.
2 Remove the cover from the front
side.
<To remove the battery pack>
1. Turn off the computer.
2. Slide the latch (B).
3. Remove the battery pack (A).
<To insert the battery pack>
1. Insert the battery pack until it
securely fits the connector.
<To slide the back cover back>
1. Place the cover horizontally.
2. Slide the cover while pushing it.
Keyboard Base
Refer to the computer's Reference Manual for detail method
and notice.
<Only for model with Built-in Bridge Battery>
You can replace the battery pack while the computer turns
on. Refer to the "Reference Manual" for detail method and
notice.
<Charge the battery pack>
Connect the AC Adaptor to the computer.
The battery charging starts automatically.
• Charging time and operating time vary according to the state
of the computer's power supply and the temperature.
• The battery pack may become warm during charging or nor-
mal use. This is completely normal.

Specifications

Type
Li-ion
Voltage
11.4 V
Capacity
2600 mAh (Minimum)
Physical
Approx. 200 mm x 76 mm x 8.6 mm
Dimensions
{Approx. 7.9" x 3.0" x 0.3"}
(W x D x H)
Weight
Approx. 175 g {Approx. 0.39 lb.}
Refer to the Operating Instructions about the charging time/op-
erating time.
2
2
1
1
1
1
A
2
2
1
1
B
