LABQUEST APP – GRAPH SCREEN
E
B
A
When data collection is complete, the graph autoscales to the data.
12
A. Axis Label – The Graph is set to display your sensor data. When you have more than one
sensor or run, you can change what is plotted on the axis by tapping on the label and
D
selecting the desired data column.
B. Examine Point – Tap any point to activate the examine cursor. Tap a different point or
use the Examine buttons to move to a new point.
C. Current Reading – The coordinates of your examine point are displayed to the right of
the graph. During collection, the live sensor reading is shown.
C
D. Store Run – To collect multiple trials of an experiment, store the run before collecting
more data.
E. Graph Menu – Use the Graph menu for even more graph options.
LABQUEST APP – GRAPH SCREEN
13
