Basic Adapter

4.2
Attach the UNAwheel Mini
4.2.1
1 When seated in the wheelchair, hold the UNAwheel Mini by its handlebar and
slide its wheel underneath the wheelchair.
2 Insert the bottom cylinder of the UNAwheel's connector into the bottom hook of
the central adapter.
3 Pull the UNAwheel's handlebar up. The connector will snap into place.
After attaching the UNAwheel Mini, the front wheels of the wheelchair should be raised
10 to 40 mm above the ground. If this is not the case, adjust the height of the central
adapter accordingly.
