Page 1: Table Of Contents
Thank you for buying the Energy Sistem Cinne™ 2000 speakers. For a better usage and enjoyment, read carefully the following instructions before connecting it. Contents: 1. Contents / Feature 2. Precautions 3. Safety W arnings 4. Front Panel Operation 5. Rear Panel Setting 6. -
Page 2: Precautions
Precautions CAUTION: To reduce the risk of electric shock, do not remove the cover or back. Refer servicing to qualified service personnel. The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 3: Safety Warnings
Safety Warnings Leave 15 cm for ventilation Do not function the system when liquid gets into the subwoofer.. Do not open the cove and do not Pull out the plug while smoke, repair yourself particular smell or noise inside. Refer servicing to qualified personnel Do not climb on this system. -
Page 4: Front Panel Operation
Front panel operation 1. Remote sensor 2. Power LED light ( Red : AUX ;Green : 5.1CH ) 3. Power On / Off Button User manual Cinne™ 2000. 4 / 13 Ref: 200205... - Page 5 Ajuste y funcionamiento del panel trasero. 1. Front Left and Right Input terminal 2. Center Input terminal 3. Subwoofer Input terminal 4. Rear Left and Right Input terminal 5. Front Left and Right Output terminal 6. Center Output terminal 7. Rear Left and Right Output terminal User manual Cinne™...
-
Page 6: Connection With Sound Source And Satellites
Connections with sound source and satellites 1) Connection with sound source equipment. User manual Cinne™ 2000. 6 / 13 Ref: 200205... - Page 7 2) Connection with satellite speakers User manual Cinne™ 2000. 7 / 13 Ref: 200205...
- Page 8 Satellite speakers connection A. Setting up the satellite speakers. Connection between ü Befote connecting the satellite speakers and amplifier speakers to the amplifier, make sure that amplifier Amplifier powered off and disconnected to any power current. ü Make sure that the amplifier impedance is the same than the speaker impedande (when using a different amplifier from...
- Page 9 B. Speakers location. Ø Place the rear speakers in a rear side from the hearer position. Ø The high frequency speaker of the main channel of speaker should be located at the same elevation than the hearer’s head. Ø The surround speakers should be located at one meter and a half from the floor.
-
Page 10: Operation Instruction
Operation instructions 1. Stereo / 5.1 Mode Selection For stereo mode, please connect the sound source with Front L and Front R input terminal. This unit is AC-3 and DTS compatible. For 5.1 sound effect, please connect it with 5.1 input terminals. 2. -
Page 11: Trouble Shooting
Trouble Shooting Problem Cause Solution ü Improper connection ü Ensure that the of speaker terminal. equipment is connected properly. ü Improper connection ü Ensure of sound frequency that terminal. sound frequency connected properly. ü Improper connection ü Insert the AC plug of AC plug and the socket. -
Page 12: Specifications
Specifications 1. Output Power : 20W + 7 W x 5 2. Impedance: 4 Ohm. 3. Frequency response: 60Hz~20kHz 4. S/N ratio: 80dB (A-W eighted) 5. Input sensitivity: ine in 500mV/47k 6. Power: 220V-240V 50/60Hz 7. Dimension (H×W ×D) : ü... - Page 13 Frequenly Asked Questions section located in the product record. Warranty duration. Energy Sistem warranties that your product doesn’t have any material, design or manpower defect in the moment of purchase. • The warranty is 60 month from purchase date for Memory Pocket, Bluetooth and Memory Cards.
