Section 7.1 BS3680/ISO 1438/1 V Notch Weir Configuration Table
Parameter number
P600 Set to 7 (BS 3680/ISO 1438/1 V Notch Weir)
P602 = (1 & 2) Enter the values of
index 2, view the value of discharge coefficient C
P603 Enter the value of maximum head in unit as set in
P005.
P605 Zero Head Off-set
P608 Flow rate units
P607 Flow rate decimal
P620 Low flow cut-off.
P621 Auto zero head calibration
Note:
Both Primary devices BS 3680 / ISO 4359 Rectangular Flume and the BS 3680 / ISO 1438/1 Thin Plate V notch weir
can also be configured for Ratiometric calculation in case the flow rate units are not supported in P608.
MultiRanger 200 and Flow Configuration
Description to explain the value
in degrees in index 1. In
AG040303
APPLICATION GUIDE
Configuration Priority
Must be configured.
Must be configured.
e
Must be configured.
Must be configured because the zero of the weir
is above the channel zero.
Must be configured.
Optional, configured to display the flow rate (Q).
Factory set to 2.
Optional, to avoid totalizing at flows below this
set level.
Optional, configured if displayed head has
constant off-set.
