3 Installation
3.1
Delivery contents
The UNAwheel Mini is delivered in two packages:
A travel case containing the UNAwheel Mini and its charger.
•
•
A box containing all parts of the Active Adapter.
OR
A box containing all parts of the Basic Adapter.
•
3.2
Requirements
To determine which of the two adapters is compatible with your wheelchair, see the
following requirements:
Active adapter
•
The wheelchair should have a rigid or
foldable frame and undetachable leg
supports.
•
The wheelchair's front tubes should
have a vertical straight part of 40 mm
at a height of 270 - 350 mm above the
ground.
The width between the front tubes
•
should be 320 - 380 mm.*
* If the width is less than 320 mm, the
adapter's tubes can be cut to the
desired width; min. 180 mm.
The tubes should be round
•
(Ø30, 25 or 22 mm).
•
Total weight with user should be less
than 125 kg
Basic adapter
•
The basic wheelchair should have
swing-away and detachable leg
supports.
•
The wheelchair's frame should have
a horizontal straight part of 50 mm
under its cushion (or up to 100 mm to
the rear) at a height of 210 - 290 mm
above the ground.
The width between the tubes should
•
be 415 - 458 mm.*
* If the width is less than 415 mm, the
adapter's tubes can be cut to the
desired width; min. 180 mm.
The tubes should be round
•
(Ø22 or 25 mm).
•
Total weight with user should be less
than 125 kg
11
