Commissioning
• Connect the LED driver output cable to the LED panel,
ensuring it is securely clipped together.
• Refit the LED panel and diffuser unit by clipping it into
place ensuring the sides are aligned with the body. Take
care not to trap any cables.
Fitting/replacing bulbs
• The LEDs in this fitting are non-replaceable.
• If any damage occurs this fitting should be discarded.
We recommend cleaning with a soft dry cloth.
Do not use solvents or abrasive cleaners as these could damage the finish.
Recycling advice
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for recycling advice.
Safety information
Live Voltages may be present in this unit even when turned off or when completely disconnected. For your safety,
always switch off the supply before cleaning.
www.saxbylighting.com
• Refit the end caps ensuring they are clipped into
position.
• Replace fuse or circuit breaker and switch on. Your
light is now ready for use..
Iss.2 05062018
Saxby Lighting. BH23 3PE
Instruction leaflet
Linear Pro
72364, 72365, 72366, 72367, 72368, 72369
Advertisement
Related Manuals for Saxby Lighting Linear Pro 72364
Summary of Contents for Saxby Lighting Linear Pro 72364
- Page 1 Instruction leaflet Commissioning • Connect the LED driver output cable to the LED panel, • Refit the end caps ensuring they are clipped into ensuring it is securely clipped together. position. Linear Pro • Refit the LED panel and diffuser unit by clipping it into • Replace fuse or circuit breaker and switch on. Your place ensuring the sides are aligned with the body. Take light is now ready for use.. care not to trap any cables. 72364, 72365, 72366, 72367, 72368, 72369 Fitting/replacing bulbs • The LEDs in this fitting are non-replaceable. • If any damage occurs this fitting should be discarded. We recommend cleaning with a soft dry cloth.
- Page 2 Installation Thank you for purchasing this light fitting. Please read the instructions carefully before use to ensure safe and satisfactory operation of this product. Please retain these instructions for future reference. Existing fittings must be completely removed before If wall mounting, ensure that the product is level. installation of a new product. Before removing the • Ensure the ceiling or wall is capable of holding the existing fitting, carefully note the position of each set weight of the product. Take care to avoid damaging Warning of wires. any concealed wiring and pipes. The correct fixings • Remove both end caps by pushing in the clips with a should be used for brick, cavity walls or plasterboard. This is a Class 1 product and must be earthed. This product is rated at IP20. small screwdriver or similar tool. • Feed the supply cable through the centre hole and fix Please read these instructions carefully before This light fitting contains non-replaceable parts and • Starting from one end and working along, remove the...
