ENGLISH
Precautions
●
Be Absolutely Sure to Use the Battery Pack With the
Specified Product
If it is used with a product other than the one for which it was
designed, electrolyte leakage, generation of heat, ignition or
rupture may result.
●
Do Not Charge the Battery Using Methods Other Than
Those Specified
If the battery pack is not charged using one of the specified
*1
methods
, electrolyte leakage, generation of heat, ignition
or rupture may result.
*1 Refer to the manual of your product (or battery charger).
●
Do Not Throw the Battery Pack Into a Fire or Expose It
to Excessive Heat
Generation of heat, ignition or rupture may result.
●
Avoid Extreme Heat (Near the Fire, In Direct Sunlight,
for Example)
Electrolyte leakage, generation of heat, ignition or rupture
may result.
●
Do Not Insert Sharp Objects Into the Battery Pack, Ex-
pose It to Bumps or Shocks, Disassemble, or Modify It
Electrolyte leakage, generation of heat, ignition or rupture
may result.
•■
If this product is subjected to a strong impact, stop using it
immediately.
●
Do Not Short the Positive (+) and Negative (-) Contacts
Generation of heat, ignition or rupture may result.
•■
Do not place the battery pack together with articles such
as necklaces or hairpins when carrying or storing.
●
When the battery pack has deteriorated, replace it with
a new one
Continued use of a damaged battery pack may result in heat
generation, ignition or battery rupture.
●
Do not touch the terminals on the battery pack and the com-
puter. The battery pack may no longer function properly if
the contacts are dirty or damaged.
●
Do not expose the battery pack to water, or allow it to be-
come wet.
●
Should the battery leak and the fluid get into your eyes, do
not rub your eyes. Immediately flush your eyes with clear
water and see a doctor for medical treatment as soon as
possible.
●
Store the battery pack in a place with a temperature of be-
tween 10°C to 30°C (50 °F to 86 °F).
●
When the battery pack is left installed in a computer, it dis-
charges electricity gradually in small amounts even if the
computer's power is off. If left for a long period (several
months or more), the battery pack will over discharge and its
performance may deteriorate.
If the battery pack will not be used for a long period of time (a
month or more), charge or discharge (use) the battery pack
until the remaining battery level becomes 30% to 40% and
store it in a cool, dry place.
●
Read the computer's Reference Manual or the Operating
Instructions before use. For how to start up the Reference
Manual, please refer to the computer's Operating Instruc-
tions.
Specifications
Type
Li-ion
Voltage
10.65V
Capacity
8.55 Ah (Typical) / 8.10 Ah (Minimum)
Physical Dimensions
Approx. 165 mm x 82 mm x 21 mm
(W x D x H)
{Approx. 6.5" x 3.3" x 0.9"}
Weight
Approx. 475 g {Approx. 1.1 lb.}
Environment (In use)
Temperature: 5 °C to 35°C {41 °F to 95 °F}
Humidity: 30% to 80% RH (No condensation)
Refer to the Operating Instructions about the charging time/op-
erating time.
For use with I.T.E. Listed Notebook Computer, Panasonic,
Models CF-30, CF-31 and CF-52.
(The statement based on UL standards.)
CAUTION:
Risk of Explosion if Battery is replaced by an Incorrect Type.
Dispose of Used Batteries According to the Instructions.
How to Replace and Charge the Battery Pack
The battery pack is not charged when it is first purchased. Be
sure to charge it before using for the first time.
Refer to the computer's Reference Manual or the Operating
Instructions
<CF-52 series>
1.
Turn off the computer.
2.
Reverse the computer, then
press and hold the
mark part (A).
3.
Slide and remove the cover.
4.
Slide and hold the latch (B),
and pull the tab (C) of the
battery pack.
5.
Insert the battery pack (D)
until it securely fits the con-
nector.
6.
Slide the cover back.
7.
Push the cover until it clicks.
8.
Connect the AC Adaptor to
the computer.
The battery charging starts automatically.
<CF-30/31 seires>
1.
Turn off the computer.
2.
Slide the latch (A) to the
right to unlock the cover.
3.
Slide the latch (A) down, and
open the cover.
4.
Pull the tab (B) of the battery
pack.
5.
Insert the battery pack (C)
until it securely fits the con-
nector.
6.
Close the cover until it
clicks.
7.
Slide the latch (D) to the left
to lock the cover.
8.
Connect the AC Adaptor to the compute.
The battery charging starts automatically.
●
Charging time and operating time vary according to the
state of the computer's power supply and the temperature.
●
The battery pack may become warm during charging or
normal use. This is completely normal.
52-M-1
58-E-1
A
C
B
1
C
B
D
D
