- Page 1 MÁQUINA DUPLICADORA VIENNA Manual de instrucciones KEY CUTTING MACHINE VIENNA instruction Manual KOPIERMASCHINE VIENNA anweisungshandbuch MACCHINA DUPLICATRICE VIENNA Manuale d’istruzione MACHINE A TAILLER LES CLES VIENNA notice d’utilisation MÁQUINA DUPLICADORA VIENNA Manual de instruções NØGLEMASKINE VIENNA Manual VIENNA...
- Page 2 KeY cutting Machine VIENNA instruction Manual...
-
Page 3: Presentation And General Aspects
1.- PRESENTATION AND GENERAL ASPECTS .1 general Points 1.2 transPort and PacKing 1.3 identiFication label 2.- CHARACTERISTICS OF THE MACHINE 2.1 Parts oF the KeY 2.2 Main eleMents oF the Machine 2.3 technical inForMation 2.4 coMPonents and Functional Parts 2.4.1 accessories 2.4.2 electric circuit 2.4.3 Four-sided claMP 3.- HOW TO OPERATE THE MACHINE... -
Page 4: Technical Information
......high speed steel (hss); Ø 80x16x5 cutter speed: ....612 rpm the Vienna key cutting machine has been designed on the basis of the safety stan- clamps: ......steel, with 4 clamping faces dards currently in force in the eu. - Page 5 LIGHTING button. to carry out the operation, making it impossible for the cutter to move. Press this button for the lighting diodes to come on (if they are off) or to go off • Clamp the adjustment templates (W) onto “side 1” of the clamps, so that the bottom (if they are on).
-
Page 6: Replacing The Brush
3.4.1 dePth adJustMent (with no electrical contact) lever (u). Make sure that the pressure exerted by the original key against the tracer is that required by the spring inside the slide. See figure 9 • Once you have finished cutting: lock the slide and remove the keys. •... - Page 7 into the large pulley: manually turn the large pulley whilst applying pressure laterally 4.3 REPLACING THE TRACER on the belt in that area. - Visually check that the belt has been fitted correctly. See figure 16 - tighten the belt, turning the tightening screw (7) clockwise. - once you have the tightness required, lock the tightening screw (7) by tightening up the procedure for replacing the tracer is as follows: the setscrew (8).
- Page 8 9) Fit the new capacitor ( c ) and connect its two cables. beforehand. 10) Put the cover onto the “terminal box”, securing it with the 4 screws (14). 9) connect the cables to the new microswitch. 11) Fit the “motor guard”, securing it in place with the 7 screws (9). 10) Put the two microswitches back, securing them with the two nuts (19).
-
Page 9: Waste Disposal
6.1 PACKING • As the packing the VIENNA comes in is made of cardboard, it can be recycled as packing. • As waste, it is comparable to solid urban waste and, therefore, can only be disposed of in special containers for cardboard. - Page 10 EUROPA PORTUGAL...
- Page 13 20.1 20.2 20.3 20.4...
- Page 14 20.5...
- Page 15 27.1 27.3 27.2 28.1 28.2 28.3...
- Page 17 Fax +44 144 286 3683 unit 2, canalside northbridge road berkhamsted herts hP4 1eg www.skskeys.co.uk sales@skskeys.co.uk JMA INDIA JMa KeYs india PVt. ltd h-239 soshant shopping arcade sunshant lok-1, block b 122002 gurgaon haryana www.jmakeys.in info@jmakeys.in JMA USA altuna grouP usa inc.
