- Page 1 User Manual...
-
Page 3: Care And Maintenance
Keep the unit clean and dust with a soft, dry cloth. ≥ Do not disassemble the device. Any repairs must be done by qualified service personnel authorised only by Energy Sistem Soyntec SA ≥ Keep your Energy™ Soundbar 200 away from water or moisture, it can be harmful tdevice. -
Page 4: Technical Specifications
3. TECHNICAL SPECIFICATIONS ≥ 2.1 soundbar system. ≥ RMS output power: 60W. ≥ Built-in subwoofer. ≥ USB reader compatible with storage devices up to 32 GB. ≥ Connections: Digital Coaxial in, RCA in, Line-In (3.5mm) and USB. ≥ Digital FM tuner with 20 presets ≥... -
Page 5: General Overview
5. GENERAL OVERVIEW ≥ Top view Standby (on/off). FUNCTION (switch function). Volume. Equalizer. -
Page 6: Bottom View
≥ Bottom view FM Antenna RCA in connectors. FM ANT COAXIAL Subwoofer output. AUXIN Digital input (Coaxial). SUB-WOOFER OUT ≥ Side view Line-in. USB port. -
Page 7: Remote Control
≥ Remote control ON / OFF PLAY / PAUSE COAXIAL / AUX SEARCH + STOP RADIO - / PREVIOUS SEARCH - MEMORY / REPEAT VOL - EQUALIZER LOUD MUTE LINE IN RADIO + / NEXT TUNER / USB CH - LEVEL VOL + MONO / STEREO SCAN... -
Page 8: Battery Installation
BATTERY INSTALLATION Remove the battery cover from the remote control and put AAA. CLOSE The following diagram shows the correct way to insert batteries. OPEN MAIN FEATURES ≥ USB port. ≥ Digital FM radio. ≥ Digital audio input (coaxial). ≥ Line-in. - Page 9 CONNECTIONS Your Energy™ Soundbar has different audio connections allowing you connect different audio devices as CD players, mp3 players, DVB-T, computers, Smartphones, etc. LINE-IN Use the audio cable (incluided) and connect it to the line-in input (jack 3.5mm) on the side of your Energy™ Soundbar and the other side of the audio cable to your audio device.
-
Page 10: Usb Function
USB FUNCTION Use the USB port to play MP3 files. You only have to plug your USB storage device and press the FUNCTION button on the top panel of your Energy™ Soundbar to find [USB] on the display. In that moment you can start to play your music through the USB. DIGITAL FM RADIO From the FUNCTION button choose the TUNER option and using the remote control you can control all the radio functions. - Page 11 SPECIFICATIONS Power Suppy ~ 110 - 240V, 50/60Hz Consumption Working Temperature -1 0 ~ +35ºC enviroment Relative humedity 5% ~ 90% Turner FM band range Rango 87.5MHz 108MHz Output power (max) 15W x 2 + 30W Frecuency reponse + 1.5dB (20Hz ~ 20kHz)
-
Page 12: Warranty Procedure
WARRANTY Energy Sistem Soyntec SA is liable for any lack of conformity which exists at the time the goods were purchased during a period of 36 months. Batteries are excluded from the 36-month warranty, having a warranty period of 12 months. -
Page 13: Declaration Of Conformity
NIF: A53107488 We declare under our own exclusive responsibility that the product: Energy Sistem® Soundbar 2.1 Energy™ Soundbar 200 USB MP3 Manufacturing country: China Is in compliance with the essential norms and standards of the Directive 2004/108/EC of the European Parlia- ment and of the Council of December 15th 2004.
