- Page 1 GPRS TRANSMITTER LX2NB Installation and programming manual Version of the manual: v1.9 Date of issue: 2018.06.04 Firmware version: LX2NB-2.5.0 GPRS transmitter configurator version: 1.4.83.1 LX2NB Manual v.1.9 Page 1 / 60...
- Page 2 DECLARATION OF COMPLIANCE We, EBS Sp. z o.o., declare with full responsibility that the present product meets all requirements provided for in the Directive 1999/5/EC of European Parliament and Council dated 9 March 1999 The copy of the “Declaration of Compliance” can be found at http://www.ebs.pl/en/certificates/...
-
Page 3: Table Of Contents
LX2NB TRANSMITTER ................8 3.1.1. Wireless module antenna connector ............. 9 3.2. INPUT CONFIGURATION ................11 3.3. REMOTE CONTROL CONFIGURATION (ONLY LX2NB-5R VERSION) ....12 3.4. LX-ZAS POWER SUPPLY ................12 QUICK START PROCEDURE ................14 OPERATION ....................15 CONFIGURATION PROGRAM ................17 6.1. - Page 4 DTMF phone number ..............47 7.8.2.2. Handshake delay ................47 7.8.2.3. Protocol ..................47 7.9. FIRMWARE .................... 48 7.10. DEVICE MONITOR ................50 7.11. EVENTS HISTORY ................50 DEVICE PROGRAMMING .................. 53 8.1. LOCAL PROGRAMING ................53 LX2NB Manual v.1.9 Page 4 / 60...
- Page 5 10.2. GSM RANGE ..................57 10.3. DATA TRANSMISSION ................57 10.4. PROGRAMMING ................... 58 10.5. FIRMWARE UPDATING ................. 58 10.6. SIM CARD ERROR................58 10.7. SYSTEM ERROR .................. 59 REVISION HISTORY ..................60 LX2NB Manual v.1.9 Page 5 / 60...
-
Page 6: Introduction
1. INTRODUCTION Transmitter GPRS type LX2NB is an advanced microprocessor device, made with surface moulding technology and designed according to the latest trends. This transmitter is purposed for data transmitting from electronic security systems of facilities and other technical devices with the use of GSM mobile phone network. -
Page 7: Functional And Technical Parameters
Therefore also the parameters as type of the power supply voltage, current consumption as well as the dimensions were introduced for following options separately: Option 1 – Transmitter LX2NB + power supply LX-ZAS in metal/plastic box Option 2 – PCB of transmitter LX2NB Option 1 Option 2 typ. -
Page 8: Assembly And Wiring
Switch power off to perform any connection. 3.1. LX2NB TRANSMITTER Figure 1. LX2NB Transmitter with LX-ZAS a) Connections of wires shall be made with due care to prevent any faults or dead shorts. Places of connections shall be protected against weather conditions. -
Page 9: Wireless Module Antenna Connector
3.1.1. Wireless module antenna connector LX2NB-5R included one internal antenna. It is also possible to connect an external dipole type. 433MHz internal antenna Internal antenna can be used wherever required compact size and antenna provides appropriate coverage level detectors. - Page 10 Before screw the antenna, remove plastic element from GND socket. Correct install position for dipol antenna in the attached photo below. Figure 3. 433MHz external antenna dipole tipe and correct install position LX2NB Manual v.1.9 Page 10 / 60...
-
Page 11: Input Configuration
Additionally inputs might be configured as end of line (EOL-NO or EOL-NC) with resistors 2,2kΩ or as double end of line (DEOL-NO or DEOL-NC) with resistor 1,1kΩ. Figure 4. Configuration of input lines LX2NB Manual v.1.9 Page 11 / 60... -
Page 12: Remote Control Configuration (Only Lx2Nb-5R Version)
3.3. REMOTE CONTROL CONFIGURATION (ONLY LX2NB-5R VERSION) The device in version LX2NB-5R provides 2 additional virtual inputs that can be triggered by radio transmitters. The way of functioning should be configured by GPRS configurator software. Remote control programming procedure Press PROG (B) and hold. After a moment, the red LED STATUS flash. If the button is held longer, the red LED STATUS will flash second time and a third and then stop blinking which would mean the exit from the programming process. - Page 13 Jumper ON => charging current 1A Jumper OFF => charging current 0,2A Figure 5. Choice of current of charging the battery Note: the applying the quick charging can bring to damage of battery. LX2NB Manual v.1.9 Page 13 / 60...
