HARDWARE OVERVIEW
Power Button
Internal
Light Sensor
Internal
Microphone
Resistive Touch
Screen for touch
or stylus
6
Collect – Control
data collection
Home – Access
applications
Escape – Exit
menus/applications
Stylus Storage
Wi-Fi Status
Battery Level/
Charge Indicator
USB 2.0 for
USB sensors
Power Button
and flash drives
Digital Sensor
Analog Sensor
Ports for Motion
Ports for
Detectors and
temperature,
other digital
pH, CO
, and
2
sensors
other analog
sensors
HARDWARE OVERVIEW
Docking Port
Micro
Audio In
for LabQuest
SD/MMC
for external
Charging Station
Card Slot
microphone
AC Power
Computer
Audio Out
Connectivity
for speakers,
to transfer
headphones,
data or to use
and Power
as a computer
Amplifier
interface
7
