Page 1 Emergency response guide ΛΦ...
Page 3 No part of this publication may be reproduced and/or published by printing, by photocopying, on microfilm or in any way whatsoever without the prior consent in writing of DAF Trucks N.V. © 201426 DW53293901...
Page 7 EMERGENCY RESPONSE GUIDE ΛΦ series Table of contents TABLE OF CONTENTS Emergency response guide Page Date SECURING THE VEHICLE ......... 1-1 ..201426 Switching off the engine .
Page 9 EMERGENCY RESPONSE GUIDE ΛΦ series Securing the vehicle 1. SECURING THE VEHICLE 1.1 SWITCHING OFF THE ENGINE Ignition switch If the ignition switch can be reached, an attempt can be made to stop the engine by switching off the ignition. Another method is to blow CO into the air inlet.
Page 10 EMERGENCY RESPONSE GUIDE ΛΦ series Securing the vehicle 1.2 MAIN SWITCH If the vehicle is equipped with a main switch, it is either mechanically or electronically operated, depending on the vehicle version. The switch can be used to interrupt the power supply from the batteries to the vehicle (except for the tachograph).
Page 11 EMERGENCY RESPONSE GUIDE ΛΦ series Securing the vehicle Mechanical main switch Mechanically operated main switches only have a switch outside the cabin. G002345 © 201426...
Page 12 EMERGENCY RESPONSE GUIDE ΛΦ series Securing the vehicle 1.3 BATTERIES Location of the batteries The batteries are located on the left- or right-hand side of the chassis frame, or at the rear within the chassis. Disconnecting the batteries Switch off the ignition. Switch off all electrical consumers.
Page 13 EMERGENCY RESPONSE GUIDE ΛΦ series Securing the vehicle 1.4 AIRBAG WARNING! Airbag modules and safety belt tensioners are pyrotechnic systems and contain an explosive charge. G001309 Vehicles equipped with an airbag and safety belt tensioner system can be identified by a sticker with the airbag symbol on the windscreen.
Page 14 EMERGENCY RESPONSE GUIDE ΛΦ series Securing the vehicle Safety belt tensioner The automatic safety belt tensioner is fitted on the rear side of the driver's and co-driver's seat. Safety instructions Do not place any objects near undeployed airbags Before any work is carried out on an airbag system: the ignition must be switched off.
Page 15 EMERGENCY RESPONSE GUIDE ΛΦ series Securing the vehicle 1.5 FLUIDS K104001 Coolant: 48 litres Engine oil: 17- 23.5 litres Gearbox oil: 14 litres AdBlue: 25 or 50 litres Fuel: up to 430 litres Battery acid The capacities and position of the tanks depend on the vehicle type.
Page 16 EMERGENCY RESPONSE GUIDE ΛΦ series Securing the vehicle WARNING! AdBlue safety instructions Avoid direct contact. In the event of contact with the skin, rinse with plenty of water. In the event of contact with the eyes, rinse for at least 15 minutes with plenty of water and seek medical assistance.
Page 17 EMERGENCY RESPONSE GUIDE ΛΦ series Securing the vehicle 1.6 REGENERATION UNIT During regeneration the exhaust gases, the surroundings of the regeneration unit and the catwalk can reach high temperatures that can potentially harm bystanders or the surrounding area. WARNING! There is a risk of fire or other hazardous situation if the temperature can ignite flammable materials.
Page 19 EMERGENCY RESPONSE GUIDE ΛΦ series Stabilising the vehicle 2. STABILISING THE VEHICLE 2.1 SEAT ADJUSTMENT NOTE: Before removing the seat, be aware of the safety instructions if the vehicle is equipped with an airbag and therefore an automatic safety belt tensioner.
Page 20 EMERGENCY RESPONSE GUIDE ΛΦ series Stabilising the vehicle 2.2 AIR SUSPENSION CHASSIS General On vehicles equipped with air suspension, a remote control unit is used to operate the vehicle height. The remote control unit is located against the console of the driver's seat. NOTE: This control unit can only be operated when the ignition is switched NOTE: Unless stated otherwise, the...
Page 21 EMERGENCY RESPONSE GUIDE ΛΦ series Stabilising the vehicle 2.3 CABIN SUSPENSION The cabin is equipped with mechanical suspension. Rear cabin mechanical suspension G001959 Front cabin mechanical suspension At the front the cabin can have rubber blocks or springs. They can be reached by removing the lower grille, and if necessary, the headlight panels.
Page 23 EMERGENCY RESPONSE GUIDE ΛΦ series Releasing a trapped driver 3. RELEASING A TRAPPED DRIVER 3.1 CABIN TYPES G002348 Day Cab Extended Day Cab Sleeper Cab © 201426...