-
Page 14: Quick Start Procedure
Number of port in server that receives messages from a device <access point name>: defines access point name to GSM network. If private network is used, SMS message shall provide the following parameters: UN=<user ID number> PW=<user password>. LX2NB Manual v.1.9 Page 14 / 60... -
Page 15: Operation
Text message on events sent to private phone numbers may be edited. LX2NB transmitter is equipped with input to connect telephone communicator module of alarm control panel. Configuration of transmitter for cooperation with an control panel’s phone communicator requires entering into memory a phone number for which transmitter is to answer. - Page 16 – since picking up a telephone number dialled with a communicator module is being checked. All programmable parameters are saved in memory and in case of voltage drop that are not lost. Supply of power starts the transmitter with saved settings. LX2NB Manual v.1.9 Page 16 / 60...
-
Page 17: Configuration Program
6. CONFIGURATION PROGRAM 6.1. INITIAL REMARKS GPRS transmitters configurator may be downloaded at www.ebs.pl (login: ebs, password: ebs) To install program an installation wizard shall be started that performs installation in default place C:\Program Files\EBS\. During installation process shortcuts on screen and Windows menu may be created. -
Page 18: File->New
Main menu is available as icons on fast access bar: 6.2.1. File->New Opens new set of parameters. Editing of configuration parameters is possible. Select type of device (LX2NB). 6.2.2. File->Open If file contains saved settings, they may be used to program next device. Firstly a catalogue where file has been saved shall be chosen and then name of file shall be provided. -
Page 19: File->Language
From this time on program shall enable wires connection with device and reading, and saving of parameters in LX memory will be possible. In the next tab "MINI-PROG" (the name derived from the programmer) you have to also define the connection parameters. LX2NB Manual v.1.9 Page 19 / 60... -
Page 20: Remote Connection
On screen the following window shall appear: Define: Name of connection e.g.: Remote Select name of analyzer e.g.: Primary Enter analyzer address e.g.: www.ebs.pl Enter port on which analyzer operates e.g. 9000 LX2NB Manual v.1.9 Page 20 / 60... - Page 21 OSM.Server via GPRS. During programming procedure (with GPRS link- See above) a question will be displayed if user want to use a modem connected to the server. After confirmation procedure will follow as in case of other programming channels. LX2NB Manual v.1.9 Page 21 / 60...
-
Page 22: File->Automatic Device Settings Backup
This function is analogical to the above one, at the same time it enables data saving into EEPROM module. There is also possibility to set correct time into LX device. Correct saving is confirmed with message on a screen. LX2NB Manual v.1.9 Page 22 / 60... -
Page 23: Operations->Restore Default Settings
„Events history” provides information about last events stored in LX device memory. See chapter 7.11. 6.2.12. Operations->Device monitor “Device Monitor” provides real-time information on LX device state. See chapter 7.10. 6.2.13. Help->About program Select this information to view additional information about program. LX2NB Manual v.1.9 Page 23 / 60... -
Page 24: Programmable Parameters
GPRS: GPRS standard transmission (TCP/IP Protocol), and in case of any problems with this link no transmission will follow. o Serverless: no transmission to the server with is possible, remote communication possible only via SMS notifications to the user LX2NB Manual v.1.9 Page 24 / 60... -
Page 25: Gprs Test Time
User ID When using public APN, user ID is mostly not required. For private APN this parameter shall be obtained from operator (it is impossible to be granted access to GPRS network without it). LX2NB Manual v.1.9 Page 25 / 60... -
Page 26: User Password
Mark this check box means, that the device will try in first order to connect to primary server, without regard on definition of parameters for backup server (in peculiarity of number of connection attempts). LX2NB Manual v.1.9 Page 26 / 60... -
Page 27: Backup Server Parameters
CSD connection. Factory setting is 1111. During the first starting of device (programming) it shall be changed. Code may consist of up to seven alpha numerical characters. LX2NB Manual v.1.9 Page 27 / 60... -
Page 28: Installer Code
Module is equipped with one output. In/Out option enable programmable configuration so that transmitter operates pursuant to requirements of the user. All inputs of the device are 24 hour alarm inputs. LX2NB Manual v.1.9 Page 28 / 60... -
Page 29: Inputs Configuration
In case of temporary lock – user can set lock time and number of input state changes after which lock occurs. Lock time is counted from first input state change. Both types of lock can be deactivated by SMS command (see RLIMIT command described in chapter 9.1). LX2NB Manual v.1.9 Page 29 / 60... - Page 30 - N and Tb parameters may be set per input - Locally there can be 2 x N – 1 input activations. In summary average number of activations during defined period of time will be preserved. LX2NB Manual v.1.9 Page 30 / 60...
