Attach the central adapter
3.3.4
1
Insert the short ends of the central adapter's tubes into the clamps' brackets
2 Adjust the width of the assembly if necessary
3 Use the clamps' handles to tighten the brackets and secure the central adapter in
place .
3
3
4 Position the hook of the central adapter 21 cm above the ground, at a vertical
angle of approx. 10º. Adjust the height by sliding the clamps up or down the
frame.
5 Tighten the two front bolts of each clamp. Use a 4 mm Allen wrench.
6 Tighten all 10 bolts of the central adapter.
.
2
2
16
1
21 cm
10
O
.
1