Page 24 EMERGENCY RESPONSE GUIDE ΛΦ series Releasing a trapped driver 3.2 CABIN DIMENSIONS The external dimensions from the ground vary depending on the tyre size, choice of suspension, load and settings. Day Cab 1610 1610 8-12t 14-16t 1603 1610 2130 8-12t G002442 ©...
Page 25 EMERGENCY RESPONSE GUIDE ΛΦ series Releasing a trapped driver Extended Day Cab 1250 1250 1610 1610 8-12t 14-16t 2003 1250 1610 2130 14-16t G002445 © 201426...
Page 26 EMERGENCY RESPONSE GUIDE ΛΦ series Releasing a trapped driver Sleeper Cab 1130 1130 1610 1610 8-12t 14-16t 2003 1130 1610 2130 G002446 © 201426...
Page 27 EMERGENCY RESPONSE GUIDE ΛΦ series Releasing a trapped driver 3.3 OPENING THE GRILLE Open the front panel by gripping it at the bottom and lifting it up. The front panel tilts upwards and is held in position by two gas struts. G002349 ©...
Page 28 EMERGENCY RESPONSE GUIDE ΛΦ series Releasing a trapped driver 3.4 DOORS Hinge Wiring harness Door check G001310 © 201426...
Page 29 EMERGENCY RESPONSE GUIDE ΛΦ series Releasing a trapped driver 3.5 DOOR LOCK The door lock is installed higher than the door handle. The position is indicated in the image. G002350 © 201426...
Page 30 EMERGENCY RESPONSE GUIDE ΛΦ series Releasing a trapped driver 3.6 MECHANICAL STEERING WHEEL ADJUSTMENT To adjust, pull the handle towards you and simultaneously move the steering column to the desired position. The steering column is locked by releasing the handle. G002351 ©...
Page 31 EMERGENCY RESPONSE GUIDE ΛΦ series Releasing a trapped driver 3.7 STEERING WHEEL ADJUSTMENT NOTE: The steering wheel can be adjusted if the vehicle air pressure (circuit 4) is at least 7 bar. G001293 Adjusting Push up the two-position switch. The steering column is temporarily unlocked.
Page 33 EMERGENCY RESPONSE GUIDE ΛΦ series Towing information 4. TOWING INFORMATION 4.1 REMOVING THE DRIVE SHAFT Make sure that the parking brake is engaged. Loosen the bolts, do not remove them. Loosen the bearing. Hold the shaft while removing the bolts. Fix the bearings to the shaft.
Page 34 EMERGENCY RESPONSE GUIDE ΛΦ series Towing information 4.2 RELEASING THE PARKING BRAKE WARNING! Never release the park brake on an incline without precautionary measures. Releasing the park brake on an incline causes the vehicle to move unintentionally. This can lead to serious injury and damage to the vehicle.
Page 35 EMERGENCY RESPONSE GUIDE ΛΦ series Towing information 4.3 TOWING It is possible to install a towing eye behind the grille. Always use a towing bar when towing. Deviation from this rule is only allowed in emergencies. When towing, the fault messages may appear in the master display when the ignition is switched NOTE: The maximum permissible vehicle speed, weight and distance...
Page 36 EMERGENCY RESPONSE GUIDE ΛΦ series Towing information WARNING! When the engine is not running during towing and no additional measures are taken, there is no power steering and no air is supplied to the braking system. This results in difficult steering and increased brake pedal force and ultimately leads to automatic engagement of the parking brake.
Page 37 EMERGENCY RESPONSE GUIDE ΛΦ series Towing information NOTE: Vehicles with an AS Tronic Lite gearbox or automatic gearbox cannot be towed to start the engine. © 201426...
Page 39 EMERGENCY RESPONSE GUIDE ΛΦ series Lifting information 5. LIFTING INFORMATION 5.1 LIFTING AT THE FRONT OR BACK The truck can be lifted under the axles, frame structure or wheel stations. © 201426...
Page 40 EMERGENCY RESPONSE GUIDE ΛΦ series Lifting information 5.2 JACKING UP MECHANICALLY SPRUNG FRONT AXLES Place the jack under the special shock absorber bracket. CAUTION: Do not jack up under the protection bar at the front of the vehicle. This is a protection bar made of sheet metal.
Page 41 EMERGENCY RESPONSE GUIDE ΛΦ series Lifting information 5.3 JACK UP AT THE BACK Place the jack under the jacking point at the bottom of the spring bracket. © 201426...