-
Page 31: Partitions
Input can be assigned up to one partition. Arming inputs can not be assigned to any partition. If input is not assigned to any partition, it acts as 24 hours input – it is monitored regardless of partitions state. LX2NB Manual v.1.9 Page 31 / 60... -
Page 32: Delayed Inputs
7.3.3. Output configuration Tab „Output 1 (OUT1)” specify conditions of switch output. 7.3.3.1. Activation mode and timing Thanks to this option you may choose output operation mode. There are two operation modes available: LX2NB Manual v.1.9 Page 32 / 60... -
Page 33: Conditions
LX2NB Manual v.1.9 Page 33 / 60... -
Page 34: Output 1
The output state does not change if the current state of the output coincides with the result of the action. 7.3.4.2. Time of output activation Parameter defining amount of time for which the output is to be turned on for the functions of advanced outputs control. LX2NB Manual v.1.9 Page 34 / 60... -
Page 35: Event: Clip
(OUT1). The phone number is entered at option: “When icoming call detected from number” (see item 7.3.3.2.). 7.3.4.4. Event: Input 5 (RC) and Input 6 (RC) Virtual RC input (only for LX2NB-5R), which allow you to control the output state. Possible choices are described in section 7.3.4.1. 7.4. MONITORING Thanks to this option you may determine which of available signals generated by the device shall be transmitted to monitoring station. -
Page 36: Sms On / Sms Off
One of device additional options is monitoring of power supply voltage. As short voltage drop may follows at some facilities, it is possible to avoid reporting by entering time after which information will be sent. LX2NB Manual v.1.9 Page 36 / 60... -
Page 37: Low Dc Power Voltage
(OUT1). The phone number is entered at option: “When icoming call detected from number” (see item 7.3.3.2.). 7.4.7. Event: Input 5 (RC) and Input 6 (RC) Virtual RC input (only for LX2NB-5R), which allow you to send a report on status of active inputs. 7.5. RESTRICTIONS 7.5.1. -
Page 38: Gsm Modems Authorized Phones
1234. As a result all numbers with this sequence will be authorized e.g.600123456 or 601234567. b) If modem connected to OSM.Server server will be used to make connections CSD, its number have to be entered on the list. LX2NB Manual v.1.9 Page 38 / 60... -
Page 39: Validity Period Of Outgoing Sms Messages
To edit you shall follow this procedure: o Enter due telephone number into edition field. o Click on [Add] button to transfer number to the below table o Repeat procedure (up to 5 phone numbers). LX2NB Manual v.1.9 Page 39 / 60... -
Page 40: Events
If the “Copy the contents from first message” will be marked then selection and text content will be automatically copied from the first message, otherwise you may copy one text and paste to other field manually LX2NB Manual v.1.9 Page 40 / 60... -
Page 41: Sms User Tests
The format of the test period field is “the total number of days, number of hours:the number of minutes”. No selection in the “Send test every” will disable SMS user tests. LX2NB Manual v.1.9 Page 41 / 60... -
Page 42: Status
In reply about status a device shall send one SMS message containing proper text defining actual output , input state and power supply. Note : Counter “Allowed characters” informs about the total number of characters that may be inserted into the table. LX2NB Manual v.1.9 Page 42 / 60... -
Page 43: Sms Forward
Note : It is a user’s responsibility to provide correct rules which will not create loops of forwarded SMS messages. LX2NB Manual v.1.9 Page 43 / 60... -
Page 44: Link Control
Device reset o Turn on output In case of no connection with GSM network the device after recognizing the situation shall wait during provided time limit and then shall perform programmed actions. LX2NB Manual v.1.9 Page 44 / 60... -
Page 45: Gprs
The device is equipped with simulated PSTN phone line, which may collect information from an control panel using its a phone communicator, and next transmit them via GPRS or SMS. The mentioned below parameters shall be defined for proper operation of the device. LX2NB Manual v.1.9 Page 45 / 60... -
Page 46: Phone Line
Some alarm control panels require that during a receiver picking up a tone of dialling was actuated. To enable cooperation with a transmitter it is possible to make a transmitter to generate such tone. LX2NB Manual v.1.9 Page 46 / 60... -
Page 47: Detect Off-Hook After
Default setting is 2.0 sec. European Standard determines this value at 0.5 to 12.5 sec. 7.8.2.3. Protocol Select protocol of data transmission used by an alarm control panel and that is acceptable for monitoring station - ContactID. LX2NB Manual v.1.9 Page 47 / 60... -
Page 48: Firmware
7.9. FIRMWARE The device is equipped with built in bootloader that allow for updating and change of firmware. During programming all information is displayed in respect of carried out operation. LX2NB Manual v.1.9 Page 48 / 60... - Page 49 Close the window after completed saving From this time on the device will work under control of new firmware. Note : The above procedure shall be carry out with due care to avoid improper device operation. LX2NB Manual v.1.9 Page 49 / 60...
