Vernier LabQuest 2 Quick Start Manual

Getting Started
Before using LabQuest 2 Quick Data Collection
1 Remove the pull tab, which 1 Turn on LabQuest 2.
protects the battery, from the
2 Connect a sensor.
back of the unit.
The sensor auto-IDs and displays a
2 Connect the power adapter. live readout. The default collection
rate for the sensor is set up.
Charge for at least 12 hours.
3
3
Tap Collect
4 Read the safety information
You are now collecting data.
found in this Quick-Start Guide.
LabQuest App switches to the Graph
Complete user guide is available at screen when data collection begins.
www.vernier.com/labquest/guide
Safety Information
Read all safety information and operating instructions included in this Quick-Start Guide
prior to using LabQuest 2.
LabQuest 2 is designed to be splash resistant. However, avoid water immersion and
standing liquid on the display. If water gets in the device, immediately shut down the
device (tap System on the Home screen, then tap Shut Down, or hold down the Power
button until the shutdown sequence begins). Remove the battery, connected cables,
SD card, and any other accessories. Allow to dry thoroughly before restarting. Do not
attempt to dry using an external heat source.
Safe operating temperatures are from 0°C to 45°C. Storage temperatures are –30°C to
.
60°C. Exposures to low or high extreme temperatures will temporarily reduce battery
life. Avoid rapid temperature changes as condensation may form inside the device. Do
not leave in a car, as temperatures can exceed the maximum storage temperature.
LabQuest 2 contains a lithium-ion battery. Use only the supplied battery for this device.
Do not puncture or expose to excessive heat or flame.
Do not store LabQuest 2 in a chemical closet or in areas of concentrated chemical gases.
Care of LabQuest
Screen Calibration – The screen may need to be recalibrated periodically. To access the
calibration tool, tap System on the Home screen, then tap Calibrate Screen. If you are unable
to access the Calibration tool, press and hold the Home button to display the Calibration
tool. Tap the calibration target with the stylus in the five locations indicated to calibrate
the screen.
System Reset – To reset the system, tap System on the Home screen, then tap Reboot.
If you are unable to access the Reboot tool, press and hold the Power button. When the
LabQuest shutdown message is displayed, release the Power button. Wait until the system
shuts down, then turn the unit back on.
Battery Maintenance – Use only the supplied AC adapter or optional Charging Station to
charge the LabQuest battery. A full charge can take twelve hours. The battery cannot be
overcharged, and it can be safely recharged after a partial discharge.
Screen Maintenance – The LabQuest screen is splash resistant. Wipe the screen clean with
a cotton cloth that is slightly dampened with water or ethanol. Do not use any other
solvents. Do not submerge LabQuest in liquids.