-
Page 50: Device Monitor
Type or serial number of device Firmware and hardware revision Device time These parameters are also shown in LOG window in text style. All data can be saved to file. 7.11. EVENTS HISTORY LX2NB Manual v.1.9 Page 50 / 60... - Page 51 Service code and clicking “Open” button events data will be downloaded from LX memory. After properly reading access to features such as the "Filtering" and "Charts" becomes possible. Both of them may be used to quickly diagnose the device LX2NB Manual v.1.9 Page 51 / 60...
- Page 52 LX2NB Manual v.1.9 Page 52 / 60...
-
Page 53: Device Programming
CSD data is active both for SIM card inserted in the device, and for SIM card installed in GSM modem. In second case according to description in chapter 6.2.5.2 –GPRS Link, it is required to define remote link on grounds of OSM.Server parameters. As OSM.Server collects LX2NB Manual v.1.9 Page 53 / 60... -
Page 54: The First Programming Of Device
Select “Send” to display a new window and select remote connection (GPRS tab). Save settings in memory of device. Saving course is displayed in special window. c) After saving completion close configuration wizard d) The device is ready to transmit data according to new settings. LX2NB Manual v.1.9 Page 54 / 60... -
Page 55: Receiving Of Sms Message
“” e.g. “my user name”. PW=pw APN password. Parameter should be obtained from mobile network operator. If APN password contain space sign put it with “” e.g. “my password”. LX2NB Manual v.1.9 Page 55 / 60... - Page 56 Note: DESC, CMD, GETSTATUS, GETPARAM, GETCFG commands require separate SMS, so one command with only one SMS. Samples of commands and device reaction: Parameters setting: 1111█APN= general.t-mobile.uk█SERVER=89.112.43.78█PORT=6670█ SMS=500445566█SMSPERIOD=25 Parameters verification: Inquiry: 1111█GETCFG Answer: 89.112.43.78:6670,general.t-mobile.uk██, Inquiry: 1111█GETPARAM=SMS Answer:: 500445566 LX2NB Manual v.1.9 Page 56 / 60...
-
Page 57: Led Diodes Indication
LED Diodes Description Green GSM range = 8 GPRS mode GSM range = 6 SMS mode 10.3. DATA TRANSMISSION During data transmission a green diode indicates data transmitting. LED Diodes Description Green GPRS Transmission LX2NB Manual v.1.9 Page 57 / 60... -
Page 58: Programming
No program in device (1/sec) Software updating Received firmware 10 sec decoding 10.6. SIM CARD ERROR In case of SIM card problems, device states this with OK and ERROR LEDs LED diode Signalling LX2NB Manual v.1.9 Page 58 / 60... -
Page 59: System Error
(green) ERROR (red) 10.7. SYSTEM ERROR During operating errors may follow. Any error is indicated by constant flashing of a red diode and mostly it means communication problem with modem or SIM card. LX2NB Manual v.1.9 Page 59 / 60... -
Page 60: Revision History
17.03.2017 / v1.5 Updating information about GPRS Transmitter Configurator 10.04.2017 / v1.6 Add information about antennas (for LX2NB-5R) 16.05.2017 / v1.7 Small editorial correction 25.10.2017 / v1.8 Update requirements for the computer installing the GPRS Transmitter Configurator 04.06.2018 / v1.9 Added...
